3300 NON-ADDRESSABLE

FIRE ALARM CONTROL PANEL

INSTALLATION, COMMISSIONING AND

MAINTENANCE MANUAL

www.acornfiresecurity.com

93-530-70 Issue 0 Page 2 of 44 © Protec Fire Detection PLC 2007

Document Revision Details

Issue Modification Detail Author Date

0 Document Creation NH 12/02/07

www.acornfiresecurity.com

93-530-70 Issue 0 Page 3 of 44 © Protec Fire Detection PLC 2007

Table of Contents

1.0 3300 SYSTEM OVERVIEW ..........................................................................................................5

2.0 IMPORTANT NOTES – PLEASE READ ......................................................................................6

3.0 ITEMS SUPPLIED WITH THE 3300 PANEL................................................................................6

4.0 CABLING REQUIREMENTS ........................................................................................................7

4.1 Detector, Alarm and Auxiliary Wiring .....................................................................................7

4.2 Mains Wiring...........................................................................................................................7

5.0 INSTALLATION PROCEDURE ....................................................................................................8

6.0 TESTING OF CABLING PRIOR TO CONNECTION..................................................................11

7.0 DETECTOR CIRCUIT CONNECTIONS......................................................................................11

8.0 ALARM CIRCUIT CONNECTIONS ............................................................................................12

9.0 AUXILIARY INPUT AND OUTPUT WIRING ..............................................................................13

9.1 Keyswitch Input ....................................................................................................................13

9.2 Remote Alarm Input .............................................................................................................13

9.3 Class Change Input..............................................................................................................13

9.4 Global Fault Output ..............................................................................................................13

9.5 Global Fire Output ................................................................................................................13

10.0 REPEAT PANEL WIRING ..........................................................................................................14

11.0 INTERNAL EXPANSION PORT .................................................................................................15

12.0 COMMISSIONING.......................................................................................................................16

12.1 Connecting the Mains...........................................................................................................16

12.2 Installing and Connecting The Standby Batteries ................................................................17

12.3 Switching On ........................................................................................................................17

13.0 PROGRAMMING OVERVIEW ....................................................................................................18

13.1 Access Levels.......................................................................................................................18

13.2 Zone Programming Choices.................................................................................................19

14.0 PROGRAMMING DETAILS ........................................................................................................20

14.1 PROGRAMMING ZONE DISABLEMENTS................................................................................20

14.2 Programming Alarm Disablements ..................................................................................21

14.3 Programming Zone Delays................................................................................................22

14.4 Programming Zones into Test Mode ................................................................................23

14.5 Programming Coincidence Zones ....................................................................................24

14.6 Programming Non-Latching Zones ..................................................................................25

14.7 Programming Expansion Interface Node Information....................................................26

15.0 OVERRIDING SYSTEM DELAYS ..............................................................................................27

16.0 DISABLING THE FIRE LINK INTERFACE ................................................................................28

17.0 DELAYING FIRE LINK ACTIVATIONS ......................................................................................29

18.0 PSU MONITORING TYPE SET-UP ............................................................................................30

www.acornfiresecurity.com

93-530-70 Issue 0 Page 4 of 44 © Protec Fire Detection PLC 2007

19.0 PROGRAMMING END OF LINE TYPE ......................................................................................30

20.0 PROGRAMMING PULSING ALARMS.......................................................................................31

21.0 FAULT DIAGNOSIS FEATURES ...............................................................................................31

22.0 3300 SOFTWARE VERSION DISPLAY .....................................................................................32

23.0 DETECTOR ZONE FAULT DETAILS.........................................................................................33

24.0 ALARM FAULT DETAILS ..........................................................................................................34

25.0 SYSTEM FAULT DETAILS.........................................................................................................35

26.0 POWER SUPPLY FAULT DETAILS ..........................................................................................36

27.0 FAULT RECTIFICATION GUIDELINES .....................................................................................37

28.0 3300 TECHNICAL SPECIFICATION ..........................................................................................38

29.0 3300 FEATURES SPECIFICATION ...........................................................................................39

30.0 APPENDIX 1. ACCESSORIES AVAILABLE FOR THE 3300. ..................................................40

31.0 APPENDIX 2. 3300 SPARES LIST.............................................................................................41

32.0 APPENDIX 3. DECIMAL TO BINARY CONVERSION CHART.................................................42

33.0 APPENDIX 4. 3300 MAIN PCB DETAILS..................................................................................43

34.0 APPENDIX 5. 3300 PROGRAMMING QUICK REFERENCE GUIDE .......................................44

www.acornfiresecurity.com

93-530-70 Issue 0 Page 5 of 44 © Protec Fire Detection PLC 2007

1.0 3300 System Overview

The main features of the Protec 3300 Fire Alarm system are:

•Four and eight detector zone models available.

•Four monitored alarm circuits rated at 150mA each.

•Common negative (allowing three wire operation).

•Manual call point activation can override zone delays.

•Re-sounding of outputs if a zone changes from automatic to manual activation.

•Three auxiliary inputs, Keyswitch, Class Change and Remote Alarm.

•Global Fire and Global Fault clean contact connections.

•Monitored Auxiliary 24V output (Overload Protected, 100mA maximum).

•Programmable capacitive or resistive detector circuit end of line monitoring.

•Extensive range of engineering functions, accessed via a 5 digit code entry or key-switch

activation.

•Delays to zones.

•Disablement of zones.

•Coincidence Operation.

•testing of zones.

•Non-latching zones.

•Disablement of alarm circuits.

•Disablement of fire link output.

•Comprehensive fault diagnosis features.

•Expansion outputs to drive one fire link interface and one eight way zonal mimic interface.

•Repeat panel output to drive up to eight 3300 Repeat Panels, no extra driver board is required.

•All interfaces supported as standard.

•Low quiescent current of 15mA (24V dc supply, mains fail fault, no external equipment).

Note: Due to a policy of continuous improvement Protec Fire Detection PLC reserve the right to alter

the specification without prior notice.

www.acornfiresecurity.com

93-530-70 Issue 0 Page 6 of 44 © Protec Fire Detection PLC 2007

2.0 Important Notes – PLEASE READ

•THE FIRE ALARM PANEL AND ITS ASSOCIATED CONNECTIONS MUST BE INSTALLED,

COMMISSIONED AND MAINTAINED BY A SUITABLY SKILLED AND COMPETENT PERSON.

•THIS EQUIPMENT MUST BE EARTHED.

•THIS EQUIPMENT IS NOT GUARANTEED UNLESS INSTALLED AND COMMISSIONED IN

ACCORDANCE WITH CURRENT NATIONAL STANDARDS.

•THIS EQUIPMENT HAS BEEN DESIGNED AND MANUFACTURED TO CONFORM WITH

THE REQUIREMENTS OF ALL APPLICABLE EU COUNCIL DIRECTIVES.

•THIS MANUAL MUST BE THOROUGHLY READ AND UNDERSTOOD BEFORE

INSTALLATION AND COMMISSIONING OF THIS EQUIPMENT IS UNDERTAKEN.

3.0 Items Supplied with the 3300 panel

•Installation, commissioning and maintenance manual.

•User manual.

•Mounting template.

•Accessory pack, comprising:

•8 x 100µF/22Ωdetector circuit end of line units (41-804-52)

•4 x 10kΩalarm circuit end of line units (41-800-48)

•1 x red battery lead (41-791-64)

•1 x black battery lead (41-790-63)

•1 x inter-battery connection lead (41-796-44)

•1 x 1A HRC power supply fuse (15-131-35)

•1 x 1.6A battery fuse (15-055-40)

www.acornfiresecurity.com

93-530-70 Issue 0 Page 7 of 44 © Protec Fire Detection PLC 2007

4.0 Cabling Requirements

4.1 Detector, Alarm and Auxiliary Wiring

All external wiring associated with the system must conform to the current I.E.E Regulations and

cabling must conform to the relevant BS specifications. ECA recommended Cable Separation for

Electromagnetic Compatibility in Buildings must be followed.

To comply with EMC regulations Protec recommends the use of screened cabling throughout the

installation. The screens must be securely connected to the screwed earthing studs provided inside

the 3300 enclosure.

Screened cables that are suitable for wiring are:

MICC (PyroTM), Pirelli FP200TM, FireTuffTM, or any other cable which complies with BS 6387

(categories C, W, Z).

Proper glanding of the cable is vital to the correct performance of the system.

4.2 Mains Wiring

The 3300 requires a mains supply exclusive to the panel that uses fixed three core wiring (between

0.75mm2and 2.5mm2) which is fed from a double pole isolating fused spur, fused at 3A.

Unauthorised operation of the mains supply should not be allowed and the fused spur should be

labelled “FIRE ALARM: DO NOT SWITCH OFF”

www.acornfiresecurity.com

93-530-70 Issue 0 Page 8 of 44 © Protec Fire Detection PLC 2007

5.0 Installation Procedure

The 3300 fire alarm panel circuit boards are housed in a plastic enclosure. When the front is removed

from the panel the circuit boards and the batteries are fully accessible. The panel can still be

controlled even though the front has been removed.

The panel can be surface or flush mounted.

The panel must be located internally in an area that is not subject to dampness, extremes of

temperature or physical abuse. The environmental limits are given in section 21.0

1) Unpacking

After opening the box remove the installation template and spares pack from the packaging,

leaving the 3300 in the cardboard box for protection.

2) Preparing the Mounting Position

Use the installation template in conjunction with a spirit level to mark out the fixing locations

for the panel. Drill and plug the mounting holes previously marked.

3) Removal of the Door

Remove the 3300 unit from the packaging. Remove the two screw covers from the lower two

corners of the front door and unscrew the two front door fixing screws.

Swing the door upward from the bottom and lift away, see figure 5.0.

Put all removed parts in a safe, dry place.

Figure 5.0 – Removing the door from a 3300.

www.acornfiresecurity.com

93-530-70 Issue 0 Page 9 of 44 © Protec Fire Detection PLC 2007

4) Removal of the Main PCB.

NOTES ON ANTI-STATIC HANDLING OF THE PCBs

Before handling any of the circuit boards in the 3300 it is vital that any operatives

discharge themselves of any static charge that may have built up on them. This can be

done by momentarily touching a solid earth point (a non-painted part of a radiator, for

example).

Handle the PCBs by their sides and DO NOT touch the electronic components on them.

The PCB should be stored in a clean, dry place away from the place of work. Retain the

PCBs in a cardboard box for safety until they are required.

Disconnect the 3 way connector from the main PCB, taking care not to strain the connector or

the PCB. Leave the connector attached to the Power Supply PCB.

Unscrew and remove the two mounting screws on the main PCB. Carefully slide the Main

PCB upward (stage 1) and lift away from the plastic enclosure (stage 2). See figure 5.1.

Store all screws and PCBs in a safe, dry place.

Figure 5.1 – Removal of the 3300 Main PCB.

PCB fixing screw

Stage 1

Stage 2

3 way power

connector

PCB fixing screw

www.acornfiresecurity.com

5) Preparing and Fixing the Panel Back-box

The mains cable entry position should be kept away from other system cabling.

Carefully knock out the required cable entry positions and mount the enclosure at the position

prepared in (2) whilst feeding the cables into the enclosure.

6) Refitting the Main PCB

Note: Before re-fitting the main PCB the mains power connections to the Power Supply

PCB should be connected. See section 12.0.

DO NOT SWITCH MAINS POWER ON AT THIS POINT !!

Route the battery cables through to the battery compartment using the channels provided.

Replace the Main PCB (a reversal of removal), ensuring it is pushed fully down to the bottom

edge of the panel. Secure with the two screws removed previously. Take care not to over

tighten the screws.

Re-connect the three way cable from the Power Supply to the Main PCB, do not use undue

pressure and ensure the cable is clipped into the locking ramp on the PCB header securely.

7) Re-fitting the Door

Replace the plastic door by offering the top of the door up to the groove at the top of the

plastic back-box.

Swing the door down and ensure it pushes fully home into the back-box, without fouling the

rubber keypad or light-guides on the main PCB. See figure 5.3 for details.

Tighten the two screws in the lower two corners of the door, and replace the screw covers.

Figure 5.3 – Refitting the 3300 Door.

www.acornfiresecurity.com

Ce manuel convient aux modèles suivants

Table des matières

Manuels Panneau de contrôle populaires d'autres marques

RDZ

RDZ PC-HRX Manuel utilisateur

STG-BEIKIRCH

STG-BEIKIRCH MZ3 Manuel technique

Efka

Efka Variocontrol V810 Manuel utilisateur

Cebora

Cebora 208-10 Manuel utilisateur

AMX

AMX AutoPatch CP-15 Manuel utilisateur

Satel

Satel CA-6 KLED-S Manuel utilisateur

Evolution

Evolution IQ plus 800 Manuel utilisateur

Fagor

Fagor 8040 TCO CNC Manuel utilisateur

Trane

Trane ComfortLink II XL950 Control Manuel utilisateur

AKO

AKO PROCool AKO-17635-2 Manuel utilisateur

ABB

ABB 6136/30M-101 Manuel utilisateur

Telikou

Telikou BK-603 Belt Pack Manuel utilisateur

Mapei

Mapei Mapeheat Thermo Touch Manuel utilisateur

Bosch

Bosch D9412GV4 Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries SC-SL4-AE2/1 Manuel utilisateur

Sminn

Sminn BOX L VF1L EI Manuel utilisateur

Balboa

Balboa TP600 Manuel utilisateur

Nice

Nice HSCU1 Caractéristiques techniques
