Qualicam QC-MA105DV10 Manuel utilisateur
AHD HD Camera
（OSD、Day/Night Optional）
USER’S MANUAL
Apply to：Box Camera IR Waterproof Camera Dome Camera
Thank you for purchasing our products, please
read the manual carefully before operating
Version：YX-ZXIMX23814V01 54#
Safety Precaution
This symbol means that there might exist uninsulated dangerous
voltage inside the case, be careful of electric shock.
This symbol reminds you to pay attention to important operation and
maintenance instructions in the accompanied information.
Warning
In order to prevent damage caused by fire or electric shock, please do not
put cameras exposed in the moist environment or rainwater.
Please make sure the adapter is consistent with product specifications,
otherwise it might cause fire, electric shock or damage.
Pay attention to polarity of the adapter, it might cause some accidents like
fires.
Please don’t connect multiple cameras with the same adapter at the same
time ,overloading of adapter capacity may cause fires.
Power supply must be firmly fixed so as not to loose to cause fires.
If the device gets abnormal smell or smoke”, please stop it immediately
and contact with our customer service center.
Please contact our local distributor or our maintenance office authorized
by our company, otherwise we won’t promise warranty.
Please do not splash water on the product components when cleaning.
Notes
Do not make the products under great impact or stay away from strong
electromagnetic interference and vibration.
There are some sophisticated parts inside the camera, therefore, during
transportation and installation, please avoid the damage cause by stress or severe
vibration. For the sake of safety, please do not switch on power before
accomplishing all installation.
Please comply with all electrical safety standards during operation,
camera or signal transmission cable should maintain a sufficient distance (50
meters) with high-voltage equipment or cables, if necessary, lighting and thunder
protective measures must be taken.
Please install the camera in well-ventilated environment.
Please do not make the camera face sunshine or other strong light directly
in case of any damage to the lens and the sensor.
The temperature and humidity range for cameras work are -10 ~ 50 , ℃
less than 95% separately, please do not start cameras beyond this range.
To avoid lightning strikes, please make sure the installation of power
supply ground line in a good condition.
To prevent the equipment from damage by shower or splash of water,
please do not place the device substances such as liquid.
Contents
I Features..............................................................................................................5
II Interface.. .........................................................................................................7
2.1 Interface............................................................................................7
III OSD.................................................................................... ............................8
3.1 Lens mode...........................................................................................8
3.2 Exposure..............................................................................................8
3.3 Backlight...........................................................................................10
3.4 White BAL........................................................................................11
3.5 Day/Night..........................................................................................12
3.6 DNR..................................................................................................15
3.7 Special...............................................................................................15
3.8 Adjust................................................................................................20
3.9 Exit....................................................................................................21
IV Specification........................ ........................................................................23
V FAQ........................................................... ....................................................25
Page5of25
I、Features
This products use SONY progressive CMOS image sensor, with Nextchip
NVP2431H DSP, 720P, high definition, natural and smooth image quality. With
standard AHD connector, no compression, no delay; with ICR filter to get Day
and Night vision; OSD menu and RS-485 are optional; Camera is wildly used in
places like Financial Places, Telecom, Supermarket, Hotel, Government, School,
Airport, Factory, Police, Judicature places which demand high definition image
quality.
1、New generation AHD 720P program
SONY progressive Exmor CMOS image sensor, with Nextchip NVP2431H
DSP, 720P, high definition, with standard AHD connector.
2、High-definition resolution
（ ）Maximum color resolution output: 1280 H x720(V).
3、Day/Night
D/N cameras work just like color cameras during the day and switch to a
black and white mode at night, using a removable IR cut filter.
4、WDR
WDR could resolve the image problem when there's dramatic light
difference between outdoor and indoor areas so that all the details both in the
light zone and dark zone could be seen clearly.
5、3D DNR Digital noise reduction technology
Digital Noise Reduction Technology enhances the ability to handle with
signal noise ratio, this technology allows camera to receive more clear and vivid
images even under low-light conditions.
6、BLC
BLC function can adjust the surroundings with too weak and strong
brightness, to get the clear optimization picture.
7、MD
Motion detection function can trigger alarm or recording when sensing
moving objects, users can set the sensitivity and multiple detection zones.
8、PRIVACY
The Privacy Mask can block out sensitive areas from view, covering the areas
with a solid block of color, you can adjust the mask position and size.
9、RS-485
All the OSD Menu can be set through RS-485.
10、Smart IR
Page6of25
When getting a picture of nearby object, the reflected IR light is too strong
to cause the exposure. However, Smart IR Control could sense the IR light and
intelligently control it in order to eliminate the exposure and get a perfect
image.
11、OSD
On Screen Display Menu.
Page7of25
II Interface Function Introduction
2.1 Interface Function Description
ENTER Use this button to display the main menu, to
confirm and to enter the submenus when they
are available.
UP/DOWN Use this button to move the cursor
upwards/downwards to the desired item
1
LEFT/RIGHT Use this button to move the cursor to the
left/right to select or to adjust the parameters
of the selected item.
2
VIDEO
TEST/VIDEO OUT
No function
3
LED LEVEL For the customer to customize the IR
brightness
Page8of25
III OSD
Press the "Enter" button; the camera will pop up the main menu（as shown
in picture 1）:
3.1 Lens mode
2 different modes of LNES, DC and Manual, users can choose the mode
according to the using lens.
3.1.1 Manual lens
When using fixed iris or manual iris lens, please choose Manual mode.
3.1.2 DC lens
When using Auto Iris Lens, please choose DC mode.
3.2 Exposure
Move the cursor to the main menu "EXPOSURE", press the " Enter "
button to enter the sub-menu.
Page9of25
(1) >Shutter Speed
Select to set the camera shutter speed. The shutter speed can be fast or
slow, the value is AUTO,1/25~1/10000，2X~30X, users can select the shutter
speed value according to the condition. When using Auto Iris Lens, the shutter
speed default is “1/25”; When using Manual Iris Lens, the shutter speed default
is “AUTO”.
(Suggest X2-X4. if the circumstance with high brightness or the object
moving quickly, the shutter speed value can be lower, suggest 1/250).
(2) > AGC Control
AGC: 1~15 adjustable, this function can enhance the camera image
brightness, also can enhance the camera image noise, can be adjusted by the
user according to the real condition.
(3) >SENS-UP
SENS-UP can enhance the brightness of night vision, “OFF/AUTO”
adjustable, the value of SENS-UP cannot too big, or the image will be leaving
streaks at night.
(4) >Brightness
Select to set the camera image brightness, 1-100 adjustable. Users can set
the brightness according to the condition. The default value is 48.
(5) >DWDR
DWDR is digital wide dynamic range, or software DWDR function, when
there is difference between weak and strong light in the surroundings, the strong
part will overexposure and the image is white; meanwhile, the weak part will be
dark due to the effect of strong light. Turn on DWDR, it can fix this situation.
DWDR will reduce the exposure of strong part, and enhance the exposure of
weak part; therefore, it can get a clear whole picture.
The DWDR with “Auto/off”, in the “Auto” mode, 0-8 is optional, users
Page10of25
can select to set the value DWDR according to the light in the surroundings, to
get the best picture.
(6) >Through-frog function.
“Through-frog function” means when camera works outdoor with bad fog
and low visibility. It improves image definition to improve visibility through the
adjustment of camera internal software.
“Through-frog function” has two select--Auto/ Off. When it is AUTO, you
can set area, size and level. Users can set to reach best result according to the
actual situation.
(7) >Return
After finished setting, press ‘up’ ‘down’ key to move cursor to ‘Return’,
then use ‘Left’ and ‘Right’ key to select ‘Return’ (Means return to previous
menu). Or ‘Save& Exit’ (Means exit menu setting), then press ‘Enter’ to
perform the function of return.
3.3 Back light Compensation
(1) >BLC
Press ‘Left’ ‘Right’ at ‘Back Light’ mode menu to select ‘BLC’ and press
‘Enter’ into ‘BLC’ submenu.
(a) >Level. Set the level of BLC. High, middle, low for choose.
(b) >Area. Set the area, size etc.
(c) >Default. Press ‘Enter’, BLC related setting restore factory settings.
(d) >Return
After finished setting, press ‘up’ ‘down’ key to move cursor to ‘Return’,
then use ‘Left’ and ‘Right’ key to select ‘Return’ (Means return to previous
menu). Or ‘Save& Exit’ (Means exit menu setting), then press ‘Enter’ to
perform the function of return.
