Before installing your speakers, you should consider their

placement carefully, taking into account the location of

electrical, plumbing and other xtures. Contact your Dealer

for assistance if you are unsure of the best location for your

particular listening environment.

Placement In Ceiling: When placing your speakers into the

ceiling, they should ideally be located above the primary lis-

tening area. If the speakers are positioned far away from the

primary listening area, adjust the pivoting tweeters so they are

pointed towards it.

Note: To avoid possible damage to the pivoting tweeters, read the

section entitled “SPEAKER ADJUSTMENTS” in this manual prior to

performing the tweeter adjustment.

In a very large room with high ceilings, it may be necessary to

place additional speakers throughout the room. Contact your

Procient Audio Systems Dealer for assistance.

New Construction - Unnished Ceilings

A Pre-Construction Bracket, available from your Dealer, may

be installed prior to drywall application across joists (up to

24" on-center) where a speaker will be located. After the hole

is cut and the drywall is installed, the speakers are then easily

installed following the instructions for mounting in “Finished

Ceilings” below. Note: If the speakers are to be mounted more

than 24" on-center, a special “Extra Long Wing” is available from

your Dealer.

Finished Ceilings

Prior to the actual installation of the speakers, it will be neces-

sary to run cables to the speaker locations. See your Dealer for

more information about cable installation. After the cable has

been properly installed, you are ready to mount the speakers.

Following the simple steps listed below will result in a profes-

sional looking installation:

1. Determine the best area to mount your speakers. This area

of the ceiling should be free of obstructions such as electri-

cal conduit, HVAC ducts, or water lines. This can best be

determined by noting the placement of xtures and gaining

access to an attic or crawl space for further analysis of the

location of such obstacles.

2. Find the joists nearest the desired speaker mounting loca-

tion. We highly recommend using a good stud-nder tool

for this procedure. If you are lining up the speakers to some

other object or molding in the room, make sure you con-

sider the size of the bae ange which extends beyond the

mounting hole.

3. Mark the hole. A template for setting the hole is provided

in the box (along with two paint mask inserts for use when

painting). Position the template in the desired position and

pencil an outline on the ceiling.

4. Cutting the hole. CAUTION: This is the most important part

of the entire installation. If you are not certain whether any

obstructions exist behind the desired mounting area, you

should start by cutting a small hole in the center of your

penciled mounting hole with a drywall saw, cutting at a 45˚

angle towards the inside of the hole. (See Diagram 1) Cutting

the small hole at this angle will make drywall repair much

easier, using the piece cut out. Once you have determined

that there aren’t any obstructions in your desired mounting

location, start cutting the nished hole at a 90˚ angle to the

ceiling surface.

5. Add insulation. If the area in the ceiling is not already

insulated, add an adequate amount insulation material to

loosely cover the back of the speaker. If the insulation mate-

rial used is faced with foil or paper, position the foil or paper

away from the speaker.

SPEAKER PLACEMENT

MOUNTING SURFACE PREPARATION

Diagram 1:

Ceiling Cut Out

Audio Systems

OWNER’S MANUAL

CEILING SPEAKERS

C500 • C605 • C610 • C620 • C640

C645 • C790 • C800 • C850

The Ceiling Series speakers come from the factory with the

tweeter facing straight out from the bae. This will result

in the overall smoothest response. However, depending on

your particular primary listening area, room acoustics, ceiling

height, or personal preference, you may nd the sound more

pleasing by pointing the tweeters in a particular direction. If

additional treble is desired in the primary listening area, point

the tweeter towards that area; and if less treble is required,

point the tweeter away. Push gently at the edge of the tweeter

to point it in the desired direction. (See Diagram 2)

CAUTION: Avoid touching metal dome tweeters, as damage

may occur (C640, C645, C800, and C850).

Tweeter Adjustment (C640, C645, C800, & C850):

The switch labeled TREBLE allows for 3dB of treble adjustment.

Your speakers were shipped with the treble switch in the “–”

position, providing the most linear frequency response. If you

desire more treble, move the switch to the “+” position, and the

tweeter will play 3dB higher. To return to the neutral setting,

push the switch back to the “–” position. (See Diagram 3)

Woofer Adjustment (C640, C645, C800, & C850):

The switch labeled BASS allows for 3dB of bass adjustment.

Your speakers were shipped with the bass set to “–”. This set-

ting provides the attest bass frequency response. If you desire

more bass, push the switch to the “+” position and the bass

will play 3dB higher. To return to the neutral setting, push the

switch back to the “–” position. (See Diagram 3)

The unique integral four-foot mounting system incorporated

into each Ceiling Series speaker allows for a quick installation

by following these easy steps:

1. Remove the grille. It may be necessary to push one or two

of the mounting screws and its attached foot towards the

bae and against the inside surface of the grille to force the

grille out of its retaining groove.

2. Attach the speaker cable (observing the proper polarity with

your amplier, + to + and – to –). Make sure the left channel

of the amplier is connected to the left speaker, and the right

channel is connected to the right speaker.

3. Make sure the mounting feet are turned inward to clear the

opening, and insert the speaker into the ceiling. Position the

speaker into the hole.

Note: The ange of the speaker is designed to ex and conform

to any small imperfections in the ceiling’s surface. Tighten the

four screws on the front of the bae only enough to make the

ange become snug against the ceiling. As you tighten the

screws, the feet will automatically ip into an outward position

(See Diagram 4), thereby clamping the drywall between the feet

and the ange. CAUTION: Over-tightening may warp the

bae, crack the ceiling, cause the ange to distort, and

make the grille dicult to install.

4. Push the grille rmly into the slot in the speaker bae.

SPEAKER ADJUSTMENTS

SPEAKER INSTALLATION

Push Tweeter Here

Bass Adjustment Switch

Treble Adjustment Switch

If you plan to paint your speakers, we recommend that it be

done prior to installation. If you plan to paint your speakers

sometime in the future, it is best to remove them by simply

reversing the steps for “SPEAKER INSTALLATION” above.

If it is necessary to paint the speakers when they are in the

ceiling, the paint masks provided in the carton must be

installed between the grille and ange while they are being

painted with the ceiling.

Before painting your speakers, remove the white acoustic blan-

ket under the grilles. Once the speakers have been painted,

return the acoustic blanket back into place.

Great care should be taken not to clog the holes of the grille,

as this will reduce the sound quality of the speakers.

Procient recommends only light spray painting using 5 parts

thinning agent to 1 part paint.

PAINTING THE SPEAKERS

Diagram 2:

Tweeter Diagram 3:

Adjustment Switches

Diagram 4:

Mounting Feet

C500 C605 C610

Speaker Type: 2-Way Coaxial In-Ceiling 2-Way Coaxial In-Ceiling 2-Way Coaxial In-Ceiling

Tweeter: Pivoting ½" Polyamide Dome ¾" Soft Dome Pivoting 1" Soft Dome

Woofer: 5¼" Polypropylene Cone 6½" Polypropylene Cone 6½" Polypropylene Cone

with Rubber Surround with Rubber Surround with Rubber Surround

Impedance: 8  8  8 

Sensitivity: 90dB 1W/1m 90dB 1W/1m 91dB 1W/1m

Contour Switches: – – –

Frequency Response: 40Hz - 20kHz 45Hz - 20kHz 40Hz - 20kHz

Power Handling: 75 watts 75 watts 85 watts

Diameter x Depth: 7¾" x 3¼" 9¼" x 3⁄" 9¼" x 3⁄"

Ceiling Cut Out: 6⁄" 8¼" 8¼"

SPEAKER SPECIFICATIONS

C620 C640 C645

Speaker Type: 2-Way Coaxial In-Ceiling 2-Way Coaxial In-Ceiling 2-Way Coaxial In-Ceiling

Tweeter: Pivoting 1" Silk Dome Pivoting 1" Aluminum Dome Pivoting 1" Aluminum Dome

Woofer: 6½" Polypropylene Cone 6½" Graphite Cone 6½" Kevlar Cone with Cast

with Rubber Surround with Rubber Surround Magnesium Woofer Basket

and Rubber Surround

Impedance: 8  8  8 

Sensitivity: 91dB 1W/1m 92dB 1W/1m 92dB 1W/1m

Contour Switches: – Front-Mounted 2-Position Front-Mounted 2-Position

+3dB Bass & Treble Switches +3dB Bass & Treble Switches

Frequency Response: 36Hz - 20kHz 32Hz - 22kHz 32Hz - 22kHz

Power Handling: 100 watts 125 watts 150 watts

Diameter x Depth: 9¼" x 3⁄" 9¼" x 3⁄" 9¼" x 3⁄"

Ceiling Cut Out: 8¼" 8¼" 8¼"

C790 C800 C850

Speaker Type: 2-Way Coaxial In-Ceiling 2-Way Coaxial In-Ceiling 2-Way Coaxial In-Ceiling

Tweeter: Pivoting 1" Soft Dome Pivoting 1" Aluminum Dome Pivoting 1" Aluminum Dome

Woofer: 8" Polypropylene Cone 8" Graphite Cone 8" Kevlar Cone with Cast

with Rubber Surround with Rubber Surround Magnesium Woofer Basket

and Rubber Surround

Impedance: 8  8  8 

Sensitivity: 92dB 1W/1m 92dB 1W/1m 92dB 1W/1m

Contour Switches: – Front-Mounted 2-Position Front-Mounted 3-Position

+3dB Bass & Treble Switches ±3dB Bass & Treble Switches

Frequency Response: 36Hz - 20kHz 28Hz - 22kHz 28Hz - 22kHz

Power Handling: 125 watts 150 watts 175 watts

Diameter x Depth: 11⁄ " x 4¼" 11⁄ " x 4¼" 11⁄ " x 4¼"

Ceiling Cut Out: 9⁄" 9⁄" 9⁄"

Features and specications are subject to change without notice.

For technical inquiries please call 800.448.0976 or email us at techsupport@procientaudio.com. We are available to assist you

every weekday, except holidays, between the hours of 7:00 a.m. and 5:00 p.m. PST.

Procient Audio Systems warrants to the original retail pur-

chaser only that this product will be free from defects in

materials and workmanship for a period of ten years, provided

the speaker was purchased from a Procient Audio Systems

Authorized Dealer.

Defective products must be shipped, prepaid and insured,

together with proof of purchase, to the Procient Audio

Systems Authorized Dealer from whom they were purchased,

or to Procient Audio Systems at the address listed on this

installation instruction manual. Freight collect shipments will

be refused. It is preferable to ship this product in the original

shipping container to lessen the chance of transit damage. In

any case, the risk of loss or damage in transit is to be borne by

the purchaser.

If, upon examination at the Factory or Procient Audio Systems

Authorized Dealer, it is determined that the unit was defec-

tive in materials or workmanship at any time during this war-

ranty period, Procient Audio Systems or the Procient Audio

Systems Authorized Dealer will, at its option, repair or replace

this product at no additional charge, except as set forth below.

If this model is no longer available and can not be repaired

eectively, Procient Audio Systems, at its sole option, may

replace the unit with a current model of equal or greater value.

In some cases where a new model is substituted, a modication

to the mounting surface may be required. If mounting surface

modication is required, Procient Audio Systems assumes

no responsibility or liability for such modication. All replaced

parts and product become the property of Procient Audio

Systems. Products replaced or repaired under this Warranty will

be returned to the original retail purchaser, within a reasonable

time, freight prepaid.

This Warranty does not include service or parts to repair dam-

age caused by accident, disaster, misuse, abuse, negligence,

inadequate packing or shipping procedures, commercial use,

voltage inputs in excess of the rated maximum of the unit, or

service, repair or modication of the product which has not

been authorized or approved by Procient Audio Systems. This

Warranty also excludes normal cosmetic deterioration caused

by environmental conditions. This warranty will be void if the

Serial Number on the product has been removed, tampered

with or defaced.

This Warranty is in lieu of all other expressed warranties. If

the product is defective in materials or workmanship as war-

ranted above, the purchaser’s sole remedy shall be repair or

replacement as provided above. In no event will Procient

Audio Systems be liable for any incidental or consequential

damages arising out of the use or inability to use the product,

even if Procient Audio Systems. or a Procient Audio Systems

Authorized Dealer has been advised of the possibility of such

damages, or for any claim by any other party. Some states do

not allow the exclusion or limitation of consequential dam-

ages, so the above limitation and exclusion may not apply.

All implied warranties on the product are limited to the duration

of this expressed Warranty. Some states do not allow limitation

on the length of an implied warranty. If the original retail pur-

chaser resides in such a state, this limitation does not apply.

LIMITED TEN-YEAR WARRANTY

1301-11000 (rev3)

Audio Systems

940 Columbia Avenue, Riverside, CA 92507

800.448.0976 • Fax 951.787.8747 • procientaudio.com

Ce manuel convient aux modèles suivants

Autres manuels Proficient Audio Systems Intervenants

Proficient Audio Systems

Proficient Audio Systems MDS Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems AW500TTblk/wht Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems CC525 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems R650 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems WALL W670 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems F400gb Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems F400gb Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems R800 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems Proficient S8 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems F400slvr Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems AW650blk Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems IW675s Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems C870 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems C1030 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems IW525 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems C870 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems C655 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems Signature C895s Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems C870 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems W665 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems IW650 Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems Rock Series Manuel utilisateur

Proficient Audio Systems

Proficient Audio Systems Kevlar CC550 Manuel du système

Proficient Audio Systems

Proficient Audio Systems C605 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
