QFX TURN-200 Manuel utilisateur
RETRO HIFI SYSTEM
Model: TURN-200
FCC ID: 2ABM9T9
- USER MANUAL -
1
SAFETY PRECAUTIONS
* This product is designed for use in moderate climates. Do not
use or install this unit where it would be exposed to direct
sunlight or in extremely hot temperatures, or near a radiator,
stove or appliance that produces heat.
* Do not take this unit into the bathroom, or near a swimming pool.
Do not use it where it would expose to water, moisture,
dripping or splashing.
* Do not put the objects filled with liquids, such as vases, on the
product.
* Do not place the naked flame sources, such as candles, on the
product.
* If water gets inside the unit. Unplug the power adapter from the
supply socket and consult your dealer.
* Do not handle the power adapter with wet hands. To avoid
electric shock, NEVER touch any internal parts.
Repairs/Servicing should be left to a qualified service person.
* When connecting or disconnecting from the mains supply, hold
the plug, not the cord. Pulling the cord may damage it and could
be dangerous.
* Do not drop the unit. Do not spill liquid into it or allow objects to
fall in it.
* If the unit fails to operate, disconnect from the mains and
consult a qualified service person.
* When plugged in, a very small current will flow. To save
electricity and for safety when not using the unit for an extended
period of time, it is recommended that the product is completely
disconnected at the AC mains socket.
* Do not bend the cord sharply, pull or twist it.
* Do not modify the power adapter in any manner.
* Do not insert any metallic object into the unit.
* In case of malfunction due to electrostatic discharge just reset
2
the product (reconnect of power source may be required) to
resume normal operation.
We certify that the power supply is used as a device for
disconnecting the power distribution network, which
should stay easily accessible.
CAUTION: To reduce the risk of electric shock. Do not remove
the cover (or back). No User-serviceable parts inside. Refer all
servicing to qualified service personnel.
The lighting bolt with an arrowhead within a triangle indicates
the presence of non-insulated dangerous voltage within the
product enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within a triangle indicates the
presence of important operating and maintenance (servicing)
instructions in the literature accompanying the unit.
POSITIONING THE UNIT
* A minimum distance of 6 INCHES must be maintained to
provide sufficient ventilation.
* Allow adequate ventilation for the unit. Ventilation should not be
impeded by covering the ventilation openings with items such
as newspapers, table cloths, curtains etc. Do not stand it on a
thick pile carpet, or install it in a place with poor air flow.
* Place the unit on a flat even surface.
* Do not use the unit in excessively hot, cold, dusty, damp or
humid place.
* Condensation may form inside the CD player if the unit is left
3
anywhere warm and damp, or if you move the unit from
somewhere cold (e.g. Your car boot) to a warm room. In this
case, let the unit stand for 1-2 hours, or gradually increase the
room temperature so the unit is dry before you use it.
* Do not place it where it could be subject to vibration.
* When this unit is used near a TV, the TV picture could be
distorted. If this happens, move the unit away from the TV. If
this does not correct the situation, avoid using the unit when the
TV is turned on.
* Keep the CD door closed so the lens is not contaminated by
dust. Do not touch the lens.
SAFETY MECHANISM
This unit incorporates a safety interlock mechanism which
switches the laser beam on and off, so that when the disc holder
is open, the laser beam stops automatically.
This set employs an optical laser beam system in the CD mechanism
designed with built-in safeguards. Do not attempt to disassemble.
Exposure to this invisible laser light beam may be harmful a human eye.
This is a Class 1 laser product. Use of controls, adjustments or
procedures other than those specified here in may result in hazardous
laser light beam exposure. This compact disc player should not be
adjusted or repaired by anyone except qualified service personnel. The
laser mechanism in the set corresponds to the stylus (needle) of a record
player. Although this product uses a laser pick-up lens, it is completely
safe when operated according to directions.
4
LOCATION OF CONTROLS
5
FRONT VIEW
1. Power ON/OFF 7. Repeat
2. Play/Pause/Scan 8. EQ
3. Stop 9. AM/FM
4. Prev 10. Open/Close
5. Next 11. Function Knob (CD/PH/FM/AUX/BT)
6. LED Display 12. CD gate
13. Vol-/+
REAR VIEW
14. RCA output
15. AUX input
16. FM/AM Antenna
17. DC input
TOP VIEW
18. 45 RPM Adapter
19. Control Perch
20. Tone Arm
21. Speed Control Switch (33-1/3, 45, 78)
22. Tone Arm Lock
23. Platter
24. Stylus
TOP VIEW
18. 45 RPM Adapter
RIGHT SIDE
25. USB Interface to connect U-disk only
23. Platter
6
PREPARATION FOR USE
Carefully unpack the Main unit from its carton; you should have
the following items:
Packing included
zMain Unit.
z2pcs Speakers
zUser Manuel
z5V 2A adapter
zRCA cable
If any of these items are missing, consult your dealer. Keep any
packaging in case you want to transport the main unit at some
later date.
Connections
* Connect the 2 speakers with the main unit
* Connect the DC Power adapter to the DC outlet.
* Unwind the FM antenna.
Adjusting the sound
To adjust the sound, rotating the Volume Knob located on the
right side of your system in any mode.
USING THE CD/MP3 PLAYER
Loading CDs
-Press POWER button to turn on the unit. Set the Function
Knob to the CD position.
- Press the OPEN/CLOSE button to open the CD gate. Do not
force open the CD gate by hand at any time.
- Place the CD in the compartment with the label side facing
upwards.
- Press OPEN/CLOSE to Close the CD gate
7
Notes :
* Do not put anything other than a CD in the compartment. Other
objects can damage the mechanism.
* Do not force open/close the CD gate by hand at any time.
* Keep the CD gate closed when not in use to prevent dirt and
dust from getting into the mechanism.
* Never insert more than one CD at a time.
* If a disc is deeply scratched or too dirty, it may not play.
Playing CDs
Press PLAY/PAUSE button to play/pause, when pause, LED
screen will indicate II.
- Press STOP Button,it will stop playing.
- To resume play, press the PLAY/PAUSE Button again.
- Press the PREV or NEXT Button to enter into last/next songs.
USING THE TURNTABLE
- Press POWER button to turn on the unit. Set the Function
Knob to the PH (phonograph)
position.
-Place a record on the turntable,
over the central spindle.
-Set the speed selector to 33, 45,
78rpm according to the record
which will be played.
-Remove the stylus guard and push the lift lever upward to raise
the tone arm from the arm park, and then move the cartridge
holder over the record gently, now the platter will run
8
automatically .Then put down the lever, the tone arm would drop
and touch record surface gently. Now users can enjoy their
favorite songs.
-Push the arm lift lever up to raise the arm, now platter will still
running but play will pause. To continue the play, user just need
to put down the lever.
How to replace the stylus
To replace the needle, please refer to the instructions below.
Removing the needle form the cartridge
a. Place a screwdriver at the tip of the needle heads hell and
push downwards in the direction shown in sketch “A”
b. Remove the needle head shell by pulling it forwards and
pushing downwards.
Inserting the needle
c. Hold the tip of the needle head shell and insert it by pressing in
the direction illustrated by “B”
d. Push the needle head shell upwards in the direction illustrated
by “C” until the needle locks into the tip position.
9
Note:
zDo not stop or turn the platter manually.
zMoving or jarring the turntable without securing the tone arm
clamp could result in damage to the tone arm
zReplace the protective cap on the stylus when not in use.
USING THE FM/AM RADIO
- Press POWER button to turn on the unit. Set the Function
Knob to the FM position.
- Long press SCAN button, it will search the FM channels and save
the stations automatically.
- Press PREV or NEXT button, you can choose the last or next FM
station.
If you wanted to use AM radio, under the FM status, please press
FM/AM button to switch to AM status.
- Long press SCAN button, it will search the AM channels and save
the stations automatically.
- Press PREV or NEXT button, you can choose the last or next AM
station.
Antenna
- For best FM/AM reception, please extend the wire antenna located
at the back of the unit, and hang it to a high position.
- Move it around until you get the best FM/AM reception.
