Pyronix Atlas LCD Manuel utilisateur
Rins139 Issue 4
.
USER GUIDE
To Be Used With The Atlas 4 and Atlas 8 Control Panels
9
>
9
D
9
1
<
C
J
?
>
5
%
J
?
>
5
&
J
?
>
5
'
J
?
>
5
(
Rins139 Issue 4
WELCOME
Thank you for purchasing the
Atlas Panel
. This panel uses the latest technology in design
and manufacture.
As the end user of the Atlas this manual is written to help you use the functions of your
alarm system enabling you to get the best out of your system. The capability of the panel
means that the engineer can carry out any alterations to programming of the alarm without
having to visit the installation.
NOTE: The fire zone is intended as an extra feature to the alarm system and must not be
regarded as a total fire protection system.
There are two levels of user access to the system:
The Master Code (Code 1) defaulted to: 1 2 3 4, access to all user functions and
programming features.
The User Codes (Codes 2 to 7) - 6 codes, allow setting / unsetting of the panel and viewing
of the event log only.
Fire
To activate the fire alarm, press and hold the and keys together.
Personal Attack
To activate the personal attack, press and hold the and keys together.
2
System Test
Press
Use the down scroll key to display ´6<67(07(67µ
Press to accept.
Use the right key to scroll through the following tests.
GLVSOD\WHVW
VWUREHWHVW
EHOOWHVW
VRXQGHUVWHVW
After last test, ‘System Test’ is exited automatically.
Change Text
Press
Use the down scroll key to display “FKDQJHWH[Wµ
User 1 will now be displayed, use the up / down scroll keys to scroll through
the user definable text. When the required user name is displayed the text can be changed
by using the numeric keys which are marked with their alternative letter functions, to move
from letter to letter press the keys several times. To move along the display text letters use
the left / right scroll keys. To insert a space press the 0 key twice.
To save changes to the text the key must be pressed.
Set Backlight
Press
Use the down scroll key to display “VHWEDFNOLJKWµ
Use the up / down keys to select the desired backlight brightness.
To save changes the key must be pressed.
7
Rins139 Issue 4
Walk Test
Press
Use the down scroll key to display ´ZDONWHVWµ
Press to accept.
Use the up/down scroll keys to display the Set mode required. e.g.. ´VHWDµ
Press to accept.
Display reads ´HQWHUFRGHµEnter the Master User Code .
Press to accept.
Walk test the system, each zone triggered during walk test will be entered in the event log.
Enter Master Code to exit walk test mode.
Pulse PGM
Press
Use the down key to display ´38/6( 3*0µ or the new label programmed by the
engineer.
Press to accept. The dual tone is heard on acceptance and ´RSHUDWLQJµ is displayed.
If ´127$87+25,6('µ is displayed the option has not been configured by the engineer.
Accept Calls
Press the menu key
Use the down key to display ´DFFHSWFDOOVµ.
Press to accept. The dual tone is heard on acceptance and ´+5$&7,9(µ is displayed.
6
MASTER AND USER FUNCTIONS
Setting The Panel
Press The display reads ´VHWV\VWHPµ
Press to accept. Display reads ´VHWDµ
Use the down scroll key to display the set mode required. e.g. ´VHWEµ
Press to accept.
Enter user code Exit timer starts countdown.
Exit the building.
Quick Setting
Enter user code and press a function key or for the set
required.
Set With Omits
Press
Use the down scroll key to display ´VHW:,7+20,76µ
Press to accept. Display reads ´VHWDµ
Use the down scroll key to display the Set mode required. e.g.. ´VHWEµ
Press to accept and enter a User Code .
Display reads ´20,7=21(6µ Enter zone or zone numbers to be omitted.
1. This can be done by two methods.
Either press a numerical key representing the required zone (the zone selected is then
displayed and accepted) and pressing the key after all the zones have been selected.
or
2. Use the up/down keys to display the required zone and selecting each
required zone using the key. After all the required zones have been selected press
the key to accept the programming.
Exit timer starts countdown.
Exit the building.
3
Rins139 Issue 4
Unsetting The Panel
Enter the building via one of the programmed Entry/Exit Zones.
To Unset the panel Enter Master / Manager or User Code.
Select Chime
Press
Use the down scroll key to display ´VHOHFW&+,0(µ
Press to accept. Display reads ´FKLPHRQ RII ´
Use the up key to turn the chime on or use the down key to turn the chime
off
Reading The Event log
Press
Use the down scroll key to display ´GLVSOD\/2*µ
Press to accept.
The last event is displayed, use the and keys to display the previous events.
To exit Event Log press .
4
MASTER ONLY FUNCTIONS
Clear Event Log
Press
Use the down scroll key to display ´&/($5/2*µ
Press to accept.
If allowed by the Engineer ´ORJ FOHDUHGµ will be displayed and a two tone sound will be
heard, if not allowed ´QRWDXWKRULVHGµ will be displayed.
Change User Code
Press
Use the down scroll key to display ´&+$1*(&2'(6µ
Press to accept.
Display reads´NH\PDVWHUFRGHµ Enter (Master or Manager Code)
Display reads ´SUHVVXVHUWRµ
Enter a number between 1 to 7 for the code you require to change.
1 = Master Code (Master Code can only be changed by Master User)
2,3,4,5,6 and 7 = User Codes.
To delete a code press the key. NOTE: the Master Code cannot be deleted.
Display reads´HQWHUQHZFRGHµ
Enter the new four digit code, a dual tone will be heard on acceptance and display will read
´UHHQWHU FRGHµ enter the same four digit code again to confirm. On acceptance the dual
tone will again be heard and the keypad will go back into ‘Day Mode’. If the code was
entered incorrect a single bleep will be heard and ´LQYDOLGFRGHµ will be displayed.
5
