Manual Wheelchairs

OWNERS MANUAL

PROBASICS EC MANUAL WHEELCHAIRS

MODEL NO. EC03

EC04

EC06

EC07

EC09

EC10

EC11

EC12

PROBASICS DX MANUAL WHEELCHAIRS

MODEL NO. 1003DX

1004DX

1006DX

1007DX

1009DX

1010DX

1011DX

1012DX

PROBASICS FULL RECLINING MANUAL WHEELCHAIRS

MODEL NO. 1816

1818

1820

PROBASICS HIGH STRENGTH LIGHTWEIGHT

MANUAL WHEELCHAIR

MODELS NO. 1610

1611

1810

1811

1812

1813

HEAVY DUTY MANUAL WHEELCHAIR

MODEL NO. 1013

1014

1124

1224

INDEX PAGE

1. Special Notes.................................................................................................................. 3

2. Specifications.................................................................................................................. 4

3. Wheelchair Safety and Handling.................................................................................... 6

3. WARNINGS – ALL MODELS......................................................................................... 7

3. WARNINGS – RECLINER OPERATION....................................................................... 7

5. Stability and Balance .................................................................................................... 8

6. Coping with Everyday Obstacles ................................................................................. 8

7. A Note to Wheelchair Assistants.................................................................................. 8

8. Importance of Weight Distribution................................................................................ 9

9. Reaching, Leaning, and Bending Forward .................................................................... 9

10. Reaching, Leaning Backwards..................................................................................... 10

11. Tipping .......................................................................................................................... 10

12. Climbing Curbs ............................................................................................................. 10

13. Transferring To and From Other Seats........................................................................ 11

14. Unfolding and Folding the Wheelchair......................................................................... 12

15. Installing and Repositioning Headrest Pillow (Recliners Only) ................................... 13

16. Safety Inspection Checklist .......................................................................................... 14

17. Maintenance Safety Precautions ................................................................................. 15

18. Installing/Removing the Front Riggings ....................................................................... 16

19. Footrest Height Adjustment.......................................................................................... 17

21. Raising/Lowering the Elevating Leg Rest.................................................................... 17

21. Removing/Installing Armrests ...................................................................................... 18

22. Adjusting Armrest Height.............................................................................................. 18

22. Flip-Back Arms ............................................................................................................. 19

23. Replacing Standard Seat Upholstery........................................................................... 20

24. Replacing Standard Back Upholstery .......................................................................... 20

25. Replacing Slip-On Back Upholstery............................................................................. 21

26. Adjusting the Back Height ............................................................................................ 22

27. Changing Rear Wheel Position and Sizes................................................................... 22

28. Adjusting Forks ............................................................................................................. 23

29. Replacing Front Casters............................................................................................... 23

30. Wheel Lock Adjustment................................................................................................ 24

31. Installing Seat Positioning Strap .................................................................................. 25

32. Limited Lifetime Warranty............................................................................................. 26

NOTICE

THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE

WITHOUT NOTICE.

SAFETY INFORMATION

UPON INITIAL DELIVERY

NOTE: Check ALL parts of the wheelchair for shipping damage before use. In case of

shipping damage, DO NOT use. Contact Carrier/Dealer for further instruction.

WHEELCHAIR USER

NOTE: Check ALL parts of the wheelchair for damage before each and every use.

If a component is suspect contact you Dealer for repair.

WARNING/CAUTION notices as used in this manual apply to hazards or unsafe

practices which could result in personal injury or property damage.

As a manufacturer of wheelchairs, Probasics endeavors to supply a wide variety of

wheelchairs to meet many needs of the end user. However, final selection of the type

of wheelchair to be used by an individual rests solely with the user and his/her

healthcare professional capable of making such a selection.

This wheelchair has not been approved as a seat surface to be used within a vehicle

of any kind. Always transfer wheelchair user o an approved vehicle seat with the

appropriate restraints for this application.

Probasics strongly recommends the use of rear anti-tippers as an additional

safeguard for the wheelchair user.

AS REGARDS TO RESTRAINTS- SEAT POSITIONING STRAPS- IT IS THE

OBLIGATION OF THE DEALER, THERAPISTS AND OTHER HEALTHCARE

PROFESSIONALS TO DETERMINE IF A SEATING RESTRAINT IS REQUIRED TO

ENSURE THE SAFE OPERATION OF THIS EQUIPMENT BY THE USER. SERIOUS

INJURY CAN OCCUR IN THE EVENT OF A FALL FROM A WHEELCHAIR. PROBASICS

STRONGLY RECOMMENDS THE USE OF SEAT POSITIONING STRAPS AS AN

ADDITIONAL SAFEGUARD FOR THE WHEELCHAIR USER.

PRODUCT SPECIFICATIONS

MODEL EC STANDARD WHEELCHAIRS

MODEL DX STANDARD WHEELCHAIRS

MODEL

NO.

SEAT

WIDTH

SEAT

DEPTH

SEAT

HEIGHT

BACK

HEIGHT

OVERALL

WIDTH

WEIGHT

LIMIT

FRONT

RIGGINGS

ARM

STYLES

EC03 16” 16” 17½”-19½

” 17” 24” 300lbs Swingaway

footrest

Removable

desk

EC04 16” 16” 17½”-19½”

17” 24” 300lbs Elev. Leg

rest

Removable

desk

EC06 18” 16” 17½”-19½”

17” 26” 300lbs Swingaway

footrest Fixed desk

EC07 18” 16” 17½”-19½”

17” 26” 300lbs Elev. Leg

rest Fixed desk

EC09 18” 16” 17½”-19½”

17” 28” 300lbs Swingaway

footrest

Removable

desk

EC10 18” 16” 17½”-19½”

17” 28” 300lbs Elev. Leg

rest

Removable

desk

EC11 20” 16” 17½”-19½”

17” 30” 300lbs Swingaway

footrest

Removable

desk

EC12 20” 16” 17½”-19½”

17” 30” 300lbs Elev. Leg

rest

Removable

desk

MODEL

NO.

SEAT

WIDTH

SEAT

DEPTH

SEAT

HEIGHT

BACK

HEIGHT

OVERALL

WIDTH

WEIGHT

LIMIT

FRONT

RIGGING

ARM

STYLES

1003DX

16” 16” 17½”-19½”

17” 24” 300lbs Swing

footrest

Removable

desk

1004DX

16” 16” 17½”-19½”

17” 24” 300lbs Elev. leg

rest

Removable

desk

1006DX

18” 16” 17½”-19½”

17” 26” 300lbs Swing

footrest Fixed full

1007DX

18” 16” 17½”-19½”

17” 26” 300lbs Elev. leg

rest Fixed full

1009DX

18” 16” 17½”-19½”

17” 26” 300lbs Swing

footrest

Removable

desk

1010DX

18” 16” 17½”-19½”

17” 26” 300lbs Elev. leg

rest

Removable

desk

1011DX

20” 16” 17½”-19½”

17” 28” 315lbs Swing

footrest

Removable

desk

1012DX

20” 16” 17½”-19½”

17” 28” 315lbs Elev. leg

rest

Removable

desk

STANDARD BARIATRIC WHEELCHAIRS (Removable Desk Arms)

MODEL

NO.

SEAT

WIDTH

SEAT

DEPTH

SEAT

HEIGHT

BACK

HEIGHT

OVERALL

WIDTH

WEIGHT

LIMIT

FRONT

RIGGINGS

1013 22” 18” 21”-19” 16” 30” 400lbs Swing Foot

rest

1014 22” 18” 21”-19” 16” 30” 400lbs Elev. Leg

rest

1124 24” 18” 21”-19” 16” 32” 400lbs Swing Foot

rest

1224 24” 18” 21”-19” 16” 32” 400lbs Elev. Leg

rest

Model High Strength Lightweight Wheelchairs (Flip Up Desk Arms)

MODEL

NO.

SEAT

WIDTH

SEAT

DEPTH

SEAT

HEIGHT

BACK

HEIGHT

OVERALL

WIDTH

WEIGHT

LIMIT

FRONT

RIGGINGS

1610 16” 16” 18”-20” 16” 24” 300 lbs Swingaway

footrest

1611 16” 16” 18”-20” 16” 24” 300 lbs Elev. Leg

rest

1810 18” 16” 18”-20” 16” 26” 300 lbs Swingaway

footrest

1811 18” 16” 18”-20” 16” 26” 300 lbs Elev. Leg

rest

1812 20” 16” 18”-20” 16” 28” 300 lbs Swingaway

footrest

1813 20” 16” 18”-20” 16” 28” 300 lbs Elev. Leg

rest

STANDARD RECLINING WHEELCHAIRS

MODEL

NO.

SEAT

WIDTH

SEAT

DEPTH

SEAT

HEIGHT

BACK

HEIGHT

OVERALL

WIDTH

WEIGHT

LIMIT

FRONT

RIGGINGS

ARM

STYLES

1816 16” 16” 19.5” 31” 26” 300lbs Elev. leg

rest

Removable

desk

1818 18” 16” 19.5” 31” 28” 300lbs Elev. leg

rest

Removable

desk

1820 20” 16” 19.5” 31” 30” 300lbs Elev. leg

rest

Removable

desk

WHEELCHAIR SAFETY AND HANDLING

“Safety and Handling” of the wheelchair requires the close attention of the wheelchair user

as well as the assistant. This manual points out the most common procedures and

techniques involved in the safe operation and maintenance of the wheelchair. It is important

to practice and master these safe techniques until you are comfortable in maneuvering

around the frequently encountered architectural barriers.

Use this information only as a “basic” guide. The techniques that are discussed on the

following pages have been used successfully by many users.

Individual wheelchair users often develop skills to deal with daily living activities that may

differ from those described in this manual. Probasics recognizes and encourages each

individual to try what works best for him/her in overcoming architectural obstacles that they

may encounter, however ALL WARNINGS and CAUTIONS given in this manual MUST be

followed. Techniques in this manual are a starting point for the new wheelchair user and

assistant with “safety” as the most important consideration for all.

WARNINGS (All MODELS)

The position of the front casters, position of the rear wheels, as well as the user

condition directly relate to the stability of the wheelchair. Any change to one (1) or

any combination of the three (3) may cause the wheelchair to decrease in stability.

These adjustments MUST be performed by a qualified technician.

ALL warnings and cautions in this manual must be followed unless otherwise noted.

DO NOT TRAVERSE, CLIMB or GO DOWN ramps or slopes greater than 9°.

DO NOT operate on roads, streets or highways.

DO NOT attempt to ride over curbs or obstacles. Doing so may cause your

wheelchair to tip over and cause bodily harm to you or damage to the wheelchair.

DO NOT stand on the frame of the wheelchair.

DO NOT use the footplate as a platform. When getting in or out of the wheelchair,

make sure that the footplates are in the upward position.

ALWAYS use the hand rims for self-propulsion. DO NOT grip the rear wheels

themselves.

DO NOT use parts, accessories, or adapters other than those authorized by

Probasics.

WARNINGS (Recliner Operation)

Rear anti-tippers MUST BE attached at all times.

ALWAYS make sure that the wheelchair is stable and either in the full reclined (180°)

position and the full upright (90°) position BEFORE operation the recliner mechanism.

ALWAYS engage both wheel locks while reclining or raising the back of the

wheelchair.

Make sure the spreader bar is secured with the tightening knob before using the

wheelchair. Make sure both back canes are at the same angle before releasing the

handles of the recline mechanism.

ALWAYS return the back to the upright position before lifting the wheelchair.

TO HEALTHCARE PROFESSIONALS/ASSISTANTS:

This Recliner wheelchair MUST be operated by a healthcare professional or assistant

when in any reclined position.

Make sure the patient is properly positioned in the wheelchair before reclining or

raising the back to maintain maximum stability and safety.

Assistants MUST be prepared to support the weight of the occupant when reclining,

or returning the occupant of the wheelchair to the full upright position. Make sure to

use proper body mechanics (use your legs) or seek assistance if necessary to avoid

injury.

Make sure occupant's and bystanders' hands and body are clear of all pinch points

before reclining back. Use caution, otherwise injury may occur.

WEIGHT TRAINING

Probasics DOES NOT recommend the use of its wheelchairs as a weight training

apparatus. Probasics wheelchairs have NOT been designed or tested as a seat

for any kind of weight training. If occupant uses said wheelchair as a weight

training apparatus, Probasics shall NOT be liable for bodily injury and the

warranty is void.

STABILITY AND BALANCE

To assure stability and proper operation of your wheelchair, you must at all times maintain

proper balance. Your wheelchair has been designed to remain upright and stable during

normal daily activities as long as you do not move beyond the center of gravity.

Virtually all activites that involve movement in the wheelchair have an effect on the cent of

gravity. Probasics recommends using seat/chest-positioning straps for additional safety

while involved in activities that shift your weight.

DO NOT lean forward out of the wheelchair any further than the length of the armrests.

Make sure the casters are pointing in the forward position whenever you lean forward. This

can be achieved by advancing the wheelchair and then reversing it in a straight-line.

COPING WITH EVERYDAY OBSTACLES

Coping with the irritation of everyday obstacles can be alleviated somewhat by learning how

to manage your wheelchair. Keep in mind your center of gravity to maintain stability and

balance.

A NOTE TO WHEELCHAIR ASSISTANTS

When assistance to the wheelchair user is required, remember to use good body

mechanics. Keep your back straight and bend your knees whenever tipping the wheelchair

or traversing curbs, or other impediments.

When learning a new assistance technique, have an experienced assistant help you before

attempting in alone.

WARNINGS

DO NOT attempt to lift the wheelchair by any removable (detachable) parts. Lifting

by means of any removable (detachable) parts of a wheelchair may result in injury to

the user or damage to the wheelchair.

Always verify that hand grips on the rear back posts are secure PRIOR to use

whenever an assistant is used to propel or lift the chair. Check for any signs of

looseness or deterioration and if found, contact a qualified technician. DO NOT

attempt to move the wheelchair by pulling on the handgrips if they are found to be

unsecure or have deteriorated.

IMPORTANCE OF WEIGHT DISTRIBUTION

Many activities require the wheelchair owners to reach, bend and transfer in and out of the

wheelchair. These movements will cause a change to the normal balance, the center of

gravity, and the weight distribution of the wheelchair.

Proper positioning is essential for your safety. When reaching, leaning, or bending forward,

it is important to use the front casters as a tool to maintain stability and balance.

WARNING

To determine and establish your particular safety limits, practice bending, reaching

and transferring activities in several combinations in the presence of a qualified

healthcare professional BEFORE attempting active use of the wheelchair.

REACHING, LEANING AND

BENDING FORWARD

Position the front casters so that they are

extended as far forward as possible and

lock the wheel locks.

REACHING, LEANING

BACKWARDS

Position the wheelchair as close as

possible to the desired object. Point the

front casters forward to create the longest

possible wheelbase. Reach back but only

as far as your arm will extend without

changing your sitting position.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Probasics Fauteuil roulant

Probasics

Probasics K4 Manuel utilisateur

Probasics

Probasics Wheelchair XP6520 Mode d'emploi

Probasics

Probasics 9200 Manuel utilisateur

Probasics

Probasics WC4L1616DE Manuel utilisateur

Probasics

Probasics WCR1616E Manuel utilisateur

Manuels Fauteuil roulant populaires d'autres marques

Otto Bock

Otto Bock Skippi plus Manuel utilisateur

Invacare

Invacare Action 4NG series Manuel utilisateur

SORG

SORG LoopSORG 802 Manuel utilisateur

Designability

Designability WizzyBug Instructions d'installation

Vermeiren

Vermeiren RAPIDO Manuel utilisateur

Excel

Excel G5 KIDS 0285 Manuel utilisateur

M. Bartels

M. Bartels SA-3 Manuel utilisateur

nino robotics

nino robotics NIno Manuel utilisateur

Vermeiren

Vermeiren Turios Manuel utilisateur

Invacare

Invacare MK5 EX Manuel utilisateur

Invacare

Invacare Solara Spree GT Manuel

Nova

Nova TKW-12 Manuel utilisateur

BCW

BCW Advantage Manuel utilisateur

You-Q

You-Q Luca Manuel utilisateur

interco

interco Ortolight Standard Mode d’emploi

Nova

Nova 7190L Manuel utilisateur

Vermeiren

Vermeiren EZ1 Manuel utilisateur

PaceSaver

PaceSaver Scout M-300 Manuel utilisateur
