Proline CVMP660W-1 Manuel utilisateur
OPERATING AND INSTALLATION
INSTRUCTIONS OF
ELECTRICAL COOKER
EN
CVMP660W-1
Downloaded from www.vandenborre.be
Dear Customer,
Thank you for purchasing this Cooking Appliance. The safety precautions and
recommendations in these instructions are for your own safety and that of others.
They will also provide a means by which to make full use of the features offered by
your appliance.
Please keep this booklet in a safe place. It may be useful in future, either to
yourself or to others in the event that doubts should arise relating to its operation.
This appliance must be used only for its intended purpose, that is for the domestic
cooking of foodstuffs. Any other form of usage is to be considered as inappropriate
and therefore dangerous.
The manufacturer declines all responsibility in the event of damage caused by
improper or incorrect use of the appliance.
CE Declaration of conformity
This cooking appliance has been designed to be used only for cooking. Any other use
(such as heating a room) is improper and dangerous.
This cooking hob has been designed, constructed and marketed incompliance with:
- Safety requirements of the ''LVD'' Directive 2006/95/EC;
- Safety requirements of the ''EMC'' Directive 2004/108/EC;
- Requirements of the Directive 93/68/EC.
Downloaded from www.vandenborre.be
CONTENTS:
1. INTRODUCTION OF PRODUCT
2. SAFETY WARNINGS
3. INSTALLATION AND PREPARATION FOR USE
4. USING THE PRODUCT
5. CLEANING AND MAINTENANCE
6. TROUBLESHOOTING
Downloaded from www.vandenborre.be
1
PART 1: INTRODUCTION OF PRODUCT
List of Components
1. Cooktop
2. Control panel
3. Oven door handle
4. Storage compartment door
5-
6. Oven door
7. Oven Tray
8. Wire Grid
9. Grill element
Adjustable foot
10. Oven lamp
1
2
345
6
7
8
9
10
MODEL
CVMP660W-1 60 60 85
WIDTH
(cm)
HEIGHT
(cm)
DEPTH-
DECODER (cm)
Downloaded from www.vandenborre.be
4
2
READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING YOUR
APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY.
General Safety Warnings
-This appliance is intended for domestic
household use only and should not be used for
any other purpose or in any other application,
such as for non-domestic use or in a
commercial environment.
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
- If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
- WARNING: The appliance and its accessible
parts become hot during use. Care should be
taken to avoid touching heating elements.
Children less than 8 years of age shall be kept
PART 2 SAFETY WARNINGS
Downloaded from www.vandenborre.be
3
away unless continuously supervised.
- WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in
fire. NEVER try to extinguish a fire with water,
but switch off the appliance and then cover flame
e.g. with a lid or a fire blanket.
- WARNING: Danger of fire: do not store items
on the cooking surfaces.
- WARNING: If the surface is cracked, switch off
the appliance to avoid the possibility of electric
shock.
- The appliance is not intended to be operated
by means of an external timer or separate
remote-control system.
- During use, the appliance becomes hot. Care
should be taken to avoid touching heating
elements inside the oven.
- Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass and
other surface since they can scratch the surface,
which may result in shattering of the glass.
- Do not use steam cleaners for cleaning the
appliance.
The oven must be switched off before removing
the guard. After cleaning, the guard must be
replaced according to the instructions.
Downloaded from www.vandenborre.be
4
- WARNING: Ensure that the appliance is
switched off before replacing the lamp to avoid
the possibility of electric shock.
- CAUTION: Accessible parts may be hot during
use. Young children should be kept away.
General safety instructions:
• Your appliance is produced in accordance with all applicable local and international standards and
regulations.
• Maintenance and repair work must be made only by authorised service technicians. Installation and
repair work that is carried out by unauthorised technicians may endanger you. It is dangerous to alter
or modify the specifications of the appliance in any way.
• Prior to installation, ensure that the local distribution conditions (electricity voltage and frequency)
and the requirements of the appliance are compatible. The requirements for this appliance are stated
on the label.
• CAUTION: This appliance is designed only for cooking food and is intended for indoor domestic
household use only and should not be used for any other purpose or in any other application, such
as for non-domestic use or in a commercial environment or room heating.
• Do not try to lift or move the appliance by pulling the door handle.
• All possible security measures have been taken to ensure your safety. Since the glass may break,
you should be careful while cleaning to avoid scratching. Avoid hitting or knocking on the glass with
accessories.
• While the oven door is open, do not let children climb on the door or sit on it.
Installation Warnings
In order to prevent tipping of the appliance, the stabilizing brackets provided must be installed
following the manufacturer's instructions.
• Do not operate the appliance before it is fully installed.
• The appliance must be installed by an authorised technician and put into use. The producer is not
responsible for any damage that might be caused by defective placement and installation by
unauthorised people.
• When you unpack the appliance, make sure that it has not been damaged during transportation. In
case of any defect; do not use the appliance and contact a qualified service agent immediately. As
the materials used for packaging (nylon, staplers, styrofoam...etc) may cause harmful effects to
children, they should be collected and removed immediately.
• Protect your appliance against atmospheric effects. Do not expose it to effects such as sun, rain, snow
etc.
Downloaded from www.vandenborre.be
5
During use
• When you first run your oven a certain smell will emanate from the insulation materials and the
heater elements. For this reason, before using your oven, run it empty at maximum temperature for
45 minutes. At the same time you need to properly ventilate the environment in which the product is
installed.
• During usage, the outer and inner surfaces of the oven get hot. While opening the oven door, step
back to avoid the hot steam coming out of the oven. There may be a risk of burns.
• Do not put flammable or combustible materials, in or near the appliance when it is operating.
• Always use oven gloves to remove and replace food in the oven.
• Always position pans over the centre of the cooking zone, and turn the handles to a safe position
so they cannot be knocked or grabbed.
• If you will not use the appliance for a long time, plug it off. Keep the main control switch off.
• Make sure the appliance control knobs are always in the "0" (stop) position when it is not used.
• The trays incline when pulled out. Be careful not to let hot liquid spill over.
• When the oven door or storage compartment door is open, do not leave anything on it. You may
unbalance your appliance or break the door.
• Do not put heavy things or flammable or ignitable goods (nylon, plastic bag, paper, cloth...etc) into
the storage compartment. This includes cookware with plastic accessories (e.g. handles).
• Do not hang towels, dishcloths or clothes from the appliance or its handles.
During cleaning and maintenance
• Always turn the appliance off before operations such as cleaning or maintenance. You can do it
after plugging the appliance off or turning the main switches off.
• Do not remove the control knobs to clean the control panel.
TO MAINTAIN THE EFFICIENCY AND SAFETY OF YOUR APPLIANCE, WE RECOMMEND YOU
ALWAYS USE ORIGINAL SPARE PARTS AND TO CALL ONLY OUR AUTHORISED
SERVICE AGENTS IN CASE OF NEED.
Downloaded from www.vandenborre.be
6
PART 3: INSTALLATION AND PREPARATION FOR USE
Before any installation work can be carried out a number of requirements must be met.
Make sure that you and your installer are familiar with all the relevant building and fire
regulation requirements before choosing the location of your appliance.
This appliance must be installed in accordance with the instructions to validate the guarantee.
· The position of the cooker should ensure free access to all controls.
· Avoid installing the cooker next to a fridge, freezer or boiler.
· Do not install directly below or near combustible materials (e.g. curtains).
· Ensure that the surrounding material is heat resistant and non-combustible and must be
manufactured resistant to temperatures of up to 80°c.
· The electricity supply must be routed near to the installation.
· There must not be any plugs, wires or sockets in the wall directly above or behind the cooker top.
Certain minimum clearances must be allowed for when planning the unit's location.
· There should be an open space above the hob to allow kitchen odours to disperse. A cooker hood
may be installed to either absorb or extract the odours. The distance between the hob and the
hood must not be less than 65cm (with hood) or 70cm (without hood).
· There should be a space of a minimum of 2cm at the rear and sides of the appliance to ensure
good ventilation.
· If the kitchen furniture is higher than the cooktop, it must be at least 10cm away from the
appliance.
THIS APPLIANCE MUST BE INSTALLED BY AN AUTHORISED SERVICE TECHNICIAN
Min. 60cm
COOKER HOOD
Min. 42cm
Min. 42cm
Min. 65cm(with hood)
Min. 70cm(without hood)
Downloaded from www.vandenborre.be
7
Before proceeding with the electrical connection, verify that the current carrying capacity of the
is adequate for the maximum power rating of the cooker.
Do not use adaptors, multiple sockets and/or extension leads.
Fused switch must be accessible once the cooker has been installed.
IMPORTANT: The following diameters of supply cable must be used at least in case of one
phase connection:
electrical supply
Connection diagram is given below.
3x2.5 mm 220V~
3x2.5 mm 230V~
3x2.5 mm 240V~
²
²
²
5x1.5 mm 380V 3N~
5x1.5 mm 400V 3N~
5x1.5 mm 415V 3N~
²
²
²
3.2 ADJUSTMENT OF FEET
Do not lift by pulling the oven door handle.
Your cooker stands on 4 adjustable feet. When the cooker is
placed where it will be used, check if the cooker is balanced. If
it is not balanced, you can make the adjustment by turning the
feet clockwise if required. It is possible to raise the appliance a
maximum of 30mm by the feet. If the feet are adjusted
appropriately, you should not move the appliance by dragging,
it should be moved by lifting it up.
PART 3: INSTALLATION AND PREPARATION FOR USE
THIS COOKER MUST BE HARDWIRED ONLY
Figure 2
3.3 ELECTRIC CONNECTION AND SAFETY
One-phase, 32A Three-phase, 16A
Downloaded from www.vandenborre.be
