Proxim ORINOCO AP-600B Manuel utilisateur
January 2008 Edition
1725-36050-001
Version H
Configuration Guide
Proxim ORiNOCO
AP-600b, AP-600g, AP-700, AP-2000, AP-4000
Fi
e
l
d
V
e
rifi
ed
Field Verified Configuration Guide
PN: 1725-36050-001_H.doc
2
Trademark Information
Polycom® and the logo designs
SpectraLink®
LinkPlus
Link
NetLink
SVP
Are trademarks and registered trademarks of
Polycom, Inc. in the United States of America
and various countries. All other trademarks
used herein are the property of their respective
owners.
Patent Information
The accompanying product is protected by one
or more US and foreign patents and/or pending
patent applications held by Polycom, Inc.
Copyright Notice
Copyright © xxxx to 2007 Polycom, Inc.
All rights reserved under the International and
pan-American copyright Conventions.
No part of this manual, or the software
described herein, may be reproduced or
transmitted in any form or by any means, or
translated into another language or format, in
whole or in part, without the express written
permission of Polycom, Inc.
Do not remove (or allow any third party to
remove) any product identification, copyright or
other notices.
Every effort has been made to ensure that the
information in this document is accurate.
Polycom, Inc. is not responsible for printing or
clerical errors. Information in this document is
subject to change without notice and does not
represent a commitment on the part of Polycom,
Inc.
Notice
Polycom, Inc. has prepared this document for
use by Polycom personnel and customers. The
drawings and specifications contained herein
are the property of Polycom and shall be neither
reproduced in whole or in part without the prior
written approval of Polycom, nor be implied to
grant any license to make, use, or sell equipment
manufactured in accordance herewith.
Polycom reserves the right to make changes in
specifications and other information contained
in this document without prior notice, and the
reader should in all cases consult Polycom to
determine whether any such changes have been
made.
No representation or other affirmation of fact
contained in this document including but not
limited to statements regarding capacity,
response-time performance, suitability for use,
or performance of products described herein
shall be deemed to be a warranty by Polycom
for any purpose, or give rise to any liability of
Polycom whatsoever.
Contact Information
Please contact your Polycom Authorized
Reseller for assistance.
Polycom, Inc.
4750 Willow Road,
Pleasanton, CA 94588
http://www.polycom.com
Proxim ORiNOCO AP-600b, AP-600g, AP 700, AP 2000, AP 4000
PN: 1725-36050-001_H.doc 3
Introduction
This document details the specifications for configuring the Proxim
Orinoco AP-600b, AP-600g, AP-700, AP-2000, AP-4000 series access
points (APs) with SpectraLink 8000 Wireless Telephones.
Product Summary
Manufacturer: Proxim: www.proxim.com
Approved product(s): AP-600b, AP-600g, AP-700, AP-2000, AP-4000 with Radio
Card: Orinoco 11Mb/s GoldCard
RF technology: Spread-spectrum, direct sequence(DS), 2.4 GHz
AP software version: Release 2.5.5 †
SpectraLink handset models: e340/h340/i640 8020/8030
SpectraLink radio mode: 802.11b 802.11b
Maximum telephone calls per AP: 12 * 12 *
AP configuration parameters: See Access Point Configuration below.
Indoor range (typical): See vendor specifications for AP.
Required network topology: Switched Ethernet
Network constraints: Dedicated segment for wireless, single subnet
WEP capability: Yes *
ESSID auto-learn function: Yes *
† Earlier and later software versions have not been tested for the SpectraLink 8000 SVP Server
compliance, except as noted. Refer to
Polycom WLAN Compatibility Table
for Field Verified AP software
versions.
* Telephone calls per AP must be configured in the system per documentation provided by Polycom.
WEP and Automatic Learn are programmed into each handset in addition to being configured in the AP.
SpectraLink 8000 Wireless Telephones
SpectraLink 8000 Wireless Telephones use voice over IP (VoIP)
technology on IEEE 802.11b-compatible wireless local area networks
(WLANs). Access points utilize radio frequencies to transmit signals
to and from the SpectraLink 8000 Wireless Telephones.
Field Verified Configuration Guide
PN: 1725-36050-001_H.doc
4
Access Point Capacity and Positioning
Each site is unique in its AP requirements. Please take the following
points into account when determining how many APs are needed and
where they should be placed in the facility.
Handset range
There must be wireless LAN coverage wherever SpectraLink 8000
Wireless Telephones will be used. The typical range for a SpectraLink
8000 Wireless Telephone is comparable to that of a laptop computer
utilizing a wireless LAN PC card. However, SpectraLink 8000
Wireless Telephones are likely to be used in areas where data devices
are not typically used, such as stairwells and outdoor areas.
SpectraLink 8000 Wireless Telephones have a Site Survey mode that
displays dBm levels to determine adequate WLAN coverage. Refer to
the Administration Guide for your SpectraLink Wireless Telephones
for details about this feature.
Number of handsets per access point
Estimate the number of SpectraLink 8000 Wireless Telephones and
their anticipated call volume per AP area to ensure that the maximum
number of calls per AP will not be exceeded. In this estimate, consider
the data rates at which the handsets will operate. Higher data rates
can only be sustained while well within the range of the AP. If the
SpectraLink 8000 Wireless Telephones will be operating near the
limits of the RF coverage from the AP, they will automatically drop to
1 Mb/s operation. SpectraLink 8000 Wireless Telephones require
approximately 15% of the available bandwidth per call for 1 Mb/s
operation, approximately 10% of the available bandwidth per call for
2 Mb/s operation, approximately 7% of the available bandwidth per
call for 5.5 Mb/s operation, and approximately 5% of the available
bandwidth per call for 11Mb/s operation.
The maximum number of telephone calls per AP quoted in the
summary table above is based on 11 Mb/s operation, and will be
reduced if some or all SpectraLink 8000 Wireless Telephones are
operating at 1, 2, or 5.5 Mb/s.
LAN bandwidth
Estimate anticipated peak call volume to ensure that the LAN has
enough bandwidth available to handle the network traffic generated
Proxim ORiNOCO AP-600b, AP-600g, AP 700, AP 2000, AP 4000
PN: 1725-36050-001_H.doc 5
by all of the wireless devices. Network traffic can be
monitored/analyzed using a network sniffer or a simple network
management protocol (SNMP) workstation.
Number of other wireless devices per AP
The SpectraLink 8000 Wireless Telephones share bandwidth with
other wireless devices. To ensure adequate RF bandwidth availability,
consider the number of wireless data devices in use per AP.
Notes on Configuration
The AP must support SpectraLink Voice Priority (SVP). Contact
your AP vendor if you need to upgrade the AP software.
If you encounter difficulties or have questions regarding the
configuration process, please contact the Customer Support Hotline at
(800) 775-5330. The hotline is open Monday through Friday,
6 a.m. to 6 p.m. Mountain time.
Field Verified Configuration Guide
PN: 1725-36050-001_H.doc
6
Access Point Configuration
1. Connect to the AP via Netscape or Internet Explorer by navigating
to the URL http://<IP_Addr> (where <IP_Addr> is the IP
address of the AP). Note: these configuration steps can also be
accomplished using the Orinoco ScanTool program.
2. From the main page, click the Configure link.
3. To configure WEP settings, obtain the key values from the local
network administrator and use the AP-600b, AP-2000 User Guide
for guidance in programming the encryption settings. The WEP
configuration screen is reached from the main menu by clicking
Configure, followed by Security, followed by Encryption.
Note that the SpectraLink 8000 Wireless Telephones must each be
configured manually with the identical WEP settings.
4. Click Configure, then click the Interfaces link and choose the
appropriate radio (Slot A or Slot B) to configure.
5. From the Interfaces tab confirm that the RTS/CTS Medium Reservation
Threshold is greater than 600 or disabled.
6. Set the Multicast Transmit Rate to 11Mb/s.
7. Next go to the Bridge tab, select SpectraLink VoIP to ensure that
SpectraLink Voice Priority (SVP) is enabled.
8. Conditional: If the AP’s software version is 2.5.xx or later, SVP
must be activated using the Avaya command line interface (CLI).
a. Connect to the access point via serial interface or Telnet.
b. Check to see if SVP is enabled by typing show spectralink,
then press Enter.
c. enabled or disabled will display.
d. Enable SVP by typing set speclinkstatus enable, then
press Enter.
9. From the Bridge tab, select Advanced Filtering. Enable the Proxy ARP
function and disable IP/ARP Filtering.
10. From the Commands tab, restart the AP.
The AP is now ready for use with SpectraLink 8000 Wireless
Telephones.
