TWF2-FTT Fiber Termination Tool Adjustment Procedure

The TOTALWIRE™ TWF2 bers, with its patented integral 3M Polymer coating, is stronger and more bend insensitive than typical

glass bers. The TWF2-FTT Termination Tool comes factory adjusted to cleave TWF2 ber.

NOTE: If you are using a standard cleaver, perform the Blade UP steps listed above. To adjust your cleaver to cleave standard ber perform the

Blade DOWN adjustments listed above until the cleaver no longer cleaves standard ber, followed by the Blade UP adjustment until a successful

cleave is achieved.

Using the M2 Allen wrench included with

the cleaver, on the top right side remove

the screw that secures the ber scrap

box. Set the scrap box aside.

2ea M2

Using the M2 Allen wrench remove the

two screws that secure the guide cover.

2. Set the guide cover aside.

2ea T10

Loosen the two T10 guide screws with the

supplied wrench. Only approx. one turn is

required, do not loosen completely.

Blade Up A

Loosen the T10 hex screw located

behind the blade looking down on the

unit, counter clockwise one full turn.

Blade Up B

Turn the M2 Allen screw clockwise

2 positions. Tighten the previously

loosened T10 hex screw and the two

T10 side guide screws clockwise until

snug.

Attempt to cleave TWF2 ber. If the ber

does not successfully cleave repeat Blade

UP steps A & B to increase blade height

until a successful cleave is achieved,

reassemble.

Blade Down A

Loosen the T10 hex screw located

behind the blade looking down on the

unit, counter clockwise one full turn.

Blade Down B

Turn the M2 Allen screw counter

clockwise 2 positions. Rotate the

previously loosened T10 hex screw and

the two T10 side guide screws clockwise

until snug.

All brand names, product names and trademarks are the property of their respective owners. Certain trademarks, registered trademarks, and trade names may be used to refer to

either the entities claiming the marks and names or their products. PureLink disclaims any proprietary interest in the marks and names of others. PureLink is not responsible for errors

purelinkav.com

Unscrew boot from rear of connector and

slide onto cable jacket. For 2.0mm slide

included build tube onto cable jacket.

1. Using strippers remove approximately

50mm / 2” of cable jacket.

2. Place onto VFL using an LC type adapter.

Ensure activator slide tab is in “open”

position - slide towards rear of connector.

Open hinge on connector.

Cleave ber measuring from cable jacket.

For TWF2 LC = 24mm.

5. Insert ber into the rear of connector until

a slight “bow” is created and the light

emitting from connector window dims

and/or extinguishes.

Slide activator tab towards connector tip.

Remove from VFL. Ensure ber is straight,

hold Kevlar to one side (2.0mm seat tube

at rear of connector). Close hinge.

7. Install dust cap. Slide boot forward and

thread one full turn to “lock in” Kevlar

strands. Cut Kevlar close to boot. Tighten

boot until secure.

1. TWF2 Fiber does not require the use of alcohol

cleaning as the glass ber is not exposed being

protected with TWF2 proprietary coating.

Remove the soft peel coating completely from all

sides of the ber with ngers only. Do not use

strippers.

2. Due to the extreme durability and bend

insensitivity of TWF2 ber, your cleaver may

require a wheel height adjustment procedure

to allow successful cleaving of TWF2 bers. For

more information, please refer to the TWF2-FTT

adjustment guide.

Pull Kevlar yarns back to locate TWF2

ber. Use only nger tips/nails to gently

remove “Soft Peel” 250um coating to

within 12mm/1/2” of cable jacket.

Do Not

Use Strippers

TWF2 CONNECTOR Termination Guide for: TWF2 Jacketed Fiber 2.0mm / 3.0mm

(A) TWF2 Glass Fiber

(B) 250μm Soft Peel

12 12

(A) (B) (C)

*12mm Soft Peel is an approx. Do not exceed 12mm

All brand names, product names and trademarks are the property of their respective owners. Certain trademarks, registered trademarks, and trade names may be used to refer to

either the entities claiming the marks and names or their products. PureLink disclaims any proprietary interest in the marks and names of others. PureLink is not responsible for errors

purelinkav.com

TWF2 CONNECTOR Termination Guide for: TWF2 Fiber & 900m fan out kit/tubing

(A) TWF2 Glass Fiber

(B) 900µm Fan Tubing

(A) (B)

Slide included 900µm build tube section

onto fan tubing.

Slide build tube forward and seat in rear of

connector, ensure ber is straight, close

hinge. Slide boot forward and tighten until

secure.

Cleave ber measuring from fan tubing. For

TWF2 LC = 12mm.

1. TWF2 Fiber does not require the use of alcohol

cleaning as the glass ber is not exposed being

protected with TWF2 proprietary coating.

Remove the soft peel coating completely from all

sides of the ber with ngers only. Do not use

strippers.

2. Due to the extreme durability and bend

insensitivity of TWF2 ber, your cleaver may

require a wheel height adjustment procedure

to allow successful cleaving of TWF2 bers. For

more information, please refer to the TWF2-FTT

adjustment guide.

Place onto VFL using an LC type adapter.

Ensure activator slide tab is in “open”

postion - slide towards rear of connector.

Open hinge on connector.

Insert ber into the rear of connector

until a slight “bow” is created and the

light emitting from connector window

dims and/or extinguishes.

Ensure a minimum of 50mm of ber exits

the fan tubing. Unscrew boot from rear of

connector and slide onto fan tubing.

Slide activator tab towards connector tip.

Remove from VFL, Install dust cap.

Use only nger tips/nails to gently remove

“Soft Peel” 250µm coating completely to

fan tubing.

Do Not

Use Strippers
