Pure-Pro POSEIDON Manuel utilisateur

USER'S MANUAL

REVERSE OSMOSIS SYSTEM

MEMBER

Water

Quality

ASSOCIATION

MEMBER

WATER QUALITY ASSOCIATION

World Assembly Division

PurePro

POSEIDON

Plus!

Thank you very much for selecting Pure-Pro Water Corp.

In order to bring the best use of your system, please read the user's

manual carefully before installation and follow the regulations.

System overview

Components

Poseidon PRO

Poseidon LUXURY

Poseidon ELITE

Mineral Filter

Stage 5 / Service Life : 6-12 Months

This filter improves the qualities of clean water by adding necessary for proper human

development and health minerals, such as Calcium, Magnesium, Sodium, Potassium

others readily found in many natural mineral waters.

and

Far-Infrared Filter

Stage7 / 6-12 MonthsService Life :

This Infra-Red filter can activate water molecules in our body and improve oxygen levels

in our body. Warming and eliminating fats, chemicals and toxins from our blood and thus

smoothening the flow of blood.

Alkaline Filter

Stage 6 / Service Life : 6-12 Months

The Alkaline filter boosts the PH of the RO water into a perfect Natural Alkali Calcium

Water. TheAlkaline filter also gives back minerals such as ionized calcium,

sodium, potassium ion, which were taken away while purifying the water.

Ionized

magnesium,

Stage 1 / Service Life : 6-12 Months

With only five micron rating. It is effective in

removing dirt, rust and sand particles.

Stage 2 / Service Life : 6-12 Months

It takes out 99% of the chlorine and organic

chemicals. It provides enhanced reduction

of taste, odor, and color.

Stage 3 / Service Life : 6-12 Months

It takes out 99% of the chlorine and organic

chemicals. It provides enhanced reduction

of taste, odor, and color.

TFC Membrane

Stage 4 / Service Life : 2 Year

A thin film composite (TFC) high quality membrane that processes 100 gallons per day. It

remove the following hard water contaminants that may be present in your water: lead,

copper, barium, chromium, mercury, sodium, cadmium, fluoride, nitrite, nitrate, and selenium.

Water supply connectorDeliver-valve Drain saddle

RO / ECO Membrane

Tubing

Euro-Luxury faucet

(Poseidon PRO / LUXURY)

European ceramic faucet

(Poseidon ELITE)

Ultraviolet Sterilizer

(Optional)

Stage8 / 6-12 MonthsService Life :

Ultraviolet light (UV), a natural part of the sunlight is widely accepted as a reliable, efficient &

environmentally friendly solution for water disinfection. This UV lamp utilize the application of

particularly efficient UV radiator with a 254nm wave length to cause immediate death for

organisms and wipe out their ability to survive and reproduce.

99.99% DESTRUCTION OF BACTERIA AND VIRUSES

Install drain saddle :

Drill a 1/4" hole into

the drain pipe.

Mount drain

saddle aligning

holes.

Input water :

To RO system

Deliver valve

Water supply connector

To water

source pipe

Install faucet :

Faucet

Kitchenware table

Twisted plastic locker

Rubber gasket

Flat metal piece

Screw locker

Tubing

Cutting ring

Concave type screw

Installation diagram

Tubing connection diagram

Install membrane :

Remove the tube. Remove the membrane housing cap.

Install the membrane by carefully

pushing the spigot end into the

socket at the far end of the housing

until completely in.

PRO

URE

DRINKINGWATERSYSTEM

Tube

Connecting the color tubing

A. Connect the WHITE tubing to

the water supply connector.

B. Connect the BLUE tubing to

the countertop faucet.

C. Connect the BLACK tubing to

the drain saddle.

AB C

Back view

(A)(B)(C)

DRAIN OUTLET INLET

S300STS300NDS300RD

DRAIN OUTLET INLET

S300STS300NDS300RD

1.Turn off the water supply. Loosen the stainless steel pipe

connector. Get feed water connector and connect it to the

stainless steel pipe.

2.Get tubing white, connect it with deliver valve and the

inlet water supply.

DRAIN OUTLET INLET

S300STS300NDS300RD

Cold

5.Make sure that you complete. If so, switch on

water supply and plug in electricity.

PS. Do not use drink water from the first made

water in the tank.

4.Use an electric drill and drill an approximately 1 cm

hole through the kitchenware table. Take out the faucet

and its components. Install the faucet and the rubber

gasket to the kitchenware table.

Take tubing blue. Wear the concave type screw on

tubing blue and insert the tubing shroud as shown in

the picture. Connect the tubing top with the faucet end.

Then connect the tubing end to the hole of "TO FAUCET".

3.Take tubing black, connect it with the drain out.

Installation diagram

Change filters

Change RO / ECO membrane

Change stage 4

1 Before filter replacement, please make sure water and electricity supply are cut off.

Please turn off the tank ball valve, too.

2 Remove the tube.

3 Remove the membrane housing cap anticlockwise.

4 Remove the membrane by a pincer.

5 Install the membrane by carefully pushing the spigot end into the socket at the far end of the

housing until completely in.

6 Be sure tighten with O-ring to prevent from leaking.

After changing filters, let water run for about 15 minutes to clear the filters.

Membrane housing

O'ring

Membrane housing cap

RO / ECO membrane

Tube

Change stage 1, 2, 3

1 Before filter replacement, please make sure water and electricity supply are cut off. Please turn off the tank

ball valve, too.

2 To loosen filters, turn and rotate clockwise.

3 To tighten filters, turn and rotate anti-clockwise.

Clockwise Anti-clockwise

Change stage 5, 6, 7, 8

1 Before filter replacement, please make sure water and electricity supply are cut off. Please turn off the tank

ball valve, too.

2 Filters carry direction of water flow. Please make sure the correct flow direction during installation.

3 Loosen the quick fitting on both ends to replace the filter.

4 To avoid leakage, please tighten the quick fitting with Teflon tape before filter replacement.

FLOW

1 1

To faucet

To RO membrane

To tank

Type of product

Date of purchase

Name Tel

Address

If the supply cord is damaged, it must be replaced by a special cord or assembly available from

the manufacturer or its service agent.

Warranty

Caution

1. Do not use hot water (over 45 C)!

2. Do not freeze the machine!

3. Switch off electricity and water source if away for more than 5 days, and drain out pure water.

Operation regulation

A. With everything connected, turn on the water check for leaks.

B. Make sure the storage tank shut-off valve is "OFF". Open the sink top faucet.

C. Within a few minutes (up to 15) the water will start to run from the faucet slowly.

D. Let the water run for at least 30 minutes. This flushes the carbon filters on first time use.

E. After initial flushing, open the shut-off valve on the tank and close the sink top faucet.

F. Tank will now full of water (usually 2 to 3 hours) after the tank has filled.

Open the sink top faucet and drain all water until the storage tank is empty and there is only a small flow from the

sink top faucet. *** DO NOT USE FIRST TANK OF WATER.***

G. Close the sink top faucet. The system is now ready for use.

H. Change filters regularly every 6 to 12 months and have the membrane checked annually.

Pure-Pro Water Corporation

19636 S. 97th Ave Mokena, Illinois, U.S.A.

Tel: +1 708 479 4473 Fax: +1 708 479 4332

www.purepro.net

Pure-Pro Reverse Osmosis (RO) Systems

Over ten years expertise in reverse osmosis drinking water systems, our unique design features make

installation easier and operation more reliable, and our wide selection of colors and sizes allows you

to solve virtually any RO application.
