ProofVision PV320A-HB Manuel utilisateur

Proofvision Outdoor LED TV

Please read these instructions thoroughly before attempting to operate or adjust this television.

•Installation must be carried out by a qualified installer i.e. AV technician.

•The installation of the cables must be carried out in a dry place and sealed tightly with the

8 screws provided. Failure to do this will void your warranty.

•The VESA screws provided should be the only screws used with the Proofvision Outdoor

TV, for spares please contact Proofvision directly.

•Please make sure the wall chosen to install on is of a substantial nature and that rust proof

fixtures are used.

•We strongly recommend the Proofvision screen is not installed in DIRECT SUNLIGHT

for long periods of times. The units top operating temperature is 60 Celsius and the unit

can reach this temperature if exposed to direct sunlight over a long period of time.

Never tamper with any of the components, or any other adjustment controls not mentioned in this

manual.

The LED panel used in this product is made of glass. Therefore, please take care it can break when

the product is dropped or applied with impact. When you are cleaning the panel, make sure the

power cord is pulled out from the plug receptacle. Then wipe the receiver with a dried soft cloth.

All technical work on the TV should only be performed by an electrician, due to the high voltage.

Note: the remote control has a waterproof IP68 rating.

Insertion of the batteries

1. Remove the back cover of the remote control with the supplied opening tool.

2. Pull out the PVC paper and insert one 3V battery, make sure the rubber gasket is inside the

slot to ensure the remote control is waterproof.

3. Replace the back cover of the remote control with the opening tool by twisting round the tool

until you hear a click sound.

Precautions when using batteries

Do not use different types of batteries that the remote control cannot support

Remove the batteries from the remote control if you do not intend to use it for a long

time

Do not drop the remote control

Replace the batteries with new ones when operation of the unit deteriorates

Front view of TV set

1. Menu-Press this button to show the menu choice

2. CH+ Press this button to increase the TV channel

3. CH- Press this button to decrease the TV channel

4. Power-Press this button to turn on/off the TV power

5. VOL+ press this button to increase the volume

6. VOL- Press this button to decrease the volume

7. Input Press this button to show the input sources

Note. 1. The front touch buttons are not the standard install, some models will not have the

buttons.

2. All the front buttons are touch keys

3. When the TV is on, all the buttons will have a blue background

Ports definition of TV set

1. DC 12V input

2. HDMI input

3. VGA input

4. AV input

5. RF(TV in)

Note:

All cables of ports are extended out from the TV bottom in a bundle

When using external equipment with this TV set, please read the instructions

external equipment.

Switch off all power supplies to the equipment and TV set before connection

Always ensure that the input and output terminals are correctly connected

All the above ports are standard, for some models, they may have less or more

ports according to customer’s request

1. POWER button-Press this button to switch on the TV

when in standby mode or to turn off and put on standby

2. MUTE button-Press this button to mute or restore sound

3. AUDIO button-Press this button to get Mono

channel/doubly channel/Stereo

4. ZOOM button-Press this button to switch between 4:3

and 16:9 picture format

5. VOL+, VOL- button- Increase or decrease the Volume

6. CH+, CH- button-To change the TV channel

7. ENTER button-Confirm the menu option

8. UP/DOWN/LEFT/RIGHT button-Press these buttons to

get last/next/left/right menu options

9. MENU button-Press this button to enter into TV main

10. EXIT button-Press this button to go back to menu

11. 0-9 button-Press these buttons to get given TV channels

12. -/--button-One/two/three-digit channel selection

13. Return to previous TV channel

14. P-MODE button-Switch the picture

mode(USER/STANDARD/BRIGHT/SOFT)

15. S-MODE button-Press this button to switch to a different

sound mode

16. Return to previous TV channel

17. P-MODE button-Switch the picture

mode(USER/STANDARD/BRIGHT/SOFT)

18. S-MODE button-Press this button to switch to a different

sound mode

19. INPUT button-Press this button to switch the input source.

Change the SOURCE from VGA/HDMI/TV/AV

20. SLEEP button-Adjust the sleep timer

21. FAV button-Press this button to open or close favorite

program group

22. TV RADIO button-Press this button to switch to TV or radio

23. INFO button-Display the information on the top-right corner

of screen(e.g. channel number, TV system, resolution and

frequency for PC etc)

24. EPG button-Press this button to display preview programs

25. HOLD button-Press this button to enter into hold mode

26. LANG button-Press this button to choose different

languages

27. TETX button-Press this button to enter TELETEXT mode

28. SUBTITLE button-Press this button to display the subtitle

29. SIZE button-Press this button to zoom up half of the

TELETEXT page

30. REVEAL button-This command will only be valid if the

TELETEXT page is being displayed. This command displays any concealed characters in the

TELETEXT display

31. INDEX button-Press this button to enter the index page of the TELETEXT content

32. SUBPAGE button-Press this button to display a sub-page of the selected page

33. Red/Green/Yellow/Blue colour button-Press these buttons to execute various colour coded

texts/functions in TELETEXT
