Pulsar Axion 2 Manuel utilisateur

Axion 2

Manual

Content

Specifications

About the device

Description

Package Contents

Features

Components and Controls

Power supply

Precautions

Recommendations for Battery Use

Battery Charging

Battery Installation

External Power Supply

Getting Started

Powering on and Image Settings

Button Operation

Interface

Status Bar

Quick Menu

Main Menu

Enter the Main Menu

Colour Modes

Smoothing Filter

User Mode

Icon Brightness

PiP Mode

Wi-Fi Activation

Wi-Fi Settings

Microphone

Calibration Mode

General Settings

Defective Pixel Repair

Restore Default Pixel Map

Device Information

Functions

Amplification Level

Video Recording and Photography

Discrete Digital Zoom

PiP Function

Display-Off Function

Wi-Fi Function

Stadiametric Rangefinder

Installing the Device on a Tripod

USB Connection

Software

Stream Vision 2

Firmware Update

Maintenance

Technical Inspection

Technical Maintenance and Storage

Troubleshooting

Legal Compliances and Disclaimers

Specifications

XQ35

Model XQ35

SKU 77478

Microbolometer 

Type uncooled

Resolution, Pixels 384x288

Pixel Pitch, µm 17

Frame Rate, Hz 50

Optical

Characteristics 

Optical

Magnification, x 2

Smooth Digital

Zoom, x 2-8

Digital Zoom, x x1, x2, x4

Lens Focus, mm 35

Relative Aperture,

D/f' 1.0

Minimum Focus

Distance, m/y 5 / 5.47

Eye Relief

Diameter,

mm/inch 4 / 0.16

Angular Field of

View (Horizontal x

Vertical), degree 10.7х8

Linear Field of

View, m at 100 m 18.2

Eyepiece Focus

Range, Dioptre +4 / -5

Detection

Distance for Deer-

Sized Objects, m/y 1300 / 1422

Display 

Type AMOLED

Resolution, Pixels 640x400

Operational

Characteristics 

Power Supply, V 3 - 4.2

Battery

Type/Capacity/Nominal

Output Voltage

APS 5 Li-ion Battery Pack / 4900 mAh / DC

3.7 V

External Power

Supply 5 V, 9 V (USB Type-C)

Battery Run Time

at t=22°C, hours* 11

Degree of

Protection, IP

Code (IEC60529) IPX7

Operating

Temperature

Range, °C / °F -25 … +40 / -13 – +104

Dimensions,

mm/inch 152x50x74 / 5.98x1.97x2.91

Weight (without

battery), kg/oz 0.3 / 10.58

Video Recorder 

Photo/Video

Resolution, Pixels 528x400

Video/Photo

Format .mp4 / .jpg

Built-in Memory 16 GB

Wi-Fi Channel** 

Frequency 2.4/5 GHz

Standard IEEE 802.11 b/g/n/ac

* Actual battery life may vary depending on the use of Wi-Fi and the built-in

video recorder.

** Reception range may vary depending on various factors: obstacles, other

Wi-Fi networks.

XG35

Model XG35

SKU 77476

Microbolometer 

Type uncooled

Resolution, Pixels 640x480

Pixel Pitch, µm 12

Frame Rate, Hz 50

Optical

Characteristics 

Optical

Magnification, x 2.5

Smooth Digital

Zoom, x 2.5-20

Digital Zoom, x x1, x2, x4, x8

Lens Focus, mm 35

Relative Aperture,

D/f' 1.0

Minimum Focus

Distance, m/y 5 / 5.47

Eye Relief

Diameter,

mm/inch 4 / 0.16

Angular Field of

View (Horizontal x

Vertical), degree 12.5х9.4

Linear Field of

View, m at 100 m 21.9

Eyepiece Focus

Range, Dioptre +4 / -5

Detection

Distance for Deer-

Sized Objects, m/y 1750 / 1914

Display 

Type AMOLED

Resolution, Pixels 1024x768

Operational

Characteristics 

Power Supply, V 3 - 4.2

Battery

Type/Capacity/Nominal

Output Voltage

APS 5 Li-ion Battery Pack / 4900 mAh / DC

3.7 V

External Power

Supply 5 V, 9 V (USB Type-C)

Battery Run Time

at t=22°C, hours* 7

Degree of

Protection, IP

Code (IEC60529) IPX7

Operating

Temperature

Range, °C / °F -25 … +40 / -13 – +104

Dimensions,

mm/inch 152x50x74 / 5.98x1.97x2.91

Weight (without

battery), kg/oz 0.3 / 10.58

Video Recorder 

Photo/Video

Resolution, Pixels 1024x768

Video/Photo

Format .mp4 / .jpg

Built-in Memory 16 GB

Wi-Fi Channel** 

Frequency 2.4/5 GHz

Standard IEEE 802.11 b/g/n/ac

* Actual battery life may vary depending on the use of Wi-Fi and the built-in

video recorder.

** Reception range may vary depending on various factors: obstacles, other

Wi-Fi networks.
