Prorack K997W Manuel utilisateur

K997W

Fitting Kit

EN Fitting Instructions for Basic Carrier

x 2 x 1 x 1 x 2

x 2 x 2 x 1 x 1

x 2 x 2 x 2

Revision No: 1A 1

Fitting Kit K997W

MAX kgs (lbs)

W/P WHD

Jeep

Renegade Sport, 5dr SUV 15-+ AU 68 kgs (149 lbs) 68 kgs (149 lbs)

Renegade Sport, 5dr SUV 15-+ EU 68 kgs (149 lbs) 68 kgs (149 lbs)

Renegade Sport, 5dr SUV 16-+ NZ 68 kgs (149 lbs) 68 kgs (149 lbs)

Fitting Kit K997W

A B C 1 2 3

Renegade Sport, 5dr SUV 15-+ (AU) 275mm 480mm - 915mm 970mm -

10 13/16ths" 18 7/8ths" - 36" 38 3/16ths" -

Renegade Sport, 5dr SUV 15-+ (EU) 275mm 480mm - 915mm 970mm -

10 13/16ths" 18 7/8ths" - 36" 38 3/16ths" -

Renegade Sport, 5dr SUV 16-+ (NZ) 275mm 480mm - 915mm 970mm -

10 13/16ths" 18 7/8ths" - 36" 38 3/16ths" -

Fitting Kit EN

K997W

First Time Installation

●Remove parts from inside the package and

check. Contact your dealer if any parts are

missing or damaged.

●This kit fits type A, B, C and D.

●These instructions show type A crossbar

fitted. They also apply to type B, C and D.

●Use keys to remove covers.

Fitting Kit EN

K997W

Fitment FRONT ONLY

●Use hex screwdriver to reverse adjusting

screw 10 turns.

●Press adjusting screw and pull crossbar

legs out. Refer to the crossbar instructions

for crossbar adjustment method.

●Ensure each end of the crossbar is

adjusted equally.

●Please check the front of this manual for

information relating specifically to your

vehicle.

●Adjust crossbar in or out to suit vehicle.

Refer to the crossbar instructions for

crossbar adjustment.

Fitting Kit EN

K997W

●Tighten adjusting screw to 3 Nm (2.2 ft lb)

hand tight.

●Remove plastic clamp block by gripping bar

leg with fingers and push firmly with

thumbs until clamp block drops out behind

leg.

●Select plastic internal block (from fitting kit)

and insert into foot.

Fitting Kit EN

K997W

●Remove as shown.

●Mark as shown.

Fitment Front Bar Only

●Use drill bit supplied, to drill holes in

marked positions.

Fitting Kit EN

K997W

●Re-install rubber ditch mould back into roof

channel and click into place.

●Select grubscrews and screw into the

vehicle's fixed points.

●Do not over tighten.

●Repeat for all items.

●Refer to the underside of the pad for the

part number.

Fitting Kit EN

K997W

●It is important to put the pads in the correct

position on the vehicle.

●Letters refer to the pad part numbers and

position.

●Pad Part Number:

A = 224

B = 225

●Place crossbars on pads ensuring the pads

fit into the holes underneath the foot and

the grubscrew passes through the hole in

the foot.

●Tighten the plastic knob. The side with the

nut showing should be facing up.

Fitting Kit EN

K997W

●Ensure the plastic knob is in the position

shown when fully tightened.

●Repeat at other end.

●Check crossbar is securely attached to the

vehicle.

●Use keys to fit and lock covers

●If crossbars are removed, please install the

rubber plugs into the ditch moulding.
