Pro-Team Vac Station Manuel utilisateur

Items Included for Installation:

a. ProTeam Vac Station

b. Mounting Bracket (Factory Installed)

c. Tool storage for cover plate

d. Wall Bracket

e. 2 in. wall bracket screws (3)

Tools Needed for Installation:

Stud Finder

Pen or Pencil

Measuring Tape or Yard Stick

Level

Phillips Head Screwdriver

Drill with 1/8 in. bit

Using a stud finder in the area you wish

to mount the ProTeam Vac Station,

locate and mark a wall stud. Be sure to

mount the Vac Station into a stud, not

just the wall board or sheet rock.

Step 1

Using a tape measure, mark a spot

on the wall 36 in. from the floor.

This will be the location of the

middle mounting hole and screw

for the wall bracket.

Step 3

First Inspect your ProTeam

Vac Station and make sure

that the following items

have been included:

Using a drill with a 1/8 in. bit, drill a

hole 2 in. deep on the mark you made

in step 2. Line the middle hole of the

wall bracket up with the hole and

insert a wall bracket screw. Leave the

screw loose for now.

Step 2

Warning!

DO NOT treat the Vac Station as a toy or seat.

DO NOT take any short cuts or skip steps in the installation of the Vac Station.

Failing to follow instructions, can lead to failure of the Vac Station, damage to the

mounting surface, injury from falling equipment, or any combination thereof.

TURN OFF any ProTeam vacuum before storing it on the Vac Station.

DO NOT LEAVE any ProTeam vacuum plugged in while being stored on the Vac

Station.

USE AND INSTALL ONLY according to the instructions contained in this instruction

sheet. Use only the manufacturer-supplied parts or recommended parts.

DO NOT STORE anything other than your ProTeam vacuum, attachments and

filters on the Vac Station.

DO NOT store any chemicals or materials near the Vac Station that may be

flammable or combustible.

SECURE ONLY to a wall stud. If you are not sure how to find a wall stud, consult

with qualified personnel.

BEFORE DRILLING make sure there are no electrical or pluming lines running

through the wall were you plan to mount the ProTeam Vac Station.

Vac Station Installation

[email protected]

866.888.2168 106848 4/11

Step 4

Vac Station Installation

[email protected]

866.888.2168 106848 4/11

Using a level, align the wall bracket into

the vertical position. Mark the location

of the other two mounting screw points

at both ends of the wall bracket.

Step 5

Rotate the wall bracket back into the

vertical position and place screws in

the last two holes and tighten. Don’t

forget to tighten the center screw

that was left loose in Step 3.

Step 7

Line up the standard guide and mounting

bracket on the Vac Station. Mount the

vac station at the proper height.

You may need to loosen the three mount-

ing screws a little if the bracket doesn’t

slide into a secure fit.

Step 6

Rotate the wall bracket to the side and

with the same 1/8 in. bit, drill two

more holes 2 in. deep, one on each

of the marks you made in Step 4.

Step 8

The proper height of the ProTeam Vac

Station is determined by the user of

the vacuum. The vacuum user should

be able to back up to the Vac Station

and without bending his or her knees

or rising on the balls of his or her feet,

slip the vacuum on or off of the Vac

Station easily.

Step 9

The ProTeam Vac Station has space

to hold all of your ProTeam vacuum

tools, power cord and filters.
