Radiodetection SPX RD7100 Manuel utilisateur
RD7100™
Utility cable and pipe locator range
User guide
Bedienungsanleitung
Gebruikershandleiding
Guía del usuario
Guide d’utilisation
用户指南
Uživatelská příručka
90/UG103INT/07
2
ENGLISH 3
NEDERLANDS 43
ESPAÑOL 63
FRANÇAIS 83
DEUTSCH 23
中文 103
ČESKÝ 123
رع
142
3
ENGLISH
Preface
About this guide
CAUTION: This guide provides basic operating instructions for the RD7100
locator and transmitter. It also contains important safety information and
guidelines and as such should be read in its entirety before attempting to
operate the RD7100 locator and transmitter.
This guide is intended as a quick reference guide only. For detailed instructions,
including the use of accessories, help with eCert™, CALSafe™and usage-logging*
please refer to the RD7100 locator Operation Manual and RD Manager™manuals,
which are available for download from www.radiodetection.com.
The online User Manual library also contains links to the SurveyCERT+ and
RD Manager manuals.
Certificates of conformity for the RD7100 locators and Tx transmitter ranges can be
found at www.radiodetection.com.
*Logging and GPS models only
4
WARNING! Direct connection to live conductors is POTENTIALLY LETHAL.
Direct connections to live conductors should be attempted by fully qualified
personnel only using the relevant products that allow connections to energized
lines.
WARNING! The transmitter is capable of outputting potentially lethal voltages.
Take care when applying signals to any pipe or cable and be sure to notify other
technicians who may be working on the line.
WARNING! Reduce audio level before using headphones to avoid damaging
your hearing.
WARNING! This equipment is NOT approved for use in areas where
hazardous gases may be present.
WARNING! When using the transmitter, switch off the unit and disconnect
cables before removing the battery pack.
WARNING! The RD7100 locator will detect most buried conductors but there
are some objects that do not radiate any detectable signal. The RD7100, or any
other electromagnetic locator, cannot detect these objects so proceed with
caution. There are also some live cables which the RD7100 will not be able to
detect in Power mode. The RD7100 does not indicate whether a signal is from a
single cable or from several in close proximity.
WARNING! Batteries can get hot after prolonged use at full output power.
Take care while replacing or handling batteries.
WARNING! Only use charging equipment provided by Radiodetection. The use of
alternative chargers may cause a safety hazard and/or reduce the life of the battery.
CAUTION: Do not let your battery completely discharge as this may reduce its life
or damage it permanently. If you are not using your equipment for a long period
do charge them at least once a month.
WARNING! Batteries can get hot after prolonged use at full output power.
Take care while replacing or handling batteries.
WARNING! Do not tamper with, or attempt to disassemble the battery packs.
CAUTION: If battery failure is suspected or if the battery shows any sign of
discoloration/physical damage return the entire unit to an authorized repair
center for investigation and repair. Local, national or IATA transport regulations
may restrict the shipment of faulty batteries. Check with your courier for
restrictions and best practice guidelines. Your local Radiodetection representative
will be able to direct you to our authorized repair centers.
NOTE: The charging temperature range is 0 to 45 °C, 32 to 113°F. Do not attempt
to recharge your batteries outside this temperature range.
5
ENGLISH
3 Year Extended Warranty
RD7100 locators and transmitters are covered by a 1 year warranty as standard.
Customers can extend their warranty period to a total of 3 years by registering
their products within 3 months of purchase.
There are 2 ways to register your product:
1. Radiodetection portal
Visit https://portal.radiodetection.com to create your portal account* and use
the Product page to register your locator or transmitter.
Visit https://support.radiodetection.com for instructions on how to create a
portal account or register your product.
*A valid email address and mobile number are required.
2. Windows Applications
RD Manager™available from www.radiodetection.com/RDManager.
From time to time Radiodetection may release new software to improve the
performance or add new functionality to its products. By registering, users will
benefit from email alerts advising about new software and special offers related
to its product range.
Users can opt-out at any time from receiving software and technical notifications,
or just from receiving marketing material by contacting Radiodetection.
eCert and Self-Test
The RD7100 locator is safety equipment which should be regularly checked to
ensure its correct operation.
eCert provides a thorough test of the RD7100’s locating circuitry, and supplies a
Radiodetection Calibration Certificate when a positive test result is obtained.
To run an eCert, the locator should be connected to an internet-enabled PC on
which the RD Manager software is installed.
Refer to the RD Manager operation manual for further details. Additional purchase
may be required.
RD7100 locators incorporate an Enhanced Self-Test feature. In addition to the
typical checks for display and power functions, the RD7100 locator applies test
signals to its locating circuitry during a Self-Test to check accuracy and performance.
We recommend that a self-test is run at least weekly, or before each use.
6
RD7100 locator
1
23
4
5
6
8
7
13 14 1515
9
10
11 12
11
26
29
28
30
31
16
17
18
19
20
21 22 2427 2523
12 or more satellites locked
9-11 satellites locked
6-8 satellites locked
3-5 satellites locked
GPS satellite lock acquired
GPS
active, seeking satellite lock
7
ENGLISH
Locator features
1. Keypad
2. LCD with auto backlight.
3. Speaker.
4. Battery compartment.
5. Optional Lithium-Ion battery pack.
6. Accessory connector.
7. Headphone connector.
8. USB port
(inside battery compartment).
Locator keypad
9. Power key.
10. Frequency key.
11. Up and down arrows.
12. Antenna key.
Locator screen icons
13. Signal strength bargraph with peak
marker.
14. Signal strength readout.
15. Null / Proportional Guidance arrows.
16. Battery level.
17. Sensitivity readout
18. Volume level.
19. Radio Mode icon.
20. Power Mode icon.
21. Accessory / Measurement icon.
22. A-Frame icon.
23. Frequency / current / menu readout.
24. Antenna modes icon:
Indicates antenna mode selection:
Peak/Peak+™/Null/Guidance.
25. Sonde icon: Indicates that a sonde
signal source is selected.
26. Line icon: Indicates that a line signal
source is selected.
27. Compass: Shows the orientation
of the located cable or sonde relative
to the locator.
28. Transmitter standby indicator.
29. Depth readout.
GPS equipped locators only:
30. GPS Status.
31. GPS Signal quality.
8
Tx-1, Tx-5 and Tx-10 transmitters
1
3
4
2
10
11
12 13 14
15
16
17
18
19
5
6
7
8
9
9
ENGLISH
Transmitter features
1. Keypad.
2. LCD.
3. Removable accessory tray.
4. D-cell battery tray.
5. Optional Lithium-Ion battery pack.
Transmitter keypad
6. Power key.
7. Frequency key.
8. Up and down arrows.
9. Measure key.
Transmitter screen icons
10. Battery level indicator.
11. Operation mode readout.
12. Standby icon.
13. Output level indicator.
14. Clamp icon: Indicates when a signal
clamp or other accessory is connected.
15. DC Power connected indicator.
16. Induction mode indicator.
17. A-Frame: Indicates when the
transmitter is in Fault-Find Mode.
18. Voltage warning indicator: Indicates
that the transmitter is outputting
potentially hazardous voltage levels.
19. Volume level indicator.
10
Keypad actions and shortcuts
Switch the locator or transmitter on by pressing the key. Once powered up, the keys
function as follows:
Locator keys
KEY ● SHORT PRESS ●■■■● LONG PRESS
Enter the menu. Switch power off.
Scroll through locate frequencies
from low to high. –
When using active frequencies:
Toggles Peak, Peak+, Null, and Guidance
antenna modes.
PL & PLG models in Power Mode:
Scrolls through Power Filters™for improved
discrimination of parallel or strong power
signals.
In Peak+ antenna mode:
Switch between Guidance and Null arrows.
and
Increase and decrease gain.
RD7100 automatically sets gain to
mid-point when pressed.
Rapidly increase and decrease gain steps
in 1dB increments.
KEY ● SHORT PRESS ●■■■● LONG PRESS
Enter the menu. Switch Power off.
Scroll through locate frequencies
from low to high. –
Take voltage and impedance measurements
using the currently selected frequency.
Take voltage and impedance
measurements at a standardized frequency.
and Adjusts the output signal. Select standby /maximum standard
power .
Transmitter keys
Tip: to scroll through frequencies from high to low, hold while pressing the button
(applies to both locators and transmitters).
