Radenso RC-M Mode d’emploi
USER + INSTALLATION MANUAL
Radar Detector Radenso RC-M
Radar Detector Radenso RC-M
Congratulations on your purchase of world's most
intelligent radar and laser detector Radenso RC-M.
Main functions of Radenso RC-M
Radenso RC-M is the most advanced detector from Radenso family and is designed to protect the driver from speeding fines.
Radenso RC-M communicates with driver in English language and its main functions are detection of microwave radars (X / K /
Ka bands), red light cameras and sectional speed cameras (using its own GPS database), MultaRadars CT/CD and radar Gatso
RT3, or jamming laser guns. It also provides a quick deactivation of all functionality via removing the magnetic display. Radenso
RC-M also displays connectivity status of GPS antenna and all connected radars and accessories. Disconnected GPS is signaled
by flashing GPS icon on the screen, and accessories are signaled in the same way by flashing the HWY, A-C or CTY icon.
Notifications:
Text warning and voice alert appears on Radenso RC-M during radar alert. The strength of the signal and beeps expresses the
intensity of the received signal. Signal strength has ten levels. GPS alerts are reported by voice. For example “Speed Camera”.
Accessories alerts are reported by voice: „Laser”.
Control:
1) First button MENU / ON-OFF
Short press: You will enter into the setup menu.
During the signaling radar, you will mute the volume. The next alarm will be reported again in the standard volume.
Long press: Turn ON / OFF Radenso RC-M.
During radar signaling, you enter the menu via long press
Radar Detector Radenso RC-M
2) Second button BRIGHTNESS / ALERT SUPPRESSION
Short press: You can change the brightness of the display - Bright -> Dim -> Smart Dark -> Full Dark. Long Press: If you hold it
during an alert you will mark the place of false radar reporting so at a given point detector during the next passage will be
suppressed. If you suppress a false alert, the detector will not detect radars. Hold button during the "suppressed" radar alert and
this listing will be canceled. After next passage radar alert will be signaled acoustically.
3) Third button SENSITIVITY / ADD YOUR OWN GPS POINT
Short press: You can scroll between Highway / City / Auto City modes. In City or Auto City modes the sensitivity of X / K / Ka
bands can be reduced according to user preference. Long Press: Add your own GPS point.
4) Buttons ⋀⋁
Short press: Changing volume of the detector.
Menu:
Press first button for entering into the menu.
Press the second button to go from one category to the next.
Press VOLUME ⋀ or ⋁ (on the right side of the detector) to change your setting within a category. To complete this change,
simply wait a few seconds without pressing a button. The unit will display “Setting Completed” to confirm your selection.
Alternatively, you can get out of the menu by pressing the third button. After five seconds of inactivity, the menu will automatically
save and quit. Alternatively, you can quit the settings menu by pressing the mid button.
Radar Detector Radenso RC-M
Items in the menu are as follows:
(recommended settings are highlighted)
Front Radar: On / Off - Switches on Front Radar functionality. In case this option is turned off, further menu items controlling the
Front Radar are not displayed.
Rear Radar: On / Off - Switches on Rear Radar functionality. In case this option is turned off, further menu items controlling the
Rear Radar are not displayed.
Sensitivity: Highway / City / Auto City
Setting the speed in Auto City (item is present only if the sensitivity is set to Auto City): Through second button you are selecting
between speeds for editing (left number indicates the speed below which the detector will not respond to alerts. Right number
indicates the speed below which the detector will detect alerts like in City mode). ⋀⋁ buttons on the detector change the specific
speed. When the detector is set up to “20 50” speed below 20 km/h on the radar will not respond. In the velocity range, 20-50
km/h will only respond to stronger radar signals. Maximum detector sensitivity on the radar starts from 50 km/h.
Setting values City and Auto City sensitivity (entry is present only if the detector sensitivity is set to other than Highway): Via the
second button you can select radar band for editing. To change the signal level which will respond to radar signals use ⋀⋁. The
level of suppression can be selected in the range 0-9. For example, when setting is X2 K2 and Ka2 the level of detection in all
bands are slightly decreased.
The minimum speed for signaling radar: Off, 10 km/h, 20 km/h, 30km/h ......... .. 130 km/h
F - X-Band: On / Off
Radar Detector Radenso RC-M
F - K-Band: Wide / Narrow / Instant Only / Off (In countries, where police use K band radars, it is recommended to use K Narrow
setting)
F - K Filter: Off / Low / High - Filtering false alerts from blind spots and ACC. (When K Filter is activated, pulsed radars such as
Iskra are not detected)
F - Ka-Band: Wide / Narrow / Off
F - Ka 34.0 On / Off (if you are sure that police in your region does not use this band, then Off)
F - Ka 34.3 On / Off (if you are sure that police in your region does not use this band, then Off)
F - Ka 34.7 On / Off (if you are sure that police in your region does not use this band, then Off)
F - Ka 35.5 On / Off (if you are sure that police in your region does not use this band, then Off)
F - Ka Filter: Off / Low / High - Filtering false alerts from blind spots and ACC. (When Ka Filter is activated, detection distance on
Ka band radars is slightly reduced. We recommend using „Normal“ which is very good in sensitivity/false alerts immunity ratio.)
F - Laser: On / Off
F - MR CT: Wide / Narrow / Off - These radars are being used in countries SR, A, PL, NL, ES, P, LT. We recommend using
„Narrow” settings in these countries. In any other country, we recommend to leave the function „Off”. F - MR CD: Wide /
Narrow / Off
F - Gatso: On / Off
F - MR Filter: Low / High / Off - Filtering false alerts from blind spots and ACC. (When MR Filter is activated, detection distance
on MR band radars is slightly reduced. We recommend using „Normal“ which is very good in sensitivity/false alerts immunity
ratio.)
Radar Detector Radenso RC-M
R - X-Band: On / Off
R - K-Band: Wide / Narrow / Instant Only / Off (In countries, where police use K band radars, it is recommended to use
K Narrow setting)
R - K Filter: Off / Low / High - Filtering false alerts from blind spots and ACC. (When K Filter is activated, pulsed radars
such as Iskra are not detected)
R - Ka-Band: Wide / Narrow / Off
R - Ka 34.0 On / Off (if you are sure that police in your region does not use this band, then Off)
R - Ka 34.3 On / Off (if you are sure that police in your region does not use this band, then Off)
R - Ka 34.7 On / Off (if you are sure that police in your region does not use this band, then Off)
R - Ka 35.5 On / Off (if you are sure that police in your region does not use this band, then Off)
R - Ka Filter: Off / Low / High - Filtering false alerts from blind spots and ACC. (When Ka Filter is activated, detection
distance on Ka band radars is slightly reduced. We recommend using „Normal“ which is very good in sensitivity/false
alerts immunity ratio.)
R - Laser: On / Off
R - MR CT: Wide / Narrow / Off - These radars are being used in countries SR, A, PL, NL, ES, P, LT. We recommend using
„Narrow” settings in these countries. In any other country, we recommend to leave the function „Off”.
R - MR CD: Wide / Narrow / Off
R - Gatso: On / Off
Radar Detector Radenso RC-M
R - MR Filter: Low / High / Off - Filtering false alerts from blind spots and ACC. (When MR Filter is activated, detection distance
on MR band radars is slightly reduced. We recommend using „Normal“ which is very good in sensitivity/false alerts immunity
ratio.)
Jammer: ALP / FF / Off - Turns on accessories. Please note, that it is important that you would select the correct type of
accessories you have installed in your car, for the PRO will not work as intended if your settings are incorrect.
Parking Assistance: On / Off
Jamming: Off / 1s / 2s / … / 9s / Unlimited - Sets the length of laser gun jamming.
Display Mode: Speed/Time, Speed/Voltage, Battery Voltage, Time, Speed, Speed/Compass Auto Mute: On / Off: If it´s activated,
after two seconds of ongoing alert the volume will be reduced.
Startup sound: On / Off
GPS connect announce: On / Off
GPS detection by database type: Via Second button you can select the type of GPS points. For editing use ⋀⋁. You can turn on
and off particular type of point.
GPS warning distance: Normal (approx. 250m) / Farther (approx. 375m) / Farest (approx. 500m)
Unit: Imperial (mph) / Metrics (km/h)
Setting local time: You can change time zone via ⋀⋁
Radar Detector Radenso RC-M
Language: English / Deutsch / Czech
Factory reset: For reset press third button.
Delete all user points: For deleting all user points press third button.
S/N: XXXXX - Displays you Serial Number, that might be needed for you Radenso RC-M Update
SpeedMeter Option:
This function is intended for the legalization of the detector when used in countries where radar detectors are illegal. The detector
stops alerting you on GPS points, radars, and lasers and there is only current speed shown at the display. To activate this
function you need to hold the Second and third button for approximately 5 seconds. After that, you will enter into SpeedMeter. In
SpeedMeter mode GPS points, radars and laser functions are disabled. To reactivate your detection capabilities you need to run
a complete FW update.
Radar Detector Radenso RC-M
Operating frequency:
GPS: SiRF STAR IV
Ka narrow: 34.0GHz, 34.GHz, 34.7GHz, 35.5GHz
(±120MHz)
Ka wide: 33.4 GHz ~ 36.0 GHz
K narrow: 24.125GHz (±70MHz)
K wide: 24.125GHz (±150MHz) MultaRadar
CD/CT, Gatso RT3
Laser: 904nm
Database Updates:
Technical parameters:
Operating temperature: -20 +85 °C
Storage temperature: -20 +85 °C
Operating voltage: 11 – 16 V
Power consumption: 250mA normal,
330mA max
Dimenisons: 62 x 92 x 34 mm
Database update is recommended to check once in three months.
Download of the new database is performed according to the instructions at www.radenso.com
You can register and receive notifications of new and updated database to your email
Radar Detector Radenso RC-M
Installation manual Radenso RC-M
