INSTALLATION MANUAL

PAA29+

INSTALLATION MANUAL: PAA29+ V 1.4 (07/2011) 2

Imprint

All ri hts reserved

Ronda Gu lielmo Marconi 4.

Parque Tecnoló ico.

46980 Paterna (Valencia)

Spain

Printed in Spain, issue September

2009

This operatin manual even in

extracts may only be reprinted or

otherwise copied with special,

written permission from Proyecson

S.A.

Editor responsible for the contents:

Proyecson S.A.

Editin and layout:

Proyecson S.A.

Ronda Gu lielmo Marconi 4

Parque Tecnoló ico

46980 Paterna (Valencia)

Spain

INSTALLATION MANUAL: PAA29+ V 1.4 (07/2011) 3

TABLE OF CONTENTS

1. SAFETY ..............................................................................................5

1.1

GENERAL 5

1.2

INSTALLATION 5

1.3

PROPER USE 6

2. INTRODUCTION .................................................................................7

3. FEATURES ..........................................................................................8

4. FRONTAL PANEL ..............................................................................10

5. REAR PANEL.....................................................................................11

6. CONNECTION PROCEDURE ...............................................................12

6.1

CONNECTION TO A DOLBY SERVER 12

6.2

CONNECTION TO A DOREMI SERVER OVER ETHERNET 15

6.3

CONNECTION TO A DOREMI SERVER USING THE SERIAL PORT 17

6.4 CONNECTION TO A DOREMI SERVER USING THE GPIO PORT 19

7. CONFIGURATION OF THE PAA29+ ETHERNET PORT........................20

7.1 OVER A TCP/IP CONNEXION 20

7.1.1 CONFIGURE THE ETHERNET FOR A DOREMI SERVER 23

7.2. THROUGH A RS232 CONNECTION 25

8. SER ERS CONFIGURATION ..............................................................28

8.1. SERVER SELECTION IN THE PAA29+ 28

8.2. DOLBY SERVER CONFIGURATION 28

8.3 DOREMI SERVER SET-UP 31

8.3.1 ADD THE PAA29+ TO THE SERVER 31

8.3.2 SETUP THE OUTPUT CUES (NON-LIBRARY METHOD) 33

8.3.3 SETUP THE OUTPUT CUES USING PAA29+ XML LIBRARY 36

8.3.4 SETUP THE INPUT CUES USING PAA29+ XML LIBRARY 40

9. OUTPUTS / INPUTS OF THE PAA29+................................................43

9.1. OUTPUT 1 CONNECTOR: 43

9.2 OUTPUT 2 CONNECTOR: 44

9.3 OUTPUT 3 CONNECTOR: 45

9.4 INPUT CONNECTOR: 46

INSTALLATION MANUAL: PAA29+ V 1.4 (07/2011) 4

9.5 EXAMPLES OF INPUT CONNECTION: 47

9.5.1 INPUT WITH A NEGATIVE COMMON: 47

9.5.2

INPUT WITH A POSITIVE COMMON: 48

10. NOTES............................................................................................49

10.1 FIRMWARE VERSIONS 49

11. ELECTRICAL PROPERTIES ..............................................................49

12. DIMENSIONS .................................................................................50

APPENDIX A: SERIAL COMMANDS FOR DOLBY.....................................51

APPENDIX B: COMMANDS FOR DOREMI SER ERS................................53

INSTALLATION MANUAL: PAA29+ V 1.4 (07/2011) 5

1. SAFETY

1.1 GENERAL

IMPORTANT: READ THIS MANUAL ALONG WITH THE MANUAL OF

EACH PART OF THE POWER SUPPLY.

•Never modify or handle the mechanical or electrical safety devices

installed in the power supply.

•Do not chan e or modify in any way the ori inal desi n of the power

supply.

•If the power supply does not work properly, stop at once and notify the

installer service.

•In case of an eventual repair, leave it in the hands of the distributor who

installed it.

•Always use ori inal spare parts and accessories, which must be installed

by an authorized installer.

1.2 INSTALLATION

•Do not handle the electrical system of the power supply. It must be

installed by an authorized technician.

•Installation must be done in conformity with the operatin manual and

the local security norms. The customer and the installer take

responsibility for the non-compliance of the norms.

•Before startin , verify the line connections, as well as the earth

connection and/or differential and ma neto-thermic switches. There

could be an electrical dischar e if you don’t follow the above-mentioned

procedure.

INSTALLATION MANUAL: PAA29+ V 1.4 (07/2011) 6

1.3 PROPER USE

•Do not use this power supply if you have not previously received the

necessary instructions of safety, use and cleanin by an expert user.

•Read and understand the operatin manual of this power supply before

usin .

•Keep your hands away while the power supply is in operation.

•Don’t leave the power supply durin operation.

•Do not wear any loose clothes or jewelry which could et cau ht in the

movable parts.

•Always disconnect the power supply before cleanin or any kind of

maintenance or repair. Pull out the plu from socket (do not pull from

cable). Keep cable away so as not to step on it, which could be

dan erous.

•Make sure that all safety metal plates and stickers on power supply are

easily readable. If not ask your distributor for more and attach them.

•For maintenance, cleanin works,… the system must be disconnected

from the main supply. Do not operate the power supply without havin

received the proper safety, use and cleanin instructions from an expert

user.

INSTALLATION MANUAL: PAA29+ V 1.4 (07/2011) 7

2. INTRODUCTION

The Proyecson PAA29+ Automation adapter makes it easy to interface di ital

cinema playback equipment with existin cinema control systems, enablin fully

automated presentations.

Input and output connections enable di ital cinema equipment to control

existin li htin , automation, and other old systems. The unit converts network

or serial control from the di ital cinema playback system in relay closures. The

unit can be connected in parallel with existin film automation systems makin

it easy to switch between film and di ital shows, and even to run seamless

presentations mixin both film and di ital content.

Advanced features include 12 confi urable momentary / latchin outputs and 8

inputs that can be used for tri er individual cues. These relay closures can

drive 16 A 250 Vac / 16A 30Vdc in normally open and closed dry contacts.

Front-panel indicators are provided for all inputs and outputs, ensurin that

system status is clearly visible at all times.

The unit is easy to install and 19” rack-mounted. Rear panel connectors are

provided to allow an easy wirin .

Valid for any other application not related with Di ital Cinema.

INSTALLATION MANUAL: PAA29+ V 1.4 (07/2011) 8

3. FEATURES

PAA29+ Front Panel

Power Button

With LED indicator.

LED Indicator

General purpose input, relay

output status, +24 V and + 5

Test Buttons

Buttons for test and manually

activation purposes for each

input/output.

PAA29+ Rear Panel

Connections

General Purpose Inputs

Ei ht opto-isolated low-

volta e inputs, screw

terminals, 24V lo ics.

General Purpose Outputs

Twelve hi h current

latcheable relay outputs,

screw terminals, normally

closed and normally open

contacts 16A VDC max.

Relays are replaceable.

24v / 1A output

Usable for input and output

auxiliary circuits.

Serial Ports

9-PIN female D-connector.

Network Connection

RJ-45 female connector;

10Base-T.

INSTALLATION MANUAL: PAA29+ V 1.4 (07/2011) 9

Construction

Warranty

Industrial chassis, screw closure,

connectors in the back panel, 1

unit 19” rack-mountin .

Three years limited, parts and labor;

see disclaimer. Specifications subject to

chan e without notice.

Power Requeriments

Disclaimer of Warranties

100-240 VAC, 50-60 Hz, 50w

from a centrally switched power

source.

Dimensions and Weight

483 x 183 x 44 mm.

Environmental Conditions

Operatin : 0º to 40º (32º to

104ºF), 20 to 80% relative

humidity (non-condensin ).

Equipment manufactured by Proyecson

S.A. is warranted a ainst defects in

materials for a period of three years

from the date of purchase. There are

no other express or implied warranties

and no warranty of merchantability or

fitness for a particular purpose, or of

non-infrin ement of third-party ri hts

(includin , but not limited to, copyri ht

and patent ri hts).

INSTALLATION MANUAL: PAA+29 V 1.2

(05/2010)

4. FRONTAL PANEL

Figure 4.A

1. Power button

2. 24vdc indicator

3. 5vdc indicator

4. Manual activation push button and output active status led’s.

•The led indicate that the output is active.

•Activate the outputs directly with the push bottoms without

usin the server. Outputs will only remain active while keepin

button pressed.

5. Manual activation push button and input active status led’s.

•The led indicate that input is active.

•With push buttons it is possible to force inputs manual

activation.
