english
2Multi image processor User’s Guide – Introduction
www.projectiondesign.com
english
3
1 Introduction
1.1 Thank you
Thank you for purchasing a Multi image processing system processor.
The Multi image processing systems WB2560 and WB1920 are state-of-the-art image
processing engines for the combination and setup of multiple projectors in order to create
one, large, seamless image. By combining multiple projectors, images with unprecedented
resolution and fidelity can be created.
The multi image processing system processors feature unique functionality and unmatched
compatibility, and are perfectly tailored to working with projectiondesign projectors for use in
multi-image environments.
1.1 Features
• Geometry correction
• Blending and overlap
• 2560x1600, and 1920x1200 models available
• User selectable algorithm setups
• 4x4 Lanczos scaling
• Bi-linear scaling
• B-cubic scaling
• Project onto any surface
• Zero, or near zero latency, depending on set up and configuration
• 3D stereo compatible, up to 1920x1200 on WB2560, and 1280x800 on WB1920
• Patented Black Level Matching for uniform black levels
• Per-pixel Colour-, Uniformity-, and brightness matching
• 12-bit internal resolution
• Dual-Link DVI-D in / out
• All control through Ethernet
• Built-in power supply for easy power management in large racks
• Integrates seamlessly with projectiondesign ProNet multi image processing system
software setup suite
• Rack mount, ½ width, 1U height
• Unlimited scalability and channel count
• Fully transparent to source, no special software or source requirements
english
4Multi image processor User’s Guide – Introduction
Contents of this User’s Guide
1 Introduction 3
1.1 Thank you
1.1 Features
2 SAFETY 7
2.1 GENERAL WARNINGS
2.2 WEEE INFORMATION
2.3 WARNING ABOUT SUBSTANCES
2.3.1 WARNING SYMBOLS
3 What’s in the box? 9
3.1 The multi image processing system comes with the following:
4 Installation and setup 11
4.1 System requirements
4.2 System overview
4.3 Connectors
4.4 LED indicators / Front button
4.5 Network settings
4.6 Firewall settings
4.7 Software
4.8 Mounting the multi image processing system processor in rack
5 Getting to know the GUI 15
5.1 ProNet.site
5.2 WB Calibrator – Device View
5.2.1 Creating and saving a multi image processing system setup project
5.2.2 Backing up and restoring calibration
5.2.3 Adding multi image processing system units to a project
5.2.4 Using the Device View Toolbar, DVT
5.2.5 Clearing calibration
5.2.6 Notifications and advanced network settings
5.2.7 Performing software upgrades
5.2.8 Controlling EDID information
5.3 WB calibrator – Calibration View
5.3.1 Using the Calibration View Toolbar (CVT)
5.3.2 Selecting/deselecting multi image processing system units
5.3.3 Using the Calibration Panel Toolbar (CPT)
www.projectiondesign.com
english
5
5.4 Multi image processing operational states
5.4.1 Bypass states
5.4.2 Calibration state
5.4.3 Online state
5.4.4 Auto state
6 Geometry correction 27
6.1 Warping algorithms
6.1.1 Perspective
6.1.2 Mesh Warp Transform
6.1.3 Mesh Warp Bezier
6.2 Warping user interface
6.3 Scaling filters
6.3.1 Lanczos filter
6.3.2 B-spline filter
6.3.3 C-spline filter
6.3.4 Linear interpolation filter
6.4 Working with the perspective algorithm
6.5 Working with the Mesh Transform algorithm
6.6 Working with Mesh Bezier algorithm
6.7 Fine tuning control points
6.8 Real Time Warp
7 Edge blending 35
7.1 Introduction
7.2 Edge blending algorithms
7.2.1 Basic edge blending
7.2.2 Advanced edge blending
7.2.3 User interface for basic edge blending
7.2.4 User interface for advanced edge blending
7.2.5 Adjusting the shape of advanced edge blending zones
7.2.6 Adjusting the advanced blend drop-off curve
8 Test patterns 41
8.1 Circle test pattern
8.2 Grid (Pixel) test pattern
8.3 Grid (Angle) test pattern
8.4 Turning test patterns on and off
english
6Multi image processor User’s Guide – Introduction
9 Black Level Management 45
9.1 Creating adjustment zones
9.2 Removing BLM zones
9.3 Adjusting black level in a defined zone
10 Masking 49
10.1 Adding areas to clip
10.2 Removing clip areas
11 Storing and recalling data 53
11.1 Storing/recalling calibration to/from the multi image processor unit
11.2 Storing/recalling data to/from the control PC
11.2.1 Restoring calbration files
11.3 Accept calibration
12 Technical specifications 57
12.1 Electrical
12.2 Mechanical
english
7
www.projectiondesign.com
2 SAFETY
This device complies with safety regulations for Information Technology Equipment intended
to operate in “normal” environments (offices and homes). Before using the device for the first
time, please read the safety instructions thoroughly.
2.1 GENERAL WARNINGS
Use only the cables and cords supplied with the device or original replacement cables. Using
other cables or cords may lead to malfunction and permanent damage of the device.
Always use 3-prong / grounded power cord to ensure proper grounding of the device. Never
use 2-prong power cords, as this is dangerous and could lead to electrical shock.
Never open the device. The device contains no user serviceable parts. Refer all repairs to
qualified personnel only. Make sure that no objects enter into the vents and openings of the
set.
Do not spill any liquids on the device or into the vents or openings of the device.
Always remove protective plastic covering the device before operating the device.
Only place the device on a stable surface, or mount it securely in a rack.
Do not drop the device.
The device can be used as desktop or rack mounted with the certification labels facing
down. Any other mounting directions are not allowed. When rack mounted, care must
be taken to keep ventilation on back and front sides open. Operating the device in other
positions may lead to overheating, resulting in malfunctioning.
Always allow ample airflow through the device. Never block any of the air vents. Never
cover the device in any way while running. Allow for sufficient distance to walls and other
obstructions to avoid overheating.
Minimum safety distance to front or rear of the device is 20 cm (8”) to rear and 5 cm (2”) to
front.
The device is designed for indoor use only. Never operate the device outdoors.
Do not operate the device outside its temperature and humidity specifications, as this may
result in overheating and malfunctioning.
Only connect the device to signal sources and voltages as described in the technical
specification. Connecting to unspecified signal sources or voltages may lead to malfunction
and permanent damage of the device.
2.1 WEEE INFORMATION
This product conforms to all requirements of the EU Directive on waste electrical and
electronic equipment (WEEE). This product should be recycled properly. It can be
disassembled to facilitate proper recycling of the individual parts.
Consult your dealer or relevant public authority regarding drop-off points for collection of
WEEE.
english
8Multi image processor User’s Guide – Safety instructions
2.1 WARNING ABOUT SUBSTANCES
This product contains chemicals, including lead, known to the State of California to cause
birth defects or other reproductive harm. Recycle properly, do not dispose of in ordinary
waste!.
2.1.1 WARNING SYMBOLS
READ USER GUIDE Attention! Read the user guide for further information!
RECYCLE Warning! Recycle properly, do not dispose of in ordinary waste!
NO TELEPHONE Warning! Do not connect to telephone lines!
english
9
www.projectiondesign.com
3 What’s in the box?
3.1 The multi image processing system comes with the following:
Multi image processing system unit
Power Cable (Country Dependant)
2x Dual Link DVI cables
CD with software
Network cable
User Documentation
Please verify that you have all compoents upon unpacking the unit, and its contents.
Please save packaging materials for future use, should it be necessary to ship the unit.
english
10Multi image processor User’s Guide - What’s in the Box?
