Quantum Q10 Manuel utilisateur

Q10

Quick Guide

Quantum S.p.A

Via L. D’Aragona, 11 - 20132 MILANO

www.qtm.it

Index

Warning

Precautions and safety

Remote control

Audio/Video switch

Receiver Menu

Settings

Tv List

Diagnostics

First Use

Daily Use

Installation

Installation and Connections

Technical features

Warning

Warranty

EQUIPMENT

Each package contains:

RECEIVER

REMOTE CONTROL

REMOTE INFRARED SENSOR

POWER CAR CABLE

QUICK GUIDE











Page 3

“4

“5

“6

“8

“10

“11

“12

“14

“15

“16

“19

“20

“21

“22

Warning

CAUTION

This symbol means impor-

tant instructions. Failure to heed

them can result in serious injury or

death

DO NOT OPERATE ANY

FUNCTION THAT TAKES YOUR

ATTENTION AWAY FROM SAFELY

DRIVING YOUR VEHICLE

Any function that requires your

prolonged attention should only be

performed after coming to a

complete stop.

Always stop your vehicle in a safe

location before performing these

functions. Failure to do so may result

in an accident.

USE THIS PRODUCT FOR MOBILE

12/24 Vcc APPLICATIONS AND

NEGATIVE GROUND

DO NOT DISASSEMBLE OR ALTER

THE UNIT

USE THE CORRECT AMPERE

RATING WHEN REPLACING

FUSES

HALT USE IF A PROBLEM

APPEARS

DO NOT USE OLD BATTERIES

Any misuse that diverts from the

designed application may result in

fire, electric shock or other injury.

Doing so may result in accidents or

injuries.

Failure to do so may result in fire or

electric shock

Failure to do so may cause personal

injury or damage to the product.

When inserting batteries in the

remote control, be sure to observe

proper polarity as instructed.

Rupture or chemical leakage from

the battery may cause malfunction

ing, breakage or injury.

Warranty

WARRANTY VOUCHER

Model .........................

Serial number .........................

Defect found ...........................................................................

.............................

Customer signature

Date _ _ / _ _ / _ _

To return correctly filled in together with the purchase receipt

DEALER’S STAMP AND SIGN

Warranty

Dear customer,

thank you for choosing our product, which has been designed and manufactured to the highest quality

standards.

› failures caused by carelessness or transport.

› failures caused by installation not in accordance with the instructions

› failures caused by improper, incorrect or not in accordance with the instructions, use of the device

› In the event you require service, during the warranty period, you should fill in and show the present

certificate, together with a valid receipt issued by the dealer, showing the date of purchase of the

product.

• The product is covered by a warranty, for a period of 24 months, which is testified from a delivery document

indicating the date of purchase of the product and the dealer’s name.

• The customer is entitled to the rights provided for by Legislative Decree n° 24/2002

• The warranty covers the replacement or the repair operation of all the parts found to have manufacturing

defects.

• The warranty does not cover:

• The manufacturer cannot be held responsible for accidental damages to persons, pets, or things, as a con-

sequence of non-conformity with all the precautions furnished with the instructions manual.

IMPORTANT:

Quantum S.p.A. declines all respon-

sibility for any errors or omissions in

this guide and reserves the right to

make changes without prior notice.

The information given in this guide

were correct at the time of going to

print.

Precautions and Safety !

PRECAUTIONS

TEMPERATURE

Be sure the temperature inside the

vehicle is between +45°C and 0°C

before turning your unit on.

The replacement of the fuses must

be of the same amperage. If one

fuse blows more than once, care-

fully check all electrical connections

to prevent short circuits. Also have

your vehicle’ s voltage regulator

checked.

If you have problems, do not

attempt to repair the unit yourself.

Require assistance at the nearest

retailer or service station.

Installindry,safelocations,away

from dangers and humidity.

Use only in cars with a 12/24 Vcc

negative ground.

Before connecting the device

remove the negative terminal from

the battery to prevent short circuits.

Do not use bolts or nuts related to

any safety system (airbag, etc.), To

make ground connection.

In order to ensure vehicle safety,

the driver’s side screen must be con-

nected to the front video output con-

nector. This will ensure the driver

won’t be able to watch TV while the

vehicle is moving.Iif the handbrake

wire is properly connected, the

driver will be able to watch TV once

the handbrake is pulled. The rear

passenger screens, connected to

the rear video output connectors,

do not fall under this restriction.

FUSE REPLACEMENT

MAINTENANCE

INSTALL LOCATION

INSTALLATION PRECAUTIONS

VIDEO OUTPUT

SAFETY

CAUTION

WATCHING TV WHILE

DRIVING MAY RESULT IN SERIOUS

ACCIDENTS, INJURIES OR DEATH!

Warning

Q10 complies with:

CAUTION:

E24: according to ECE R10-03 Regulation

DiGiTVi: specifications D-Book ver.1.0 - June 2004 and following

updates where applicable

Your receiver is supplied with an operating system and resident programs.

While using the reciever, various softwares could be downloaded.

You should not make improperly use of any of these softwares wholly or

partly.

Improper use means: duplication, distribution, tampering. In other words,

that the only allowed usage is the one described in this user manual.

Remote Control

SCAN

P+

PV+

CHANNEL

456

EXIT

BACK MUTE

LIST

info

RADIO

@?!. abc

ghi jkl mno

pqrs tuv

_+ *

wxyz

def

-TV/RADIO - YELLOW

to switch between Tv and

Radio listings

SCAN

to start autoscan

to select a function or to

confirm the selection

LIST

to view channel list

P+/-

changes channels

to view info on program/

navigation button

UP BUTTON

navigation or volume adjust

button

RIGHT BUTTON

EXIT

to exit from the selected

option

0…9

alpha/numerical button

BACK

to return to the previous page

(where available)

MUTE

to switch on/off the audio

input

-RED, BLUE, GREEN

navigation buttons

DOWN BUTTON

navigation button

LEFT BUTTON

navigation or volume adjust

button

STAND-BY

to put the unit on stand-by

and to switch to a/v input

Not in use

Technical features

Mobile DVB-T signal reception

Autotracking/Autosearch

Favourite Channels List

2 video for separated monitor

1 audio stereo

Audio/video digital quality

Easy and fast plug-and-play installation

output two

output

1 video input

1 audio stereo input

DVB-T

Video Decoding and OSD

Audio Decoding

Connections

ISO/IEC 13818-1 MPEG-2 Transport Stream

ETS 300 744 DVB-T Full Compliance

VHF (Band III) / UHF 21-69

DVB-T COFDM 2k/8k supported

7,8 mhZ bandwidth support

ISO/IEC 13818-2 MPEG-2 Video MP@ML Compliance

ISO/IEC 11172-2 MPEG-1 Video Compliance

Resolution: 720x576 for PAL

16:9/4:3, 3:2 Letterbox and Pan/Scan

65K Colour OSD

ISO/IEC 13818-3 MPEG-2 Audio Compliance

ISO/IEC 11172-3 MPEG-1 Audio Compliance

Stereo / MTS

IR Remote Connector

Antenna-In : Fakra type 2x

Audio stereo Output (RCA L/R) 1x

Composite Video Output (RCA) 2x

Stereo Audio Input (RCA L/R) 1x

Composite Video Input (RCA) 1x

Safety and Reliability

Comsuptions

Mechanical Specification

Operation temperature : -5 C ~ +55 C

Storage temperature : -45 C ~ +85 C

0.4 A in full operation powering two antennas

0.35 A in stand by

500 microA when off (car key off)

Dimensions (WxDxH): 125mm x 72mm x 35mm

First Use

Be sure that every connection has been correctly set

at page

Turn the unit on

frame will be shown on the screen .

ress button to the channels n the TV

LIST. The first channel n the update TV LIST will

be shown on the screen.

If at the end of the frame is shown on

the screen, check the connections and the

installation of the receiver, then press in sequence

buttons to restart the

to start the automatic channel

o stop the press EXIT button. Frame

will be shown on the screen. Press to

stop or the button to resume it.

following installation instructions s 16-17-18-19

Q10 receiver is an automotive grade set top box able to

receive free to air DVB-T Television.

[OK] confirm

search [EXIT]

› P [OK] save o

scan phase

overall

[EXIT], [SCAN] and [OK]

scan phase.

vGetting started

• Please wait until

› press [OK] button

search.

Tsearchthe

At the end of the scan phase, frame will be shown

on the screen.









SCAN

[OK] to start search - [EXIT] to quit

SCAN

No services found - [EXIT] to quit

RADIO

50% 100%

SCAN

[OK] to stop - [EXIT] to continue

RADIO

50% 100%

SCAN

[OK] to save - [EXIT] to quit

TV 1

TV 2

TV 3

TV 4

RADIO 1

RADIO 2

RADIO 3

RADIO 4

RADIO

50% 100%

Installation and Connections

vTECHNICAL FEATURES

+ 5V DC PHANTOM POWERED DVB-T

ANTENNAS

Operation frequencies: 174 - 230 (band III)

470 - 866 (bands IV - V)

Gain: 18 dB Max

Cable type: coaxial 75 ohm

Cable lenght: 5 m

Connector: type FAKRA

Power: +5 Vcc

Consumption: 25mA min - 35 mA max

Temperature range : - 40° <> +85° C

Protection class: IP40

Size (L x B x H): 28 x 2,5 x 1,5 cm

TV ANTENNAS

Specifications

First Use

TUNING

[OK] to start search - [EXIT] to quit

TV LIST

ADD FAVOURITE: [OK] to confirm - [EXIT] to quit

SETTINGS DIAGNOSTICS

CREATE SORT DEL.CHAN DEL.LIST

vAutotracking and Autosearch

These innovative automatic functions enable the receiver

to still be in tune with the selected channel while on the

move.

Typical DTT Networks are Multi Frequency Network (MFN);

each TV channel may be transmitted at different

frequencies depending on the specific geographical area.

Once a specific TV channel has been selected, the

Autotracking and Autosearch functions will tune, track and

in some cases automatically search for a channel where

there is a frequency change or signal loss without the need

of manually starting a new search.

To have the Autotracking and Autosearch functions

performing in the best possible way, it is recommended to

carefully follow the instructions below:

tune into the available channels

in that specific area

If the Autosearch function does not permit tuning into all

favourite channels, start the operations described at the

point 1 and 2 again but in another location.

1.Start an autoscan

2.Create a FAVOURITE TV LIST (from menu) -

3. Select the FAVOURITE TV LIST as default

by pressing [SCAN]

defi-

ne and organize the list of your favourite channels







WARNING: channels marked in red are

temporarily not available due to the lack of

network coverage .

WARNING: channels marked in red are

temporarily not available due to the lack of

network coverage .

FAVOURITE TV

1 Channel TV

2 Channel TV

3 Channel TV

4 Channel TV

5 Channel TV

6 Channel TV

7 Channel TV

TV LIST

[GREEN] to change list

FAVOURITE TV

TV LIST

1TV

Channel

Channel TV

3 Channel TV

4 Channel TV

5 Channel TV

6 Channel TV

7 Channel TV

[GREEN] to change list

Installation and Connections







TV ANTENNAS

Recommendations

active antennas

receiver

(DVB-T).

•

• Placing the antenna in the

firstly

;

•

INSTALLATION GUIDELINES







Use only amplified with adequate

gain directly powered by the antenna

connector and suitable to the reception of the Digital

Terrestrial signal

Quantum Antennas, linked together with

Q10 receiver, have been manufactured in order to

optimize the system's functioning.

WARNING: ONLY use Quantum antenna

provided. Use of different antenna or external

power may result in product damage and

might affect the warranty terms.

Be sure to position the antennas as far away and

opposing from each other as possible. For exam-

ple, place the first antenna on the right side of the

wind screen of the vehicle and the second one

on the left side of the rear window or on the left

rear vent wing .

Antennas must be installed as far away from the

metal parts (vehicle's roof or vertical borders of

the wind screen/rear vent wing) as possible.

bonnet or the boot (de-

pending on the vehicle) can influence the signal

reception. It's recommend to experiment

where to place the antennas whether on the

higher or the lower part of the window. The higher

part usually guarantees more protection from

noises caused by motorcycles and scooters.

Handle with care the coaxial cable setting in order

to avoid damages due to vibration or crushing.

Be sure that the connections have been correctly

set and check the screwing of the connectors. Sig-

nal reception's problems are often caused by

incorrect assembly.

Daily Use

How to switch the receiver on

How to select a channel

Depending on the specific car installation, the receiver will

be switched on as soon as the car key turns on the battery.

In case an external a/v source was previously activated,

please use the [ ] button on the remote control to exit

stand-by mode.

A TV or Radio channel can be selected in three different

modes:

[]and[] [OK]

INFORMATION BAR will be previewed on the screen

tuning.

directly t rough channels without using the

[OK] button.













• DIRECT: select the desired channel by using the numeri-

cal buttons

• USING ARROWS: select the desired channel by using the

up/down buttons and press to

confirm the selection.

before the channel

• USING PROGRAM BUTTONS: press [P+] [P-] to

browse h

15 Channel TV

rogramP title

TV 12:17

12:00 12:45



SCAN A/V

P+

PV+

CHANNEL

456

EXIT

BACK MUTE

LIST

info

RADIO

@?!. abc

ghi jkl mno

pqrs tuv

_+ *

wxyz

def









Installation and Connections

FRONT PANEL

WARNING:

+5V PHANTOM POWER IS PRESENT

TO ALL “ANTENNA IN” CONNECTORS

+12/24V KEY - Red

+12/24V BATTERY - Yellow

BRAKE - Green

GND - Black

VIDEO OUT 1 (FRONT)

VIDEO OUT 2 (REAR)

VIDEO IN

AUDIOOUTR(rigth)

AUDIO OUT L (left)

ANTENNA IN 1

ANTENNA IN 2

IR RECEIVER

TO CAR AUDIO

SYSTEM

RJ11 PORT

AUDIOINR(rigth)

AUDIO IN L (left)

EXTERNAL

AUDIO SOURCE

EXTERNAL

VIDEO SOURCE

FRONT

MONITOR

REAR

MONITOR

Daily Use

How to select a channel in a TV/Radio List

How to adjust the volume level

Mute

How to view program info

How to select the audio language

• Press [LIST] to show the TV List

› Press [GREEN] to switch between the general TV LIST

and the FAVOURITE TV LIST if previously preset [see

MENU]

• Press [TV/RADIO] (yellow) to show the RADIO LIST

› Press the same button to switch between the Radio List or

the previously selected TV LIST

• Select the desired channel

The volume level can be adjusted by using the [VOL+] [VOL-]

buttons

• Press [MUTE] to switch on/off the audio output

• Press [info] to view the short information about the

selected program

• Press [BLUE] to get detailed informations

To select the desired language in case of multilanguage

programs follow the instructions:

• Press [info] + [GREEN] and select the desired

language by using the up/down[ ] [ ] buttons

• Press [info] + [GREEN] and select desired subtitle

language by using the up/down[ ] [ ] buttons























WARNING in red

due to lack of network coverage

channels marked are temporarily not

available

channels marked are temporarily not

available

FAVOURITE TV

1C TV

hannel

Channel TV

3 Channel TV

4 Channel TV

5 Channel TV

6 Channel TV

7 Channel TV

TV LIST

[GREEN] to change list



SCAN A/V

P+

PV+

CHANNEL

456

EXIT

BACK MUTE

LIST

info

RADIO

@?!. abc

ghi jkl mno

pqrs tuv

_+ *

wxyz

def













RADIO



Installation

HAVE THE INSTALLATION DONE BY

A QUALIFIED PERSONNEL

DO NOT INSTALL IN LOCATIONS

WITH HIGH MOISTURE OR DUST

MAKE THE CORRECT CONNECTIONS

The installation and wiring of this unit

require special technical skills and expe-

riences. To ensure safety always have

the installation done by experts

Route the electrical and audio/video

cables and wiring away from moving

parts or sharp/pointed edges. This will

prevent crimping and damage to the

wiring. If wiring passes through a metal

hole, use a rubber grommet to prevent

the wires’ insulation from being cut by

the metal edge of the hole

Avoid installing the unit in locations with

high incidence of moisture or dust.

Moisture or dust that penetrates into

this unit may result in product failure

Failure to make the proper connections

may result in product damage

USE SPECIFIED ACCESSORY PARTS

ARRANGE THE WIRING CORRECTLY

USE ONLY IN CARS WITH A 12 / 24

Vcc NEGATIVE GROUND

BEFORE WIRING DISCONNECT THE

CABLE FROM THE NEGATIVE (-)

BATTERY TERMINALS

DO NOT CUT INTO ELECTRICAL

CABLES

DO NOT USE BOLTS OR NUTS IN THE

BRAKE OR STEERING SYSTEM TO

MAKE GROUND CONNECTIONS

DO NOT INSTALL IN LOCATIONS

WHICH MIGHT HINDER VEHICLE

OPERATION, SUCH AS THE

STEERING WHEEL OR GEARSHIFT

Be sure to use only the specified acces-

sory parts. Use of other than designed

accessory parts may damage this unit or

cause an incorrect functioning of the

appliance

Failure to do so may result in fire, electric

shock or other injuries

Failure to do so may result in electric

shock or injuries due to electrical shock

Never cut away cable insulation to supply

power to other equipment. Doing so will

exceed the current carrying capacity of

the wire and result in fire or electric shock

Bolts or nuts used for the brake or steer-

ing systems (or any other safety-related

system), or tanks should NEVER be used

for installations or ground connections

Doing so may obstruct forward vision or

hamper movement etc., and result in seri-

ous accident

WARNING:

Before installing the device

read carefully the following instruc-

tions

1510

Audio/Video switch Menu - DIAGNOSTICS

SCAN A/V

P+

PV+

CHANNEL

EXIT

info



LIST



DIAGNOSTICS

P NU]

Receiver provides the following diagnostics information:

• SIGNAL QUALITY

• RECEIVER INFO

• ress [ME

• Select DIAGNOSTICS by using the right and left

[ ] [ ] buttons

• ress [OK] to confirm the selection or [EXIT] to can-

cel it.

How to view the DIAGNOSTICS:

34





SCAN A/V

LIST

P+ info

The receiver enables the user to connect an external

audio/video source (e.g. Videogame console, DVD player,

etc..) to an audio/video input (as shown on page 17) using

the remote control

Using the Power button of the remote control the user

may switch from a digital TV signal to an external source

signal and viceversa.

vAudio/video Inputs



How to select audio/video input:

WARNING: FRONT monitor should be enabled only

once the handbrake control is activated.

Table des matières

Autres manuels Quantum Récepteur

Quantum

Quantum FreeWire FW7Q Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
