PTZOptics Move 4K User Manual

MODEL No.

PT12X-4K-GY, PT12X-4K-WH

PT20X-4K-GY, PT20X-4K-WH

PT30X-4K-GY, PT30X-4K-WH

™

Preface ............................................... 1

Precautions ........................................... 2

Warning............................................... 2

Packing List ........................................... 3

Warranty ............................................. 3

FCC Statement ....................................... 4

Features............................................... 5

Technical Specications............................... 6

Dimensions ...................................... 10

Connection Guide ..................................... 11

Resolution Dial................................... 12

IR Remote Controller Guide ........................... 13

Shortcut Functions ............................... 16

Resetting Your Camera’s IP Address .............. 16

On-Screen Display .................................... 17

Serial Communication Control......................... 21

RS-232 Interface ...................................... 21

RS-485 Interface ...................................... 22

Network Connection .................................. 23

NDI ®| HX3 Connection................................ 26

Web UI ................................................ 27

Serial & IP Command List.............................. 50

Troubleshooting....................................... 63

ptzoptics.com II 1-800-486-5276

™

534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com

Preface

Before installation and usage, please read the manual thoroughly. If you have any

questions or issues with this process, please contact our Support Team.

Precautions

▪Do not subject the camera to rain or moisture.

▪Do not remove the cover. Removal of the cover will void the camera’s warranty and may

cause an electric shock. For any abnormal operation, please contact support@ptzoptics.

com.

▪Never operate outside of the specied operating temperature range or humidity.

▪The power supply included in the box is the only power supply to be used with this cam-

era. To purchase a replacement, please visit ptzoptics.com/where-to-buy/.

▪Please use a soft cloth to clean the unit. If the unit is very dirty, clean it with diluted neutral

detergent; do not use solvents which may damage the surface.

Warning

▪Electrical safety

Installation must be in accordance with national and local electric safety

standards.

▪Polarity of Power Supply

The power supply output for this product is 12V DC with a maximum current

supply of 2A. The polarity of the power supply plug is critical and is as follows:

▪Handling

ŜAvoid subjecting the camera to stress, vibration, or moisture during

transportation, storage, installation, and operation.

ŜDo not lift or move the camera by grasping the camera head. To avoid

mechanical damage, do not turn the camera head by hand.

ŜDo not expose the camera to any corrosive solid, liquid, or gas.

ŜPlease make sure that there are no obstacles in the pan or tilt ranges of the

camera lens.

ŜAfter installation is complete, power on the camera.

ŜDo not dismantle the camera - PTZOptics is not responsible for any

unauthorized modication or dismantling.

3Ver 2.0 A_6/28/2023

™

▪This is an FCC Class-A product. In a domestic environemt, this camera may cause radio

interference. In the event of radio interference, the user may be required to adequately

mitigate it.

▪Remote Control Battery Safety Information:

▪Store batteries in a cool and dry place.

▪Do not throw away used batteries in the trash. Properly dispose of used batteries through

specially approved disposal methods.

▪Remove the batteries if they are not in use for long periods. Battery leakage and corrosion

can damage the remote control.

▪Do not use old batteries with new batteries.

▪Do not mix and use dierent types of batteries: alkaline, standard (carbon-zinc), or re-

chargeable (nickel-cadmium).

▪Do not dispose of batteries in a re. Do not attempt to short-circuit the battery terminals.

Packing List

Please make sure the items below are included in your camera box:

ŜCamera

ŜAC Power Supply

ŜUSB A-A Cable

ŜRS-232C Cable

ŜQuick Start Guide

ŜIR Remote

Ŝ2 AA Batteries

Warranty

PTZOptics includes a limited parts & labor warranty for all PTZOptics manufactured

cameras. The warranty is valid only if PTZOptics receives proper notice of such

defects during the warranty period. PTZOptics, at its option, will repair or replace

products that prove to be defective. PTZOptics manufactures its hardware products

from parts and components that are new or equivalent to new in accordance with

industry-standard practices.

Here is the link to the PTZOptics Hardware Warranty Documentation. This product

has a 5-year warranty.

Covered by one or more claims of

the HEVC patents listed at

patentlist.accessadvance.com.

™

534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com

™

FCC Statement

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

FCC Caution: Any changes or modications not expressly approved by the

party responsible for compliance could void the user’s authority to operate this

equipment. Operation is subject to the following two conditions: This device may

not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

The entire contents of this manual / guide, whose copyright belongs to PTZOptics,

may not be cloned, copied, or translated in any way without the explicit permission

of the company. The product specications referred to in this document are for

reference only and as such are subject to updating at any time without prior notice.

5Ver 2.0 A_6/28/2023

™

Features

• Automatic Tracking

Advanced algorithms to enable auto-tracking in various scenarios such as education,

conferences, and live broadcasts.

• 12X, 20X, 30X Optical Zoom Models

8 million pixel ultra-high resolution 4K telephoto lens in 12X, 20X, or 30X optical

zoom.

• 4K Ultra HD

Next generation SONY UHD CMOS sensor for shooting high quality 4K video at 60

FPS, with the exibililty to adjust numerous other resolutions and frame rates.

• HDMI 2.0

HDMI 2.0, can directly output 4K uncompressed digital video.

• Low Light

CMOS image sensor with ultra-high SNR can reduce image noise in low light.

• 3D Noise Reduction

Produces a clean, clear image even in low light with a signal-to-noise ratio as high as

55db.

• Built in Gravity Sensor

Built in automatic image ip function, convenient for installation.

• Multiple Interfaces

Supports Simultaneous USB 2.0, HDMI 2.0 / 3G-SDI / IP streaming (SRT, RTSP,

RTMP) (HDMI & SDI are not simultaneous)

• Multiple Control Options

Controllable via IR remote, network connection, RS-232, RS-485, and the USB port.

• Tally Light

Features a built-in tally light that shines GREEN to indicate when the camera is in preview

mode. The light shines RED when the camera is on-air. The tally light illuminates when it’s

being used with NDI-compatible video mixing software.

™

534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com

Model PT12X-4K-GY-G3, PT12X-4K-WH-G3

PT20X-4K-GY-G3, PT20X-4K-WH-G3

PT30X-4K-GY-G3, PT30X-4K-WH-G3

Type PTZOptics Move 4K

Description 4K60 PTZ camera with video auto tracking & HDMI, SDI, USB,

NDI & IP video outputs

Resolution & Frame Rate HDMI: 3840x2160p-60/59.94/50/30/29.97/25,

1920x1080p 60/59.94/50/30/29.97/25,

1920x1080i-60/59.94/50, 1280x720p-60/59.94

SDI: 1920x1080p-60/59.94/50/30/29.97/25,

1920x1080i-60/59.94/50, 1280x720p-60/59.

Sensor (12X) Sony 1/2.5 inch, CMOS, Eective pixels: 8.51M

(20X) Sony 1/1.8 inch, CMOS, Eective pixels: 8.42M

(30X) Sony 1/1.8 inch, CMOS, Eective pixels: 8.42M

Scanning Mode Progressive

Lens (12X) f = 4.4mm ~ 52.8mm, F1.8 ~ F2.6

(20X) f = 6.25mm ~ 125mm, F1.58 ~ F3.95

(30X) f = 7.1mm ~ 210mm, F1.61 ~ F5.19

Digital Zoom O (3840x2160), 2X (1920x1080), 3X (1280x720), 4X

(960x540),

8X (480x270), 16X (256x144)

Video Based Auto-Tracking Supported

Minimum Illumination 0.5 Lux @ (F1.8, AGC ON)

Shutter 1/30s ~ 1/10000s

White Balance Auto, Indoor, Outdoor, One Push, Manual, VAR

Backlight Compensation Supported

Digital Noise Reduction 3D Digital Noise Reduction

Technical Specications

7Ver 2.0 A_6/28/2023

™

Video Signal Noise Reduction ≥55dB

Horizontal Field of View (12X).......... 6.9° ~ 72.5°

(20X).......... 3.5° ~ 60.7°

(30X).......... 2.5° ~ 59.2°

Veritical Field of View (12X).......... 3.9° ~ 44.8°

(20X).......... 1.9° ~ 34.1°

(30X).......... 1.4° ~ 34.6°

Horizontal Rotation Range ±170°

Vertical Rotation Range -30° ~ +90°

Pan Speed Range 1.7°/s ~ 100°/s

Tilt Speed Range 1.7°/s ~ 69.9°/s

Image Flip Supported (built-in gravity sensor)

Image Mirror Supported

Image Freeze Supported

POE+ Supported

USB Specications

Operating System Windows 7 / 8.1 / 10 / 11 / Mac OS, Linux, Android

Color System/Compression YUY2 / MJPEG / H.264 / H.265

Video Format ▪YUY2: Max resolution: 3840x2160pp@5

▪MJPEG: Max resolution: 3840x2160p@30

▪H.264 AVC: Max resolution: 3840x2160p@30

▪H.265: Max resolition: 3840x2160p@30

USB Audio Supported

UVC Version UVC 1.1 ~ 1.5

UVC Control Supported

534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com

™

IP Video Specications

Video Compression H.264, H.265, MJPEG

Video Stream First Stream, Second Stream

First Stream Resolutions 3840x2160, 1920x1080, 1280x720, 1024x576,

720x480, 720x408, 640x480, 640x360

Second Stream Resolutions 720x480, 720x408, 640x480, 640x360, 480x320,

320x240

Video Bitrate First Stream: 32kbps ~ 102400kbps

Second Stream: 32kbps ~ 20480kbps

Bit Rate Type Constant Bit Rate (CBR), Variable Bit Rate (VBR)

Frame Rate 50Hz: 1 ~ 50 fps

60Hz: 1 ~ 60 fps

Audio Comppression AAC

Audio Bit Rate 96kbps, 128kbps

Supported Protocols TCP/IP, UDP, HTTP, RTSP, RTMP/RTMPS, ONVIF, SRT,

Multicast, etc.

Input & Output Interface

HD Output ▪1x RJ45: 10/100/1000M Adaptive Ethernet Port

▪1x HDMI: version 2.0

▪1x USB 2.0: type A

▪1x 3G-SDI: BNC type, 800mVP-p, 75Ω, Along to SMPTE

424M standard

Audio Interface ▪1x 3.5mm Line level Input

▪1x 3.5mm Line level Output

™

Communication Interface ▪1x 8-pin Mini DIN RS232 Input, Max distance: 98.5ft / 30m,

Protocol: VISCA / Pelco-D / Pelco-P

▪1x 8-pin Mini DIN RS232 Output, Max distance: 98.5ft / 30m,

Protocol: VISCA / Pelco-D / Pelco-P

▪1x 2-pin Phoenix port RS485 Input / Output, Max distance:

3,937ft / 1200m, Protocol: VISCA / Pelco-D / Pelco-P

IR 4x IR Addresses, Max distance 30ft / 9m

Power Jack JEITA Type (DC IN 12V)

Physical Parameter

Input Voltage DC 12V / PoE+(802.3af)

Current Consumption Max 2A

Operating Temperature 14°F ~ 104°F (-10°C ~ 40°C)

Storage Temperature -40°F ~ 140°F (-40°C ~ 60°C)

Humidity Range 10% - 80%

Power Consumption Max 18W

Size in. (W x D x H) (12X) 5.57” W x 5.94” (6.65 including SDI) D x 6.93” (7.91” with tilt

up) H

(20X) 5.57” W x 5.94” (6.65 including SDI) D x 6.93” (7.91”

with tilt up) H

(30X) 6.69” W x 7.12” (7.75 with SDI) D x 8.98” (10.5” with tilt

up) H

Size mm. (W x D x H) (12X) 141.5 W x 151 (169 including SDI) D x 176 (201 with

tilt up) H mm

(20X) 141.5 W x 151 (169 including SDI) D x 176 (201 with

tilt up) H mm

(30X) 170 W x 181 (196.85 including SDI) D x 228 (266.7

with tilt up) H mm

Camera Weight (12X) 3.25 lbs | 1.47 kg

(20X) 3.25 lbs | 1.47 kg

(30X) 4.41 lbs | 2.0 kg

Autres manuels pour Move 4K

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels PTZOptics Caméra de sécurité

PTZOptics

PTZOptics PTZOptics 20x NDI HX ZCAM Manuel utilisateur

PTZOptics

PTZOptics EPTZ NDI HX ZCAM G2 Manuel utilisateur

PTZOptics

PTZOptics ZCAM G2 Manuel utilisateur

PTZOptics

PTZOptics PT20X-USB-GY-G2 Manuel utilisateur

PTZOptics

PTZOptics PTVL-NDI-ZCAM Manuel utilisateur

PTZOptics

PTZOptics PT12X-NDI-GY Manuel utilisateur

PTZOptics

PTZOptics PT12X-SE-GY-G3 Manuel utilisateur

PTZOptics

PTZOptics PT12X-SDI-WH-G2 Manuel utilisateur

PTZOptics

PTZOptics PT12X-NDI-GY-G2 Manuel utilisateur

PTZOptics

PTZOptics EPTZ-ZCAM-G2 Manuel utilisateur

PTZOptics

PTZOptics PT-WC-G1 Fiche technique

PTZOptics

PTZOptics PT12X-NDI-ZCAM Manuel utilisateur

PTZOptics

PTZOptics Move PT12X-4K-GY Manuel utilisateur

PTZOptics

PTZOptics Link PT12X-LINK-4K-GY Manuel utilisateur

PTZOptics

PTZOptics PT20X-NDI-GY Manuel utilisateur

PTZOptics

PTZOptics PTEPTZ-ZCAM-G2 Manuel utilisateur

PTZOptics

PTZOptics PT12X-USB-GY-G2 Manuel utilisateur

PTZOptics

PTZOptics PT30X-SDI-GY-G2 Manuel utilisateur

PTZOptics

PTZOptics PTEPTZ-NDI-ZCAM-G2 Manuel utilisateur

PTZOptics

PTZOptics Move 4K Manuel utilisateur

PTZOptics

PTZOptics PT20X-USB-GY-G2 Manuel utilisateur

PTZOptics

PTZOptics NDI HX ZCAM G2 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
