Qomo QPC30M Manuel utilisateur

PRECAUTIONS

Please follow these precautions:

To prevent fire or sh ock hazard, do n ot expose the unit to rain or

moisture.

To prevent electrical shock, do no t open the unit. Refer to qualified

personnel for service only.

Do not use the unit continuously for more than 24 hours with camera

auto focus on. It may cause damage to the camera lens.

Be careful not to spill water or other liquid s onto the unit, or allow

combustible or metallic objects to get inside the base.

Unplug the visualiser from the wall outlet when it is not being

used for a long period of time.

Clean the unit with a sof t cloth lightly moistened w ith a mild

detergent solution.

Clean the lens carefully with an a ir spray or soft dry cloth to avoid

scratching it.

Rotate the camera lens cap before power the unit on.

Contents

Product Introduction..................................................3

Parts Identification .....................................................3

Making Adjustments...................................................4

Control Panel ..............................................................7

Remote Control Instruction.......................................8

Installing Visualizer Software....................................9

USB Port....................................................................10

USB Image Capture..................................................10

Specification .............................................................12

Product Introduction

Thank you for purchasing the visualiser. This visualiser comes with a new

design which is more sim ple, flexible, portable and with a high resolution.

The visualiser can be used to pr esent 3D o bjects, texts, graphs,

transparencies and nega tive films. It can be connected to projector , PC

and other multi-media equipments. The visualiser is not just a equipment

in corporate environment but also a indispensable tool to academic,

medical and scientific community.

Parts Identification

Making Adjustments

On the visualiser, there are six places can be adjusted.

1. Adjust Mechanical Arm

This adjustment can in crease and decrease image. Hold the visualiser

base with o ne hand, carry the mechanical arm with another hand an d

adjust it up and down. The mechanical arm can be moved from almost any

angle.

2. Adjust LED light

The LED light can be rotated 90 degrees. (as blow illustration)

3. Adjust Camera Box

Hole the camera bo x and rotate it up and dow n. The camera box can b e

rotated 45 degrees. (as blow illustration)

Hold the camera bo x and rotate it left and right. The camera box can b e

rotated 90 degrees. (as blow illustration)

4. Adjust Camera Head

Hold the c amera connector with one h and, rotate the camera b ox

connector with another hand. The camera head can be rotated 90 degrees.

(as blow illustration)

5. Adjust Base Bracket

Hole the vislualizer base with one hand, rotate the base bracket with

another hand. The base bracket can be rot ated 45 de grees. (as blow

illustration)

Notice: Do not rotate the parts emphatically when the rotation

reached maximum.

Control Panel

There are four touch buttons located on the top of visualiser base:

T : Enlarge image

: Reduce image

·Light：Turn the LED light on/of f. Press and hol d for three seconds to

delete all the stored files under recall status..

·Power/Input: Turn the visualiser on/off and switch input source between

CAM and PC

·Pilot Light: In standby mode the co lor of the light will be red ,in CAM

input mode will be green and in PC input mode will be orange.

Remote Control Instruction

POWER (Control the visualiser On/Off)

LAMP (Control the arm lights. Press and hold for three seconds to delete

all the stored files under recall status)

FREEZE (Freeze the image)

NEG (Display film negatives)

MIRROR (V-Reverse the image)

SPLIT (Image Split function)

ROTATE (Rotate the image)

XGA (Switch among XGA , SXGA , 720P and WXGA)

B&W (Switch between Color mode and Black & White mode)

TITLE (Freeze the top 1/8 of the screen)

TEXT (Switch between image/text mode. Delete the selected file under

recall status)

VOL+/- (Increase or decrease the volume)(Option)

TELE/WIDE (Increase and decrease magnification)

FAR/NEAR (Focus near or far)

AUTO (To auto adjust brightness, auto white balance and auto focus)

CAM/PC (CAM or PC signal output selection)

(Captured Videos and save in SD Card)

(Captured images and save in SD Card or Flash Rom)

(Play the captured Videos or pause)

(Stop captured Videos or play)

RECALL (Multiple Screen Display)

EXIT (Exit recall)

BRIGHT+/- (Increase or decrease the brightness)

Installing Visualizer Software

This function is to snap and display images with the USB inter face, which

includes displaying static and dynamic pictures, snapping dynamic images

and playback the dynamic images with the Windows Media Player o r its

own player.

Insert the CD-ROM that c omes with the visualiser into the CD-ROM

drive.

A. Click the Capture Program file to install the program that ca ptures

images in the AVI or JPG format.

B. Shut down your computer when pr ompted in order for the changes to

take effect.

C. Use the USB2.0 cable provided to connect you r computer to the

visualiser before your computer is restarted.

USB Port

The USB port can be used to store still images from the visualiser in a

computer. Connect the visualiser to y our computer with the supplied USB

cable. The visualiser software is available on the supplied CD-ROM.

* Please pay attention to the following:

1. Computer hardware requirement: CPU: 2.4GHz, RAM: 256M or above,

Graphic card 64M, USB 2.0 port, H ard disk 40 G or more, Monitor

display resolution higher than XGA (1024*768).

2. Operating system: Windows XP SP2 (Service Pack 2).

3. Must use a high-speed USB 2.0 cable provided

4. When connecting the visualiser to a desktop computer with the

high-speed USB 2.0 cable pro vided, we recommend using the USB

port located on the rear of the mainframe. The USB port on the front

of the computer might have interference.

USB Image Capture

You can capture and co ntrol images on the visualiser from a computer

connected with a USB connector.
