PROTECT MultiCard™7
6. Operational modes
6.1. Panic function mode with separated fault outputs
Softwarerequirement,fogcannon:Softwareversion2.50orhigher.
Softwarerequirement,MultiCard:Softwareversion1.02orhigher.
Devicerequirement:ThisprogramwillrunonanytypeofPROTECTFogCannon.
Dipswitchsettings:
1
0
2
0
3
0
4
0
5
0
6
0
7
0
8
0
9
0
10
0
Terminal “V+” iscurrentlynotused,andshouldbeleftunconnected.
For the Panic Release function to work, the following conditions must be met:
• The Disable input on the fog cannon’ mainboard must be inactive
- UsetheDisableinputontheMultiCardinstead,sincethisinputwillnotinuencethePanicsignal
• The Fire Alarm input on the fog cannon’ mainboard must be inactive
- TheFireAlarminputISDESIGNEDTOSTOPANDBLOCKALLFOGimmediately
- Thisisamandatoryfunctiondemandedbynationalandlocalreauthorities,whenusedinpremises
monitoredbyrealarmsystems,andhencemaynotandcannotbeoverruled
- Ifservicedisablefunctionalityisrequested,forservicingattachedalarmsystem,pleaseusethe
SSinputontheMultiCardinstead.Itwasdesignedspecicallywiththispurposeinmind
• Dipswitch 9 on the fog cannon’ mainboard must be set to ON, to enable Panic functionality
Thisinputisxed“normallyopen”(activateswhenvoltageisapplied).
Outputs 2 to 9signalvariousfaultconditionsonseparateoutputs.
Seelistabove.
Do NOT rely solely on the fault indicating outputs on the MultiCard.
Fault, Fluid and Fog outputs on fog cannon mainboard should still be monitored for activity.
Inputs functionality:
IN-SS Activates“Blockingmode”whenconnectedtogndonmainboard
IN-2 Panicbutton
IN-3 Disable(thisDisableinputallowsPanictowork.Willnotturnoffheat)
IN-4 Nofunction
Outputs functionality:
OUT-1 Panicreleaseactive
OUT-2 E1_MAINS_VOLTAGE_LOST
OUT-3 E3_FIRE_ALARM_ACTIVEorE16_PANNIC_NOT_RELEASED
OUT-4 E4_BATTERY_VOLTAGE_LOWorE5_BAT_CHARGE_TIMEOUTorE6_BAT_LOADTEST_FAIL
OUT-5 E7_BOARD_TEMP_HIGHorE8_BOARD_TEMP_LOWorE14_BAT_TEST_CIRC_FAIL
OUT-6 E9_TEMP_TERM_HIGH
OUT-7 E10_TEMP_TERM_LOW
OUT-8 E12_PUMP_TIMEOUT
OUT-9 E13_AUX_12V_OVERLOAD
