Raven SmarTrax Manuel utilisateur

SmarTrax, Case IH Patriot 2250,

Non-Steer Ready, MY17 and

Newer Installation Manual

Manual No. 016-5032-037 Rev. A 12/16 E28539

While every effort has been made to ensure the accuracy of this document,

Raven Industries assumes no responsibility for omissions and errors. Nor is any

liability assumed for damages resulting from the use of information contained

herein.

Raven Industries shall not be responsible or liable for incidental or consequential

damages or a loss of anticipated benefits or profits, work stoppage or loss, or

impairment of data arising out of the use, or inability to use, this system or any of

its components. Raven Industries shall not be held responsible for any

modifications or repairs made outside our facilities, nor damages resulting from

inadequate maintenance of this system.

As with all wireless and satellite signals, several factors may affect the availability

and accuracy of wireless and satellite navigation and correction services (e.g.

GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the

accuracy, integrity, continuity, or availability of these services and cannot

guarantee the ability to use Raven systems, or products used as components of

systems, which rely upon the reception of these signals or availability of these

services. Raven Industries accepts no responsibility for the use of any of these

signals or services for other than the stated purpose.

Disclaimer

Table of Contents

Manual No. 016-5032-037 Rev. A i

Chapter 1 Important Safety Information............................................................................. 1

Hydraulic Safety ........................................................................................................................2

Electrical Safety ........................................................................................................................2

Instructions for Wire Routing .....................................................................................................2

Instructions for Hose Routing ....................................................................................................4

Chapter 2 Introduction............................................................................................................. 7

Preparing for Installation ...........................................................................................................7

Recommendations .................................................................................................................................................................7

Point of Reference .................................................................................................................................................................8

Updates .....................................................................................................................................8

Kit Contents ...............................................................................................................................9

Chapter 3 Hydraulic System Installation............................................................................ 13

Install Fittings in the SmarTrax Valve ......................................................................................14

Install Fittings on the Flow Switch ...........................................................................................14

Mount the SmarTrax Valve ......................................................................................................15

Install the Left and Right Steering Hoses ................................................................................16

Install the Pressure Hose ........................................................................................................19

Install the Tank Hose ...............................................................................................................19

Hydraulic Diagram ...................................................................................................................20

Chapter 4 Cab Component Installation.............................................................................. 23

Install the SmarTrax Node .......................................................................................................23

Mount the SmarTrax Node ...............................................................................................................................................23

Node Mounting Locations ................................................................................................................................................24

Install the Foot Switch .............................................................................................................25

Install the Node Harness .........................................................................................................25

Install the Valve Harness .........................................................................................................27

Chapter 5 Startup Procedures.............................................................................................. 33

Verify the SmarTrax System Installation .................................................................................33

Calibrate the SmarTrax System ..............................................................................................34

Table of Contents

ii SmarTrax, Case IH Patriot 2250, Non-Steer Ready, MY17 and Newer Installation Manual

CHAPTER

Manual No. 016-5032-037 Rev. A 1

CHAPTER 1

IMPORTANT SAFETY

INFORMATION

Read this manual and the operation and safety instructions included with your implement and/or controller

carefully before installing the SmarTrax™ system.

• Follow all safety information presented within this manual.

• If you require assistance with any portion of the installation or service of your Raven equipment, contact your

local Raven dealer for support.

• Follow all safety labels affixed to the SmarTrax system components. Be sure to keep safety labels in good

condition and replace any missing or damaged labels. To obtain replacements for missing or damaged safety

labels, contact your local Raven dealer.

When operating the machine after installing SmarTrax, observe the following safety measures:

• Be alert and aware of surroundings.

• Do not operate SmarTrax or any agricultural equipment while under the influence of alcohol or an illegal

substance.

• Remain in the operator’s position in the machine at all times when SmarTrax is engaged.

• Disable SmarTrax when exiting the operator’s seat and machine.

• Do not drive the machine with SmarTrax enabled on any public road.

• Determine and remain a safe working distance from other individuals. The operator is responsible for disabling

SmarTrax when the safe working distance has diminished.

• Ensure SmarTrax is disabled prior to starting any maintenance work on SmarTrax or the machine.

• When starting the machine for the first time after installing SmarTrax, be sure that all persons stand clear in

case a hose has not been properly tightened.

• The machine must remain stationary and switched off during SmarTrax installation or maintenance.

NOTICE

WARNING

CAUTION

CHAPTER 1

2 SmarTrax, Case IH Patriot 2250, Non-Steer Ready, MY17 and Newer Installation Manual

HYDRAULIC SAFETY

• Raven Industries recommends that appropriate protective equipment be worn at all times when working on the

hydraulic system.

• Never attempt to open or work on a hydraulic system with the equipment running. Care should always be

taken when opening a system that has been previously pressurized.

• When disconnecting the hydraulic hoses or purging is required, be aware that the hydraulic fluid may be

extremely hot and under high pressure. Caution must be exercised.

• Any work performed on the hydraulic system must be done in accordance with the machine manufacturer’s

approved maintenance instructions.

• When installing SmarTrax hydraulics or performing diagnostics, maintenance, or routine service, ensure that

precautions are taken to prevent any foreign material or contaminants from being introduced into the

machine’s hydraulic system. Objects or materials that are able to bypass the machine’s hydraulic filtration

system will reduce performance and possibly damage the SmarTrax valve.

ELECTRICAL SAFETY

• Always verify that the power leads are connected to the correct polarity as marked. Reversing the power leads

could cause severe damage to the equipment.

• Ensure that the power cable is the last cable to be connected.

INSTRUCTIONS FOR WIRE ROUTING

The word “harness” is used to mean all electrical leads and cables, bundled and unbundled. When installing

harness, secure it at least every 30 cm (12in) to the frame. Follow existing harness as much as possible and use

these guidelines:

Harness should not contact or be attached to:

• Lines and hoses with high vibration forces or pressure spikes

• Lines and hoses carrying hot fluids beyond harness component specifications

Avoid contact with any sharp edge or abrading surfaces such as, but not limited to:

• Sheared or flame cut edges

• Edges of machined surfaces

• Fastener threads or cap screw heads

• Ends of adjustable hose clamps

• Wire exiting conduit without protection, either ends or side of conduit

• Hose and tube fittings

Manual No. 016-5032-037 Rev. A 3

IMPORTANT SAFETY INFORMATION

Routing should not allow harnesses to:

•Hang below the unit

• Have the potential to become damaged due to exposure to the exterior environment. (i.e. tree limbs, debris,

attachments)

• Be placed in areas of or in contact with machine components which develop temperatures higher than the

temperature rating of harness components

• Wiring should be protected or shielded if it needs to route near hot temperatures beyond harness component

specifications

Harnessing should not have sharp bends

Allow sufficient clearance from machine component operational zones such as:

• Drive shafts, universal joints and hitches (i.e. 3-point hitch)

• Pulleys, gears, sprockets

• Deflection and backlash of belts and chains

• Adjustment zones of adjustable brackets

• Changes of position in steering and suspension systems

• Moving linkages, cylinders, articulation joints, attachments

• Ground engaging components

For harness sections that move during machine operation:

• Allow sufficient length for free movement without interference to prevent: pulling, pinching, catching or

rubbing, especially in articulation and pivot points

• Clamp harnesses securely to force controlled movement to occur in the desired harness section

• Avoid sharp twisting or flexing of harnesses in short distances

• Connectors and splices should not be located in harness sections that move

Protect harnesses from:

• Foreign objects such as rocks that may fall or be thrown by the unit

• Buildup of dirt, mud, snow, ice, submersion in water and oil

• Tree limbs, brush and debris

• Damage where service personnel or operators might step or use as a grab bar

• Damage when passing through metal structures

IMPORTANT:Avoid directly spraying electrical components and connections with high pressure water. High pressure water

sprays can penetrate seals and cause electrical components to corrode or otherwise become damaged.

When performing maintenance:

•Inspect all electrical components and connections for damage or corrosion. Repair or replace

components, connections, or cable as necessary.

•Ensure connections are clean, dry, and not damaged. Repair or replace components, connections,

or cable as necessary.

•Clean components or connections using low pressure water, pressurized air, or an aerosol electrical

component cleaning agent.

•Remove visible surface water from components, connections, or seals using pressurized air or an

aerosol electrical component cleaning agent. allow components to dry completely before

reconnecting cables.

CHAPTER 1

4 SmarTrax, Case IH Patriot 2250, Non-Steer Ready, MY17 and Newer Installation Manual

INSTRUCTIONS FOR HOSE ROUTING

The word “hose” is used to mean all flexible fluid carrying components. Follow existing hoses as much as possible

and use these guidelines:

Hoses should not contact or be attached to:

• Components with high vibration forces

• Components carrying hot fluids beyond component specifications

Avoid contact with any sharp edge or abrading surfaces such as, but not limited to:

• Sheared or flame cut edges

• Edges of machined surfaces

• Fastener threads or cap screw heads

• Ends of adjustable hose clamps

Routing should not allow hoses to:

• Hang below the unit

• Have the potential to become damaged due to exposure to the exterior environment. (i.e. tree limbs, debris,

attachments)

• Be placed in areas of or in contact with machine components which develop temperatures higher than the

temperature rating of hose components

• Hoses should be protected or shielded if it needs to route near hot temperatures beyond hose component

specifications

Hoses should not have sharp bends

Allow sufficient clearance from machine component operational zones such as:

• Drive shafts, universal joints and hitches (i.e. 3-point hitch)

• Pulleys, gears, sprockets

• Deflection and backlash of belts and chains

• Adjustment zones of adjustable brackets

• Changes of position in steering and suspension systems

• Moving linkages, cylinders, articulation joints, attachments

• Ground engaging components

For hose sections that move during machine operation:

• Allow sufficient length for free movement without interference to prevent: pulling, pinching, catching or

rubbing, especially in articulation and pivot points

• Clamp hoses securely to force controlled movement to occur in the desired hose section

• Avoid sharp twisting or flexing of hoses in short distances

Protect hoses from:

• Foreign objects such as rocks that may fall or be thrown by the unit

• Buildup of dirt, mud, snow, ice, submersion in water and oil

• Tree limbs, brush and debris

• Damage where service personnel or operators might step or use as a grab bar

• Damage when passing through metal structures

Manual No. 016-5032-037 Rev. A 5

IMPORTANT SAFETY INFORMATION

• High pressure wash

CHAPTER 1

6 SmarTrax, Case IH Patriot 2250, Non-Steer Ready, MY17 and Newer Installation Manual

Autres manuels pour SmarTrax

Table des matières

Autres manuels Raven Matériel agricole

Raven

Raven Apache AS840 Manuel utilisateur

Raven

Raven SC1 Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven Unverferth NutriMax Series Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven AutoBoom XRT Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven Hawkeye Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven SBGuidance Side-Shift Manuel utilisateur

Raven

Raven RS1 Manuel utilisateur

Raven

Raven Spray Air 2010 Predator Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven AutoBoom Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven AutoBoom Case IH Patriot 250 Manuel utilisateur

Raven

Raven Cruizer II Manuel utilisateur

Raven

Raven SBGuidance Auto Manuel utilisateur

Raven

Raven SmarTrax Manuel utilisateur

Raven

Raven SC1 Manuel d'utilisation et d'entretien

Manuels Matériel agricole populaires d'autres marques

GSi

GSi PNEG-2314 Manuel utilisateur

Checchi & Magli

Checchi & Magli TEXDRIVE Manuel utilisateur

Amazone

Amazone Cenius 4003-2TX Manuel utilisateur

MASSEY FERGUSON

MASSEY FERGUSON MF 9313S Manuel utilisateur

Cima

Cima BLITZ Instructions d'utilisation et d'entretien

Amazone

Amazone CombiDisc 3000 Instructions d'installation

HE-VA

HE-VA Disc-Roller XL Contour Manuel utilisateur

AGT

AGT AGT-SSFM Manuel utilisateur

Milestone

Milestone 72-84 Manuel utilisateur

KUHN

KUHN Hector 3000 Manuel utilisateur

Krone

Krone X-Disc 6200 Manuel utilisateur

Eliet

Eliet DZC450 Manuel utilisateur

Taarup

Taarup BIO+ B4000 Manuel utilisateur

Garland

Garland SHAKER 310 DPG Manuel utilisateur

stable comfort

stable comfort StableWall System Manuel utilisateur

International

International 710 Manuel utilisateur

Ashland

Ashland HDW-3217-14 Manuel utilisateur

TURF TANK

TURF TANK One+ Manuel utilisateur
