SW1 SERIES NOTEBOOK PC
USER’S MANUAL
JAN2006
ENGLISH
2
ENGLISH FRANÇAIS DEUTSCH ESPAÑOL ITALIANO
CONTENTS
BEFOREYOUSTART ............................................................................................. 5
Make sure you have everything..................................................................................... 5
Familiarize yourself with the computer ........................................................................ 6
OPENINGTHEDISPLAY PANEL ................................................................................ 6
FRONTOVERVIEW .................................................................................................... 7
LEFT SIDE OVERVIEW .............................................................................................. 9
RIGHT SIDE OVERVIEW.......................................................................................... 11
BACKOVERVIEW..................................................................................................... 12
BOTTOMOVERVIEW................................................................................................ 12
GETTINGSTARTED ............................................................................................. 13
Power Sources ............................................................................................................. 13
CONNECTINGTHE POWER ADAPTERS ............................................................... 13
RECHARGINGTHE BATTERY ................................................................................. 14
Starting Your Notebook................................................................................................. 15
POWER ON .............................................................................................................. 15
Status Indicators ...................................................................................................... 16
Using Function Keys ................................................................................................ 18
Using the TouchPad................................................................................................. 19
Memory Module Upgrade......................................................................................... 20
TROUBLESHOOTING........................................................................................... 21
Identifying the Problem................................................................................................. 21
APPENDIX ............................................................................................................ 22
Notebook Specifications .............................................................................................. 22
3
TAKING CARE OF YOUR NOTEBOOK PC
DO NOT place or drop objects on the computer
and DO NOT apply heavy pressure on it. DO NOT subject the computer to magnetic
fields.
To prevent possible overheating of the computer's
processor, make sure you don't block the open-
ings provided for ventilation.
DO NOT press or touch the display panel.
DO NOT place on uneven or unstable work
surfaces. DO NOT use your notebook computer under
harsh conditions.
DO NOT expose to direct sunlight. DO NOT use or store in extreme temperatures.
4
ENGLISH FRANÇAIS DEUTSCH ESPAÑOL ITALIANO
DO NOT expose to dust and/or corrosive
chemicals.
DO NOT spray water or any other cleaning fluids
directly on the display.
DO NOT slam your notebook shut and never
pick up or hold your notebook by the display.
If you are traveling with your computer, remem-
ber to carry it as hand luggage.Do not check it in
asbaggage.
DONOT place near fire or other sources of heat. DO NOT tamper with the batteries. Keep them
away from children.
Avoid sudden changes in temperature or humid-
ity by keeping it away fromA/C and heating vents. DO NOT expose the computer to rain or
moisture.
5
BEFORE YOU START
Make sure you have everything
When you receive your notebook PC, unpack it carefully, and check to make sure you have all the
items listed below. For a pre-configured model you should have the following:
• Notebook Computer
• Lithium-Ion battery
• AC adapter with power cord
• Driver and Applications CD
• Quick Start Guide or User Guide
Depending upon the configuration of your notebook, you may also need following items:
• DVD / CD-RW Combo Application CD
• Dual DVD+/-RW Application CD
Once you have checked and confirmed that your notebook system is complete, read through the
following pages to learn about all of your notebook components.
BEFORE YOU START
6
ENGLISH FRANÇAIS DEUTSCH ESPAÑOL ITALIANO
Familiarize yourself with the computer
OPENING THE DISPLAY PANEL
To open, slide the latch and then simply lift the lid up.
When closing it, be sure not to slam it shut.
BEFORE YOU START
7
Display Panel
Suspend/Resume/Power
On Button
Keyboard
Status Indicator
Lights
Memory Card
Reader
Microphone Jack
Headphone Jack
TouchPad
Pointing Device
Quick Start Buttons
Wireless LAN
FRONT OVERVIEW
The following is an overview of the front of the notebook.
Display Panel
The display panel is a color LCD panel with back lighting for the display of text and graphics.
Array Microphone
The built-in array microphone is an omni-directional audio input device. It allows for the stereo
reception and transmission of voice and/or other audio data to any program capable of accepting
such input.
Keyboard
A full-size keyboard with dedicated Windows®keys.
Stereo Speakers
The built-in dual speakers allow for stereo sound.
Microphone Jack
The microphone jack allows you to connect an external mono microphone.
Stereo Speakers
Array Microphone
BEFORE YOU START
8
ENGLISH FRANÇAIS DEUTSCH ESPAÑOL ITALIANO
Headphone Jack
The headphone jack allows you to connect headphones or external speakers and amplifiers.
Status Indicator Lights
The Status indicator lights correspond to specific operating modes. These modes are: Power On
status, Battery status, Hard Drive Activity (HDD), Memory Card Reader Activity, Wireless
LAN/Bluetooth Activity, Caps Lock, Scroll Lock, and Num Lock. Indicator lights are located
below the TouchPad and above the Keyboard.
Wireless LAN
The Wireless LAN button enables and disables Wireless LAN activity.
TouchPad Pointing Device
The TouchPad pointing device is a mouse-like cursor control with two buttons and a touch
sensitive movement pad.
Suspend/Resume/Power On Button
This button turns your notebook on and off as well as puts it to sleep. (See Suspend/Resume/
Power On Button in the Power On section for more information.)
Quick Start Buttons
The four quick start buttons allow you to launch your favorite email and Internet applications
with the press of a button. You can also engage the computer's Silent and Mute modes by press
Silence and Mute button.
Memory Card Reader
The memory card reader offers the fastest and most convenient method to transfer pictures, music
and data between your notebook and flash compatible devices such as digital cameras, MP3
players, mobile phones, and PDAs.
BEFORE YOU START
9
Port Replicator Interface
External Monitor Port/ DVI Port LAN (RJ-45) Port
Kensington
Lock Slot
Modem (RJ-11) Port
USB Port
LEFT SIDE OVERVIEW
The following is a brief description of the left side of the notebook.
Depending on your configuration:
External Monitor Port
The external monitor port allows you to connect an external monitor.
Or
DVI Port
The DVI port allows you to connect an external monitor or television to the computer using
aDigital Video Interface cable.
Port Replicator Interface
The Port Replicator Interface allows you to connect additional peripheral devices to your com-
puter through a "universal" port, as it were. The Port Replicator itself contains all the necessary
additional ports, and connects to your computer through a single port on the left side of the
computer. (Not available in all configurations.)
LAN (RJ-45) Port
The LAN port is designed to support a 10/100 or 10/100/1000(option) Base-TX standard RJ-45
plug.
USB Port
The USB port allows you to connect Universal Serial Bus devices. It supports v2.0 of the USB
standard, which allows data exchange rates as high as 480 Mb/s.
BEFORE YOU START
10
ENGLISH FRANÇAIS DEUTSCH ESPAÑOL ITALIANO
Modem (RJ-11) Port
The modem (RJ-11) port is used to attach a telephone line to the internal 56K modem.
Kensington Lock Slot
The Kensington lock slot allows you to secure your notebook to an immovable object through an
optional security cable.
