Protech BS-0981 Manuel utilisateur

USER

MANUAL

BS-0981M0

BS-0981

Fanless19" 1U Rockmount

PC with Intel® Celeron

N3350 SoC

BS-0981

Fanless Fanless 19" 1U Rockmount

PC with Celeron N3350 SoC

All trademarks and registered trademarks mentioned herein are the

property of their respective owners.

This manual is copyrighted in March 2018. You may not reproduce or

transmit in any form or by any means, electronic, or mechanical,

including photocopying and recording.

DISCLAIMER

This user’s manual is meant to assist users in installing and setting up

the system. The information contained in this document is subject to

change without any notice.

CE NOTICE

This is a class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

page 2

FCC NOTICE

This equipment has been tested and found to comply with the limits for

a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

You are cautioned that any change or modifications to the equipment

not expressly approve by the party responsible for compliance could

void your authority to operate such equipment.

CAUTION: Danger of explosion may occur when the battery

is incorrectly replaced. Replace the battery

only with the

same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer’s

instructions.

WARNING: Some internal parts of the system may have high

electrical voltage. We strongly recommend that only qualified

engineers are allowed to service

and disassemble the

system. If any damages should occur on the system and are

caused by unauthorized servicing, it will not be covered by

the product warranty.

page 3

1Introduction

This chapter provides the introduction for BS-0986 system

as well as the framework ofthe user manual.

The following topic is included:

•About This Manual

page 4

1.1 About This Manual

Thank you for purchasing our BS-0981 system. The BS-0981 provides faster

processing speed, greater expandability and can handle more tasks than before. This

manual is designed to assist you how to install and set up the whole system. It

contains 5 chapters and 2 appendixes. Users can configure the system according to

their own needs. This user manual is intended for service personnel with strong

hardware background. It is not intended for general users.

The following section outlines the structure of this user manual.

Chapter 1 Introduction

This chapter provides the introduction for the BS-0981 system as well as the

framework of the user manual.

Chapter 2 Getting Started

This chapter describes the package contents and outlines the system specifications.

Read the safety reminders carefully on how to take care of your system properly.

Chapter 3 System Configuration

This chapter describes the external I/O ports, outlines the locations of the

motherboard components and their respective functions. You will learn how to set the

jumpers and configure the system to meet your own needs.

Chapter 5 AMI BIOS Setup

This chapter indicates you how to change the BIOS configurations.

Appendix A Technical Summary

This appendix provides the exploded diagrams and part numbers of the BS-0981.

Appendix B Technical Summary

This appendix provides the information about the allocation maps for system

resources, Watchdog Timer Configuration and Flash BIOS Update.

Chapter 4 Software Utilities

This chapter contains helpful information for proper installations of the Intel®Chipset

Software Installation Utility, Graphics Driver Utility, LAN Driver Utility, Sound

Driver Utility, Intel®Serial I/O Driver Utility and Microsoft Hotfix Driver Utility.

page 5

2Getting Started

This chapter provides the information for the BS-0981

system.It describes the package contents and outlines the

system specifications.

The following topics are included:

•Package List

•System Overview

•System Diagrams

•System Specification

•Safety Precautions

page 6

Unit: mm

System Overview

Front View

Rear View

USB

Storage indicated light

Power S/W

DC-IN COM VGA DP

LINE OUT LAN USB

Unit: mm

Top View

page 7

Quarter View

Front I/O Panel

Rear I/O Panel

page 8

BS-0981 System Specifications

System

CPU Type

Memory Support 1 x SO-DIMM socket, supporting 1600

DDR3L DRAM up to 8G (non-ECC)

API Hardware monitor / WatchDog

Storage Support 1 x 2.5” 7mm SATAIII HDD / SSD drive space

Power Supply Supports DC 12V power input (3-pin lockable

terminal block )

O.S. Support Windows® 10 64bit

BIOS AMI UEFI BIOS

Expansion Slots 1 x full-sized mPCIe slot (with PCIe and USB signals)

1 x full-sized mSATA slot (with SATA and USB signals)

Dimensions (W x H x D)  432mm x 45mm x 250mm

Weight 2kg

I/O Ports (Rear side)

USB 4 x USB 3.0

Serial Ports

COM1: RS232

COM2: RS232/422/485 selectable under BIOS

COM3: RS232 w/ RI/5V/12V selectable under BIOS



I/O Ports (Front side)

Sound 1 x Line Out

USB 4 x USB 3.0

Intel ApolloLake Celeron N3350

COM4: RS232

1 x Power LED

1 x HDD LED

LED

LAN

2 x LANs (supports Wake-on-LAN)

LAN1: Intel® I210IT (I210AT)

LAN2: Intel® I210IT (I210AT)

Power Input 3-pin DC In terminal block (lockable)

Display 1 x DP, resolution: up to 4096x2160 @60Hz

1 x VGA, resolution: up to 1920x1200 @60Hz

page 9

Power Mode

Other

Optional Accessory 60W Power adapter with lockable 3-pin terminal block

Environment

Operating Temp.

Storage Temp. -40°C ~85°C (-40°F~185°F)

Humidity 20%~ 90%

(1) BIOS Power Fail “On”: Boot-up when AC power

returns from “Off” to “On” (default)

(2) BIOS Power Fail “Off”: Non-boot-up when AC

power returns from “Off” to “On”

Way to boot up from S5: (1) Power Button

(2) Wake-On-LAN

(3) RTC-wake

(set under BIOS)

Way to Shutdown to S5/S4/S3: (1) Power Button

(2) OS Command

Supports S0/S3/S4/S5

Celeron N3350 /0°C ~ 40°C
