Queclink GV35 Manuel utilisateur
GV35 User manual
TRACGV35UM001
GPS Locator GV35
User Manual
TRACGV35UM001
Revision: 1.00
http://www.queclink.com
GV35 User manual
TRACGV35UM001 - 2 -
Document Title GV35 User Manual
Version 1.00
Date 2012-05-17
Status Release
Document Control ID TRACGV35UM001
General Notes
Queclink offers this information as a service to its customers, to support application and
engineering efforts that use the products designed by Queclink. The information provided
is based upon requirements specifically provided to Queclink by the customers. Queclink
has not undertaken any independent search for additional relevant information, including
any information that may be in the customer’s possession. Furthermore, system validation
of this product designed by Queclink within a larger electronic system remains the
responsibility of the customer or the customer’s system integrator. All specifications
supplied herein are subject to change.
This device complies with part 15B, part 22 and part 24 of the FCC rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference
(2) this device must accept any interference, including interference that may cause
undesired operation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Users must maintain a separation distance of at least 20cm from the EUT to satisfy RF
exposure compliance.
Copyright
This document contains proprietary technical information which is the property of Queclink
Limited., copying of this document and giving it to others and the using or communication
of the contents thereof, are forbidden without express authority. Offenders are liable to the
payment of damages. All rights reserved in the event of grant of a patent or the
registration of a utility model or design. All specification supplied herein are subject to
change without notice at any time.
Copyright © Shanghai Queclink Wireless Solutions Co., Ltd. 2012
GV35 User manual
TRACGV35UM001 - 3 -
Contents
1. Introduction...................................................................................................................................7
1.1. Reference.............................................................................................................................7
1.2. Terms and Abbreviations.....................................................................................................7
2. Product Overview .........................................................................................................................8
2.1. Check Part List....................................................................................................................8
2.2. Parts List..............................................................................................................................9
2.3. Interface Definition.............................................................................................................9
3. Getting Started ............................................................................................................................11
3.1. Opening the Case ..............................................................................................................11
3.2. Closing the Case................................................................................................................11
3.3. Installing a SIM Card........................................................................................................12
3.4. Power Connection.............................................................................................................12
3.5. Ignition Detection..............................................................................................................13
3.6. Digital Input......................................................................................................................13
3.7. Digital Output....................................................................................................................14
3.8. Relay .................................................................................................................................15
3.9. Device Status LED............................................................................................................16
GV35 User manual
TRACGV35UM001 - 4 -
Table Index
TABLE 1: GV35 PROTOCOL REFERENCE.........................................................................................7
TABLE 2: TERMS AND ABBREVIATIONS .........................................................................................7
TABLE 3: PART LIST .............................................................................................................................9
TABLE 4: DESCRIPTION OF 6 PIN CONNECTIONS.......................................................................10
TABLE 5: ELECTRICAL CHARACTERISTICS OF IGNITION DETECTION.................................13
TABLE 6: ELECTRICAL CHARACTERISTICS OF THE DIGITAL INPUT.....................................13
TABLE 7: ELECTRICAL CHARACTERISTICS OF DDIGITAL OUTPUT.......................................15
TABLE 8: ELECTRICAL CHARACTERISTICS OF RELAY.............................................................15
TABLE 9: DEFINITION OF DEVICE STATUS AND LED.................................................................17
GV35 User manual
TRACGV35UM001 - 5 -
Figure Index
FIGURE 1. APPEARANCE OF GV35..............................................................................................8
FIGURE 2. THE 6 PIN CONNECTOR ON THE GV35..................................................................10
FIGURE 3. OPENING THE CASE..................................................................................................11
FIGURE 4. CLOSING THE CASE..................................................................................................11
FIGURE 5. SIM CARD INSTALLATION.......................................................................................12
FIGURE 6. TYPICAL POWER CONNECTION.............................................................................12
FIGURE 7. TYPICAL IGNITION DETECTION............................................................................13
FIGURE 8. TYPICAL DIGITAL INPUT CONNECTION..............................................................14
FIGURE 9. DIGITAL OUTPUT INTERNAL DRIVE CIRCUIT....................................................14
FIGURE 10. TYPICAL CONNECTION WITH LED .......................................................................15
FIGURE 11. TYPICAL CONNECTION WITH RELAY ..................................................................16
FIGURE 12. GV35 LED ON THE CASE..........................................................................................16
GV35 User manual
TRACGV35UM001 - 6 -
Revision History
Revision Date Author Description of change
1.00 2012-5-17 Cid Xu Initial
GV35 User manual
TRACGV35UM001
1. Introduction
The GV35 is a powerful GPS locator designed for vehicle or asset tracking. It has superior
receiver sensitivity, fast TTFF (Time to First Fix) and supports Quad-Band GSM
frequencies 850/900/1800/1900, its location can be monitored in real time or be
periodically tracked by a backend server or other specified terminals. The GV35 has
multiple input/output interfaces that can be used for monitoring or controlling external
devices. Based on the integrated @Track protocol, the GV35 can communicate with a
backend server through the GPRS/GSM network to transfer reports of Emergency,
geo-fence boundary crossings, low backup battery or scheduled GPS position as well as
many other useful functions. Users can also use GV35 to monitor the status of a vehicle
and control the vehicle by its internal relay output. System Integrators can easily setup
their tracking systems based on the full-featured @Track protocol.
1.1. Reference
Table 1: GV35 Protocol Reference
SN Document name Remark
[1] GV35 @Track Air Interface Protocol The air protocol interface between
GV35 and backend server.
1.2. Terms and Abbreviations
Table 2: Terms and Abbreviations
Abbreviation Description
GND Ground
NC Not Connected
IN1 Input Port
PWR External DC power input
OUT1 Output Port
IGN Ignition input
GV35 User manual
TRACGV35UM001
2. Product Overview
2.1. Check Part List
Before starting, check all the following items have been included with your GV35. If
anything is missing, please contact your supplier.
Figure 1. Appearance of GV35
GV35 User manual
TRACGV35UM001 - 9 -
2.2. Parts List
Table 3: Part List
2.3. Interface Definition
The GV35 has a 6 PIN interface connector. It contains the connections for power and I/O.
The sequence and definition of the 6PIN connector are shown in following figure:
Name Picture
GV35 Locator 74*49.5*24 mm
User Cable
Relay Inserted spring
Relay Inserted spring Protective sleeve
GV35 User manual
TRACGV35UM001 - 10 -
Figure 2. The 6 PIN connector on the GV35
Table 4: Description of 6 PIN Connections
Index Description Comment
1 GND Ground
2 NC
3 IN1 Digital input, negative trigger
4 PWR External DC power input, 9-16V
5 OUT1 Open drain output signal(max drive current is 150mA)
6 IGN Ignition input, positive trigger
