Quantum Composers 9530 Series Manuel utilisateur

QUANTUM COMPOSERS, INC

PO Box 4248

Bozeman, MT 59772

(406)582-0227 phone

(406)582-0237 fax

www.quantumcomposers.com

January 2008

9530 Series Pulse Generator

Operating Manual

This document was created with Win2PDF available at http://www.daneprairie.com.

The unregistered version of Win2PDF is for evaluation or non-commercial use only.

This document was created with Win2PDF available at http://www.daneprairie.com.

The unregistered version of Win2PDF is for evaluation or non-commercial use only.

This manual is a reference designed to familiarize you with the Quantum Com-

posers 9530 series pulse generator and is arranged so that you can easily find

the informationyou relooking for. Generally, each topichas its own section and

nosectionassumesthat youvereadanythingelse inthemanual.

Technical Support

For questions or comments about operating the 9530 -- our technical staff can

be reached via one of the following methods:

- Phone - (406) 582-0227

- Fax - (406) 582-0237

- Internet - www.quantumcomposers.com

Warranty

In addition to a 30-day money back guarantee, the 9530 has a one-year limited

warranty from the date of delivery. This warranty covers defects in materials and

workmanship. Quantum Composers will repair or replace any defective unit.

Contact us for information on obtaining warranty service.

Package Contents

The box you receive should contain the following:

- 9530 Pulse Generator

- AC Power Cord

- User s Manual on Disc

Contact Quantum Composers (406) 582-0227 if any parts are missing.

Safety Issues

Normal use of test equipment presents a certain amount of danger from electri-

cal shock because testing must be performed where exposed voltage is

present.

An electrical shock causing 10 milliamps of current to pass through the heart will

stop most human heartbeats. Voltage as low as 35 VDC or RMS AC should be

considered dangerous and hazardous since it can produce a lethal current under

certain conditions. Higher voltages pose an even greater threat because such

voltage can easily produce a lethal current. Your normal work habits should

include all accepted practices that will prevent contact with exposed high volt-

age, and steer current away from your heart in case of accidental contact with a

high voltage. You will significantly reduce the risk factor if you know and observe

the following safety precautions:

If possible, familiarize yourself with the equipment being tested and the

location of its high-voltage points. However, remember that high voltage may

appear at unexpected points in defective equipment.

Do not expose high voltage needlessly. Remove housing and covers only

when necessary. Turn off equipment while making test connections in high-

voltage circuits. Discharge high-voltage capacitors after shutting down power.

When testing AC powered equipment, remember that AC line voltage is

usually present on power input circuits, such as the on-off switch, fuses, power

transformer, etc.

Use an insulated floor material or a large, insulated floor mat to stand on,

and an insulated work surface on which to place equipment. Make certain such

surfaces are not damp or wet.

Usethetime-proven one hand inthepocket techniquewhilehandlingan

instrument probe. Be particularly careful to avoid contact with metal objects that

could provide a good ground return path.

Never work alone. Someone should always be nearby to render aid if

necessary. Training in CPR first aid is highly recommended.
