Procom BLUE FLAME MNSD100TBA Guide de démarrage rapide

VENT-FREE GAS WALL

HEATER

OWNER’S OPERATION AND

INSTALLATION MANUAL

BLUE FLAME MODELS

MNSD100TBA, MNSD200TBA

MNSD300TBA, MNSD100HBA

MNSD200TBA-BB

MNSD300TBA-BB

Questions, problems, missing parts? Before returning to your retailer, call

our customer service department at 1-866-573-0674, 8:00 am - 4:30 pm CST,

Monday through Friday or email [email protected]

PFS

WARNING: If the information in this manual is not

followed exactly, a re or explosion may result causing

property damage, personal injury or loss of life.

— Do not store or use gasoline or other ammable va-

pors and liquids in the vicinity of this or any other

appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any

phone in your building.

•

Immediately call your gas supplier from a neighbor’s

phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the re

department.

—

Installation and service must be performed by a quali-

ed installer, service agency or the gas supplier.

WARNING: This appliance is equipped for Natural and

Propane gas. Field conversion is not permitted other than

between natural or propane gases.

www.usaprocom.com 200213-01C2

INSTALLER: Leave this manual with the appliance.

CONSUMER: Retain this manual for future reference.

This is an unvented gas-red heater. It uses air (oxygen)

from the room in which it is installed. Provisions for ad-

equate combustion and ventilation air must be provided.

Refer to Air For Combustion and Ventilation section on

page 7 of this manual.

WARNING: Improper installation, adjustment, al-

teration, service or maintenance can cause injury or

property damage. Refer to this manual for correct in-

stallation and operational procedures. For assistance

or additional information consult a qualied installer,

service agency or the gas supplier.

This appliance may be installed in an aftermarket,* per-

manently located, manufactured (mobile) home, where

not prohibited by local codes.

This appliance is only for use with propane or natural

gas. Field conversion by any other means including the

use of a kit is not permitted.

* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.

SAVE THIS BOOK

TABLE OF CONTENTS

Safety ........................................................ 3

Product Features....................................... 4

Specications ............................................ 5

Qualied Installing Agency ........................ 5

Local Codes............................................... 6

Product Identication................................. 6

Unpacking.................................................. 6

Water Vapor: A By-Product Of

Unvented Room Heaters..................... 7

Air For Combustion and Ventilation........... 7

Installation ................................................. 9

Operation................................................. 19

Electrical Connection............................... 22

Electrical Wiring....................................... 22

Inspecting Heater .................................... 23

Care And Maintenance............................ 24

Troubleshooting....................................... 25

Service Hints ........................................... 28

Technical Service..................................... 28

Replacement Parts.................................. 29

Accessories ............................................. 29

Parts ........................................................ 30

Warranty .................................................. 34

PROCOM HEATING, INC. PATENT INFORMATION

This product may be covered by one or more of the following United States patents:

9,829,195 9,423,123 9,441,833 9,518,732 9,752,779 9,416,977 8,764,436

8,568,136 8,516,878 8,297,968 8,281,781 8,235,708 7,967,006

7,967,007 7,730,765 7,677,236 7,607,426 7,434,447

www.usaprocom.com 3200213-01C

SAFETY

WARNING: Do not attempt to

access or change the setting of

the fuel selection means.

Access to and adjustment of

the fuel selection means must

only be performed by a qualied

servicepersonwhenconnecting

this appliance to a specied fuel

supplyat the time of installation.

Change of the selector setting

to other than the fuel type speci-

ed at the time of the installation

coulddamagethisapplianceand

render it inoperable.

The installer shall replace the

access cover before completing

the installation and operating

this appliance.

IMPORTANT: Read this owner’s

manualcarefullyandcompletely

before trying to assemble, op-

erate, or service this heater.

Improper use of this heater can

cause serious injury or death

from burns, fire, explosion,

electrical shock and carbon

monoxide poisoning.

Only a qualied installer, service

agent, or local gas supplier may

install and service this product.

WARNING: Keep the appli-

ance area clear and free from

combustible materials, gasoline,

and other ammable vapors and

liquids.

WARNING: This appliance

can be used with propane or

natural gas. It is shipped from

the factory adjusted for use with

propane.

This appliance is only for use

with the type of gas indicated on

the rating plate. This appliance

is not convertible for use with

other gases.

DANGER: Carbon monoxide

poisoning may lead to death!

CARBON MONOXIDE POISONING: Early

signs of carbon monoxide poisoning resemble

the u, with headaches, dizziness or nausea.

If you have these signs, the heater may not be

working properly. Get fresh air at once! Have

heater serviced. Some people are more af-

fected by carbon monoxide than others. These

include pregnant women, people with heart or

lung disease or anemia, those under the inu-

ence of alcohol and those at high altitudes.

NATURAL AND PROPANE GAS: Natural and

Propane gas are odorless. An odor-making

agent is added to the gas. The odor helps you

detect a gas leak. However, the odor added to

the gas can fade. Gas may be present even

though no odor exists.

WARNING: Any change to

this heater or its controls can

be dangerous.

WARNING: Do not use any

accessories not approved for

use with this heater.

WARNING: Carefully super-

vise young children when they

are in the room with the heater.

WARNING: Make sure grill

guard is in place before running

heater.

WARNING: Due to high tem-

peratures, the appliance should

be located out of trafc and away

from furniture and draperies.

www.usaprocom.com 200213-01C4

WARNING: Heater becomes

very hot when running. Keep

childrenandadultsawayfromhot

surfaces to avoid burns or cloth-

ing ignition. Heater will remain

hot for a time after shutoff. Allow

surfaces to cool before touching.

WARNING:Donotplacecloth-

ing or other ammable material

on or near the appliance. Never

place any objects in the heater.

1. Do not place propane supply tank(s) inside

any structure. Propane supply tank(s)

must be placed outdoors.

2. Heaters with a maximum input over

6,000 Btu/Hr shall not be installed in a

bathroom. Heaters with a maximum input

over 10,000 Btu/Hr shall not be installed

in a bedroom.

3. This heater needs fresh air ventilation to

run properly. This heater has an Oxygen

Depletion Sensing (ODS) safety shutoff

system. The ODS shuts down the heater

if not enough fresh air is available. See

Air for Combustion and Ventilation, pages

7 and 8. If heater keeps shutting off, see

Troubleshooting, page 25.

4. Keep all air openings in front and bottom

of heater clear and free of debris. This will

ensure enough air for proper combustion.

SAFETY

5. If heater shuts off, do not relight until you

have provided fresh, outside air. If heater

keeps shutting off, have it serviced.

6. Do not run heater:

• Where ammable liquids or vapors are

used or stored.

• Under dusty conditions.

7. Before using furniture polish, wax, carpet

cleaner, or similar products, turn heater off.

If heated, the vapors from these products

may create a white powder residue within

burner box or on adjacent walls or furniture.

8. Manual Control Models Only: Always

run heater with control knob at PILOT/

IGN, LOW (1) or HIGH (5) locked positions.

Never set control knob between locked

positions. Poor combustion and higher

levels of carbon monoxide may result.

9. Do not use heater if any part has been

under water. Immediately call a qualied

service technician to inspect the room

heater and to replace any part of the

control system and any gas control which

has been under water.

10. Turn off and unplug heater and let cool

before servicing. Only a qualied service

person should service and repair heater.

11. Operating heater above elevations of

4,500 feet could cause pilot outage.

12. To prevent performance problems, do not

use propane fuel tank of less than 100 lbs.

capacity.

PRODUCT FEATURES

SAFETY PILOT

This heater has a pilot with an Oxygen Deple-

tion Sensing (ODS) safety shutoff system. The

ODS/pilot shuts off the heater if there is not

enough fresh air.

2 GAS OPTIONS AVAILABLE

Your heater is equipped to operate on either

Propane or Natural gas. The heater is shipped

from the factory ready for connecting to Pro-

pane. The heater can easily be changed to

Natural gas by having your qualied installer

follow the instructions on page 14 and the

markings on the heater.

THERMOSTATIC CONTROL

(Thermostat Models Only)

These heaters have a control valve with a

thermostat sensing bulb. This results in the

greatest heater comfort and may result in

lower gas bills.

www.usaprocom.com 5200213-01C

MODEL MNSD100TBA MNSD200TBA MNSD300TBA

BTU (available) 10,000 20,000 30,000

Ignition Electric Piezo Electric Piezo Electric Piezo

Gas Type Using Natural Gas Using Natural Gas Using Natural Gas

Pressure Regulator Setting 4" W.C. 4" W.C. 4" W.C.

Inlet Gas Pressure*

(inches of water)

Maximum 9" Maximum 9" Maximum 9"

Minimum 5" Minimum 5" Minimum 5"

Gas Type Using Propane Gas Using Propane Gas Using Propane Gas

Pressure Regulator Setting 9.5" W.C. 9.5" W.C. 9.5" W.C.

Inlet Gas Pressure*

(inches of water)

Maximum 14" Maximum 14" Maximum 14"

Minimum 11" Minimum 11" Minimum 11"

Heater Dimensions (HxWxD)

" × 14

" × 6

" × 19

" × 8" 23

" x 26

" x 8"

Carton Dimensions (HxWxD)

22 ×16

" × 8

" × 21

" × 9

" x 28

" x 9

Heater Weight 14.6 lbs 22.2 lbs 28.1 lbs

Shipping Weight 17.6 lbs 26.2 lbs 33.1 lbs

MODEL MNSD100HBA MNSD200TBA-BB MNSD300TBA-BB

BTU (available) 10,000 20,000 30,000

Ignition Electric Piezo Electric Piezo Electric Piezo

Gas Type Using Natural Gas Using Natural Gas Using Natural Gas

Pressure Regulator Setting 4" W.C. 4" W.C. 4" W.C.

Inlet Gas Pressure*

(inches of water)

Maximum 9" Maximum 9" Maximum 9"

Minimum 5" Minimum 5" Minimum 5"

Gas Type

Using Propane Gas

Pressure Regulator Setting 9.5" W.C. 9.5" W.C. 9.5" W.C.

Inlet Gas Pressure*

(inches of water)

Maximum 14" Maximum 14" Maximum 14"

Minimum 11" Minimum 11" Minimum 11"

Heater Dimensions (HxWxD)

" × 14

" × 6

" × 19

" × 8" 23

" x 26

" x 8"

Carton Dimensions (HxWxD)

22 ×16

" × 8

" × 21

" × 9

"25

" x 28

" x 9

Heater Weight 14.1 lbs 25.1 lbs 31 lbs

Shipping Weight 17.1 lbs 29.1 lbs 36 lbs

SPECIFICATIONS

QUALIFIED INSTALLING AGENCY

Only a qualied agency should install and

replace gas piping, gas utilization equipment

or accessories, and repair and equipment ser-

vicing. The term “qualied agency” means any

individual, rm, corporation, or company that

either in person or through a representative

is engaged in and is responsible for:

a) Installing, testing, or replacing gas piping

b) Connecting, installing, testing, repairing, or

servicing equipment; that is experienced in

such work; that is familiar with all precautions

required; and that has complied with all the

requirement of the authority having jurisdiction.

Electrical Requirement for Blower Kit (if equipped)

Voltage • 120 VAC, 60 Hz

www.usaprocom.com 200213-01C6

LOCAL CODES

Install and use heater with care. Follow all

local codes. In the absence of local codes,

use the latest edition of The National Fuel

Gas Code, ANSI Z223.1/NFPA 54*.

*Available from:

American National Standards Institute, Inc.

25 West 43rd Street

New York, NY 10036

National Fire Protection Association, Inc.

1 Batterymarch Park

Quincy, MA 02269-9101

State of Massachusetts: The installation

must be made by a licensed plumber or

gas tter in the Commonwealth of Mas-

sachusetts.

Sellers of unvented propane or natural

gas-red supplemental room heaters shall

provide to each purchaser a copy of 527

CMR 30 upon sale of the unit.

In the State of Massachusetts the gas

cock must be a T-handle type. The State

of Massachusetts requires that a exible

appliance connector cannot exceed three

feet in length.

PRODUCT IDENTIFICATION

UNPACKING

1. Remove heater from carton.

2. Remove all protective packaging applied

to heater for shipping

Figure 1 - Vent-Free Gas Heater

Control

Knob

Ignitor

Button

Front

Panel

Grill

Burner

Heater Cabinet

3. Check heater for any shipping damage. If

heater is damaged, promptly inform dealer

where you bought heater.

www.usaprocom.com 7200213-01C

Water vapor is a by-product of gas combus-

tion. An unvented room heater produces ap-

proximately one (1) ounce (30 mL) of water for

every 1,000 BTUs (0.3 KWs) of gas input per

hour. Unvented room heaters are recommended

as supplemental heat (a room) rather than a

primary heat source (an entire house). In most

supplemental heat applications, the water vapor

does not create a problem. In most applications,

the water vapor enhances the low humidity

atmosphere experienced during cold weather.

The following steps will help ensure that water

vapor does not become a problem.

1. Be sure the heater is sized properly for the

application, including ample combustion

air and circulation air.

2. If high humidity is experienced, a dehu-

midier may be used to help lower the

water vapor content of the air.

3. Do not use an unvented room heater as

the primary heat source.

AIR FOR COMBUSTION AND VENTILATION

WARNING: This heater shall

not be installed in a conned

space or unusually tight con-

struction unless provisions are

provided for adequate combus-

tion and ventilation air. Read the

following instructions to insure

proper fresh air forthis and other

fuel-burning appliances in your

home.

Today’s homes are built more energy efcient

than ever. New materials, increased insulation

and new construction methods help reduce

heat loss in homes. Home owners weather

strip and caulk around windows and doors

to keep the cold air out and the warm air in.

During heating months, home owners want

their homes as airtight as possible.

While it is good to make your home energy

efcient, your home needs to breathe. Fresh

air must enter your home. All fuel-burning ap-

pliances need fresh air for proper combustion

and ventilation.

Exhaust fans, replaces, clothes dryers and

fuel burning appliances draw air from the

house to operate. You must provide adequate

fresh air for these appliances. This will insure

proper venting of vented fuel-burning appli-

ances.

WATER VAPOR: A BY-PRODUCT OF

UNVENTED ROOM HEATERS

WARNING: This heater shall

not be installed in a room or

space unless the required vol-

ume of indoor combustion air

is provided by the method de-

scribed in the National Fuel Gas

Code, ANSI Z223.1/NFPA 54, the

International Fuel Gas Code, or

applicable local codes.

WARNING:Iftheareainwhich

the heater may be operated does

notmeet the required volume for

indoor combustion air, combus-

tion and ventilation air shall be

provided by one of the methods

described in the National Fuel

Gas Code,ANSI Z223.1/NFPA54,

the International Fuel Gas Code,

or applicable local codes.

www.usaprocom.com 200213-01C8

AIR FOR COMBUSTION AND VENTILATION

Outlet

Air

Ventilated

Attic

Outlet

Air

Inlet

Air

Inlet Air Ventilated

Crawl Space

Crawl

Space

To Attic

Figure 2 - Ventilation Air from Inside

Building

Figure 3 - Ventilation Air from Outdoors

Note: Base not included. Not for use in bed-

rooms or bathrooms.

Remove

Door into

Adjoining

Room,

Option 3

Ventilation Grills

Into Adjoining Room,

Option 2

12"

Ventilation

Grills into

Adjoining

Room,

Option 1

Ventilation Air From Inside Building

This fresh air would come from an adjoining

unconned space. When ventilating to an

adjoining unconned space, you must provide

two permanent openings: one within 12" of the

ceiling and one within 12" of the oor on the

wall connecting the two spaces (see options

1 and 2, Figure 2). You can also remove door

into adjoining room (see option 3, Figure 2).

Follow the National Fuel Gas Code, ANSI

Z223.1/NFPA 54, Air for Combustion and

Ventilation for required size of ventilation

grills or ducts.

VENTILATION AIR

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation

grills or ducts. You must provide two perma-

nent openings: one within 12" of the ceiling

and one within 12" of the oor. Connect these

items directly to the outdoors or spaces open

to the outdoors. These spaces include attics

and crawl spaces. Follow the National Fuel

Gas Code, ANSI Z223.1/NFPA 54, Air for

Combustion and Ventilation for required size

of ventilation grills or ducts.

IMPORTANT: Do not provide openings

for inlet or outlet air into attic if attic has a

thermostat-controlled power vent. Heated air

entering the attic will activate the power vent.

Rework worksheet, adding the space of the

adjoining unconned space. The combined

spaces must have enough fresh air to supply

all appliances in both spaces.

www.usaprocom.com 9200213-01C

INSTALLATION

NOTICE: This heater is intended

for use as supplemental heat.

Use this heater along with your

primary heating system. Do not

install this heater as your pri-

mary heat source. If you have a

central heating system, you may

run system’s circulating blower

whileusing heater.This will help

circulatetheheatthroughoutthe

house. In the event of a power

outage, you can use this heater

as your primary heat source.

CAUTION: When installing

heater in a home garage

• heater pilot and burner must

be at least 18" above oor

• locate heater where moving

vehicle will not hit it

WARNING: A qualied ser-

vice person must install heater.

Follow all local codes.

WARNING: Never install the

heater

• 10,000 Btu/Hr in a bathroom

• over 10,000 Btu/Hr in a bed-

room or bathroom (Check local

codes.)

• in a recreational vehicle

• where curtains, furniture,

clothing, or other ammable

objects are less than 36" from

the front, top, or sides of the

heater

• in high trafc areas

• in windy or drafty areas

CAUTION: This heater cre-

ates warm air currents. These

currents move heat to wall sur-

faces next to heater. Installing

heater next to vinyl or cloth wall

coverings or operating heater

where impurities (such as to-

bacco smoke, aromatic candles,

cleaning uids, oil or kerosene

lamps, etc.) in the air exist, may

cause walls to discolor.

IMPORTANT: Vent-free heaters add moisture

to the air. Although this is benecial, installing

heater in rooms without enough ventilation air

may cause mildew to form too much moisture.

See Air for Combustion and Ventilation, pages

7 and 8.

www.usaprocom.com 200213-01C10

Figure 4 - Mounting Clearances as

Viewed From Front of Heater

CEILING

36"

Minimum

From

Sides of

Heater

Left

Side

Right

Side

2" Minimum to Top Surface of Carpeting,

Tile or Other Combustible Material

FLOOR

Figure 5 - Mounting Bracket Location

Removing Front Panel of Heater

1. Remove two screws near bottom corners

of lower front panel.

2. Pull bottom of lower front panel forward,

then down (see Figure 6).

INSTALLATION

Figure 6 - Removing Front Panel Of

Heater

Mounting Bracket

CHECK GAS TYPE

Be sure your gas supply is right for your heat-

er. Otherwise, call dealer where you bought

the heater for proper type heater.

CLEARANCES TO

COMBUSTIBLES

Carefully follow the instructions below. This

heater is a freestanding unit designed to be

mounted on a wall or set on a base.

WARNING: Maintain the

minimum clearances shown in

Figure 4. If you can, provide

greater clearances from oor,

ceiling, and joining wall.

FASTENING HEATER TO WALL

Mounting Bracket

The mounting bracket is located on back panel

of heater (see Figure 5). It has been taped

there for shipping. Remove mounting bracket

from back panel.

LOCATING HEATER

This heater is designed to be mounted on a

wall. For convenience and efciency, install

heater:

1. Where there is easy access for operation,

inspection, and service.

2. In the coldest part of room.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Procom Chauffage au gaz

Procom

Procom MN200TBA-B Guide de démarrage rapide

Procom

Procom ML100HBAHR Guide de démarrage rapide

Procom

Procom ML300HGA Guide de démarrage rapide

Procom

Procom MDS30HGA Manuel utilisateur

Procom

Procom MG10HBF Guide de démarrage rapide

Procom

Procom MN300HGA Guide de démarrage rapide

Procom

Procom MG1TIR Guide de démarrage rapide

Procom

Procom ML100HBAHR Guide de démarrage rapide

Procom

Procom HearthSense BF30T-BB Guide de démarrage rapide

Procom

Procom MD2TPA Manuel utilisateur

Procom

Procom MN060HPA Guide de démarrage rapide

Procom

Procom MN200HBA Manuel utilisateur

Procom

Procom MN060HPA Guide de démarrage rapide

Procom

Procom Lost River PCILVFD18-1 Manuel utilisateur

Procom

Procom MN060HBA Guide de démarrage rapide

Procom

Procom Lost River PCILVFD18RT Guide de démarrage rapide

Procom

Procom ML170EPC Guide de démarrage rapide

Procom

Procom MN180HPA Guide de démarrage rapide

Procom

Procom FeatureComforts ML150TPE Manuel utilisateur

Procom

Procom Blue Flame Manuel utilisateur

Procom

Procom ML200HBA Guide de démarrage rapide

Procom

Procom NVDWA2 Manuel utilisateur

Procom

Procom ML150HPA Guide de démarrage rapide

Procom

Procom ML060HPA Guide de démarrage rapide

Manuels Chauffage au gaz populaires d'autres marques

Superior

Superior BGE18NV Manuel utilisateur

Dru

Dru Room-sealed atmospheric gas-fired heating... Manuel utilisateur

klover

klover TKR 35 Manuel utilisateur

Rothenberger Industrial

Rothenberger Industrial 035984 Manuel utilisateur

New Buck Corporation

New Buck Corporation 34 Manuel utilisateur

Hargrove

Hargrove Timberland Glow Guide de démarrage rapide

Kinder

Kinder Cameo BF Manuel utilisateur

Qlima

Qlima GH 438 B-2 Manuel

Desa

Desa 125-R Manuel utilisateur

Gasmate

Gasmate AH100 Series Manuel utilisateur

Medallion

Medallion MBP20TLB Guide de démarrage rapide

Clarke

Clarke DEVIL 910SS Manuel utilisateur

Superior

Superior BGE18NR Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters QTD Series Instructions d'installation

L.B. White

L.B. White Therma Grow HW220 Manuel

Sealey

Sealey LP35.V5 Manuel utilisateur

Italkero

Italkero Falo Evo Manuel utilisateur

Desa

Desa 30LP Manuel utilisateur
