Promaker PRO-H2000 Manuel utilisateur
High Pressure Washer
User’s Manual
Model No.: PRO-H2000
2
SAVE THESE INSTRUCTIONS
Please read and comply with these original instructions prior to
the initial operation of your appliance and store them for later use or
subsequent owners.
Apart from the notes contained herein the general safety provisions
and rules for the prevention of accidents of the legislator must be
observed.
Warnings and notes that are attached on the appliance provide
important notes for the safe operation.
DANGER
Pointer to immediate danger, if not avoided, which leads to severe
injuries or death.
WARNING
Pointer to a possibly dangerous situation, if not avoided, which can
lead to severe injuries or death.
CAUTION
Pointer to a possibly dangerous situation, if not avoided, which can
lead to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation, which can lead to property
damage.
DANGER
Risk of electric shock.
IMPORTANT SAFETY INSTRUCTIONS
Hazard levels
Electric components
3
Never touch the mains plug and the socket with wet hands.
Check the power cord with mains Plug for damage prior to every use.
Do not operate an appliance if the power cord is damaged.
All current-conducting parts in the working area must be protected
against jet water.The mains plug and the coupling of an extension
cable must be watertight and must never lie in water. Moreover, the
coupling may never lie on the ground. The use of cable reels that
ensure that the sockets are at least 60 mm above the ground is
commended.
Make sure that the power cord or extension cable is not damaged by
running over, pinching, dragging or the like. Protect the power cords
from heat, oil, and sharp edges.
Turn off the appliance and remove the mains plug prior to any care and
maintenance works.
Repair work and work on the electrical components may only be
performed by an authorized customer service.
WARNING
The appliance may only be connected to an electric supply that has
been installed by an electrician in accordance with IEC 60364.
The appliance may only be connected to alternate current. The voltage
must correspond with the type plate of the appliance.
Safety class I appliances may only be connected to sockets with
proper earthling.
For safety reasons, we recommend that you operate the appliance
only via a residual current device (max. 30mA).
An unsuitable electrical extension cable can be hazardous. Only use
an electrical extension cable which has been approved and labeled for
this purpose and has an adequate cable cross-section outdoors: 1 - 10
m: 1.5 mm2;10 - 30 m: 2.5 mm2
Always fully unreel the extension cable from the cable drum.
4
DANGER
The user must be the appliance as intended. The person must
consider the local conditions and must pay attention to other persons
in the vicinity when working with the appliance.
Check important components, such as high pressure hose, hand
spray gun and safety installations, for damage prior to every operation.
Immediately replace damaged components. Do not operate appliance
with damaged components.
High-pressure jets can be dangerous if improperly used.The jet may
not be directed at persons, animals, live electrical equipment or at the
appliance itself.
The high-pressure jet must not be directed at other persons or the
user him-/herself to clean clothing or footwear.
Vehicle tyre/ tyre valves are susceptible to damage from the
high-pressure jet and may burst. The rst indication for this is a
discoloration of the tyre. Damaged vehicle tyres/ tyre valves are
perilous. Keep a minimum jet distance of 30cm during cleaning!
WARNING
Do not use the appliance when there are other persons around unless
they are also wearing protective clothing.
The appliance must not be operated by children or persons who have
not been instructed accordingly.
This appliance is not intended for use by persons with limited physical,
sensory or mental capacities or lacking experience and/or skills,
unless such persons are accompanied and supervised by a person in
charge of their safety or they have received precise instructions on the
use of this appliance and have understood the resulting risks.
Children must not play with this appliance.
Supervise children to prevent them from playing with the appliance.
Safe handling
5
Create stability for the appliance prior to any work on or with the
appliance to prevent accidents damage.
The water jet that is emitted from the high pressure nozzle results in
a repulsion power acting on the hand spray gun. Make sure that you
have a rm footing and are also holding the hand spray gun and spray
lance rmly.
Never leave the appliance unattended as long as it is in operation.
ATTENTION
In case of extended breaks, switch the appliance off at the main switch
or pull the mains plug.
Do not operate the appliance at temperatures below 0ºC.
DANGER
The appliance may not be operate in explosive atmospheres.
Never use the appliance to clean objects containing hazardous
substances (e.g. asbestos).
Do not spray ammable liquids.
Never draw in uids containing solvents or undiluted acids and
solvents! This includes petrol, paint thinner and heating oil. The spray
mist is highly inammable, explosive and poisonous. Do not use
acetone, undiluted acids and solvents, as they corrode the materials
used on the appliance.
Keep packaging lms away from children, there is a risk of suffocation!
Other risks
6
WARNING
According to applicable regulations, the appliance must never be used
on the drinking water net without a system separator. Ensure that
the connection of your building water installation on which the high
pressure cleaner is operated is equipped with a system separator
pursuant.
Water that has own through a system separator is no longer
classied as drinking water.
High-pressure hoses, xtures and couplings are important for the
safety of the appliance. Only use high-pressure hoses, xtures and
couplings recommended by the manufacturer.
When disconnecting the supply or high pressure hose, hot water may
leak from the connections after operation.
CAUTION
Mind the weight of the appliance when selecting the storage location
and during transport to prevent accidents or injuries.
Several hours of continuous use of the appliance can lead to
numbness in the hands in rare cases.
• Wear gloves.
• Keep hands warm.
• Take breaks at regular intervals. Working with detergent.
WARNING
This appliance was designed to be used with detergents which are
supplied or recommended by the manufacturer.
The use of other detergents or chemicals may compromise the safety
of the appliance.
The improper use of detergents can cause severe injuries or oxidation.
Store detergents away from the reach of children.
7
CAUTION
Safety installations serve the protection of the user and may not be
modied or by passed.
The appliance switch prevents unintentional operation of the
appliance.
This lock locks the lever of the trigger gun and prevents the
inadvertent start of the appliance. Overow valve with.
If the lever on the trigger gun is released the pressure switch turns off
the pump, the high pressure jet is stopped. If the lever is pulled the
pump is turned on again.
The motor protection switch off the device if the power consumption is
high.
CAUTION
Wear protective clothing and safety goggles to protect against splash
back containing water or dirt.
During the use of high-pressure cleaners aerosols can develop.
Inhaling aerosols can cause health damage.
- Depending on the application, completely shielded nozzles(e.g.
surface cleaner)that signicantly reduce the emission of aqueous
aerosols can be used for high-pressure cleaning.
- The use of such shielding is not possible with all applications.
Safety devices
Power switch
Lock trigger gun
Pressure switch
Motor protection switch
Personal protective equipment
8
The high pressure jet must not be directed at persons,
animals, live electrical equipment or at the appliance itself.
The appliance must not be directly connected to the public
drinking water network.
For protection against injury, wear ear defenders and safety
goggles.
Wear safety gloves during use to protect hands.
Wear non-slip footwear that will protect your feet and improve
your footing on slippery surfaces.
Sound power level is 92dB(A).
Use this pressure washer for private households only:
—For cleaning machines, vehicles, buildings, tools, facades,
terraces, gardening tools, etc. by means of a high pressure water
jet (if necessary, with additional cleaning agents) with accessories,
replacement parts and cleaning agents approved. Please observe the
information accompanying the cleaning agents.
—With accessories, replacement parts and cleaning agents approved
by Promaker®. Please observe the information accompanying the
cleaning agents.
Symbols on the machine
PROPER USE
9
1. Carrying handle
2. High-pressure hose roller
3. Appliance switch „0/OFF“ / „I/ON“
4. Cord hook
5. Power cord
6. Detergent switch
7. Water outlet
8. Trigger gun
9. High pressure hose
10. Gun hook
11. Detergent bottle
12. Detachable
13. Bearing wheel
DESCRIPTION OF THE APPLIANCE
10
Mount loose parts delivered with appliance prior to start-up.
1. Installing the handle
• Attach the handle
• Secure the handle by means of two screws
Voltage 120V ~
Frequency 60Hz
Watt 2000W
Protection Class IPX5
Degree of protection I
Max. pressure 15MPa
Rated pressure 11MPa
Max. ow rate 7.2l/min
Rated ow rate 6.7l/min
Sound pressure level LpA 83dB(A)
Sound pressure level LwA 86dB(A)
ASSEMBLY
TECHNICAL SPECIFICATIONS
