PSC Falcon 4620 Manuel utilisateur

)DOFRQ



:LQGRZV

9HKLFOH0RXQW&RPSXWHU

8VHUV*XLGH

R44-2394.book Page 0 Tuesday, December 23, 2003 10:02 AM

PSC Inc.

959 Terry Street

Eugene, Oregon 97402

Telephone: (541) 683-5700

Fax: (541) 345-7140

cedures described therein may be reproduced or transmitted in any form or by any means without prior written permission of

PSC Inc. or its wholly owned subsidiaries (“PSC”). Owners of PSC products are hereby granted a non-exclusive, revocable

license to reproduce and transmit this documentation for the purchaser's own internal business purposes. Purchaser shall not

remove or alter any proprietary notices, including copyright notices, contained in this documentation and shall ensure that all

notices appear on any reproductions of the documentation.

Should future revisions of this manual be published, you can acquire printed versions by contacting PSC Customer Administra-

tion. Electronic versions will either be downloadable from the PSC web site (www.pscnet.com) or provided on appropriate

media. If you visit our web site and would like to make comments or suggestions about this or other PSC publications, please let

us know via the “Contact PSC” page.

Disclaimer

Reasonable measures have been taken to ensure that the information included in this manual is complete and accurate. How-

ever, PSC reserves the right to change any specification at any time without prior notice.

PSC is a registered trademark of PSC Inc. The PSC logo is a trademark of PSC. All other trademarks and trade names referred

to herein are property of their respective owners.

Falcon®is a registered trademark of PSC Inc. and of its wholly owned subsidiaries.

Microsoft®Windows®, Windows®2000, and Windows®XP, are registered trademarks of Microsoft Corporation.

R44-2394.book Page 1 Tuesday, December 23, 2003 10:02 AM

8VHU¶V*XLGH 

L

7DEOHRI&RQWHQWV

$ERXWWKLV*XLGH  

+RZWR8VH7KLV0DQXDO 

'RFXPHQW2YHUYLHZ 

'RFXPHQW&RQYHQWLRQV 

0RXVH6W\OXV$FWLRQV

HJLVWHULQJ<RXU36&3URGXFW 

*HWWLQJ6WDUWHG  

2YHUYLHZ 

3RZHULQJWKH)DOFRQ 

7XUQLQJWKH8QLW2Q

3RZHU6XSSO\ 

7XUQLQJWKH8QLW2II 

HERRWLQJWKH)DOFRQ 

%DFNXS%DWWHU\

8VLQJWKH7RXFKVFUHHQ

&DOLEUDWLQJWKH7RXFKVFUHHQ 

$GMXVWLQJWKH%ULJKWQHVV 

&RQILJXULQJWKH)DOFRQ 

&RPPXQLFDWLQJZLWKWKH1HWZRUN 

0DLQWHQDQFH

7HFKQLFDO6SHFLILFDWLRQV 

%DVLF6\VWHP 

8SJUDGH2SWLRQV)DFWRU\2QO\  

R44-2394.book Page i Tuesday, December 23, 2003 10:02 AM

LL DOFRQ





.H\ERDUG6SHFLILFDWLRQV  

&RPPHUFLDO*UDGH.H\ERDUG  

XJJHG1(0$.H\ERDUG6WDQGDUG 

6HWWLQJXSDQG&RQILJXULQJD3RZHU6FDQ 

2YHUYLHZ  

36&3RZHU6FDQ )3URGXFW2YHUYLHZ  

&RQQHFWLQJ$3RZHU6FDQWRWKH)DOFRQ  

6HWXSIRU.H\ERDUG:HGJH,QWHUIDFH 

$FFHVVRULHVDQG3HULSKHUDOV 

2YHUYLHZ  

0RXQWLQJ6\VWHPV 

.H\ERDUGV 

XJJHG1(0$;.H\ERDUG6WDQGDUG 

&RPPHUFLDO*UDGH.H\ERDUG  

2Q6FUHHQ9LUWXDO.H\ERDUG  

6W\OXV

)$FFHVVRULHV  

2WKHU$FFHVVRULHV 

R44-2394.book Page ii Tuesday, December 23, 2003 10:02 AM

8VHU¶V*XLGH 

&KDSWHU

$ERXWWKLV*XLGH

+RZWR8VH7KLV0DQXDO

This User’s Guide contains instructions for using the PSC®Falcon®4620

Vehicle Mount Computer (VMC), including configuration, and use of its

software, peripherals, and accessories. It assumes the computer has been

installed and is ready for use. For full instructions on installation of the com-

puter, reference the Installation Guide packaged with the unit. Other publica-

tions and important updates for this product can be downloaded from the

PSC website listed on the back cover of this manual.

'RFXPHQW2YHUYLHZ

This section of the manual provides an overview of the manual’s contents and

organization:

• This first chapter, “About this Guide” provides an overview of the man-

ual contents and document style conventions.

•Chapter

2, “Getting Started” on page 5, discusses powering up the com-

puter, working with the Touchscreen, and setting up a mouse.

• Refer to Appendix A, “Technical Specifications", on page 11, for specifi-

cations of the computer.

• Refer to Appendix B, for information on “Setting up and Configuring a

PowerScan” with the computer.

• Refer to Appendix C, “Accessories and Peripherals" for a list of all avail-

able accessories, peripherals, and their specifications, on page 19.

R44-2394.book Page 1 Tuesday, December 23, 2003 10:02 AM

$ERXWWKLV*XLGH

DOFRQ





'RFXPHQW&RQYHQWLRQV

Formatting conventions are used throughout this guide to provide a consistent

method for representing the user interface and vehicle mount computer mate-

rial. This guide also provides special conventions for information of high inter-

est, in the form of notes, cautions, and warnings.

1RPHQFODWXUH

For the purposes of this manual, the PSC®Falcon®4620

Vehicle Mount Computer may be referred to as the computer, the VMC, or

the unit.

.H\VWURNHV

Filenames, file paths, field selections from a pull-down list, and

data or keystrokes entered by the user are shown in this monospaced type-

face.

:LQGRZV&RQWUROV

Windows controls including task bar icons, menubar

sequences, prompts, dialog boxes, fields, pull-down lists, checkboxes and

radio-buttons are printed in this bold typeface.

Notes appear throughout the manual to provide additional information on a topic,

including technical details, exceptions to instructions and other pertinent

information. These notes are identified by the notepad symbol to the left.

CAUTION

‘CAUTION’ blocks inform you that proper handling (adherence to the procedures

described) is required to avoid damage to equipment and/or property.

WARNING

‘WARNING’ blocks alert you to potential physical harm or injury.

R44-2394.book Page 2 Tuesday, December 23, 2003 10:02 AM

HJLVWHULQJ<RXU36&3URGXFW

8VHU¶V*XLGH 

0RXVH6W\OXV$FWLRQV

Your computer may come with an integrated keyboard mouse (on a NEMA4

keyboard) and/or a stylus. This section describes actions that you take with the

mouse or the stylus and how they are referred to in this manual.

6HOHFW&OLFNRU7DS

Press and immediately release the left mouse button

without moving the mouse or tap with the stylus and release. Clicking and

tapping are used to select specific buttons on various forms and tables.

'RXEOH&OLFN'RXEOH7DS

Click the left mouse button twice in rapid suc-

cession or tap twice with the stylus. Used to initiate an application.

5LJKW&OLFN7DSDQG+ROG

Press and hold the right mouse button without

moving the mouse or tap and hold the stylus to view the context menu.

5HJLVWHULQJ<RXU36&3URGXFW

PSC values your feedback. Please take a few moments and complete the Prod-

uct Registration form located on PSC’s website. Registering your products

ensures that you will be informed of the latest product news, software updates

and other future developments from PSC.

Never use a pen, pencil, or other sharp object on the computer’s touchscreen display.

Use only a PSC accessory stylus or other plastic-tipped pens intended for use with a

touchscreen-sensitive display. Order or replace a missing stylus from your

authorized dealer.

R44-2394.book Page 3 Tuesday, December 23, 2003 10:02 AM

$ERXWWKLV*XLGH

DOFRQ





127(6

R44-2394.book Page 4 Tuesday, December 23, 2003 10:02 AM

8VHU¶V*XLGH 

&KDSWHU

*HWWLQJ6WDUWHG

2YHUYLHZ

The Falcon®4620 is a Vehicle Mount Computer, to which you can attach

numerous peripheral devices for data collection. When the Falcon 4620 has

been attached to its mounting bracket and the peripherals and accessories have

been connected (as instructed in the Installation Guide), the system is ready

for use.

This chapter provides descriptions of the basic unit, peripherals, and basic

configuration information:

• “Powering the Falcon 4620”, below

• “Using the Touchscreen” on page 7.

• “Configuring the Falcon 4620” on page 9.

• “Communicating with the Network” on page 9.

3RZHULQJWKH DOFRQ

The following sections cover information on turning the unit on, power sup-

ply, backup battery, rebooting the unit, and turning it off.

Unless you have ordered a custom system, your Falcon 4620 comes from the

factory with either Windows®



2000, Windows®XP Embedded, or Win-

dows®XP Professional operating system installed.

7XUQLQJWKH8QLW2Q

CAUTION

During certain conditions, the power drain from a vehicle’s power source may cause

the voltage level to drop below 10V. A delay timer filter or available external UPS unit

may be necessary. Refer to the pricebook at www.pscnet.com for accessories and

peripherals.

R44-2394.book Page 5 Tuesday, December 23, 2003 10:02 AM

*HWWLQJ6WDUWHG

DOFRQ





LJXUH 3RZHUDQG'LPPHU%XWWRQV

1. Turn the power on by pressing the power button, illustrated above.

2. When the start-up sequence is complete, the system is ready for use.

Upon initial boot-up the Falcon 4620 will go through the calibration

sequence. Refer to “Calibrating the Touchscreen” on page 7for more

information.

3. You can now open and run the desired applications.

3RZHU6XSSO\

Power is supplied by the vehicle to which it is mounted, or an external AC

power supply. PSC provides the following four power accessories:

Refer to page 25 for more information on power supplies.

7XUQLQJWKH8QLW2II

1. Close all applications.

2. Select Start > Shut down.

3. When It is now safe to turn off your computer dialog opens, press and hold

the power button for seven (7) seconds or until the screen goes blank.

Dimmer Buttons

Power Button

Power Cable with Bare leads 8 foot long (One bare leads power cord is included with the

unit when ordered.)

Power Supply 110/220 VAC Power supply (70w)

DC to DC Power Converter DC to DC Converter (18VDC - 72 VDC for vehicles > 24

volts.)

DC/DC Delay Timer/Filter DC/DC Delay Timer/Filter

R44-2394.book Page 6 Tuesday, December 23, 2003 10:02 AM
