RAB Lighting Lightcloud LCLCSENSE Manuel utilisateur
Welcome
1(844) LIGHTCLOUD
1(844) 544-4825
WE’RE HERE TO HELP:
PIR Micro Sensor
LCLCSENSE/P/EG/B/2
1(844) LIGHTCLOUD
1(844) 544-4825
WE’RE HERE TO HELP:
Hello
The Lightcloud Blue PIR Micro Sensor is a dual-technology
motion detector and daylight sensor that can switch and
dim both local and remote circuits. The PIR Micro Sensor is
compatible with Lightcloud Blue Controllers and fixtures.
Specifications
PART NUMBER
LCLCSENSE/P/EG/B/2
INPUT
5VDC
RATUREOPERATING TEMPE
-4°F to 113°F (-20°C to 45°C)
DIMENSIONS
1.14”W x 1.33”H x 2.64”D
SENSOR COVERAGE
20 ft. diameter at 9 ft.
MOUNTING HEIGHT
8 to 12 ft.
CONNECTOR
RJ09
Setup & Installation
1The PIR Micro Sensor is only compatible with select
sensor-ready fixtures. Visit www.rablighting.com to
see the full compatibility list.
2Mount the PIR Micro Sensor with the tape included.
Example shown using RAB's SWISH fixture.
PIR Micro Sensor
SWISH
Setup & Installation (Cont’d)
3Connect the PIR Micro Sensor to the Lightcloud Blue
Controller.
Lightcloud Blue Controller: Use the enclosed RJ09
adapter to connect the PIR Micro Sensor to the
Controller.
PIR MICRO SENSOR
WireShort, Wire
Female to
Female RJ09
CONTROLLER
ADAPTER
Sensor Coverage
PIR
(LCBS)
SIDE VIEWTOP VIEW
10’ 7.5’ 7.5’ 10’
20’
9’
0’
0’
5’
5’
10’
10’
Configuration
All configuration of Lightcloud Blue products may
be performed using the Lightcloud Blue mobile app.
Learn more at www.rablighting.com
1(844) LIGHTCLOUD
1(844) 544-4825
©2022 RAB LIGHTING Inc.
Custom manufactured in China
Pat. rablighting.com/ip
