Pylontech RT12100B-G31 Manuel utilisateur

User Manual

Information Version: 1.0

Smart Lithium Iron Battery

RT12100B-G31

Rated Voltage:

Rated Capacity:

Rated Energy:

Recommended Charging Voltage:

Recommended Charging / Discharging Current:

Maximum Charge Current:

Maximum Discharge Current:

Operating Ambient Temperature:

Short-circuit Current / Duration Time:

12.8Vdc

100Ah

1280Wh

14V~14.4V

50A/50A

100A

-40°C~60°C

<1KA/100μs

FCC ID：2AYEF-RT12100B

214-

230162

Rechargeable Lithium-ion Battery

Any reproduction or distribution of this manual or any part of this manual, in any form

by any means, without the prior written consent of Pylontech is prohibited.

Disclaimer

The Manual contains instructions for the use of the product. All the pictures and

charts hereinafter are for description and explanation only. The information in the

manual is subject to change, without further notice.

Please read this manual carefully before using the product. Failure to do so may

result in serious injury, property damage and may void the warranty. Please keep this

manual for further reference.

By using this product, you hereby signify that you have read this manual carefully

and that you understand and agree to abide by all terms and conditions of this

manual and all relevant documents of this product. You agree that you are solely

responsible for your own conduct in using this product, and for any consequences

thereof. Pylontech shall not be liable for any damages resulting from the use of this

product not in accordance with this manual. In the event of any conﬂicts between

this manual and the applicable law, the latter prevails.

Legal Information

Safety Instructions

• The device should be used in strict compliance with local laws, electrical safety

regulations, and ﬁre prevention regulations of the nation or the region.

• Do not place the device near open ﬁre, heat sources and ﬂammable materials.

• Do not leave the device in an extremely hot environment.

• Do not place the device in damp locations.

• Do not expose the device to high electromagnetic radiation.

• Do not strike, mechanically crush or cut the device.

• Do not puncture the device with sharp objects.

• Do not stack heavy objects on the device.

• Do not place metal objects or wires on the device.

• For safety purposes, please use only the accessory (cable, charger, and etc) supplied

or recommended by Pylontech. Pylontech shall not be liable for damage caused by

third-party devices.

• Before ﬁrst use, please check if the device is in good condition. If the device is

deformed or has an odor, do not use the device and return it to the distributor.

• Keep the device out of reach of children and pets.

• If the device falls into water during use, please take it out immediately.

• If the battery leaks, avoid contact with the leaking liquid or gas. In case of contact with

skin or eyes, ﬂush immediately with plenty of clean water and seek medical advice.

• Do not install the device in an unstable place. Personal injury or property damage

may be caused if the device falls.

• Do not place the device in dusty locations.

General

Installation

• Please ensure good ventilation while the device is in use.

• If the device has been stored for more than one year, please check it carefully to

make sure there is no problem before using it.

Operation

• Keep the device upright when moving it.

• Handle the device gently.

Transportation

Warning

Caution

• Charge the device regularly. If you need to store the device for a long time, please

charge it to at least 60% every time before storing it.

• Recharge the device as soon as possible after it has been fully discharged.

• If the device does not work properly, please contact your distributor or the nearest

service center within 24 hours. DO NOT disassemble the battery for repair or mainte-

nance by yourself. Pylontech shall not assume any responsibility for problems

caused by unauthorized repair or maintenance.

• Do not charge the device which is hot, deformed, or leaking.

• It is recommended to check the connection between power cords and screws

regularly to ensure that there is no loosening, breakage or corrosion at the connec-

tion points.

• It is recommended to regularly check if the battery storage environment is normal.

Maintenance

Safety Instructions

• Dispose of used batteries according to the laws or the regulations of the nation or the

region.

• Please use a soft and dry cloth to clean the exterior surfaces.

Disposal

Cleaning

Speciﬁcations

12.8 VDC

100 Ah

＜10 mΩ4S4P

＞4500 (80% DOD, 0.5 C, 25 °C)

50 A

200 A @30 s

12 V

10.8 V

Relative Humidity

-4 °F ~ 158 °F (-20 °C ~ 70 °C)

32 °F ~ 158 °F (0 °C ~ 70 °C)

-4 °F ~ 140 °F (-20 °C ~ 60 °C)

-4 °F ~ 122 °F (-20 °C ~ 50 °C)

5% ~ 95%

50 A

100 A

14 V ~ 14.8 V

14.6 V

13.5 V

Design Life

Short Circuit Current Duration

≥ 10 years

<1 kA/100 us

≤3% per month

Electrical Speciﬁcation

Discharge Speciﬁcation

Charge Speciﬁcation

Temperature & Humidity Speciﬁcation

Nominal Voltage

Nominal Capacity

Resistance

Self Discharge

Maximum Modules in Parallel or Series

Cycle Life (25°C)

Max. Continuous Discharging Current

Peak Discharging Current

Under-voltage Disconnect

Reconnect Voltage

Over-voltage Disconnect

Reconnect Voltage

Recommended Charging Current

Max. Continuous Charging Current

Recommended Charging Voltage

325 mm × 173.5 mm × 238 mm

(12.8 in × 6.83 in × 9.37 in)

Discharging Temperature

Charging Temperature

Storage Temperature

Working Temperature

Mechanical Speciﬁcation

Dimensions (L*W*H)

Approx.12 kg (26.46 lbs)

IP67

LiFePO4

Max. Altitude

Speciﬁcations

M8 × 14

9 ± 1 Nm

UN38.3, TELEC, FCC, CE, Bluetooth SIG, ROHS

BLE 5.0

4000 m

Support

*Product performance is based on testing in a controlled environment. Your results may vary due to

several external and environmental factors.

Dimension

238 mm (9.37 in)

Unit: mm (inch)

Other

Certiﬁcations

Communication

APP

Weight

Terminal Type

Terminal Torque

Case Material

Enclosure Protection

Cell Type-chemistry

325 mm (12.8 in)

173.5 mm (6.83 in)

*Donot disconnect or disassemble by non-professional

personnel.

*Donot drop, deform, impact, cut or spearing with a

sharp object.

*Donot place at children or pet touchable area.

*Donot place near open ﬂame or ﬂ ammable material.

*Avoidof moisture or liquid.

EmergencySituations

*If detect leakage, ﬁre or damage to the module, keep away and contact your

suppliers immediately for assistance.

RT12100B-G31

Rated Voltage:

Rated Capacity:

Rated Energy:

Recommended Charging Voltage:

Recommended Charging / Discharging Current:

Maximum Charge Current:

Maximum Discharge Current:

Operating Ambient Temperature:

Short-circuit Current / Duration Time:

12.8Vdc

100Ah

1280Wh

14V~14.4V

50A/50A

100A

-40°C~60°C

<1KA/100μs

FCCID：2AYEF-RT12100B

214-

230162

Rechargeable Lithium-ion Battery

Introduction

RT12100B-G31 is a lithium iron phosphate battery module. With a standard BCI

group size, it is designed to replace deep-cycle lead-acid batteries. The battery is

perfect for recreational vehicles (RV), marine (boats), trucks, cabins, and other

off-grid deep- cycle applications.

More than 4,500 cycles at a depth of discharge of 80%.

The product has the following advantages.

•Long Cycle Life

•High Reliability

•Low Self-discharge Loss

Supports both parallel connection and series connection.

The built-in advanced BMS manages charging and discharging status, helps in

balancing the individual cells, and ensures intelligent automatic protection against

over-voltage, under-voltage, over-current, high temperature, low temperature and

short circuit.

The battery can be stored for more than 6 months if it has been disconnected from

other devices.

•Flexible Connection in Parallel and Series

•High Energy Density

With the high energy density lithium cells, our battery is half the weight of the lead

acid battery of equivalent energy, and 70% the size of the regular lithium battery of

equivalent energy. It's easier to carry, faster to charge, and more convenient to use.

The built-in Bluetooth module allows real-time monitoring via mobile devices.

•Real-time Monitoring via APP

Interface

Negative PolePositive Pole

On/Off Button

Packing List

User Manual

Battery

Pylontech Auto APP

APP Quick Guide

PylontechAuto App

*Donot disconnect or disassemble by non-professional

personnel.

*Donot drop, deform, impact, cut or spearing with a

sharp object.

*Donot place at children or pet touchable area.

*Donot place near open ﬂame or ﬂammable material.

*Avoidof moisture or liquid.

EmergencySituations

*If detect leakage, ﬁre or damage to the module, keep away and contact your

suppliers immediately for assistance.

RT12100B-G31

RatedVoltage:

RatedCapacity:

RatedEnergy:

RecommendedCharging Voltage:

RecommendedCharging / Discharging Current:

MaximumCharge Current:

MaximumDischarge Current:

OperatingAmbient Temperature:

Short-circuitCurrent / Duration Time:

12.8Vdc

100Ah

1280Wh

14V~14.4V

50A/50A

100A

-40°C~60°C

<1KA/100μs

FCC ID：2AYEF-RT12100B

214-

230162

RechargeableLithium-ion Battery

Tools

Voltmeter Screwdriver

Wire Cutter

Safety Goggles Insulating Gloves

Indicator

Light up for 0.5 s every other 1.5 s

Light up for 1 s every other 1 s

Light Off

Status Meaning

Working Mode

Networking Mode

Sleep/Power Off/System Error

Activation

Before ﬁrst use, press the on/off button to

activate the device. *Donot disconnect or disassemble by non-professional

personnel.

*Donot drop, deform, impact, cut or spearing with a

sharpobject.

*Donot place at children or pet touchable area.

*Donot place near open ﬂame or ﬂammable material.

*Avoidof moisture or liquid.

EmergencySituations

*If detect leakage, ﬁre or damage to the module, keep away and contact your

suppliersimmediately for assistance.
