RAMVAC OWL Mode d’emploi
OWL
(On Wall Logic)
User Guide
and
Installation
SOF_7.2.3-02-152
Effective date: 30-May-08
User Guide OWL
Thank you for selecting a RAMVAC OWL to serve your dental facility.
The RAMVAC OWL provides industry leading technology for convienient and efficient control of your utility room equip-
ment. While we’ve designed the OWL with the ability to control most brands of utility room equipment, its full capa-
bilities are realized when matched with intelligent controllers like those found on RAMVAC manufactured utility room
equipment.
Everything you need to install, operate and program your OWL is found in this manual, so here is all you need to do to
get started:
1. Take a few minutes to read the OWL Overview and OWL Features sections of this manual, to learn mor
about the capabilities of the OWL.
2. The Installation section should answer most of your questions on how to locate and install your OWL in
your facility. But if you do hit a snag, take comfort in knowing our industry leading Technical Service
professionals are just a phone call away and are always glad to help.
3. Once installed, the Operation and Programming sections will make using your OWL a breeze.
We at RAMVAC appreciate your business and take a personal interest in your complete satisfaction. Please let us
know how the system is working for you, by giving us a call or dropping by one of our exhibits at any major dental show.
Please accept my personal invitation to visit our manufacturing facility if you are ever in the beautiful Black Hills of South
Dakota.
Matt Olson
General Manager, RAMVAC Dental Products, Inc.
(800) 5-RAMVAC
Safety and Regulatory Information
RAMVAC’s meet the most current and highest safety standards. RAMVAC products are manufactured in an FDA regis-
tered, ISO 9001:2000 and ISO 13485:2003 certified facility.
Here is what you need to do to ensure the safety potential of this equipment is achieved:
· Make sure your equipment is installed according to the instructions found in this manual.
· Always use a RAMVAC supplied power source for powering any component in the OWL.
· Read and follow all local, state and federal codes and regulations pertaining to these types of installations.
· Never connect the OWL to any voltage higher than those recommended in this manual.
Inside Front Cover
Page 1SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
Table of Contents
OWL User Interface Page 1
OWL and Compatible Controls Page 2
OWL Overview Page 3
OWL Feature Page 3
System Schematics Page 4-5
Electrical Connections Page 6
Operation and Monitoring
Main Level Operation Page 8-9
Unit Staus Operation Page 10-11
System Staus Operation Page 12-13
Owl Configuration Operation Page 14-15
Multiple Unit System
Understanding the System Page 18
Low Voltage Electrical Connections Page 19
System Layout for 2 Units Page 20
System Layout for 3-8 Units Page 21
Adjusting Vacuum Pressure Page 22
Overhead Piping Adjustments Page 23
RAMVAC Product Support Services Inside Back Cover
OWL User Interface
LCD Screen -
Displays OWL
menus and utility
room equipment
status
Run / Stop
Buttons & LED
Indicators - Use to
start / stop the
corresponding utility
room equipment.
LED Indicators
provide equipment
status.
Menu Buttons -
Use to navigate
the various OWL
menus to check
utility room
equipment status.
SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 2
OWL and Compatible Controls
OWL – Mounts in any convenient location.
Provides user control and interaction with
utility room equipment.
Interface Control – Provides
interface / communication between an OWL
and non-RAMVAC utility room equipment.
OWL Interface Control
S1 Electrols
C1 Control
OWL – Mounted controls on the RAMVAC vacuum
pumps and communicates with the OWL.
C1 Control – Mounted controls on the
CustomAirby RAMVAC air compressor and
communicates with the OWL.
Page 3SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
OWL Overview
The OWL is a multi-functional, integrated electronic system designed to monitor and control dental utility room equip-
ment from a remote location. When used in conjunction with RAMVAC electronic controls, the OWL provides monitor-
ing, control, and displays alarms. The OWL is also flexible enough to provide start/stop functions for all other brands
of utility room equipment. The compact, attractive, easy to mount control panel features an easy to read LCD screen,
equipment control buttons, program navigation buttons, and LED indicator lights.
(OWLs are individually programmed at the RAMVAC manufacturing facility to meet the specific requirements of each facility)
OWL Features
For RAMVAC equipment:
· Automatic, sequential starting and stopping of up to 8 air compressors and 8 vacuum units based on user demand.
This feature continually sequences equipment on and off to meet varying system needs. The OWL also simplifies
maintenance by apportioning run time on each machine to balance equipment run hours. The OWL can also
simultaneously start and stop up to 8 water control valves.
· Programmable shut-off timer stops equipment at user-defined interval.
· Provides alerts when scheduled maintenance is due.
· Provides alerts when equipment has experienced a fault condition.
· Provides historical operating and fault data.
· Monitors run status of individual equipment.
For non-RAMVAC equipment:
· An Interface Control enables remote start/stop functions for up to 8 air compressors, 8 vacuum pumps, and 8 water
control valves.
· Programmable shut-off timer stops equipment at user-defined interval.
SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 4
System Schematics
Thin (Red) Solid Line - Power wires (2 – 18 ga. wires)
Thick (Black) Solid Line - Communication wires (3 – 18 ga. wires)
Dashed (Blue) Line – Other wiring
Typical applications
shown
Schematic 1: OWL and RAMVAC equipment (with water valve option)
Note: Transformer supplied with Interface Control
Wiring to water
valve solenoid
OWL
Interface Control
for Water Valve
S1 Electrols
C1 Control
Schematic 2: OWL and non-RAMVAC equipment (with water valve option)
Note: Transformer supplied with Interface Control
Interface Control
for Vacuum Unit
Interface Control for
Air Compressor
Interface Control
for Water Valve
OWL
Wiring to water
valve solenoid
Wiring to water
valve solenoid
Wiring to water
valve solenoid
Page 5SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
S1 Electrols S1 Electrols
C1 Control
C1 Control
Interface Control
for Water Valve
Schematic 3: OWL and multiple RAMVAC controls (with water valve option and autowash)
Note: Transformer supplied with Interface Control
Schematic 4: Interface Control Connection for Water Valve
Interface Control
for AutoWash
Solenoid
R Y
Interface
Control
Supply Voltage
24 Volt Max
Wiring to water
valve solenoid
Wiring to
AutoWash
Vacuum Pessure Switch
Wired to S1
Electrols Node 1
S1 Electrols Node
Designation on top
OWL
C1 Control Node
Designation on top
SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 6
Electrical Connections
Communication Wires
The OWL communicates to the utility room equipment using a RS485 communication protocol across linked communication wires. RAMVAC
recommends using 4 conductor 18 gauge shielded wire , to provide communication and power to the OWL. The A terminal on the OWL must
attach to the A terminal on each of the equipment controls in the system. Likewise, the B terminal will connect to the B terminals on the equipment
controls. The C terminal on the OWL will connect to the shield on the wire. The shield will then connect to the C terminal on the S1 Electrols and
C1 Control, but does not connect to any Interface Controls in the system. Connections A2 and B2 on the OWL are not used.
Power for the OWL
The OWL requires a 12v DC power source to operate. On most systems (see Schematic 1) the power source can be either the S1 Electrols
or the air compressor C1 Control. If using the S1 or C1 for power, connect the 5 terminal on the S1/C1 to the 5 terminal on the OWL and the 6
terminal on the S1/C1 to the 6 terminal on the OWL. (1) These wires can be included in the wire bundle with the communication wires, but
will be connected to only ONE of the RAMVAC equipment controls in the system.
In systems that do not have RAMVAC controls (see Schematic 2), a wall transformer is supplied to provide power to the OWL. Connect the black
with white stripe wire from the transformer to the 5 terminal on the OWL and the black wire with text from the transformer to the 6 terminal on the
OWL.
Interface Control Wiring
The communication wires attach to the A and B terminals per the “Communication Wires” section above, but remember the shield does not
connect to any terminal on the remote module.
(2) A wall transformer is supplied with each Interface Control as a power source. Connect the black with white stripe wire from the
tranformer to the 5 terminal on the Interface Control and the black wire with text from the transformer to the 6 terminal on the Interface Control.
The Interface Control R and Y connections act as a switch to turn on and off any equipment and can handle up to 24 V. See (Schematic 4) for
a typical attachment to a solenoid. In most applications the interface control can be connected in place of the low voltage remote switch typically
used to turn on and off the equipment.
Note: An Interface Control must be used to operate any piece of equipment without a RAMVAC control.
Note: Systems with the optional AutoWash feature require a special Interface Control to control the AutoWash
function. Function of the AutoWash feature is then controlled through the OWL controller instead of the
S1 Electrols.
RAMVAC
OWL
Connections
RAMVAC
S1
Connections
CustomAirby RAMVAC
C1
Connections
RAMVAC
Interface Control
Connections
Communication
RS485 A A A A
RS485 B B B B
shield / gnd C C C N/A
DC + Voltage 5 5(1) See Power for Owl 5(1) See Power for Owl 5(2) See Interface Control Wiring
DC Gnd 6 6(1) See Power for Owl 6(1) See Power for Owl 6(2) See Interface Control Wiring
Low Voltage
Switching N/A N/A N/A R
Y
Page 7SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
Notes
SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 8
Main Level Flow Chart
the Enter and Press Esc keys to change levels
Press the Next and Prev keys to change catagories
Maximum 4 presses on the esc button takes you back to the top level
Press Esc button
Press Enter button
RAMVAC OWL
ALL UNITS NORMAL
UNIT STATUS
SYSTEM STATUS
OWL CONFIGURATION
RAMVAC SUPPORT
800-572-6822
UNIT IN FAULT
ENTR FOR DETAILS
See Unit Staus
(enter)
*** Screen shows for 3 seconds on power-up***
See Unit Staus
See Unit Staus
See Unit Staus
(enter)
(enter)
(enter)
See Unit Staus
(enter)
(prev button)
(prev button)
(prev button)
(prev button)
(prev button)
OPERATION AND MONITORING
RAMVAC
REV 1.00
