PSC12010

PSC 12V/1A/55MM power supply

v.2.0

Edition: 12 from 22.05.2023

Supercedes edition: 11 from 20.11.2020

Features:

power output 1 A/12 V DC*

universal supply voltage range ~100 - 240 V

high efficiency 86%

standby power <0,1 W

efficiency class: VI

IP 67 enclosure

protections:

short-circuit protection SCP

surge protection (AC input)

overload protection OLP

warranty –2 years from production date

1. Technical description.

1.1.General description.

The PSU is intended for ~230 V mains supply to CCTV cameras that require stabilised voltage of 12 V DC.

The unit is protected against a short circuit and an overload and a surge.

1.2. Specifications.

Supply voltage

~100 - 240 V; 50/60 Hz

Current consumption

0,3 A

Supply power

12 W max.

Efficiency (average)

86%

Efficiency (10% load)

81%

Output voltage

12 V DC

Output current tAMB<30°C

1 A instantaneous current - refer to chart 1.

Output current tAMB=40°C

0,7 A - refer to chart 1.

Ripple voltage

100 mV p-p max.

Short-circuit protection SCP

electronic, automatic recovery

Overload protection OLP

105-150% of power supply, automatic recovery

IP protection class

IP67

Operating conditions

Temperature: 0oC - 40oC, relative humidity 20%...90%,

without condensation

Dimensions (LxWxH)

50 x 48 x 25 [mm]

Net/gross weight

0,09 / 0,125 [kg]

Protection class EN 62368-1

II (second)

Length of DC cable

0,5 m + plug DC5,5/2,1 female

Length of AC cable

0,3 m

Storage temperature

-20ºC...+60ºC

* In order to extend the life of the power supply, the load current of 0,7 A is recommended.

Chart 1.

Relation between output current and ambient

temperature (instantaneous load).

Fig.1. Mechanical view and dimensions of the PSU.

*Refer to chart 1

1.3. Accessories.

Available accessories for the power supplies are: fuse blocks and cable adapters. For details –visit www.pulsar.pl

2. Installation.

2.1. Requirements.

The power supply shall be mounted by a qualified installer, holding relevant permits and licenses (applicable and

required for a given country) with ~230 V mains supply. Unit should be mounted in confined spaces with normal relative

humidity (RH=90% maximum, without condensing) and temperature from 0°C to +40°C

The device should be installed in the metallic enclosure (cabinet, intended device). In order to meet the LVD and EMC

requirements, the rules concerning: supply, development and shielding ought to be followed - accordingly to the application.

2.2. Installation procedure.

1. Fit the power supply inside the box or other device.

2. Connect the DC cables to the load or to the terminal block.

3. Connect the power supply to the AC line.

4. After tests and operation control are performed, close installation box, case etc. and switch on the power.

3. Maintenance.

Any and all maintenance operations may be performed following the disconnection of the power supply from the power

network. The power supply does not require any specific maintenance procedures, however, in the case of significant level of

dust, it should be cleaned with compressed air.

WEEE LABEL

Waste electrical and electronic equipment must not be disposed of with normal household waste.

According to European Union WEEE Directive, waste electrical and electronic equipment should

be disposed of separately from normal household waste.

Pulsar sp. j.

Siedlec 150,

32-744 Łapczyca, Poland

Tel. (+48) 14-610-19-45

e-mail: [email protected]

http:// www.pulsar.pl
