User Guide
FM12
Multi-Function Car FM Transmitter
Promate FM12 is Wireless FM Transmitter that helps you listen to MP3 files in your
car via an SD or MMC card slot or USB flash memory. FM12 is a multi-functional car
style FM transmitter supports 206 FM channels and has an SD/MMC card slot and a
USB port so you can listen to your MP3 files on the road. Combined with 20 key
remote control and interactive LCD Display, simply plug into your car, turn on your
car stereo and tune up. Plug in a SD/MMC card USB flash drive and even an MP3
player and listen to your favourite music on the go.
Introduction
Transmission range: 10 Meters
Power source: 12V DC(Car lighter socket)
FM channel: 87.5~108.0 MHz
Left-to-right separation: >=40dB
Distortion: 0.3%
Specifications
•FM12
•Remote Control
•User Guide
•Extra Fuse
•Audio Cable
Packing Content
1
Product Diagram
• Panel-button with Power On/Off switch
• Frequency phase lock loop technology and flexible sound coding technology
• Supports line-in for sound devices input flexibility
• Supports folder selection function
• Supports SD/MMC card and USB device
•Supports MP3/WMA files
•16-bit large LCD screen to display track information
•FM channel range from 87.5 ~ 108.0 MHz(Total 206 channels)
•Built-in equalizer for optional sound output
•20-key remote control for easy navigational control
•Made from ABS plastic
Features
12 - 24 Volt Adapter End
Six Position Flexible Joint
Power
SD Memory Card Slot
USB Port
2
Functions:
1. LCD Display
2. Previous Track & Volume Decrease
(USB flash Memory & SD card)
Press this button once to return to the previous file.
Press and hold to decrease the volume.
3. Press the button
To decrease the broadcast frequency
4. Press the button
To increase the broadcast frequency
5. Next Track & Volume Increase
(USB flash memory &SD card)
Press this button once to advance to the next file.
6. Play/Pause
(USB flash memory & SD card)
Press this button once to start playing an MP3 file.
Press it again to pause.
NO DEVICE
LINE IN
Car mp3
90.3
Fm12
1
2
3
4
5
6
3
1.) Insert the device to car cigar socket power supply(12V-24V DC power).
You will see the screen as shown channel in LCD display.
2.) Tune your FM radio to one of pre-set FM frequencies used by the player.
3.) Press the button or to set the player’s broadcast frequency to match
the frequency you have set on your radio.
Set-Up
Remote Control
1.)CH-: Freq Minus
2.)CH+: Freq Plus
3.) Previous music
4.) Next Music
5.) Play/Pause
6.)VOL-: volume decrease
7.)VOL+: volume increase
8.)EQ:EQ mode Selection
9.)0~9 number key: For selection music or Frequency
10.)PICK SONG: Press number key then press this key to select song
11.)CH SET: Press number key then press this key selection transmitter
Freq from 87.5Mhz to 108Mhz
SD
USB
Pre-set Broadcast Frequency
2
1
5
8
9
10
7
4
6
3
11
4
SD Memory Card & USB Flash Memory
1.) Follow the instructions in the “Set-UP” section of this manual.
2.) Insert the SD memory card into the SD card slot to the player.
3.) Press the “ ” button to play/pause. Keep press “ ” key to switch to
play mode (ALL/FOLDER/SINGLE/RANDOM)
4.) Press the “ ” button once to go to previous file. Press and hold the button
to decrease the volume.
Precautions
Please read the following suggestions carefully, that will help you to fulfill any
warranty obligations and to enjoy this product for many years.
• Please do not attempt to disassemble this product, it is possible to result in
short-circuit or even damage.
• The product should be kept in dry and ventilated environment, please avoid
high humidity and high temperature.
• Do not install the equipment near heat sources such as fire, power, or other
simplifiers that product heat.
• Please do not use organic solvent to clean product surface.
• Please keep the product away from little children.
• Rough handling can break internal circuit boards and mechanics.
• Keep the surface clean.
5
