FA-200 Alarm Bar
User’s Guide
Rev. A
October 2009
P/N F05-4030-000
© Copyright 2009 RAE Systems by Honeywell
FA-200 Alarm Bar User’s Guide
1
Contents
Warnings.............................................................................3
1 Standard Contents..............................................................4
2 General Information ..........................................................4
2.1 Key Features..............................................................4
3 Physical Description..........................................................5
4 Installation.........................................................................5
4.1 Mounting the FA-200 Alarm Bar..............................5
4.2 Drilling Chart.............................................................6
4.3 Electrical/Control Connections .................................6
4.4 Connecting to An FMC2000 Controller....................7
4.5 Positioning The Siren Horn.......................................8
5 Maintenance ......................................................................8
6 Specifications ....................................................................9
Special Servicing Note ........................................................10
7 Troubleshooting...............................................................11
7.1 Checking FMC2000 Relay Continuity....................12
8 Technical Support............................................................15
9 RAE Systems Contacts....................................................16
FA-200 Alarm Bar User’s Guide
2
Read Before Operating
This manual must be carefully read by all individuals who have
or will have the responsibility of using, maintaining, or
servicing this product. The product will perform as designed
only if it is used, maintained, and serviced in accordance with
the manufacturer’s instructions. The user should understand
how to set the correct parameters and interpret the obtained
results.
CAUTION!
To reduce the risk of electric shock, turn the power off before
opening this instrument or performing service. Never operate
the instrument when the instrument is open. Use and service
this product only in an area known to be non-hazardous.
FA-200 Alarm Bar User’s Guide
3
WARNINGS
Use only in non-hazardous locations.
For safety reasons, this equipment must be operated and
serviced by qualified personnel only. Read and understand
instruction manual completely before operating or servicing.
AVERTISSEMENT
Utiliser uniquement en zone non-dangereuse.
Pour des raisons de sécurité, cet équipment doit être utilisé,
entretenu et réparé uniquement par un personnel qualifié.
Étudier le manuel d’instructions en entier avant d’utiliser,
d’entretenir ou de réparer l’équipement.
FA-200 Alarm Bar User’s Guide
4
1 Standard Contents
•FA-200 Alarm Bar
•Integral 10-meter (33-foot) connection cable
•User’s Guide
2 General Information
The FA-200 Alarm Bar works with RAE Systems FMC2000
controller and other compatible devices. It provides bright
visible and loud audible notification when a controller is in
alarm.
2.1 Key Features
• Loud siren: 112dB @ 3 m (10′)
• Four bright strobe lights with impact-resistant polycarbonate
lenses (red, white, blue, amber)
• Heavy-duty stainless-steel enclosure
• Stainless-steel bars to protect strobe lights
• Second port for interconnection with second controller
• Low maintenance
FA-200 Alarm Bar User’s Guide
5
3 Physical Description
The FA-200 Alarm Bar comes pre-assembled and requires
only connection via its integrated cord to a controller with
relays. It has mounting flanges at the top and bottom with
four holes that accept screws for attaching the FA-200
Alarm Bar to a wall or other flat surface. It receives all
power from the controller that it is attached to, simplifying
installation and maintenance.
4 Installation
4.1 Mounting the FA-200 Alarm Bar
The FA-200 Alarm Bar is designed to be wall-mounted and has
four holes for anchoring the FA-200 Alarm Bar, using screws or
bolts.
Before mounting the FA-200 Alarm Bar, make sure that its cord
can reach the controller that it will be electrically connected to.
Make sure that there is approximately 12" (30 cm) of clearance
on all sides of the FA-200 Alarm Bar so that the siren’s sound is
not attenuated and to ensure clear view of the four visible alarm
lights.
Follow these steps:
1. Locate the FA-200 Alarm Bar on a wall or other flat surface
and mark the four holes’ locations.
2. Remove the FA-200 Alarm Bar.
3. Drill the four holes.
FA-200 Alarm Bar User’s Guide
6
4. Hold the FA-200 Alarm Bar firmly against the wall and
insert and tighten the screws.
The FA-200 Alarm Bar is now ready to be connected to the
controller.
4.2 Drilling Chart
When mounting the FMC2000 on a wall, make sure to use
heavy-duty steel screws spaced as indicated below.
4.3 Electrical/Control Connections
The FA-200 Alarm Bar has a 33’ (10 m) cable with a screw-
type multi-pin connector. It is designed to mate with the
connector on a RAE Systems FMC2000 controller and some
similar controllers that use the same connector type and relay
configuration.
FA-200 Alarm Bar User’s Guide
7
4.4 Connecting to An FMC2000 Controller
The FMC2000 has a female 6-pin connector on the bottom that
is designed for connection with a RAE Systems FA-200 Alarm
Bar.
Note: The internal wires from the FMC2000 connector are pre-
wired to the NO (Normally Open) connection points on the five
relay wiring blocks. Refer to the FMC2000 User’s Guide for
details of wiring for other configurations, including NC
(normally closed) and other alarm orders.
Note: Pin F connects to Ground. Pins B, C, D, and E transmit
12V @ 2A power when an alarm occurs.
FMC2000 Connector Pin Layout
FMC2000 Connector Pinout
Pin A: No connection
Pin B: Power switch for red light
Pin C: Power switch for blue light
Pin D: Power switch for amber light
Pin E: Power switch for white light
Pin F: Ground
Note: If a second controller is not connected to the auxiliary
port on the FA-200 Alarm Bar, keep the dust cap on the
connector to protect the pins.
FA-200 Alarm Bar User’s Guide
8
4.5 Positioning The Siren Horn
If the FA-200 Alarm Bar is to be used outdoors or in other
environments where it may become wet, point the horn slightly
downward to allow drainage. This will prolong its life and
ensure its effectiveness.
5 Maintenance
No periodic maintenance is required for the FA-200 Alarm Bar.
Check occasionally that the cable is securely fastened and
shows no sign of damage. Also check that the polycarbonate
lenses are tightened on the bases of the strobe lights and have
no cracks. If they are damaged, they should be replaced.
