Duodos 50, 100, PPS/PVT/PT

Air-driven double diaphragm pump

Assembly and operating instructions

A2740

Original operating instructions (2006/42/EC)Part number 981451 BA DUO 016 06/20 EN

Please carefully read these operating instructions before use. · Do not discard.

The operator shall be liable for any damage caused by installation or operating errors.

The latest version of the operating instructions are available on our homepage.

In order to make it easier to read, this document uses the male

form in grammatical structures but with an implied neutral sense.

The document is always aimed equally at women, men and

gender-neutral persons. We kindly ask readers for their under‐

standing in this simplification of the text.

Please read the supplementary information in its entirety.

Information

This provides important information relating to the

correct operation of the unit or is intended to make

your work easier.

Warning information

Warning information includes detailed descriptions of the haz‐

ardous situation, see

Ä Chapter 2.1 ‘Labelling of Warning Informa‐

tion’ on page 5

The following symbols are used to highlight instructions, links, lists,

results and other elements in this document:

Tab. 1: More symbols

Symbol Description

Action, step by step.

⇨Outcome of an action.

Links to elements or sections of these instructions or other applicable documents.

nList without set order.

[Button]

Display element (e.g. indicators).

Operating element (e.g. button, switch).

‘Display/GUI’

Screen elements (e.g. buttons, assignment of function keys).

CODE Presentation of software elements and/or texts.

General non-discriminatory approach

Supplementary information

Supplemental directives

Table of contents

1 Function and identification.................................................... 4

1.1 Function........................................................................ 4

1.2 Identification.................................................................. 4

2 Safety and responsibility....................................................... 5

2.1 Labelling of Warning Information.................................. 5

2.2 User qualification.......................................................... 7

2.3 Intended use................................................................. 8

2.4 Duodos general safety notes........................................ 8

3 Transport and storage......................................................... 11

3.1 Transport.................................................................... 11

3.2 Storage....................................................................... 11

4 Assembly............................................................................ 12

4.1 Installation environment.............................................. 12

4.1.1 Securing the double diaphragm pump..................... 14

4.2 Ambient conditions..................................................... 14

4.3 Design of the suction side........................................... 14

4.4 Compressed air supply............................................... 15

5 Checking tightening torque prior to commissioning............ 16

6 Operation of the double diaphragm pump.......................... 17

7 Commissioning................................................................... 18

7.1 Checks prior to commissioning................................... 18

7.2 Priming........................................................................ 19

7.3 Interrupting operation.................................................. 19

8 Maintenance of the double diaphragm pump...................... 20

8.1 Troubleshooting.......................................................... 20

8.2 Maintenance of the diaphragm................................... 23

8.3 Maintenance of the slide rod....................................... 25

8.4 Maintenance of the ball valves................................... 26

9 Disposal of used parts........................................................ 28

10 Technical drawing............................................................... 29

10.1 Exploded drawings and parts lists for Duodos 50..... 30

10.2 Exploded drawings and parts lists for Duodos 100... 32

11 Technical data..................................................................... 34

11.1 Performance curves.................................................. 35

12 Declaration of Conformity................................................... 37

13 Index................................................................................... 38

Table of contents

1 Function and identification

1.1 Function

The Duodos is an air-driven double diaphragm pump.

The Duodos is run-dry safe and self-priming.

The pump capacity of the double diaphragm pump can be con‐

trolled by changing the pressure in the air supply. The air control is

designed for oil-free operation. The Duodos is ideally suited for the

transport of liquid chemicals.

The Duodos double diaphragm pump transports liquids up to a

delivery height of 7 m. As the pump capacity depends greatly on

the back pressure, always observe the performance curve.

Check the compatibility of the material when selecting the double

diaphragm pump. Also consider the density, viscosity, solids con‐

tent and temperature of the liquid being pumped.

Permissible values for the medium

Temperature of the medium

–

PP version: 10 ... 80 °C

–

PVDF version: -13 ... 93 °C

Viscosity of the medium: max. 200 mPas

Solids: < 3 mm

1.2 Identification

Type Housing Diaphragm Pump capacity in l/min Order number

50 PPS PP Santoprene®0 ... 50 1103384

50 PVT PVDF Teflon®0 ... 50 1103382

50 PT PP Teflon®0 ... 50 On request

100 PPS PP Santoprene®0 ... 100 1103383

100 PVT PVDF Teflon®0 ... 100 1103380

Function and identification

2 Safety and responsibility

2.1 Labelling of Warning Information

These operating instructions provide information on the technical

data and functions of the product. These operating instructions pro‐

vide detailed warning information and are provided as clear step-

by-step instructions.

The warning information and notes are categorised according to

the following scheme. A number of different symbols are used to

denote different situations. The symbols shown here serve only as

examples.

DANGER!

Nature and source of the danger

Consequence: Fatal or very serious injuries.

Measure to be taken to avoid this danger.

Description of hazard

– Denotes an immediate threatening danger. If

the situation is disregarded, it will result in fatal

or very serious injuries.

WARNING!

Nature and source of the danger

Possible consequence: Fatal or very serious inju‐

ries.

Measure to be taken to avoid this danger.

– Denotes a possibly hazardous situation. If the

situation is disregarded, it could result in fatal

or very serious injuries.

CAUTION!

Nature and source of the danger

Possible consequence: Slight or minor injuries.

Material damage.

Measure to be taken to avoid this danger.

– Denotes a possibly hazardous situation. If the

situation is disregarded, it could result in slight

or minor injuries. May also be used as a

warning about material damage.

NOTICE!

Nature and source of the danger

Damage to the product or its surroundings.

Measure to be taken to avoid this danger.

– Denotes a possibly damaging situation. If the

situation is disregarded, the product or an

object in its vicinity could be damaged.

Introduction

Safety and responsibility

Type of information

Hints on use and additional information.

Source of the information. Additional measures.

–

Denotes hints on use and other useful informa‐

tion. It does not indicate a hazardous or dam‐

aging situation.

Safety and responsibility

2.2 User qualification

WARNING!

Danger of injury with inadequately qualified per‐

sonnel

The operator of the system / equipment is respon‐

sible for ensuring that the qualifications are ful‐

filled.

If inadequately qualified personnel work on the unit

or loiter in the hazard zone of the unit, this could

result in dangers that could cause serious injuries

and material damage.

– All work on the unit should therefore only be

conducted by qualified personnel.

– Unqualified personnel should be kept away

from the hazard zone.

The pertinent accident prevention regulations, as

well as all other generally acknowledged safety

regulations, must be adhered to.

Training Definition

Instructed personnel An instructed person is deemed to be a person who has been instructed and,

if required, trained in the tasks assigned to him and possible dangers that

could result from improper behaviour, as well as having been instructed in the

required protective equipment and protective measures.

Trained user A trained user is a person who fulfils the requirements made of an instructed

person and who has also received additional training specific to the system

from the manufacturer or another authorised distribution partner.

Trained, qualified per‐

sonnel

A trained, qualified employee is deemed to be a person who is able to assess

the tasks assigned to him and recognize possible hazards based on his

training, knowledge and experience, as well as knowledge of pertinent regula‐

tions. A trained, qualified employee must be able to perform the tasks

assigned to him independently with the assistance of drawing documentation

and parts lists. The assessment of a person's technical training can also be

based on several years of work in the relevant field.

Electrical technician An electrical technician is able to complete work on electrical systems and rec‐

ognise and avoid possible dangers independently based on his technical

training and experience as well as knowledge of pertinent standards and regu‐

lations. An electrical technician must be able to perform the tasks assigned to

him independently with the assistance of drawing documentation, parts lists,

terminal and circuit diagrams. The electrical technician must be specifically

trained for the working environment in which the electrical technician is

employed and be conversant with the relevant standards and regulations.

Service The Service department refers to service technicians, who have received

proven training and have been authorised by the manufacturer to work on the

system.

Safety and responsibility

2.3 Intended use

CAUTION!

Intended use

Possible consequences if the instructions are not

observed: Minor injuries and material damage

– The pump is intended for liquids transport

– The pump is not intended for the transport of

gaseous or solid media

– Only use the pump in accordance with the

technical data and specifications outlined in the

operating instructions.

– The pump is not designed for use in areas at

risk from explosion

– Only switch the device on if it has been prop‐

erly fastened to the ground or its holding fix‐

ture.

2.4 Duodos general safety notes

WARNING!

Danger from hazardous substances!

Possible consequence: Fatal or very serious inju‐

ries.

Please ensure when handling hazardous sub‐

stances that you have read the latest safety data

sheets provided by the manufacture of the haz‐

ardous substance. The actions required are

described in the safety data sheet. Check the

safety data sheet regularly and replace, if neces‐

sary, as the hazard potential of a substance can be

re-evaluated at any time based on new findings.

The system operator is responsible for ensuring

that these safety data sheets are available and that

they are kept up to date, as well as for producing

an associated hazard assessment for the worksta‐

tions affected.

Safety and responsibility

WARNING!

Hazardous media / contamination of persons and

equipment

Possible consequence: Fatal or very serious inju‐

ries. material damage

– Ensure the device is resistant to the media

being conveyed

– Always observe the safety data sheets for the

media to be conveyed. The system operator

must ensure that these safety data sheets are

available and that they are kept up-to-date

– The safety data sheets for the media being

conveyed are always decisive for initiating

counter measures in the event of leakage to

the media being conveyed

– Observe the general restrictions in relation to

viscosity limits, chemical resistance and den‐

sity

WARNING!

Service life of the diaphragm

Possible consequence: Fatal or very serious inju‐

ries

The service life of the diaphragm cannot be pre‐

cisely specified. For this reason, the possibility of

fracture and subsequent leakage of liquids must be

taken into account.

In addition, you must prevent particles from the

defective diaphragm reaching the media being

conveyed. This can be achieved e.g. by filtration, a

hose rupture alarm or other means suitable for the

respective process.

CAUTION!

Compressed air

Before working on the double diaphragm pump,

close the compressed air lines and vent the double

diaphragm pump.

Before undertaking any maintenance and repair

work, close off the compressed air supply, dis‐

charge the compressed air and detach the air

supply line from the double diaphragm pump. The

line to the discharge side of the double diaphragm

pump may be under pressure and must likewise be

vented.

CAUTION!

Hot surface

When conveying hot liquids, the pump can likewise

become hot. Hot surfaces may then be present on

the pump. Bear this in mind and take suitable

measures to reduce any hazards.

Safety and responsibility

Maximum pump sound pressure level 91 dB

Depending on the operating conditions, the max‐

imum sound pressure level of the device can reach

88 dB ± 3 dB. Bear this in mind and take suitable

measures to reduce any impact caused by this

sound pressure level. The type and implementa‐

tion of suitable measures depends on the local cir‐

cumstances and is the responsibility of the system

operator.

Check the fastening elements are correctly seated.

Before commissioning the double diaphragm

pump, you must check that all fastening elements

with sealing rings are correctly seated. The seals

may ‘creep’ , so that the fastening elements come

loose over time.

In the event of a diaphragm rupture

In the event of a diaphragm rupture, the pumped

medium can enter the air system of the double dia‐

phragm pump and from there into the atmosphere.

If the pumped medium is a dangerous, harmful or

toxic substance, the air outlet must be routed to a

suitable area where safe disposal is possible.

Operation in the open air and outdoors

–

Take suitable measures to protect the device

from environmental influences when operating

outside such as:

–

UV rays

–

Humidity

–

Frost, etc.

Safety and responsibility

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ProMinent Pompe à eau

ProMinent

ProMinent Hydro/ 4 Manuel utilisateur

ProMinent

ProMinent Sigma/ 1 Basic S1Ba Manuel utilisateur

ProMinent

ProMinent DULCOflex DF4a Manuel utilisateur

ProMinent

ProMinent Makro/ 5 M5Ka Manuel utilisateur

ProMinent

ProMinent DULCO flex Control Manuel utilisateur

ProMinent

ProMinent DULCO flex Control Manuel utilisateur

ProMinent

ProMinent Hydro/4 HP4a Manuel utilisateur

ProMinent

ProMinent ProMinent von Taine 0807 PP Manuel utilisateur

ProMinent

ProMinent Sigma / 2 Basic S2Ba Manuel utilisateur

ProMinent

ProMinent Hydro/ 2 Manuel utilisateur

ProMinent

ProMinent DULCO flex DFAa Manuel utilisateur

ProMinent

ProMinent gamma/ X Mode d'emploi

ProMinent

ProMinent Dulco Flex DF2a Manuel utilisateur

ProMinent

ProMinent Sigma/ 2 Control S2Cb Manuel utilisateur

ProMinent

ProMinent mikro delta Manuel utilisateur

ProMinent

ProMinent gamma XL Manuel utilisateur

ProMinent

ProMinent Sigma/3 Basic S3Ba Series Manuel utilisateur

ProMinent

ProMinent DULCODOS ULIa Manuel utilisateur

ProMinent

ProMinent Sigma 3 S3Ba Manuel utilisateur

ProMinent

ProMinent Beta BT4b Manuel utilisateur

ProMinent

ProMinent Beta BT4a Mode d’emploi

ProMinent

ProMinent DULCO Trans 41/1200 PVDF Manuel utilisateur

ProMinent

ProMinent DULCOnneX Manuel utilisateur

ProMinent

ProMinent Meta MTKa Manuel utilisateur

Manuels Pompe à eau populaires d'autres marques

Neptun

Neptun NPHW 5500 Manuel utilisateur

Sensidyne

Sensidyne Gilian BDX-II Instructions d'installation et d'utilisation

Draper

Draper 47808 Manuel utilisateur

Trolla

Trolla 12820 Manuel utilisateur

Sunfab

Sunfab SVH Series Manuel utilisateur

WilTec

WilTec 50740 Manuel utilisateur

Fieldmann

Fieldmann FVC 5015 EK Manuel utilisateur

Everbilt

Everbilt EFSUB5-122HD Manuel utilisateur

Graco

Graco Husky 3300e Manuel utilisateur

esotec

esotec 101018 Manuel utilisateur

moyno

moyno 2000 CC Manuel utilisateur

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuel utilisateur

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guide de dépannage

DUROMAX

DUROMAX XP WX Series Manuel utilisateur

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuel utilisateur

Franklin Electric

Franklin Electric IPS Manuel utilisateur

Xylem

Xylem e-1532 Series Manuel utilisateur

Milton Roy

Milton Roy PRIMEROYAL Manuel utilisateur
