Pure-Pro EC106M Manuel utilisateur

EC106M

PRO

URE

DRINKING WATE R SYSTEM

REVERSE OSMOSIS SYSTEM

PURE-PRO REVERSE OSMOSIS SYSTEM

Type ofproduct

Date of purchase

Name Tel

Address

PRO

URE

DRINKING WATE R SYSTEM

USER'S MANUAL

01 Introduction ofEC106M

02 What isreverse osmosis

03 Components &Selected filters

04 Cartridge filters

05 The parts of EC106M

06 Tubingconnection diagram

07 Installation diagram

08 Change filters

09 Change membrane

10 Operation regulation

13 FAQ

14 Maintenance checkinglist

15 Memo

The functions ofMineral Filter

Thank you verymuch for selectingPure-Pro WaterCorp.

In order to bring the best use of your system, please read

the user's manual carefully before installation and follow

the regulations.

Memo

EC106M

EC106 Upgrade Body Function RO System

PURE-PRO REVERSE OSMOSIS SYSTEM

PRO

URE

DRINKING WATE R SYSTEM

PRO

URE

DRINKING WATE R SYSTEM

Introduction of EC106M

¨EC106M- Upgrade Body Function RO System

Comply with revolutionary advanced technologies, new 6-stage Mineral Filter,

and highly positive performance, EC106M not only can be installed easily, but

activate water molecules and improve health minerals level in our bodies.

EC106M provides with 50 gallons of clear, refreshing water that is not only

healthy to drink, but good for cooking. It's capable of removing over 95% of total

dissolved solids, +99% of all organics and +99% of all bacteria, as well as

reducing the followinghard water contaminantsthat may bepresent in yourwater:

lead, cooper, barium, chromium, mercury, sodium, cadmium, fluoride, nitrite,

nitrate, and selenium.EC106M is thefinest unit ofits class.

Maintenance checking list

EC106 Upgrade Body Function RO System EC106 Upgrade Body Function RO System

Date

Filters

1st stage 2nd stage 3rd stage 4th stage 5th stage 6th stage

Production: 50 GPD/ 189 LPD

Operation pressure: 50-100 PSI

Dimensions: (cm) 37(L) x 20(W) x 48(H) - System

(cm) 28 (L)x 28 (W)x 35 (H)-Tank

Weight: 9kg - system

4 kg -tank

¨Features

100% factory testedand sterilized readyfor installation

3.2 gallons NSFstandards water storagetank

FDA approvedpolypropylene made flatcap housing (doubleO'ring)

Automatic shut-off valve

Mini flow restrictor

Stainless steel checkvalve

Long reach chromefaucet

Feed water connector

Drain saddle valve

Four-color coded 1/4inch tubing forsystem connection

Completely assembled

¨Specifications

Reverse osmosis was originally designed to make sea water drinkable for the

navy. It is ideal for anyone on a low sodium diet. An R.O. membrane has a pore

size much smaller than bacteria virus, or the cryptosporidium parasite. When

functioning properly itwill remove allmicroorganisms from tapwater and produce

sterile water. Reverse osmosis is the reversal of the natural flow of osmosis. In a

water purification system, the goal is not to dilute the salt solution, but to

separate the pure water from the salt and other contaminants. When the natural

osmotic flow isreversed, water fromthe salt solutionis forced topass through the

membrane in the opposite direction by application of pressure-thus the term

REVERSE OSMOSIS. Through this process, we are able to produce pure water

by screening outthe salts andother contaminants.

PURE-PRO REVERSE OSMOSIS SYSTEM

PRO

URE

DRINKING WATE R SYSTEM

PRO

URE

DRINKING WATE R SYSTEM

What is reverse osmosis

Reverse Osmosis

Pressure

Membrane

Water flow

FAQ

EC106 Upgrade Body Function RO System EC106 Upgrade Body Function RO System

Q: What is the guaranteeon the PurePro system ?

The PurePro system (excluding filters) is guaranteed for 1 year for material and

workmanship. All defective parts will be replaced free within the first year under

natural breakdown. The membrane has one year pro-rated guarantee.

Q: What factors affect thequantity and the quality ofthe water production?

There are four major variablesto consider:

1.Pressure-The greater the water pressure, the better water quantity and

quality it produced. Water pressure of 60 PSIis ideal.

2.Temperature-76 F is the ideal water temperature for R.O. 40 F water will

cause the production of R.O. water to fall to half of that at 76 F. The maximum

water temperature recommended is 85 F.

3.Total Dissolved Solids (TDS)-The higher the amount of dissolved

contaminants in the water, the lower the quantity of water produced. A high

level of TOTAL DISSOLVED SOLIDS can be overcome with additional water

pressure.

4.Membrane-Different membranes have different characteristics. Some

produce more water than others; some have better contaminant rejection

capabilities; some have greater resistance to chemical abrasion for longer life.

PurePro system includes TW30-1812-50 The Thin Film Composite (TFC)

membranes combine the best of these characteristics and are considered the

finest membrane in the world.

Q: What is the maintenanceschedule for the PurePro system?

The three pre-filter cartridges should be changed every 6 months. The 5 micron

sediment cartridge filter is the first one; the second is a carbon cartridge filter,

and the third one is a 1 micron sediment filters. (some systems comes with the

Extruded carbon filter.) Failure to change the cartridge every 6 months may

cause chlorine to destroy themembrane.

Q: What does the PureProseries drinking water taste like?

The taste of the PurePro water depends on the amount of contaminants in the

tap water originally. If 95% of dissolved minerals and chemicals are removed,

the R.O. water may taste like distilled water (no minerals), bottled water (low

mineral), or natural spring water(moderate mineral content).

PURE-PRO REVERSE OSMOSIS SYSTEM

T.D.S

UVC-LIGHTING

ULTRAVIOLETWATER STERILIZER

PRO

URE

DRINKING WATE R SYSTEM

Components & Selected filters

Standard faucet 3.2G water storagetank Housing wrench

Deliver-valve Water supplyconnector Drain saddle

¨Selected filters

¨Components

UV water sterilizer

TDS meter

PRO

URE

DRINKING WATE R SYSTEM

Upgraded european

ceramic faucet

EC106 Upgrade Body Function RO System EC106 Upgrade Body Function RO System

Infra-red cartridge filter

The functions of Mineral Filter

Tank ball shut-off valve Tubing

Infra-Red

The mineralized water after the Mineralized filter has perfectly balanced proportions

of minerals necessary for healthy development of the human body. The Mineralized

filter was designedby top specialistsin The Military MedicalAcademy in Taiwan.This

filter improves thequalities of cleanwater by adding necessary health minerals, such

as Calcium, Magnesium, Sodium, Potassium, as well as others readily found inmany

natural mineral waters for proper human development. Mineral filters are mainly

installed with ROsystems to complementtheir absolute filtrationqualities.

Calcium-It is the basic mineral for building teeth and bones. It allows proper

digestion, and is necessary to regulate normal and healthy heart rhythm as well as

good functions ofarteries and muscles.

Magnesium-takes part in over 300 different biochemical functions inside human

bodies. It's a deciding factor for the immune system and proper blood circulation. It

prevents cancer relatedillnesses, atherosclerosis, strokes, and kidney diseasesfrom

happening.

Sodium-It is responsible for controlling the water adsorption and retention of a

human body aswell as properbalance of pH.This is anexcellent moderator ofblood.

Daily absorption ofminerals in waterdoesn't have amajor impact onthe physiological

functions of our body, but it can be a great addition to the regular daily mineral intake

with solid foodsand supplements.

TechnicalSpecifications:

Diameter: 53mm

Length: 254mm

Max. flow rate:250 l/24h

Max. pressure: 6bar

Max. temperature: 51 C

Capacity: 6000 liters

Cations in filteredwater:

Ca : 34mg/l

Mg : 12mg/l

Na : 22mg/l

K : 8.5mg/l

Anions in filteredwater:

CO : 10mg/l

SO : 0.3mg/l

Cl : 0.8mg/l

F-: 0.06mg/l

PURE-PRO REVERSE OSMOSIS SYSTEM

6 Months

2 Years

1 Year

PRO

URE

DRINKING WATE R SYSTEM

Cartridge Filters

Stage 1

Stage3

Stage 2

Block Carbon Filter

Stage 4

TFC Membrane

Stage 5

Post Carbon Filter

Cartridge Filters Filter Description

6 Months

This 5micron sediment filter is made of 100%

pure polypropylene fibers. High capacity filter

removes dusts, particlesand rusts.

This block carbon filter is composed of high-

performance carbon that removes free chlorine,

odor, organic contaminants, pesticides and

chemicals that contributedto taste andodor.

This 1micron sediment filter is made of 100%

pure polypropylene fibers. High capacity filter

removes dusts, particlesand rusts.

Made in USA. High rejection TFCtype membrane

with the capacity of producing 50gallons per day.

This membrane removes the following hardwater

contaminants that may be present in your water:

lead, cooper,barium, chromium, mercury, sodium,

cadmium, fluoride, nitrite,nitrate, and selenium.

NSF approved. Thispost carbon filter is designed

to improve taste. It removes any residual

impurities and odorsfrom the tank and provides a

finer conditioning ofpure water.

5 Micron

Sediment Filter

1 Micron

Sediment Filter

PRO

URE

DRINKING WATE R SYSTEM

A.With everything connected,turn on thewater check forleaks.

B.Make sure the storage tank shut-off valve is "OFF". Open the sink

top faucet.

C.Within a few minutes (up to 15) the water will start to run from the

faucet slowly.

D.Let the water run for at least 30 minutes. This flushes the carbon

filters on firsttime use.

E.After initial flushing, open the shut-off valve on the tank and close

the sink topfaucet.

F.Tank will now full of water (usually 2 to 3 hours) after the tank has

filled. Open the sink top faucet and drain all water until the storage

tank is empty and there is only a small flow from the sink top

faucet.*** DO NOTUSE FIRST TANKOF WATER.***

G.Close the sinktop faucet. The system isnow ready foruse.

H.Change filters regularly every 6 to 12 months and have the

membrane checked annually.

Caution

1.Do not usehot water (over45 C)!

2.Do not freezethe machine!

3.Switch off electricity and water source if away for more than5 days,

and drain outpure water.

Operation regulation

Stage 6

Mineral Filter

This filter improves the qualities of clean water by

adding necessary health minerals, such as Calcium,

Magnesium, Sodium, Potassium, as well as others

readily found in many natural mineralwaters for proper

human development. Mineral filters are mainly

installed with RO systems to complement their

absolute filtration qualities.

EC106 Upgrade Body Function RO System EC106 Upgrade Body Function RO System

Service Life

1 Year

PURE-PRO REVERSE OSMOSIS SYSTEM

PRO

URE

DRINKING WATE R SYSTEM

PRO

URE

DRINKING WATE R SYSTEM

Operation regulation

The parts of EC106M

EC106 Upgrade Body Function RO System EC106 Upgrade Body Function RO System

3 Let the waterrun for atleast 30

minutes. This flushes the carbon

filters on firsttime use.

2 Switch on watertank.

1 Turn onwater source.

ToRO system

Mineral filter

RO membrane housing

Post carbon filter

OUT

The 1st stage housing

The 2nd stage housing

The 3rd stage housing

Post carbon filter

Housing bracket white

RO membrane housing

Auto shut-off valve

Mini flow restrictor

To the 3rdstage

Todrain out tube

To the faucet

To the tank

Input water

PURE-PRO REVERSE OSMOSIS SYSTEM

PRO

URE

DRINKING WATE R SYSTEM

Tubing connection diagram

Faucet

Tank

Drain

Input water

PRO

URE

DRINKING WATE R SYSTEM

Change membrane

EC106 Upgrade Body Function RO System EC106 Upgrade Body Function RO System

Jaco

PRO

URE

DRINKINGWATE RSYSTEM

3Loose the Jaco fitting anticlockwise. 4Remove the membranehousing

cap anticlockwise.

PRO

URE

DRINKINGWATERSYSTEM

5Remove the membrane by a pincer. 6Install the membrane by carefully

pushing the spigotend into the

socket at thefar end ofthe housing

until completely in.

1Turn off water source. 2Switch off water tank.

ToRO system

CONNECTING THE COLORTUBING:

A. Connect theWHITE tubing tothe water supplyconnector.

B. Connect theBLUE tubing tothe sink topfaucet.

C. Connect theBLACK tubing tothe drain saddle.

D. Connect theRED tubing tothe storage tank.

PURE-PRO REVERSE OSMOSIS SYSTEM

07 08

PURE-PRO REVERSE OSMOSIS SYSTEM

Input water : Install water tank:

1.Remove the membrane housing cap.

2.Replace the membrane.

PRO

URE

DRINKING WATE R SYSTEM

ToRO system

Deliver valve

Tofaucet

Towater source pipe

Install faucet : Install drain saddle:

Assemble membrane :

Hand tighten plastic

shut-off valve totank.

Then connect color

tubing.

Drill a 1/4"hole into

the drain pipe.

Mount drain

saddle aligning

holes.

Installation diagram

PRO

URE

DRINKING WATE R SYSTEM

Change filters

EC106 Upgrade Body Function RO System EC106 Upgrade Body Function RO System

Micro Computer Controller

POWER

SOURCEPROCESSFLUSH

FULL

1 Prepare a housingwrench.

5 Put the replacementfilters in the

housings and doubleO'ring.

6 Drain out 1Gallon of waterto

purify replacement filters.

Be sure tightenwith

O-ring to prevent

from leaking.

4 Open housings clockwise with a wrench.

3Switch off water tank.

2Turn off water source.

ToRO system

Table des matières

Autres manuels Pure-Pro Système de filtration d'eau

Pure-Pro

Pure-Pro RS-106M-P Manuel utilisateur

Pure-Pro

Pure-Pro RS-106A-P Manuel utilisateur

Pure-Pro

Pure-Pro ERS-106A Manuel utilisateur

Pure-Pro

Pure-Pro PERFECT WATER Series Manuel utilisateur

Pure-Pro

Pure-Pro EC106PH Manuel utilisateur

Pure-Pro

Pure-Pro EC105 Manuel utilisateur

Pure-Pro

Pure-Pro ERS-105P Manuel utilisateur

Pure-Pro

Pure-Pro ERS-106R Manuel utilisateur

Pure-Pro

Pure-Pro RS4000 Manuel utilisateur

Pure-Pro

Pure-Pro UV-5 1 Manuel utilisateur

Pure-Pro

Pure-Pro JA-568 Manuel utilisateur

Pure-Pro

Pure-Pro ET-PURE Manuel utilisateur

Pure-Pro

Pure-Pro ERO-Q3 Manuel utilisateur

Pure-Pro

Pure-Pro HRO-400 Manuel utilisateur

Pure-Pro

Pure-Pro RO1500 Manuel utilisateur

Pure-Pro

Pure-Pro RO600 Manuel utilisateur

Pure-Pro

Pure-Pro RO103TDS Manuel utilisateur

Pure-Pro

Pure-Pro RS3000R Manuel utilisateur

Pure-Pro

Pure-Pro M100-P Manuel utilisateur

Pure-Pro

Pure-Pro ERS-106MP Manuel utilisateur

Pure-Pro

Pure-Pro AlphaAqua RO105 Manuel utilisateur

Pure-Pro

Pure-Pro RS-105P Manuel utilisateur

Pure-Pro

Pure-Pro HRO-500 Manuel utilisateur

Pure-Pro

Pure-Pro EC106R Manuel utilisateur

Manuels Système de filtration d'eau populaires d'autres marques

Wisy

Wisy LineAir 100 Manuel utilisateur

Schaffner

Schaffner Ecosine FN3446 Series Manuel d'utilisation

Pentair

Pentair FLECK 4600 SXT Guide de l'utilisateur

H2O International

H2O International H20-500 Manuel utilisateur

Renkforce

Renkforce 2306241 Manuel utilisateur

Neo-Pure

Neo-Pure TL3-A502 Manuel utilisateur

FLTR

FLTR OBF Manuel utilisateur

STA-RITE

STA-RITE VERTICAL GRID DE FILTERS S7D75 Manuel utilisateur

Applied Membranes

Applied Membranes W-G844EM Manuel utilisateur

BEGA

BEGA 116 Manuel utilisateur

WATA

WATA Standard Manuel utilisateur

Price

Price FFU series Manuel

Gaggenau

Gaggenau BRITA INTENZA 467873 Manuel utilisateur

Brita

Brita SAFF-100 Manuel utilisateur

HEISSNER

HEISSNER FPU24000-00 Manuel utilisateur

BGS technic

BGS technic 1518 Manuel utilisateur

Reverse Osmosis

Reverse Osmosis RF Series Manuel utilisateur

ubbink

ubbink Filtramax Series Manuel utilisateur
