Rand McNally Intelliroute TND-710 Manuel utilisateur

Quick Start Guide 2-19

Guide de démarrage rapide 21-39

Guía de Inicio Rápido 41-59

TND_710_Booklet_COVER_110921.indd 3 9/22/11 2:20 PM

TND_710_Booklet_INSIDE_110922.indd 1 9/22/11 2:07 PM

TO ENTER OR RETURN FROM STANDBY MODE: Press and release the Power Key.

IMPORTANT: Connect your device to your personal computer to register your device and activate additional features. Features require

internet connection and Windows-compatible PC.

FOR CUSTOMER SUPPORT, CALL 800-333-0136.

Overview

WARNING: See safety information included with the device for warnings and precautions.

To maximize battery life, plug in the navigation unit for the ﬁrst 2 hours of use. Always make sure your GPS has a clear view of the sky.

The ﬁrst time you use the device, it may take up to 15 minutes for your GPS to connect to the satellites.

TO POWER THE DEVICE:

On Press and hold the Power Key for two (2) seconds.

(Device powers on in 5 seconds.)

Off Press and hold the Power Key for ﬁve (5) seconds.

BATTERY POWER INDICATOR:

No Light

Device is running on the battery. Battery power is sufﬁcient.

Green

Device is plugged in and the battery is fully charged

Red

Device is plugged in and the battery is charging.

TND_710_Booklet_INSIDE_110922.indd 2 9/22/11 2:07 PM

Power Key

Battery

Power

Indicator

NOTE: Use the Reset button (located on the side of the

device) to restore factory settings and restart the device.

TND_710_Booklet_INSIDE_110922.indd 3 9/22/11 2:07 PM

Main Menu

Enter truck information and access truck-speciﬁc use tools.

Show location on the map and view navigation instructions.

Change driver status.

Choose a destination.

Select TND™and route preferences.

Mute/unmute the speaker.

Adjust speaker volume.

Select the trailer load option.

When running on battery power, icon will indicate power status.

TND_710_Booklet_INSIDE_110922.indd 4 9/22/11 2:07 PM

567

TND_710_Booklet_INSIDE_110922.indd 5 9/22/11 2:07 PM

Install the Mount

NOTE: Follow all local regulations governing the placement of the mount.

Select an area with a line of sight to the sky and GPS satellites to ensure reliable GPS information.

Clean and dry the mounting area.

Remove the suction cup protective ﬁlm.

Adjust the angle of the mount using the thumbscrew and slide the mount into the cradle.

Pull the suction cup lever up to release suction.

Place and hold the mount suction cup against the mounting surface.

Press the suction cup lever down until it snaps into place.

Angle the bottom of the device into the cradle and press the top of the device towards the cradle until you hear the upper clip latch into place.

Plug the power cord into the device and the vehicle’s 12-volt power source.

Adjust the navigation device so that it can be easily seen and does not block the driver’s line of sight.

TND_710_Booklet_INSIDE_110922.indd 6 9/22/11 2:07 PM

NOTE: Do not place

the mount in an airbag

deployment area.

TND_710_Booklet_INSIDE_110922.indd 7 9/22/11 2:07 PM

Set Warnings

Tap Truck Tools > Warnings.

Tap and to view all warning options.

Tap the option button to be changed.

Enter the new settings for the option.

Tap Back to save changes.

Enter Truck Information

Tap Truck Tools >Truck Info.

Tap and to view all options.

Tap the option button to be changed.

Enter new truck information settings.

Tap Back to save changes.

On the left,

tap on an

option

On the right,

enter settings

for the option

On the right,

enter settings

for the option

On the left,

tap on an

option

TND_710_Booklet_INSIDE_110922.indd 8 9/22/11 2:07 PM

View Timers and Logs

Countdown timers are controlled by the Driver Status (Driving,On Duty, or Off Duty) selected on the Main Menu.

Tap Truck Tools.

Tap Timers and Logs.

Tap the Timers tab to view timers,

odometer readings,and times.

Tap the Logs tab to view a list of

mileage logs by quarter.

Tap on a quarter to view individual

logs by state.

345

TND_710_Booklet_INSIDE_110922.indd 9 9/22/11 2:07 PM
