１.
Ｉｎｔｒｏｄｕｃｔｉｏｎ ０１
Ｔｈｅ ｍｏｕｎｔｉｎｇ ｓｌｏｔ
Ｉｎｔｒｏｄｕｃｔｉｏｎ
１．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ
１．２ Ａｐｐｅａｒａｎｃｅ
Upper ｖｉｅｗ
PT-PEX02GB is an industrial-rated PoE Extender with two PoE output ports,
specially designed for complex backhaul and networking applications.
Enclosed in a high-impact metal shell. The 3 ports 10/100/1000Mbps includes:
1 x PoE-powered input port with 802.3bt/PoE++ at 60W or higher of 95W(Max
) and 2 x PoE output ports with 6KV (10/700us) surge protection. Each output
port delivers 30W(Max) power for remote two PDs, totaling up to 60W.
PoE Input port requiring more power which is powered by ultra 802.3bt PoE+
+ works with an input voltage of 44- 57Vdc and operates under -40℃to +65
℃. Equipped detecting chip inside which will make the PoE identification
handshake with IEEE802.3af/at/PoE+ PDs, such as wireless APs, IP cameras,
base stations, Microwave radio, and other PoE power Ethernet backhaul
devices.For planning purposes, the total effective distance from Ultra PoE to
PDs is 200 meters over CAT5e/CAT6 cables without local power.
Ｔｈｉｓ ｐｒｏｄｕｃｔ ｆｅａｔｕｒｅｓ ｏｎｅ ＰｏＥ ｉｎｐｕｔ ｐｏｒｔ ａｎｄ ｔｗｏ ＰｏＥ ｏｕｔｐｕｔ ｐｏｒｔｓ， ａｓ
ｗｅｌｌ ａｓ two mounting ｔａｂｓ ｏｎ ｅｉｔｈｅｒ ｓｉｄｅ． Ｉｔ ｃａｎ ｂｅ ｕｓｅｄ ａｎ outdoor ＰｏＥ
ｅｘｔｅｎｄｅｒｂｙ ｃｏｖｅｒ ｗｉｔｈ ａ ｗａｔｅｒｐｒｏｏｆ ｃａｓｅ ｏｒ ａｓ ａ ｓｔａｎｄａｒｄ ｄｕａｌ－ｐｏｒｔ
ＰｏＥ ｎｅｔｗｏｒｋ ｓｗｉｔｃｈ．
１－１ Ｕｐｐｅｒ ｖｉｅｗ
２．５ｍｍ
ｓｃｒｅｗ
ｍｏｕｎｔｉｎg
ｈｏｌｅ
