SMOKE-WE &HEAT-WE
INSTALLATION GUIDE
Document SAP: 102026647-02
ii
Team of
experts
Intrusion
innovators
R&D capabilitiesComplete solutions
Service & supportGrowth platform
iii
GROWTH ACCELERATION WITH PYRONIX
REVENUE, KNOWLEDGE AND BRAND
GAP is designed with time-pressured installers and system integrators in mind, and
provides easy access to free support services that will help your business to thrive. To nd
out what GAP can oer your business, visit www.pyronix.com/uk/gap/
REVENUE
Harness the benets that superior services, upsell opportunities and an
ever-evolving product range oer, to continuously add value to your
business and your customers. Scan or click the QR code to nd out more.
KNOWLEDGE
We support you to learn more, so you know what every property needs,
what customers want and how to deliver it. And even when you need a
helping hand, we’re there for you. Scan or click the QR code to nd out
more.
BRAND
The more your business is seen, the more leads you’ll generate. GAP gives
you everything you need to develop your brand and reach new customers.
You’ll get noticed for all the right reasons. Scan or click the QR code to nd
out more.
iv
CONVENTIONS
STANDARDS
BS 5839-6 Fire detection and re alarm systems for buildings Part 6: Code of practice for
the design, installation, commissioning and maintenance of re detection and re alarm
systems in domestic premises for the UK, will hereinafter be referred to as BS 5839-6.
DIAGRAMS
All diagrams in this manual are not to scale and are intended for illustrative and indicative
purposes only.
This colour denotes important components in diagrams and does not reect the
physical product.
TECHNICAL SUPPORT
If you experience issues with the installation, please call our UK technical support team.
Alternatively if you do not require assistance straight away, you can always email the team
who will reply to you as soon as possible.
Our oce hours are: Monday to Friday 08:00 - 18:30.
0333 444 1280
Please note: In order to assist getting your issue resolved quickly, please have the software revision
of the equipment you are currently working with.
v
CONTENTS
Growth Acceleration with Pyronix iii
Conventions iv
Technical Support iv
Introduction 6
Specications 6
Dimensions & weight 6
Performance 6
Batteries 7
Installation & Location Advice 8
Where to Install 8
Where Not to Install 10
Fitting the Detector 11
Wireless Integration 12
Learning the Device to the System 12
Signal Strength Test 13
Battery Test 13
Maintenance 14
Battery Replacement 14
Testing the Devices 14
Taking Care of the Devices 15
Sensor Indications & Features 16
Standby Mode - Smoke & Heat 16
End of Life - Smoke & Heat 16
Alarm - Smoke 16
Alarm - Heat 17
Clean Me - Smoke 17
Low Sensitivity - Smoke 17
Sensor Low Battery - Smoke & Heat 18
Detector Trouble - Smoke 18
Detector Trouble - Heat 18
Rear Switch Feature - Smoke & Heat 19
Temporary Fault Mute Feature - Smoke & Heat 19
Fire Safety Advice 20
Warranty & Compliance 23
Battery Information 23
Product Information 23
Warranty & Compliance 23
6
INTRODUCTION
SMOKE DETECTOR
The SMOKE-WE is designed to sense smoke that comes into the sensing chamber and to
give early warning of developing res by alarming from its built-in piezo.
It does not sense gas, or ame.
HEAT DETECTOR
The HEAT-WE senses ambient temperature via a thermistor and provides an early warning
of developing res by alarming from its built-in piezo when the temperature rises above a
predened value.
It does not sense gas, or smoke.
Please note: These detectors can only provide pre-warning if they are located, installed, and
maintained properly as described in this guide.
SPECIFICATIONS
DIMENSIONS & WEIGHT
SMOKE-WE HEAT-WE
Dimensions (Ø x D) 120 x 52.45mm 120 x 52.45mm
Weight (including battery) 183g 172g
PERFORMANCE
SMOKE-WE HEAT-WE
Detection Smoke only Heat only
Sensor low voltage alert 2.6 - 2.7VDC 2.6 - 2.7VDC
RF low voltage alert 2.5V +/- 5% @ 25C 2.5V +/- 5% @ 25C
7
SMOKE-WE HEAT-WE
Sensor standby | alarm current 25uA | 120mA 25uA | 120mA
Sound level 85dB/3M 85dB/3M
Visual indications Power, fault and alarm Power, fault and alarm
Transmission frequency 868MHz FM transceiver narrow band
Transmission method and range Fully encrypted rolling code, 300m
Operating temperature -10 - 50°C -10 - 50°C
Humidity 5 - 90% 5 - 90%
Heat alarm temperature N/A 57°C
Sensitivity range EN14604
0.105 ~ 0.165dB/m
EN54-5
Temp class: A2
Response time limits:
Lower | Upper - 29 | 46 mins
Increases by 1°C per min
Standards EN 14604 -
BATTERIES
SMOKE-WE & HEAT-WE
Sensing element
This part is powered by 2 x 1.5V, AA and are not replaceable. When they reach
the end of their life cycle, the whole unit will need replacing.
Life expectancy ~10 years.
Radio TX and RX
The radio component is powered by 1 x 3V, CR123A and can be replaced when
discharged. When this battery is low on charge, the unit will indicate to the control
panel it needs to be replaced with a new one.
Life expectancy ~2 years
8
INSTALLATION & LOCATION ADVICE
WHERE TO INSTALL
LOCATIONS IN THE HOME
Smoke detectors should be installed in accordance with the BS5839-6. These are Grade F1
and used for LD3 categories.
Minimum coverage is one detector installed on each oor in the property and one in each
section of the property with adjacent bedrooms.
For added protection, install a separate smoke detector in each separate room and exit
way, except the kitchen and rooms which emit steam, for example bathrooms and wet
rooms, as shown below in g I and II.
I
Minimum smoke protection
Added smoke protection
Heat sensor protection
NOT TO SCALE
II
Minimum smoke protection
Added smoke protection
Heat sensor protection
NOT TO SCALE
III NOT TO SCALE
Minimum smoke protection
Added smoke protection
Heat sensor protection
Locations for placing detectors
for single-oor homes with
adjacent bedrooms.
Locations for placing detectors
for single-oor homes with
spread out bedrooms.
Locations for placing detectors
for multi-oor homes.
For complete coverage in residential properties, smoke detectors should be installed
in all rooms, halls, storage areas, basements, and attics. Install a minimum of two in any
household.
9
USEFUL TIPS
• In hallways or corridors exceeding 7.5m in length, no point within the hallway or corridor
should exceed 7.5m from the nearest detector.
• Install a rst-oor smoke detector at the top of the ground-to-rst oor stairwell. Be sure
that no door or other obstruction blocks the path of smoke to the alarm.
CEILING, WALL AND PITCHED ROOF INSTALLATION
IV NOT TO SCALE
300mm300mm
VNOT TO SCALE
150mm
300mm
300mm
600mm
150mm
VI NOT TO SCALE
Ideally, the detector should be
located as central as possible.
The detector must be installed
at least 300mm from walls
or any light ttings as shown
in g IV.
If ceiling mounting is not
possible, when wall mounting
the top of the detector should
be 150 - 300mm from the
ceiling and at least 300mm
from any walls or objects as
shown in g V.
When siting a smoke detector
on a pitched ceiling, the centre
must be no more than 600mm
and a heat detector no more
than 150mm vertically below
the apex as shown in g VI.
Please note: If it is not possible to locate the smoke or heat detector at the required distance from
the apex on a pitched ceiling, it is considered a at ceiling and should be installed as g IV.
10
WHERE NOT TO INSTALL
GENERAL
Do not install...
• In environments where the ambient temperature can exceed 40°C or be below 0°C
• Where heat/steam could cause false alarms such as directly above ovens or kettles etc.
• On surfaces that are normally warmer or colder than the rest of the room (e.g. attic
hatches) as temperature dierences may stop smoke or heat from reaching the unit.
• In close proximity to anything that can create airows such as air conditioning units,
windows, vents or heaters.
• Anywhere that not easily accessible to silence false alarms or test/replace the battery.
• Near any objects that could cause electrical interference such as dimmer switches or
proximity readers.
• Within 1.5m of uorescent light ttings as the electrical noise or ickering may aect the
unit.
SMOKE DETECTORS
Do not install...
• In bathrooms, kitchens, shower rooms, garages or other rooms where the smoke alarm
may be triggered by steam, condensation, normal smoke or fumes.
• Within 6 metres from sources of normal smoke/fumes.
• Near very dusty or dirty areas. Build-up of dust or dirt in the chamber will impair
performance. It can also block the insect screen mesh and prevent smoke from entering
the chamber.
• In insect infested areas. Small insects getting into the smoke detector chamber can cause
intermittent alarms.
HEAT DETECTORS
Do not install...
• In, or close to bathrooms, shower rooms or other rooms where the unit may be triggered
by steam or condensation.
