Quictent 1302 Manuel utilisateur
Use indoors or in a sheltered place.
*
71" x 36" x 36"
95" x 36" x 36"
56" x 29" x 77"
56” x 56” x 77”
USER MANUAL
USER MANUAL
Please read, understand, and practice guidelines in this user
manual before use, and keep it for future reference.
Tableof Contents
About Quictent
...........................................................................
..............................................................................
.....................................................................................
......................................................................................
..............................................................................
..............................................................................
..............................................................................
..............................................................................
3
Appendix 30
28
28
21
14
9
4
Maintenance
Warranty
71" x 36" x 36"
95" x 36" x 36"
56" x 29" x 77"
56” x 56” x 77”
1
IMPORTANT
We’d love to hear from our customers. If you have any questions about the
manual, would like us to help in any way, or have any suggestions and
comments about our products, please feel free to contact the support team. We
will reply in 12 hours (business days).
Other Greenhouses from Quictent
2
Size: 10' x 9' x 8'
Model #1302
Size: 12' x 7' x 7'
Model #1303
Size: 20' x 10' x 7'
Model #1306
Size: 20' x 10' x 7'
Model #1306G/W
Available in 2 colors:
Green and White
Upgraded version of
Model #1306
Available in 2 colors:
Dark and Green
Size: 98" x 49" x 53"
Model #0163
3
AboutQuictent
This user manual applies to Quictent mini greenhouses. It will help you to get to
know your Quictent mini greenhouse. Please read the guidelines in this manual and
keep the manual for future reference.
Our Vision
Creating unique spaces to meet every specific need, and become a part of America's
landscape.
Our Mission
To keep innovating and provide a wide range of reliable shelters and shades at
consumer-grade prices with customer-first service.
Our Service
The customer-centric services are what we at Quictent take great pride in. In
addition to the hassle-free warranty covering all Quictent products, an industri-
al-leading support team is standing behind at all times. Whenever you need help or
have any suggestions and comments about our products, do not hesitate to contact
us. You’re sure to get a to-the-point reply in 12 hours.
Founded in the early 21st century, Quictent has grown into a popular brand with
reliable products and excellent customer services during the past decades. We
started with pop up canopies, and then expanded to other 6 categories for shelters
and the like including party tents, carports, greenhouses, shade sails, patio umbrel-
las and grow tents. Driven by the vision to create unique spaces to meet every
specific need and become a part of America's landscape, we at Quictent would
spare no effort to keep innovating.
We may update the manual without notice in advance. You can always search
“Quictent Instructions” online for the latest version.
3
71" x 36" x 36"
4
Model #1310
1 * Clear PVC Cover
Model #1312
1 * Green PE Cover
Model #1312W
1 * White PE Cover
Model #1315
2 * Covers: a Green PE Cover + a Clear PVC Cover
IMPORTANT!
Apply to Model #1310, Model #1312, Model #1312W, and Model #1315.
All the models in this size have the SAME frame (both the structure and materials)
with the parts numbered from #1 – #D in the Parts List.
You can tell the model from each other according to the COVER (part #Ein the
Parts List) you received.
Parts List
5
Please refer to this chapter if you’re owning a Quictent mini greenhouse in 71" x 36"
x 36". All parts come in one (1) box only. Please pay particular attention to make sure
all parts are numbered and graphically indexed, so does the quantity for each part
as per the Parts List below. If you need any help, please EMAIL the support team
at your earliest convenience with the order number, required part(s), quantity
for each part, and photos (or video clips, if applicable), we’ll get back soon to
help out.
1
2
3
3
3
2
2
1
1
1
1
1
1
1
B
B
A
A
A
A
D
A
B
C
C
B
B
B
6
#1 Long Pole (30.3") 12
#2 Pole with Curved End 6
#B T-Shaped 3-Way
Connector 6
#C X-Shaped 4-Way
Connector 2
#E
1 * Clear PVC Cover for
Model #1310
1 * Green PE Cover for
Model #1312
1 * White PE Cover for
Model #1312W
2 * Covers (A Clear PVC
Cover + A Green PE
Cover) for Model #1315
#A 3-Way Connector 6
#3 Short Pole (12.8") 6
Part
Number DescriptionDiagram Quantity
(PCS)
#D 4-Way Connector 1
#FT-Shaped Plant Tag 50
Assembly
7
Check to make sure that you have all parts listed on the Parts Lists.
√
Before moving to the next step, please make sure the end of the poles are aligned
with the bottom of the connectors, which indicates that the poles are fully seated
inside the connectors.
Step 1 Connect the poles (#1) with the connectors (#A & #B). You'll use:
6x Part #1
4 x Part #A
2 x Part #B
√
Read Before the Assembly
Step 2 Insert the poles (#3) into the connectors (#A & #B), then put the
connectors (#B & #C) on the top of each pole. You'll use:
6 x Part #3
4 x Part #B
2 x Part #C
A
A
A
A
B
B
1
1
1
1
1
1
B
B
B
B
3
3
3
3
3
3
C
C
8
Step 3
4 x Part #1
6 x Part #2
Step 4 Connect the poles (#1) with the connectors (#A & #D). You'll use:
Connect the poles (#1 & #2) with the assembled connectors (#B & #C).
You'll use:
Step 5 Put on the cover.
2 x Part #1
2 x Part #A
1 x Part #D
1
2
2
2
1
1
1
A
D
A
1
1
95" x 36" x 36"
9
Model #1316 with a Clear PVC Cover Model #1318 with a Green PE Cover
IMPORTANT!
The two models in this size (Model #1316 &Model #1318) are the SAME except
for the COVER (#F).
Model #1316 has a clear PVC cover.
Model #1318 has a green PE cover.
