Vista, CA 92081
www.pythoncarsecurity.com
Directed is committed to delivering world class
quality products and services that excite and
delight our customers.
OWNER’S GUIDE
©2014 Directed. All rights reserved.
The company behind Python®Auto Security
Systems is Directed.
Since its inception, Directed has had one purpose, to
provide consumers with the finest vehicle security and
accessories available. The recipient of nearly 100 pat-
ents and Innovations Awards in the field of advanced
electronic technology.
Quality Directed products are sold and serviced
throughout North America and around the world.
Call (800) 876-0800 for more information about our
products and services.
SECURITY FOR THE BEST®
QRG4810PML 2014 07
MODEL
4810P
4610P
Congratulations
Congratulations on the purchase of your state-of-the-art remote start
and keyless entry system. Reading this Owner’s Guide prior to using
your system will help maximize the use of your system and its many
features. For any additional questions please contact your authorized
Directed dealer or contact Directed at 1-800-753-0600. (U.S. only)
Additional Guide Information
Only basic commands, features and essential information are covered
in this compact guide. Your product has many advanced features
which are not discussed here, please consult the expanded online ver-
sion for these on the website listed on the back cover. Most sections in
this guide also contain additional information which can be found in
the expanded online version.
Important information
Government Regulations and Safety information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an autho-
rized Directed dealer.
Replacement remote controls
Please see your authorized dealer or visit us at www.directedstore.
com to order additional remote controls. Remote control part numbers
are found on the back of the device.
2-way communication
Throughout this guide, there are references to 2-way communication
and/or confirmation of commands via the 2-way remote control.
Please note that your system may not be equipped with a 2-way
remote control so such feedback will not apply. For example, under
“Lock” in the “Basic Commands (Direct Access)” section, the guide
states: “..... Lock LED turns on with 1 beep.” Such references only
apply to systems with a 2-way remote control. If you would like to
upgrade to a 2-way remote control, please consult your authorized
dealer. Additional parts and labor may apply.
Contents
Remote Control Information.................................................................................. 2
Control Center .................................................................................................... 2
Using your System............................................................................................... 3
Commanding the system....................................................................... 3
Performing Commands ......................................................................... 3
Remote Control Command table ............................................................ 4
Fault Condition alerts ........................................................................... 4
Basic Commands (Direct Access) .......................................................................... 5
Lock ................................................................................................... 5
Unlock................................................................................................ 5
Remote Start........................................................................................ 5
AUX/Trunk.......................................................................................... 6
Remote Control Configuration .............................................................................. 6
Battery Information.............................................................................................. 7
Battery Disposal .................................................................................. 7
Patent Information ............................................................................................... 7
Government Regulations ...................................................................................... 8
Warning! Safety First......................................................................................... 10
Installation ........................................................................................ 10
Remote Start Capable ........................................................................ 10
Manual Transmission Vehicles ............................................................. 10
Interference....................................................................................... 12
Upgrades ......................................................................................... 12
Water/Heat Resistance ...................................................................... 12
Limited lifetime consumer warranty ..................................................................... 13
2© 2014 Directed. All rights reserved.
Remote Control Information
Feature Description
Internal Antenna Used for transmitting and receiving*information
Command buttons (4)
A U X
A U X
A U X
AUX
Used to perform locking, unlocking, auxiliary channel and
remote start commands
Function button
A U X
Used to access function levels for commands, configura-
tion menus for programming, Car Selection, and to request
reports.
Confirmation LED’s ** Each button has an associated LED next to it that is active
during related operations. These LED’s are labeled respec-
tively as: Lock LED, Unlock LED, Remote Start LED, and Aux
LED
* 2-way communication is only applicable to the Responder LE
remote control.
** Only applicable to the Responder LE remote control.
Control Center
The Control Center, typically located on the upper part of the front
windshield. It consists of:
• The In-vehicle system antenna.
• The Status LED, as a visual indicator of the system’s status.
• The Control button, for placing the system into Valet Mode* and
to perform the Emergency Override operation.
* See online guide.
3
© 2014 Directed. All rights reserved.
Using your System
Commanding the system
Commands, Basic or Advanced, are used to activate system features
and are performed by pressing one of the Command buttons. Basic
commands control the most often used keyless entry and remote start
features while Advanced commands control more specialized fea-
tures.
Confirmations for Basic or Advanced commands are indicated
by horn honks* and parking light flashes. A description of each fea-
ture confirmation is found in the following Basic command and Ad-
vanced command sections.
Performing Commands
Perform Basic commands by pressing a Command button.
Perform Advanced Commands by first accessing Levels 1-4 using the
AUX
button and then by pressing a Command button while within a
level.
Advanced command example: Silent Lock
1. Press the
AUX
button once to access Function Level 1.
2. Press the
AUX
AUX
button to perform the Silent Lock command.
3. The system will lock the doors and flash the parking lights,
without horn honks.*
* The optional Horn Honk feature must be connected.
4© 2014 Directed. All rights reserved.
Remote Control Command table
Basic
Commands
Advanced Commands
Button
Level Direct Access
A U X
x 1
A U X
x 2
A U X
x 3
A U X
x 4
A U X
Lock Silent Lock
A U X
Unlock Silent Unlock Remote Valet Car Finder
A U X
Remote Start Reset Runtime Timer Start Smart Start Defogger
AUX
Aux/Trunk* AUX 1 AUX 2 AUX 3 AUX 4
A U X
Advance
Level, Change
Car (3 sec),
Enter program-
ming (8 sec)
Temperature
Check*
(2-way only)
Lock Status
(2-way only)
Runtime
Remaining
(2-way only)
*This is an optional feature. See your authorized Directed dealer for details.
Fault Condition alerts
If, when performing a command, a condition exists that does not al-
low activation of the remote start feature* a fault tone plays to alert of
the fault condition.
* See online guide.
5
© 2014 Directed. All rights reserved.
Basic Commands (Direct Access)
No confirmation LED’s on.
Lock
Press and release
AUX
AUX
,
Doors lock. The horn honks once, and the parking lights flash. Lock
LED turns on with 1 beep.
To Lock and Panic
Press and hold
AUX
AUX
To lock the system, then activate Panic. For Panic to be effective,the
optional horn honk feature must be connected. Press the
AUX
AUX
or
AUX
AUX
button to stop Panic output.
Unlock
Press and release
AUX
AUX
.
The doors unlock. The horn honks and the parking lights flash. Unlock
LED turns on and remote beeps twice.
Remote Start*
Press and release
AUX
AUX
Activates (or if On, deactivates) the remote starter. The engine turns
On, or the engine turns Off accordingly. The parking lights flash.
Remote Start LED turns on, and plays tones.
If a Remote start configuration issue prevents the engine from starting,
the parking lights flash a Remote Start fault report to identify the fault.
6© 2014 Directed. All rights reserved.
AUX/Trunk
Press and hold AUX.
The Aux LED turns on and tones play to confirm. The Trunk opens (if
connected) when this button is pressed for 2 seconds.
This is an optional feature. See your authorized Directed dealer for
details.
* See online guide.
Remote Control Configuration
The Responder LE and 1-way companion remote controls have opera-
tions that can be configured to a user’s personal preferences*.
* See this section in online guide.
7
© 2014 Directed. All rights reserved.
Battery Information
The Responder LE remote is powered by 2 batteries (PB CR-2016)
and the 1-way companion remote is powered by 1 battery (CR-2032)
that can be purchased at most retailers. When the battery begins to
weaken, the operating range will be reduced.
Battery Disposal
Directed cares about the environment. If you need to dis-
pose of the battery, please do so in accordance with your
municipal requirements for battery disposal.
Patent Information
This product is covered by one or more of the following United States
patents:
Remote Start Patents:
5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936;
5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053;
7,483,783
Vehicle Security Patents:
5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591;
5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667;
5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484
Other patents pending.
