rainbow care FS965LH-B Manuel utilisateur
WALKING AIDS
|
USER GUIDE
FS965LH-B ROLLATOR
For illustration purposes only
PRODUCT OVERVIEW
PRODUCT OVERVIEW
FS965LH-B ROLLATOR
FS965LH-B Rollator
It is a walking aid meant to assist users to walk
independently and with stability.
With the ip up Seat Cushion and Foot
Rest, allow users to take a rest whenever. It
also comes with a basket storage for user’s
convenience.
For illustration purposes only
Height
Adjustment
Handle
Brake
Basket
Wheels
Seat Support
(changeable
direction)
Foot Rest
Seat
PRODUCT FEATURES
Lift up the seat and pull up
the basket
Flip up to keep or ip
down for usage
Remove the basket and
pull the string in the middle
upward to fold
Press the button and pull it
up to change the direction
REMOVE THE
BASKET
FLIP UP FOOT REST
FOLDABLE
CHANGEABLE SEAT
SUPPORT
FS965LH-B ROLLATOR
For illustration purposes only
CARE INSTRUCTIONS
• When using rollator, please pay attention to people and/or items around
to avoid collision.
• Make sure the level of the height of each handle is the same before using it.
• Make sure the level of ooring is even before seating down.
• Do not exceed the maximum load.
PRODUCT SPECIFICATIONS
Check our our full range of rollators. When making comparisons, our
best suggestion would be for you to think about your environment and
consider how certain task like transferring someone is done before
deciding.
Scan the QR code to nd out more about the product. To scan, use your
camera app or a QR code reader on your device.
58 cm or 22.8”
88 cm or 34.6”
44 cm or 17.3”
58 cm or 22.8”
104 cm or 40.9”
31 cm or 12.2”
35 cm or 13.8” (Cushion)
20 cm or 7.9”
80 kg
5 kg (Basket)
53 cm or 20.9” (Floor to Seat)
35 cm or 13.8” (Floor to Basket Base)
20 cm or 7.9”
8.8 kg
Overall Height
Folded Length
Folded Width
Folded Height
Seat Depth
Seat Width
Front Wheel Diameter
Safe Working Load
Seat Height
Back Wheel Diameter
Overall Weight
Overall Length 77 cm or 30.3”
Overall Width
FS965LH-B ROLLATOR
