PCH460T-E

OPERATINGAND INSTALLATIONINSTRUCTIONS

BUILT-INVITROCERAMICHOB

Downloaded from www.vandenborre.be

CONTENTS

1.DESCRIPTIONOFTHEHOB

2.SAFETYINSTRUCTIONS

3.INSTALLATION

4.ELECTRICALCONNECTION

5.USAGE

6.TOUCHCONTROLSAFETYFUNCTIONS

7.CLEANINGANDCARE

Downloaded from www.vandenborre.be

DearCustomer,

Thankyou forpurchasing thisProline Cooking Hob.The safetyprecautionsand

recommendationsintheseinstructionsareforyourownsafetyand thatof

others.Theywill alsoprovide ameansbywhichtomakefull useofthe features

offered byyourappliance.

Pleasekeep thisbookletinasafeplace.It maybe usefulinfuture,eitherto

yourselfortoothersinthe eventthatdoubtsshouldariserelating toits

operation.

Thisappliancemustbe used onlyforitsintended purpose,thatisforthe

domesticcooking offoodstuffs.Anyotherformofusage istobe considered as

inappropriateand thereforedangerous.

The manufacturerdeclinesall responsibilityinthe eventofdamage caused

byimproperorincorrectuseofthe appliance.

CEDeclarationofconformity

•Thiscooking hob hasbeen designed tobe used onlyforcooking.Anyother

use(suchasheatin g aroo m)isimproperan d dangerous.

•Thiscooking hob hasbeen designed,constructed,and marketed incompliance

with:

-Safetyrequirementsofthe

-Safetyrequirementsofthe “EMC”Directive89/336/EC;

-Requirementsofthe Directive93/68/EC.

"Lowvoltage"Directive2006/95/EC;

Downloaded from www.vandenborre.be

BEFOREUSINGFORTHEFIRSTTIME.

Read the instructionscarefullybeforeinstalling and using the appliance.

Afterunpacking the appliance,makesureitisnotdamaged.Incaseof

doubt, do notusethe applianceand contactyoursupplieroraqualified

engineer..

Removeall packaging and do notleavethe packing material(plasticbags,

polystyrene,bandsetc)ineasyreachofchildren astheymaycauseserious

injury.The packaging materialsarerecyclable..

The applianceshouldbe installed and all the electricalconnectionsmade

byaqualified engineerincompliancewithlocalregulationsinforceand

following the manufacturersinstructions..

Donotattempttomodifythe technicalpropertiesofthe appliance,asitmay

becomedangeroustouse.

Note:Appearanceofyourhob maybe differentthan themodelshownabove

due toproduction changes.

SINGLEZONE

HEATER

HOB

FRAME

CERAMIC

SURFACETOUCHCONTROL

PANEL

1DESCRIPTION OFTHEHOB

Downloaded from www.vandenborre.be

Please complywiththese instructions.Ifyou do not,anydamage

resulting fromimproper,incorrectornegligentuse orimproper

connection orinstallation isnotcoveredbythewarranty.

SAFETY INSTRUCTIONS2

·Thisapplianceisintended fordomesticuseonly,anyotherusemay

invalidatethe warrantyand mightb e dangerou s.

·Thisappliancemustonlybe used forthe purposeofheating orcooking

food,anyotheruse,forexampleheating rooms,working surfaceor

storage surface,isdangerous..

·Additionsormodificationstothe appliancearenotpermitted.

·Donotplaceorstoreflammableliquids,highlyinflammablematerialsor

fusibleobjectson ornearthe appliance..

·Children mustbe keptawayfromthe appliance..

·The appliancemayonlybe installed and connected byan authorised and

qualified installer..

·The electricalsafetyofthishob isguaranteed onlyifitisconnected to

aproperlyearthed system,whichcomplieswiththe electricalsafety

standards..

·Built-inappliancesmayonlybe used aftertheyhavebeen installed in

suitablebuilt-inunitsand worksurfacesthatmeetthe standards.

·Donotputpressureon the powersupplycablewhilefitting the hob.

·Powersupplycablelengthshouldnotexceed 2mforisolation safety.

·Inthe eventoffaultswiththe applianceordamage tothe glass ceramic

(cracksorsplits),the appliancemustbe switched off and disconnected

fromthe electricalsupplytopreventthe possibilityofan electricshock.

·Repairstothe appliancemustonlybe carried outbyauthorised service

personal..

·Makesureall the packaging hasbeen removed beforeyou usethe

appliance..

·Cablesfromelectricalappliancesmustnottouchthe hotsurfaceofany

applianceorhotcookware..

·Neverleavethe hob unattended when cooking withfatoroil.Theycan

rapidlycatchfireifoverheated..

·Donotcutanyfood on the glassofthe ceramichob.Glasspanelsshould

notbe used asworking surfaces.

Downloaded from www.vandenborre.be

·Becarefulwhen using small householdappliances,suchasirons,near

the elements..

·Donotusethe cooking zoneswithemptycookwareorwithoutcookware.

·Makesureall the controlsareinthe off position when notinuse.

·Forcleaning,the appliancemustbe switched off atthe supplyand cooled

down..

·Donotuseasteamcleanertoclean the applianceasthiscoulddamage

the productand mayinvalidatethe warranty..

·Useonlystableflat-based pans.

WARNING.

When correctlyinstalled,yourproductmeetsall safetyrequirementslaid

downforthistype ofproductcategory.Howeverspecialcareshouldbe

taken around the underneathofthe applianceasthisarea isnotdesigned

orintended tobe touched and maycontainsharporrough edges,thatmay

causeinjury..

FireRisk!Donotleaveinflammablematerialson the Hob top.

Makesurethatelectricalcordsconnecting otherappliancesinthe proximity

cannotcomeintocontactwiththe hob top..

Donotallowheavy orsharpobjectstodrop on the ceramichob.If the hob

iscracked ordamaged,unplug and call the after-salesservice.

Donotscratchthe hob withsharpobjects.Don'tusethe hob asawork

surface..

Beforedisposing ofan unwanted appliance,itisrecommended thatitis

madeinoperativeand thatall potentiallyhazardouspartsaremade harmless.

Important: Thisappliancehasbeen designed fordomesticuseonly.The

applianceisNOTsuitableforusewithinasemi-commercial,commercialor

communalenvironment. .

Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,

itsservice agentorsimilarlyqualifiedperson inordertoavoidan

electricalhazard.

Downloaded from www.vandenborre.be

Theelectricalconnection ofthishob shouldbecarriedoutbyan

authorisedservice personaloraqualifiedelectrician,according tothe

instructionsinthisguideand incompliance withthecurrentregulations.

·Priortoinstallation,ensurethatthe localdistribution conditionsand the

adjustmentofthe appliancearecompatible.

·The laws,ordinances,directivesand standardsinforceinthe countryof

usearetobe followed (safetyregulations,properrecycling inaccordance

withthe regulations,etc.)

Locating yourbuilt-inhob

Afterremoving the packagingmaterialfromthe applianceanditsaccessories,

ensurethatthe hob isnotdamaged.If you suspectanydamage,do notuse

the appliance,contactanauthorised servicepersonaloraqualified electrician

immediately.

·Thisbuilt-inhob istobe inserted intoacutoutofaworktop.It will be

electricallyconnected withthe switchboxbelowcounterlevel,especially

provided forthispurpose.

·Cutan opening withthe dimensionsshowninthe picturebelow.

INSTALLATION3

Downloaded from www.vandenborre.be

·Screwthe 4worktop mounting bracketson the side wallsofproduct.

·Applythe one-sided self-adhesivesealing tape supplied all the wayround

the loweredge ofthe cooking surfacealong the outeredge ofthe glass

ceramicpanel.Donotstretchit.

worktop mounting bracket

Downloaded from www.vandenborre.be

Electricalconnection ofyourhob

·Beforeproceeding withthe electricalconnection,verifythatthe current

carryingcapacityofthesystemand the socketisadequateforthemaximum

powerrating ofthe hob.

·Electricalinstallation ofthe residenceand the electricalcurrentplug in

usemustbe earthed and conformwithsafetyregulations.

·If thereisno dedicated hob circuitand fused switch,theymustbe installed

byaqualified electrician beforethe hob isconnected.

·The fused switchmustbe easilyaccessibleoncethe hob hasbeen

installed.

·Donotuseadaptors,multiplesocketsand/orextension leads.

·Thisapplianceconformswiththe requirementsofthe following EEC

Directives:

1.Vitroceramichob EEC/73/23 and 93/68,EEC/89/336 relating to

radiointerference,

2.EEC/89/109 relating tocontactwithfoods.

·Acircuitbreakerwithacontactopening ofatleast3mm,rated 20 Aand

delayed functioning type mustbe installed inthe supplycircuit.

·The supplycablemustbe H05VV-F3X2,5mm²/60227 IEC53.You will

find the connection diagramshownon the backofyourappliance.

·During installation,pleaseinsurethatisolatedcablesareused.Anincorrect

connection mightdamage yourappliance.The guarantee will notcover

suchdamages.

·All repairsmustbe carried outbyan authorised servicepersonalora

qualified electrician.

·Unplug yourappliancebeforeeachmaintenance.Forreconnection,follow

the connection diagrams.

*This appliance mustbe earthed.

*Forthis connetion apowerlead

ofwiretypeH05VV-Fshould be

used.

ELECTRICAL CONNECTION4

Downloaded from www.vandenborre.be

Mode Descriptions

The applianceisoperated bytouching buttonsand the functionsare

confirmed bydisplays and acousticsignals.

NOTE:See the section on HOBRESETifyou see aflashing Hinanyof

the displays.

Stand-By-Mode S-Mode The mainsare applied tothe hob control

and all heaterdisplays are off oraresidual

heatdisplayisactive.

Operating-Mode B-Mode Atleastone heaterdisplay showsa heat

setting between ´0`and ´9`

Lock Mode VR-Mode The hob control islocked.

USAGE5
