Pvelectronics Halo Chroma Guide de configuration

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 1 -

Assembly Instructions

And

User Guide

Nixie Clock Type

‘Halo Chroma’

For Parts Bag Serial

Numbers from 000 onwards

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 2 -

REVISION HISTORY

Issue

Number

Date Reason for Issue

Issue 1 1 April 2021 New document

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 3 -

1. INTRODUCTION

1.1 Halo Chroma - Features

 Hours, Minutes and Seconds display

 Drives Z560M, Z5600M, GN-4, ZM1022 and many other compatible tubes

 Uses a Quartz Crystal Oscillator as the timebase

 12 or 24 hour modes

 Programmable leading zero blanking

 Date display in either DD.MM.YY or MM.DD.YY or YY.MM.DD format

 Programmable date display each minute

 Scrolling display of date or standard display

 Alarm, with programmable snooze period

 Optional GPS / WiFi / XTERNA synchronisation with status indicator LED

 Dedicated DST button to switch between DST and standard time

 Supercapacitor backup. Keeps time during short power outages

 Simple time setting using two buttons

 Configurable for leading zero blanking

 Double dot colon neon lamps

 11 colon neon modes including AM / PM indication (top / bottom or left /

right), railroad (slow or fast) etc.

 Seconds can be reset to zero to precisely the set time

 Programmable night mode - blanked or dimmed display to save tubes or

prevent sleep disturbance

 Rear Indicator LEDs dim at night to prevent sleep disturbance

 Weekday aware ‘Master Blank’ function to turn off tubes and LEDs on

weekends or during working hours

 Separate modes for colon neons during night mode

 Standard, fading, or crossfading with scrollback display modes

 ‘Slot Machine’ Cathode poisoning prevention routine

 Programmable RGB tube lighting – select your favourite colour palette

 729 colours possible. Have a different colour or your choosing every

hour, or autochanging colours

 Not AC frequency dependent – works in all countries

 Supports output Sync Pulse for our DekaDuo Dekatron Driver Board

 All user preferences stored to non-volatile memory

 Additional wireless functions if XTERNA module used:

- Display of outdoor temperature in Celsius or Fahrenheit. Configurable.

- Min / Max temperature in last 24 hours

- Wireless, Auto Sync of time from GPS with auxilliary TCXO

- GPS Sync time, and time since last GPS Fix

- Voltage of XTERNA module battery

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 4 -

1.2 Tubes Supported

There are many types of tube this kit will drive – all have the same

pinout. The commonest types are as follows:

Z560M

Z5600M

GN-4

ZM1022

ZM1020

B-5092

Digit height is generally 15.5mm for all these tubes. A typical tube

is shown below:

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 5 -

1.3 SAFETY

DANGER: The clock pcb includes a switched-mode voltage booster

circuit. This generates nominally 170 Volts DC. Assembly may only be

undertaken by individuals who are suitably qualified and experienced in

electronics assembly, and are familiar with safe procedures for working

with high voltages. If in doubt, refer to a suitably qualified engineer

before proceeding.

The voltages generated by this circuit can give a potentially

LETHAL ELECTRIC SHOCK.

DISCLAIMER: This product is supplied as a kit of parts, intended only for

suitably qualified electronic engineers, who are suitably qualified and

experienced in electronics assembly, and are familiar with safe

procedures for working with high voltages. The supplier, his agents or

associates accept no liability for any damage, injury or death arising from

the use of this kit of parts.

This is not a finished product, and the person assembling the kit is

responsible for ensuring that the finished product complies with any

applicable local regulations governing electrical equipment, eg. UL, CE,

VDE.

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 6 -

2. TOOLS AND EQUIPMENT REQUIRED

2.1 Tools required to assemble the PCB.

The following tools will be required to assemble the PCB:

- Soldering iron (25W fixed temperature recommended) with a small tip

(1-2 mm).

- Wire cutters to trim the excess component leads after soldering.

(TIP: A small pair of nail clippers works very well for this function).

- Multimeter for voltage tests and for identifying the resistors.

- A small hot air gun will be needed to shrink the heat shrink tubing

over the neon lamp wires.

2.2 Materials you will need.

Solder – lead / tin solder is highly recommended.

USE LEAD/ TIN SOLDER!

Lead free solder, as now required to be used in commercial products in

Europe, has a much higher melting point and can be very hard to work

with.

Desoldering wick (braid) can be useful if you accidentally create solder

bridges between adjacent solder joints.

2.3 Other items you will need.

The clock kit does not include a power adapter.

The following type of adapter should be obtained and used with the kit:

Output 12V DC regulated, minimum power output capability of 500mA

Output plug: 2.1mm pin, centre positive.

A suitable adapter is shown below:

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 7 -

3. LIST OF COMPONENTS

3.1 Table of Components

Circuit Designation Part Description

Resistors

R1, R2 4.7 KΩ, ¼ Watt

R3, R4 390 KΩ, ¼ Watt

R5 300 KΩ, ¼ Watt

R6 - R11 270 Ω, ¼ Watt

R12 4.7 KΩ, ¼ Watt

R13 – R15 1 KΩ, ¼ Watt

R16 – R21 4.7 KΩ, ¼ Watt

R22 – R25 15 KΩ, ¼ Watt

Capacitors

C1, C2, C4 220uF Electrolytic

C3 1uF, 250V,

C5 15pF Ceramic

C6 33pF Ceramic

C7 100nF Ceramic

C8 0.22F

C9 100nF Ceramic

Transistors

Q1 IRFD220 MOSFET

Q2 – Q4 EL817 Optocoupler

Q5 – Q9 MPSA42

Diodes

D1 – D3 1N5819

D4 1N4148

D5 UF4004

D6, D8 5mm Yellow LED

D7 5mm Green LED

RGB1 – RGB6 APA106 RGB LED

Integrated Circuits

IC1 LM2576 5V voltage regulator SMD

IC2 PIC16F1938 8-bit microcontroller

IC3 HV5812

Miscellaneous

L1, L2 100uH inductor

AM1, AM2, PM1, PM2 4mm wire ended neon lamp

ALARM, SET, ADJ, DST Vertical miniature push button

IC2 Socket 28 Way narrow IC socket for IC2

IC3 Socket 28 Way PLCC Socket

J1 2.1mm Vertical power socket

SYNC Vertical 3.5mm jack socket

LS1 Piezo sounder

FUSE 500mA fuse

Insulation 25 cm Clear insulation for neons

X1 32.768KHz watch crystal

Tube Sockets Harwin 1mm sockets

Sockets for EL817’s 2 X 6 way SIL socket strips

DEKA 3 Way 0.1” header

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 8 -

3.2 Parts list / Packing Sheet - Component Bag

Part Description Quantity

Resistors

270 Ω, ¼ Watt 6

1 KΩ, ¼ Watt 3

4.7 KΩ, ¼ Watt 9

15 KΩ, ¼ Watt 4

300 KΩ, ¼ Watt 1

390 KΩ, ¼ Watt 2

Capacitors

15pF, Ceramic 1

33pF, Ceramic 1

100nF, Ceramic 2

1uF, 250V, Electrolytic 1

220uF, 16-25V, Electrolytic 3

0.22F 1

Transistors

IRFD220 MOSFET 1

MPSA42 5

EL817 Optocoupler 3

Diodes

1N5819 3

UF4004 fast recovery diode 1

1N4148 1

5mm Green LED 1

5mm Yellow LED 2

APA106 RGB LED 6

Integrated Circuits

LM2576 5V voltage regulator SMD 1

PIC16F1938 8-bit microcontroller 1

HV5812 1

Miscellaneous

100uH inductor 2

4mm wire ended neon lamp 4

Miniature vertical push button 4

28 way narrow IC Socket for IC2 1

28 Way PLCC Socket 1

2.1mm Vertical power socket 1

Vertical 3.5mm jack socket 1

Piezo sounder 1

500mA fuse 1

25cm Clear insulation for neons 1

32.768KHz watch crystal 1

10 Way 0.1” Female socket strip 1

2 X 6 way SIL socket strips 1

1mm Harwin Socket 66

3 Way 0.1” header 1

Plexi Tool for bending the RGB LEDs 1

We recommend to check against the list above, to ensure all parts

are present before commencing assembly.

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 9 -

The resistors used in the kit are 1% tolerance metal film. They are

marked with 4 coloured bands to identify the value. However it is

sometimes unclear in which direction the bands should be read.

Therefore, we recommend that the resistors be identified with a

multimeter.

Please note the fuse will look like the picture below. It can easily be

confused for a capacitor. It is a self-resetting fuse.

The 15pF and 33pF capacitors will be marked 15 and 33

respectively. The 100nF capacitors will be marked 104.

Q1 (IRFD220) is in a very similar package to Q2 – Q4 (EL817). You

can tell the difference, in addition to the part marking by looking at

the pins. Q1 has two pins that are actually joined at the resin body.

Q2 – Q4 have 4 separate pins.

Inductors L1 and L2 may be one of three types:

Nixie Tube Clock ‘Halo Chroma’

Issue 1 (1 April 2021)

www.pvelectronics.co.uk

- 10 -

4. ASSEMBLY OF THE PCB

4.1 1mm Sockets For Nixie Tubes

There are 66 individual sockets that need to be placed. Note that

there are 2 holes per tube with NO SOCKET.

Be sure to insert the sockets from the front side of the PCB. This is

the side with substantially more white component markings on it.

Insert and solder all the sockets for each tube at a time, before

moving to the next tube location. Be sure to insert the sockets

FROM the tube side of the PCB – the side with the tube markings.

After inserting the sockets, the best way to hold all the sockets in

place whilst soldering them is to insert a tube.

Table des matières

Autres manuels Pvelectronics Horloge

Pvelectronics

Pvelectronics SN-18 Guide de configuration

Pvelectronics

Pvelectronics WiFi NTP Sync Device Manuel utilisateur

Pvelectronics

Pvelectronics Nixie Maestro Guide de configuration

Pvelectronics

Pvelectronics Nixie QTC-Four Guide de configuration

Pvelectronics

Pvelectronics Nixie Large Tube Clock Guide de configuration

Pvelectronics

Pvelectronics Frank 3 Guide de configuration

Pvelectronics

Pvelectronics Nixie QTC Manuel utilisateur

Pvelectronics

Pvelectronics Nixie Maestro Guide de configuration

Pvelectronics

Pvelectronics Frank 3 Guide de configuration

Pvelectronics

Pvelectronics IN-8 Guide de configuration

Pvelectronics

Pvelectronics Nixie 5750 Guide de configuration

Pvelectronics

Pvelectronics Dink Guide de configuration

Pvelectronics

Pvelectronics Frank 3 Guide de configuration

Pvelectronics

Pvelectronics Halo Clock Guide de configuration

Pvelectronics

Pvelectronics Spectrum 18 Guide de configuration

Pvelectronics

Pvelectronics Elite Nixie Guide de configuration

Pvelectronics

Pvelectronics Frank 2 IN-16 Guide de configuration

Pvelectronics

Pvelectronics Nixie FunKlock Guide de configuration

Pvelectronics

Pvelectronics Quattro Guide de configuration

Pvelectronics

Pvelectronics Frank 3 Guide de configuration

Pvelectronics

Pvelectronics Spectrum 1040 Guide de démarrage rapide

Pvelectronics

Pvelectronics Nixie QTC Plus Guide de configuration

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8256-AL Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

La Crosse Technology

La Crosse Technology WT-3141b Manuel

La Crosse Technology

La Crosse Technology W86531 Manuel utilisateur

Sharp

Sharp SPC900 Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-50447 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur
