Retiga-SRV User’s Manual
Applicability
This document applies to the Retiga-SRV camera. For the latest updates, please visit
WWW.QIMAGING.COM.
Notice of Copyright
Copyright©1999-2005 Quantitative Imaging Corporation. All rights reserved. Unauthorized
duplication of this document is prohibited.
Trademarks and Proprietary Names
QImaging, Retiga, QICAM, iGlo and QCapture are trademarks of QImaging. Product names
mentioned in this document may be trademarks or registered trademarks of QImaging or other
hardware, software, or service providers and are used herein for identification purposes only.
Microsoft™and Windows®are registered trademarks in the U.S. and other countries of Microsoft
Corporation and are used herein for identification purposes only. Apple™and Macintosh®are
registered in the U.S. and other countries by Apple Computer, Inc. and are used herein for
identification purposes only.
QImaging Corporation Address Information
4190 Still Creek Drive,
Suite 110, Willingdon Business Park
Burnaby, BC, Canada V5C 6G9
604.708.5061
WWW.QIMAGING.COM
QImaging Technical Support
Technical support is available to all registered users of QImaging products from 9am to 5pm Pacific
Standard Time.
SUPPORT@QIMAGING.COM
604.708.3068
WWW.QIMAGING.COM/SUPPORT/CONTACT/
ii
CONTENTS
Retiga-SRV User’s Manual ............................................................................................... i
INTRODUCTION ............................................................................................................. 1
Power Requirements ................................................................................................... 1
Host Requirements ...................................................................................................... 1
IEEE 1394 (FireWire) Interface ................................................................................. 2
Cables .......................................................................................................................... 2
Imaging Software for Your Camera ........................................................................... 2
INSTALLATION .............................................................................................................. 4
Step 1. Install the 1394 PCI card (Windows Users Only) .......................................... 4
Step 2. Install Your Imaging Software ....................................................................... 5
Step 3. Connect the Retiga-SRV ................................................................................. 5
CAMERA BASICS ........................................................................................................... 7
Turning the Camera On and Off ................................................................................. 7
Connecting the Retiga-SRV to your Optics ................................................................ 7
Understanding the LED Indicators ............................................................................. 8
Capturing Images with the Retiga-SRV ..................................................................... 8
ADVANCED CAMERA CONTROLS ............................................................................. 9
Cooling Capability ...................................................................................................... 9
iGlo (OLED) ............................................................................................................... 9
Triggering the Retiga-SRV Extenally ......................................................................... 11
Gain and Offset Controls ............................................................................................ 13
CARING FOR YOUR CAMERA ..................................................................................... 14
TROUBLESHOOTING ..................................................................................................... 15
Resolving Problems with the camera .......................................................................... 15
Unresolved Problems - Contacting QImaging Support .............................................. 16
GLOSSARY ...................................................................................................................... 17
APPENDICES ................................................................................................................... 19
APPENDIX A: External Trigger Port ........................................................................ 19
1
CHAPTER 1
INTRODUCTION
TheQImagingRetiga-SRVCCDdigitalcamerahasbeenspeciallyengineeredforlow-light,high-speed,
high-sensitivity applications. A three-stage Peltier device and an all-metal, hermetic-vacuum-sealed
CCD chamber provides state-of-the-art cooling to -30ªC; the camera’s software-selectable, regulated
cooling enables precise control in single-degree increments. The Retiga-SRV features a 1.4-megapixel
CCD, 12-bit digital output, and an IEEE 1394 interface for enhanced connectivity and noise-shielding
performance. Additionally, the camera comes with iGlo Technology, which features an Organic Light
Emitting Diode (OLED) display that provides users with key information about camera settings in a
convenient, ergonomic way.
Power Requirements
The Retiga-SRV can be powered through a single IEEE 1394 FireWire 6-pin to 9-pin cable when the
cooling is off. When the cooling is on, the Retiga-SRV must be connected to the included external
power supply.
•Power Supply Specifications:
Input Power: 30Watts, 12-24VDC
Host Requirements
For Windows PCs:
•Pentium®CPU, running at 300MHz.
•256 MB RAM (512MB RAM preferred).
•Video card with 8 MB video memory capable of 32-bit color output.
•Windows 2000, or Windows XP Professional.
•If the PC is not equipped with a FireWire card, the included card must be installed.
2
For Mac OS Computers:
•PowerPC-based Macintosh with an OHCI compliant IEEE 1394 port (G4, G5 and iMac®
models).
•iMac models may not provide enough power to cooled cameras. QImaging’s IEEE 1394
HUB may be required to power the camera. Contact QImaging for ordering information.
•Mac OS X 10.2.x and higher
•256 MB+ RAM
•All the G4, G5 andiMac models are equipped with aFireWire card. The included IEEE 1394
PCI is not required for Mac OS computers.
IEEE 1394 (FireWire) Interface
The Retiga-SRV can be powered and controlled through an IEEE 1394 (FireWire) digital interface. To
realise the full bemefits of the Retiga-SRV, a single FireWire connection from the camera to the
computercombinedwiththeexternalpowerconnectionwillallowfullcontrolofthecameraandrapid
image data transfer from the camera to the computer.
Cables
A 4.5 meter FireWire interface cable is included with the camera. One end of this cable connects to
either of the available FireWire ports at the back of the camera (9-pin connection); the other end of
the cable plugs into your computer’s 6-pin FireWire port.
Some computers have 4-pin FireWire ports. These ports may be used if they are OHCI compliant, but
you will need to purchase a 4-pin to 9-pin FireWire cable from your local computer store or a 4-pin
to6-pinadapter fromQImaging. When connectingthe Retiga-SRVtoany FireWireport, youwill need
to use an external power supply.
What is the difference between 4-pin, 6-pin and 9-pin FireWire ports?
FireWire cables are available in three varieties: 4-pin, 6-pin and 9-pin. 9-pin and 6-pin FireWire cables
are capable of providing both power and a communication interface between the camera and
computer while 4-pin cables provide only a communication interface. Some laptop computers have
6-pin FireWire jacks that do not provide power. If your computer has such a port, you will have to
power your Retiga-SRV by attaching the included external power supply to the system.
Imaging Software for Your Camera
Industry Standard Imaging Applications
The Retiga-SRV works with industry-standard Windows and Mac OS imaging software. Please go to
the following URL for an up to date listing of third party software companies that support QImaging
cameras. HTTP://WWW.QIMAGING.COM/PARTNERS/
3
QCapture Suite Software
The Retiga-SRV operates on both Windows and Mac OS based systems. QCapture Suite Software for
both systems is available at WWW.QIMAGING.COM. The easy-to-use QCapture software gives you
complete control over the camera’s settings and image capture functions. QCapture Suite also
includes a TWAIN-compliant interface that allows many Windows image-editing applications to
acquire images using QImaging cameras.
4
CHAPTER 2
INSTALLATION
Step 1. Install the 1394 PCI card (Windows Users Only)
This step is for Windows PC users only. If you are installing the Retiga-SRV on a Mac OS computer,
please skip to Step 2.
Check your computer for an existing FireWire port:
The Retiga-SRV connects to your WindowsPC via a FireWire port. If you already have a FireWire port,
you do not have to install the IEEE 1394 PCI card. Check the connectors at the back of your PC for a
port that matches the FireWire port of the connection shown in Figure 1.
Figure 1 — 9-pin to 6-pin FireWire (IEEE 1394) Port connection
Ifyour PCdoesnot havea functioningFireWireport,youmustinstall theIEEE1394PCIcardthat came
with your camera.
IMPORTANT: Follow these steps in order to complete the installation.
DO NOT CONNECT the camera until the camera driver is installed.
1. Windows PC users only: Install the IEEE 1394 PCI card - only if necessary.
2. Imaging Software - Install the software and drivers that your new QImaging
camera needs to capture images.
3. Retiga-SRV - Connect the camera to your computer using the included IEEE 1394 cable.
DO NOT CONNECT the camera until you have a functioning FireWire port in
your computer and the camera driver is installed.
Camera Computer
5
If necessary, install the included IEEE 1394 PCI card:
•Shut down your computer.
•Openthe case,andinstall theincluded IEEE1394cardinto anempty PCIslot.See theuser’s
manual for your computer for complete instructions on installing new PCI cards.
•Restart your computer. Windows should automatically install the appropriate software
drivers for the card.
Step 2. Install Your Imaging Software
Once the IEEE 1394 card is installed in your computer, you are ready to install the FireWire drivers and
imaging software. See your Imaging Software User’s Guide for complete installation instructions.
Step 3. Connect the Retiga-SRV
Once your imaging software is installed, connect your camera. There are three different types of
connections (1) through Windows or Macintosh 6-pin PCI card, (2) through windows or Macintosh
laptop computer or (2) through Macintosh 9-pin connection. For the Retiga-SRV, in order to operate
the cooling, the camera must have the external power connected. However, should the cooling not
be required, a single 9-pin to 6-pin connection will operate the camera sufficiently.
In most cases, the FireWire cable provides the necessary power required by the Retiga-SRV. However,
if your camera is cooled you will need to provide additional power to the camera as shown in Figure 4
Connecting the QImaging Camera
Perform the following for connecting your camera.
•Remove the FireWire cable from the camera box, and plug one end of the cable (the 9-pin
end) into one of the camera’s FireWire sockets (either socket is fine).
Figure 2 — Camera FireWire Sockets.
•Plug the other end of the cable into a FireWire port on your computer
FIREWIRE PORTS
6
Figure 3 — Desktop Computer FireWire Connection
•In order to obtain the cooling specification of the camera, the supplied external power
adapter needs to be connected to the camera as shown in Figure 4 below.
Figure 4 — FireWire and External Power Supply Connection
•If you have a laptop computer, you can use the built in FireWire port or a PCMCIA card.
However, should you connect to a latpop computer you will still be required to connect the
supplied external power supply to the camera in order to power it (see Figure 4). Optional
powering of the PCMCIA card will not be required in this configuration
Camera Computer
Camera
Computer
110/240 VAC
power supply
7
CHAPTER 3
CAMERA BASICS
The Retiga-SRV’s image capture capabilities are controlled entirely by your imaging software. This
chapter provides basic instructions for working with the camera itself.
Turning the Camera On and Off
To turn the Retiga-SRV on, press the power switch. The Retiga-SRV lights will flash and the white
power light will remain on, provided that you have the appropriate configuration of “Step 3” in the
“Introduction” section. Refer to this step for all system configurations ensuring that the FireWire
cable(s) are connected as specified. If power is supplied, the WHITE LED will turn on.
To turn the Retiga-SRV off, press the power switch again. This will turn your camera off. The WHITE
LED will turn off.
Figure 5 — Power Switch on the Retiga-SRV
Connecting the Retiga-SRV to your Optics
The Retiga-SRV connects directly to widely available C-mount optics, which are standard on most
microscopes and lenses.
To attach the camera to a microscope:
Carefully thread the camera onto the microscope’s C-mount adapter, rotating the camera until it is
mounted securely. Use the microscope controls to adjust focus.
To attach a C-mount lens to the camera:
Carefully thread the C-mount lens onto the camera’s lens ring, rotating the lens in a clockwise
direction until it is mounted securely. Use the lens controls to adjust focus.
POWER SIWTCH
