120/240/277v or 347v
Avici Integrated LED Lighting System
Owner's Manual 3 March, 2021
The Box Contains
Avici Integrated LED Lighting System
Power Cord (NEMA 6-15P standard)
Two (2) RJ-14 Data Cables
RJ-14 Dual Splitter
Two custom wire light hangers
Blinking LEDs – What Your Avici Is Telling You
Blinks Once A Second – Over Temperature or Fan Failure
If the Avici internal heatsink reaches a programmed over temperature
point, it's way too hot and it will shut o with the OFF LED blinking on
and o once a second. Once the internal temperature cools to 10 degrees
below the over temp point, the Avici will automatically restart.
Blinks Four Times A Second – Over Voltage / Under Voltage
If supplied power is outside safe operating range for the Avici, the LED will
ash quickly to let you know the xture is working but not going to come on.
If the status LED is ashing quickly you can either remove and reapply power,
but best to check the electrical supply rst. Incorrect supply voltage can
destroy the xture. Avici normal voltage range is 100v-300v and must
be stable for 10 seconds to power up.
Flickers Briey Once a Second – External Control
The RLC1 and TouchMi Room Controller can control 512 Revolution lights
in two zones. You can set on and o times, sunrise and sunset ramps, dimming
with temperature and over temperature shutdown for each zone for lights
that support these commands. Avici also accepts commands for color
mixing for custom spectra. Please see the RLC1 and TouchMi manuals for
details on controlling the output spectrum.
When the provided RJ-14 phone cable is plugged into the Avici and a
Revolution controller, the front panel LED will blink o, very briey, once a
second to show you that Avici is controlled by an outside source and that
communication is up and running.
If the cable becomes disconnected, Avici will maintain chosen power level
and spectrum – just as you would expect. After a power failure, Avici returns
to full power and spectrum if not commanded otherwise by a controller.
Congratulations on your new Avici. The Avici combines an array of
Osram LEDs with our custom-designed drivers for one amazing,
programmable spectrum, computer-controlled grow lighting system.
This manual will tell you how to hang, connect and operate your new Avici.
404/334-9788
