Radio Shack 4 Manuel utilisateur

Cat. No. 15-1917

OWNER’S MANUAL

Phone Up 4

Remote Control

Please read before using this equipment.

CHAN

REW

VCR

AUX TV

CBL

LAST

SCANMENU

MUTE

FAST F

REC PAUSE

STOP PLAY

CHAN

VOL VOL

123

SLEEP ENTER

SELECT

PWR

SETUP

15-1917.fm Page 1 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

FEATURES

Your RadioShack Phone Up 4 Remote Control

lets you operate almost any infrared device in

your home from a distance. The Phone Up 4 can

replace up to four standard remote controls.

Unlike some universal remote controls, the

Phone Up 4 is preprogrammed and does not

need to learn its commands from the original re-

mote controls. All you need to do is enter the 4-

digit code for each infrared remote controlled de-

vice you want to operate. The Phone Up 4 is au-

tomatically ready to operate most of the same

functions as the original remote controls.

The Phone Up 4 Remote Control also has these

features:

Powerful Infrared Beam — lets you operate

many remote controlled devices from a greater

distance than with the original remote controls.

Convenient Ke

pad Desi

n— each control key

is in the perfect position for easy operation.

hted Ke

pad — lets you use the Phone Up 4

even in a dark or dimly lit room.

Channel Scan — lets you scan through all avail-

able channels on your TV, VCR, or cable convert-

er without having to press a button for each

channel.

Favorite Channel Scan — lets you scan through

up to 10 channels you select.

Sequences — lets you reduce a sequence of up

to 15 commands to a single key press.

Punch-Throu

h— lets you control two different

devices without pressing the device key for each

one first.

RadioShack is a trademark used by Tandy Corporation.

15-1917.fm Page 2 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

Sleep Timer — turns off your device in 15 min-

utes using the built-in sleep timer, or controls a

device’s built-in sleep timer (if one exists).

Toll-Free Upgrading — call our toll-free Custom-

er Service Hotline at 1-800-950-7044, and we will

upgrade your Phone Up 4 over the phone.

Note: You need four AAA alkaline batteries (not

supplied) to power your Phone Up 4 .

This manual includes a list of 4-digit manufactur-

ers’ codes for TVs, VCRs, cable converters, com-

pact disc players, satellites, and other popular

remote controlled devices. It also has a list of spe-

cific device codes.

15-1917.fm Page 3 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

CONTENTS

How the Phone Up 4 Works ................................... 6

Preparation ............................................................. 9

Installing Batteries .............................................. 9

Using ........................................................... 10

Setting Up Your Phone Up 4 ............................ 10

Determining the 4-Digit Code ........................... 11

Manufacturers’ Codes ...................................... 13

Cable Converters ..................................... 13

CD Players ............................................... 14

Home Automation .................................... 15

Miscellaneous Audio ................................ 15

Satellite Receivers ................................... 16

Televisions ............................................... 16

VCRs ....................................................... 19

Using Two or More Similar Devices ................. 24

Operation .............................................................. 25

Basic Operation ............................................... 25

Channel Scan .................................................. 26

Favorite Channel Scan .................................... 26

Setting Favorite Channel Scan ................ 26

Using Favorite Channel Scan .................. 27

Clearing Favorite Channel Scan .............. 28

Sequences ....................................................... 28

Setting Up a Sequence ............................ 28

Erasing a Sequence ................................ 29

Punch-Through ................................................ 29

Using Punch-Through .............................. 29

Turning Punch-Through On and Off ......... 30

Using the Sleep Timer ...................................... 30

If You Have Problems ........................................... 32

Manual Code Search ....................................... 32

Troubleshooting ............................................... 33

Downloading Updated Code Information ........... 34

Fast Search ...................................................... 35

Using Device Codes ........................................ 36

Device Codes ................................................... 37

Cable Converters...................................... 37

CD Players ............................................... 38

Home Automation .................................... 40

Miscellaneous Audio ................................ 40

Satellite Receivers ................................... 40

Televisions ............................................... 40

15-1917.fm Page 4 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

VCRs ........................................................ 44

Care and Maintenance .......................................... 49

Specifications ....................................................... 50

15-1917.fm Page 5 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

HOW THE PHONE UP 4

WORKS

Before you begin to use the Phone Up 4 , it is

helpful to understand a little about how it works—

nothing technical, only an idea of what you can

expect from the Phone Up 4 and its different

groups of keys.

When you set up the Phone Up 4, its command

keys work like the keys on your original remote

controls. For example, a key labeled POWER

ON/OFF on your original remote control is equiv-

alent to the Phone Up 4’s PWR key.

SETUP PWR

REW

VCR

AUX TV

CBL

LAST

SCANMENU

MUTE

FAST F

REC PAUSE

STOP PLAY

CHAN

VOL VOL

CHAN

123

SLEEP ENTER

SELECT

15-1917.fm Page 6 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

Your RadioShack Phone Up 4 was designed with

the functions used most often to operate your TV,

VCR, cable converter, CD player, and DSS satel-

lite receiver.

Key Function

Use these device keys when

you set up the Phone Up 4 to

replace your original remote

controls. You also use the

device keys during normal

operation to tell the Phone

Up 4 which device to control.

Used in setting up your

devices.

These keys, and the digit

keys, operate the same as

the similarly named keys on

your original remote control.

Lets you turn on the Phone

Up 4’s sleep timer function

(or a device’s built-in sleep

timer).

Lights up your keypad for

use in dark or dimly lit rooms.

Lets you easily browse

through channels on yourTV,

VCR, or cable box.

Operates the same as the

menu key on your original

remote control.

These keys are for special

sequences that you set up.

CBL

VCR

SETUP

LAST

ENTER

CHAN

VOL

SLEEP

SCAN

PWR

MUTE

15-1917.fm Page 7 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

Notes:

• The Phone Up 4’s red light turns on when

you press a key, and blinks when you enter a

feature or manufacturer’s code.

• To use REC record on the Phone Up 4, you

must press it twice. This safety feature helps

you avoid accidentally erasing video tapes.

• Depending on your device’s features, you

might need to press SELECT twice to operate

your device.

• If you use the Phone Up 4 to replace com-

plex remote controls, the Phone Up 4 might

not have some of your original remote con-

trol’s seldom-used functions.

• A key on the Phone Up 4 that has the same

name as a key on your original remote con-

trol might have a slightly different function.

These keys control VCR

functions.

Key Function

REW

REC

STOP

PLAY

PAUSE

FAST F

15-1917.fm Page 8 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

PREPARATION

INSTALLING BATTERIES

You need four AAA batteries (not supplied) to

power your Phone Up 4. We recommend alkaline

batteries, such as RadioShack Cat. No. 23-558.

1.Press the battery compartment

cover tab and lift off the cover.

2.Install four AAA alkaline batter-

ies as indicated by the polarity

symbols (+ and –) marked in

the battery compartment.

3.Replace the cover.

Note: Do not place objects on top of the Phone

Up 4 after you have installed the batteries. This

can press keys for an extended period of time and

reduce battery life.

When the Phone Up 4’s range decreases or it op-

erates erratically, replace the batteries.

Note: Although the Phone Up 4 has a built-in

memory backup, we recommend you have fresh

batteries ready to install as soon as you remove

the old ones.

15-1917.fm Page 9 Monday, July 19, 1999 12:25 PM

Need help? Call

1-800-950-7044

USING

The backlight lets you see the keys on your

Phone Up 4 in the dark. Press to light the

keys. Also, every time you press a key, the Phone

Up 4 lights up and stays lit for several seconds.

To turn off the light, and keep keypresses from

lighting the Phone Up 4, press again.

SETTING UP YOUR PHONE UP 4

1. Refer to “Manufacturers’ Codes” on Page 13

and write down the codes for your original

remote controls.

2. Turn on the device you want to control.

3. Press the device key for the type of remote

you are replacing (VCR, AUX, TV, or CBL).

4. Press and hold SETUP until the red light

blinks twice, then release it and enter the 4-

digit manufacturer’s code.

For example, to replace a TV’s remote con-

trol (with manufacturer’s code 0165), press:

TV SETUP 0 1 6 5

When the red light blinks twice again, the

Phone Up 4 has accepted the code.

5. Point the Phone Up 4 at your device and

press

PWR.

If your device turns off, press SETUP to lock

in the code.

If your device does not turn off after you

press PWR, press the numbers 1through 9

and 0, one at a time, to see if the device

responds. If the device turns off after you

press one of the digit keys, press SETUP to

lock in that code.

15-1917.fm Page 10 Monday, July 19, 1999 12:25 PM

Autres manuels pour 4

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Radio Shack Télécommande

Radio Shack

Radio Shack 15-2146 - Voice Prompt Universal Remote Manuel utilisateur

Radio Shack

Radio Shack Remote Control Manuel utilisateur

Radio Shack

Radio Shack 15-1925 Manuel utilisateur

Radio Shack

Radio Shack 6-IN-ONE TOUCHSCREEN REMOTE Manuel utilisateur

Radio Shack

Radio Shack 15-1990 Manuel utilisateur

Radio Shack

Radio Shack 15-1915B Manuel utilisateur

Radio Shack

Radio Shack 15-303 Manuel utilisateur

Radio Shack

Radio Shack 15-1931 Manuel utilisateur

Radio Shack

Radio Shack 150-2114 Manuel utilisateur

Radio Shack

Radio Shack Audio/ Video Remote Control Manuel utilisateur

Radio Shack

Radio Shack 6-in-1 Remote Control Manuel utilisateur

Radio Shack

Radio Shack 7-in-One IR Manuel utilisateur

Radio Shack

Radio Shack 15-1995 Manuel utilisateur

Radio Shack

Radio Shack Kameleon Manuel utilisateur

Radio Shack

Radio Shack 15-310 Manuel utilisateur

Radio Shack

Radio Shack Kameleon 4-in-1 Manuel utilisateur

Radio Shack

Radio Shack Kameleon Manuel utilisateur

Radio Shack

Radio Shack 7-in-One Home Theater Manuel utilisateur

Radio Shack

Radio Shack Light and Learn Remote Manuel utilisateur

Radio Shack

Radio Shack 63-1166 Manuel utilisateur

Radio Shack

Radio Shack 7-in-1 Remote Control with Lighted Keypad Manuel utilisateur

Radio Shack

Radio Shack Kameleon 4-in-1 Manuel utilisateur

Radio Shack

Radio Shack 15-309 Manuel utilisateur

Radio Shack

Radio Shack Keychain-Remote Control System Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
