PROPOINT 8355331 Manuel utilisateur

V1.0 8355331

Please read and understand all instructions before use. Retain this

manual for future reference.

USER MANUAL

7 PC QUICK CHANGE RATCHETING

WIRE TERMINAL CRIMPER KIT

8355331 7 PC QUICK CHANGE RATCHETING V1.0

WIRE TERMINAL CRIMPER KIT

2 For technical questions call 1-800-665-8685

INTRODUCTION

The tool has 6 interchangeable jaw sets to handle multiple sizes

and styles of terminals. It will crimp insulated terminals, non-

insulated terminals, open barrel terminals (small and large) and

cord end terminals (small and large).

SAFETY

WARNING! Read and understand all instructions before using

this tool. The operator must follow basic precautions to reduce

the risk of personal injury and/or damage to the equipment.

Keep this manual for safety warnings, precautions, operating or

inspection and maintenance instructions.

HAZARD DEFINITIONS

Please familiarize yourself with the hazard notices found in this

manual. A notice is an alert that there is a possibility of property

damage, injury or death if certain instructions are not followed.

DANGER! This notice indicates an immediate and specific

hazard that will result in severe personal injury or death if the

proper precautions are not taken.

WARNING! This notice indicates a specific hazard or unsafe

practice that could result in severe personal injury or death if

the proper precautions are not taken.

CAUTION! This notice indicates a potentially hazardous

situation that may result in minor or moderate injury if proper

practices are not taken.

7 PC QUICK CHANGE RATCHETING

WIRE TERMINAL CRIMPER KIT

V1.0 7 PC QUICK CHANGE RATCHETING 8355331

WIRE TERMINAL CRIMPER KIT

Visit www.princessauto.com for more information 3

NOTICE! This notice indicates that a specific hazard or unsafe

practice will result in equipment or property damage, but not

personal injury.

WORK AREA

1. Operate in a safe work environment. Keep your work area

clean, well-lit and free of distractions.

2. Keep anyone not wearing the appropriate safety

equipment away from the work area.

3. Store tools properly in a safe and dry location. Keep tools

out of the reach of children.

PERSONAL SAFETY

WARNING! Wear personal protective equipment approved by

the Canadian Standards Association (CSA) or American

National Standards Institute (ANSI).

PERSONAL PROTECTIVE EQUIPMENT

1. Always wear impact safety goggles that provide front and

side protection for the eyes. Eye protection equipment

should comply with CSA Z94.3-07 or ANSI Z87.1 standards

based on the type of work performed.

2. Wear gloves that provide protection based on the work

materials or to reduce the effects of tool vibration.

PERSONAL PRECAUTIONS

Control the tool, personal movement and the work

environment to avoid personal injury or damage to the tool.

1. Do not operate any tool when tired or under the influence

of drugs, alcohol or medications.

2. Avoid wearing clothes or jewelry that can become

entangled with the moving parts of a tool. Keep long hair

covered or bound.

8355331 7 PC QUICK CHANGE RATCHETING V1.0

WIRE TERMINAL CRIMPER KIT

4 For technical questions call 1-800-665-8685

SPECIFIC SAFETY PRECAUTIONS

WARNING! DO NOT let comfort or familiarity with product

(gained from repeated use) replace strict adherence to the

tool safety rules. If you use this tool unsafely or incorrectly,

you can suffer serious personal injury.

1. Use the correct tool for the job. This tool was designed for

a specific function. Do not modify or alter this tool or use it

for an unintended purpose.

2. Do not place any part of your body between the crimper’s

jaws. The tool can inflict a crushing injury if a part of your

hand is trapped when the jaws close.

UNPACKING

WARNING! Do not operate the tool if any part is missing.

Replace the missing part before operating. Failure to do so

could result in a malfunction and personal injury.

Remove the parts and accessories from the packaging and inspect

for damage. Make sure that all items in the parts list are included.

Contents:

• Quick Change Crimper • Six Interchangeable Jaw Sets

• Plastic Carry Case

IDENTIFICATION KEY

A Insulated Terminal Jaws

B Non-Insulate Terminal Jaws

C Open Barrel Terminal Jaws

D Insulated Cord–End

Terminal Jaws

E Quick Change Ratcheting

Crimper

F Insulated Huge Cord-End

Terminal

G Comfort Grip Handle

H Open Barrel Terminal & D-

Sub V3.5 Jaws

I Ratchet Release Lever

Fig. 1

V1.0 8355331

Please read and understand all instructions before use. Retain this

manual for future reference.

ASSEMBLY & INSTALLATION

WARNING! Do not hold or press the lower handle against

yourself or an object while removing a set of jaws. This can close

the jaws and cause a crushing injury to your fingers or hand.

Letter references in parenthesis (A) refer to the included

Identification Key.

1. Push the release lever (I) towards the jaws to release the

ratchet mechanism.

2. Spread the handles (G) apart to open the jaws. Push the

release mechanism forward to avoid catching the ratchet

mechanism.

3. Hold the upper handle only and press your thumb against

the inside of the lower handle to prevent it from closing.

4. Grip the upper jaw (A) on the top and bottom. Pull straight

out to remove the jaw. Repeat with the lower jaw.

5. Replace the jaw set with the appropriate set for crimping

(see Table 1).

6. Close the jaws when not in use to prevent accidentally

closing it on a body part.

OPERATION

1. Prepare the wire by removing enough insulation from the

end to insert into the terminal.

2. Select the jaws appropriate for the terminal type that

requires crimping and install in the crimper.

2.1 Each set of jaws has a stamped letter for identification

(see Table 1).

3. Place the terminal in the lower jaw that corresponds to the

wire size (gauge or mm) and slowly squeeze the handles until

8355331 7 PC QUICK CHANGE RATCHETING V1.0

WIRE TERMINAL CRIMPER KIT

6 For technical questions call 1-800-665-8685

you hear the first click of the ratchet mechanism. Continue

until the terminal is held in place, but not compressed.

4. Slide the bare wire into the terminal and hold in place.

5. Squeeze the handles to compress the terminal until it is

fully collapsed around the wire.

6. Press the release lever (I) to open the jaws.

7. Remove the terminal and gently pull the wire to test if it is

secure. If it pulls free from the terminal, discard the terminal

and repeat with a new one.

A Insulated Terminal Jaw AWG 22-18, 16-14, 12-10

mm20.5–1.0, 1.5-2.5, 4.0-6.0

B Non-Insulate Terminal

Jaws

AWG 20-18, 16-14, 12-10, 8

mm21.5, 2.5, 6.0, 10.0

C Open Barrel Terminal

Jaws

AWG 20-18, 16-14, 12-10

mm20.5–1.0, 1.5-2.5, 4.0-6.0

D Insulated Cord–End

Terminal Jaws

AWG 22, 20, 18, 16, 14, 12

mm20.5, 0.75, 1.0, 1.5, 2.5, 4.0

F Insulated Huge Cord-

End Terminal

AWG 10.0, 8.0, 6.0

mm26.0, 10, 16

H Open Barrel Terminal &

D-Sub V3.5 Jaws

AWG 14, 22, 8.0-6.0

mm22.5, 0.5, 8.0-10

Tabl e 1

V1.0 7 PC QUICK CHANGE RATCHETING 8355331

WIRE TERMINAL CRIMPER KIT

Visit www.princessauto.com for more information 7

CARE & MAINTENANCE

1. Maintain the tool with care. A tool in good condition is

efficient, easier to control and will have fewer problems.

2. Inspect the tool components periodically. Repair or replace

damaged or worn components. Only use identical

replacement parts when servicing.

3. Only use accessories intended for use with this tool.

4. Keep the tool handles clean, dry and free from oil/grease at

all times.

WARNING! Only qualified service personnel should repair the

tool. An improperly repaired tool may present a hazard to the

user and/or others.

TROUBLESHOOTING

Visit a Princess Auto Ltd. location for a solution if the tool does

not function properly or parts are missing. If unable to do so,

have a qualified technician service the tool.

8355331 7 PC QUICK CHANGE RATCHETING V1.0

WIRE TERMINAL CRIMPER KIT

8 For technical questions call 1-800-665-8685

V 1,0 8355331

Vous devez lire et comprendre toutes les instructions avant d'utiliser

l'appareil. Conservez ce manuel afin de pouvoir le consulter plus tard.

MANUEL D'UTILISATEUR

TROUSSE DE PINCES À SERTIR

POUR BORNES DE FIL, À CLIQUET,

À CHANGEMENT RAPIDE, 7 PIÈCES

8355331 TROUSSE DE PINCES À SERTIR POUR BORNES DE FIL, V 1,0

À CLIQUET, À CHANGEMENT RAPIDE, 7 PIÈCES

2 En cas de questions techniques, appelez le 1-800-665-8685

INTRODUCTION

L’outil comporte six ensembles de mâchoires interchangeables

qui s’adaptent à diverses dimensions et divers types de bornes.

Peut sertir des bornes isolées, non isolées, à cylindre ouvert

(petites et grosses), et des bornes d’extrémité de cordon

(petites et grosses).

SÉCURITÉ

AVERTISSEMENT ! Veuillez lire et comprendre toutes les

instructions avant d'utiliser cet outil. L'utilisateur doit respecter

les précautions de base lorsqu'il utilise cet outil afin de réduire

le risque de blessure ou de dommage à l'équipement.

Conservez ce manuel qui contient les avertissements de

sécurité, les précautions, les instructions de fonctionnement ou

d'inspection et d'entretien.

DÉFINITIONS DE DANGER

Veuillez-vous familiariser avec les avis de danger qui sont

présentés dans ce manuel. Un avis est une alerte indiquant qu'il

existe un risque de dommage à la propriété, de blessure ou de

décès si on ne respecte pas certaines instructions.

DANGER ! Cet avis indique un risque immédiat et particulier

qui entraînera des blessures corporelles graves ou même la

mort si on omet de prendre les précautions nécessaires.

TROUSSE DE PINCES À SERTIR

POUR BORNES DE FIL, À CLIQUET,

À CHANGEMENT RAPIDE, 7 PIÈCES
